Road Shock 62684 Assembly instructions

Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
Copyright©2015 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product
described herein. Tools required for assembly and service may not be included.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Save This Manual Keep this manual for the safety warnings and precautions, assembly, operating,
inspection, maintenance and cleaning procedures. Write the product’s serial number in the back of the manual
near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
Owner’s Manual & Safety Instructions
Only use with
15 amp rated auxiliary
power outlet.
Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected]
12 VOLT AUTO
DEFROSTER
WITH LIGHT
ITEM 62684
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference.
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2015 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.
REV 15e

Page 2 For technical questions, please call 1-888-866-5797. Item 62684
IMPORTANT SAFETY INFORMATION
Mounting Precautions
1. Mount the Defroster on a stable
surface with at least 2 inches of air
space around the sides of the unit.
2. Do not allow anything to come
in contact with the Defroster.
3. Do not mount the Defroster
on upholstered seats or
flammable surfaces.
4. Verify that installation surface has no
hidden wires or other components
before drilling or driving screws.
5. Wear ANSI-approved
safety goggles during mounting.
6. Do not mount when tired or
when under the influence of
alcohol, drugs or medication.
Use Precautions
1. This product is not a toy. Do not allow
children to play with or near this item.
2. Do not leave Defroster plugged
in while starting vehicle or
while vehicle’s engine is off.
Low voltage during these
circumstances will increase heat in
the wiring and may blow the fusible
link in the receptacle or another fuse.
3. Check vehicle manual to ensure
the 12V auxiliary power outlet
is rated at 15 amps or greater.
Do not use a socket extension or
pigtail to operate this Defroster.
4. Risk of Burns! Keep children
and pets away from this unit
while it is hot. Do not place
hands or feet near the vent.
5. Replace the fuse only with another
15 amp fuse of the same type.
6. Only use this Defroster for up
to 20 minutes at a time.
7. Keep this product dry.
8. Do not operate other 12VDC appliances
at the same time as the Defroster.
9. Do not leave the Defroster unattended
when it is plugged in. Unplug the
Defroster before leaving the vehicle.
10. Use as intended only.
11. Inspect before every use; do not use
if parts are loose or damaged.
12. Do not use the Defroster if Power
Switch does not turn it on or off.
13. WARNING: The cord of this product
contains lead and/or di (2-ethylhexyl)
phthalate (DEHP), chemicals known
to the State of California to cause
cancer, and birth defects or other
reproductive harm. Wash hands
after handling. (California Health &
Safety Code § 25249.5, et seq.)
14. Maintain product labels and
nameplates. These carry
important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.

Page 3For technical questions, please call 1-888-866-5797.Item 62684
Mounting Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
TO PREVENT FIRE:
Do not mount the Defroster on upholstered seats or flammable surfaces.
Mount the Defroster on a stable surface with at least
2 inches of air space around the sides of the unit.
Mounting with Screws
WARNING! Verify that installation surface
has no hidden wires or other components
before drilling or driving screws.
1. Verify that the Power Cord will
reach the 12V auxiliary power outlet
from the mounting location.
2. Remove the Base (19) by sliding it off
the Defroster Housing horizontally.
3. Using the Base as a template, mark
locations of mounting holes.
Mounting
Holes
Figure A
4. Using a drill bit slightly smaller
than the Screws (21), drill pilot
holes into the marked locations.
5. Position Base so that mounting
holes align with pilot holes.
6. Attach the Base with the Screws.
Mounting with Adhesive Strip
1. Verify that the Power Cord will
reach the 12V auxiliary power outlet
from the mounting location.
2. Remove the Base (19) by sliding it off
the Defroster Housing horizontally.
3. Wipe the Base and mounting
surface with alcohol.
Allow the alcohol to evaporate.
4. Peel off one side of the
Adhesive Strip’s (20) backing.
Place the strip on the Base,
then press down and hold for
one minute to adhere.
5. Peel off the other side of the backing
and position the Base on the mounting
surface, then press down and hold
for one minute to adhere. Leave
in place for an hour before use.

Page 4 For technical questions, please call 1-888-866-5797. Item 62684
Specifications
Power Source 12 VDC, 12.5 A
Only use with 15A rated
auxiliary power outlet.
Check vehicle manual.
Power Consumption Max. 150 W
Power Cord 78″ L
Fuse 15 A
Controls
Handle Power
Switch
Fuse
Light
Switch 12 VDC
Plug

Page 5For technical questions, please call 1-888-866-5797.Item 62684
Operating Instructions
NOTICE: To prevent blowing a fusible
link on the receptacle, only use with
15 amp rated 12 V auxiliary power outlet.
1. Place the Power Switch (11) and
the LED Switch (16) in their O (off)
positions. Plug into a 15 A rated
12 V auxiliary power outlet ONLY.
Note: This Defroster can burn
out lighter sockets.
2. Mount on dashboard, or hold over
windshield for spot defrosting. Use
for up to 20 minutes, and then
shut off for at least 5 minutes.
3. The Defroster can be removed from
the Mounting Base (6). By holding
the Handle (4/5) the Defroster can
be moved around as needed.
4. The LED Switch turns the lights on/off.
5. To select either the fan only or the
Defroster and fan, press the Power
Switch to the setting as marked.
Toggle the Power Switch to the center
position to turn off these functions.
WARNING! Do not operate longer
than 20 minutes at one time, allow
Defroster to cool completely after use.
6. Unplug the Defroster before
leaving the vehicle.
If Defroster suddenly stops operating:
WARNING! TO PREVENT FIRE:
Replace fuse only with fuse
of same type and rating.
1. Pull the Fuse (15) out of the
Fuse Holder.
If the wire inside the Fuse is broken
the Fuse needs to be replaced,
otherwise insert the Fuse back into the
Holder and proceed to the next step.
2. If the Defroster’s Fuse was not blown,
connect another 12 VDC device to the
12 V auxiliary power outlet to check it.
a. If the receptacle works, have
the Defroster serviced by
a qualified technician.
b. If the receptacle does not work,
DO NOT USE THIS DEFROSTER
WITH THAT RECEPTACLE.
That receptacle is evidently not
ratedto15 A,asthisDefrosterrequires.
Receptacles with a lower rating
will be permanently disabled
by this Defroster’s amp draw.
Note: Check vehicle’s service manual for
instructions on repairing the receptacle.
Likely failure points are the fusible link on
the receptacle itself or the vehicle’s fuse.

Page 6 For technical questions, please call 1-888-866-5797. Item 62684
Maintenance and Servicing
Procedures not specifically explained in this manual must
be performed only by a qualified technician.
TO PREVENT SERIOUS INJURY FROM ACCIDENTAL OPERATION:
Turn Power Switch to its “off” position, unplug the Defroster
from its outlet, and allow it to cool completely before performing
any inspection, maintenance, or cleaning procedures.
TO PREVENT SERIOUS INJURY FROM DEFROSTER FAILURE:
Do not use damaged equipment. If abnormal noise or vibration
occurs, have the problem corrected before further use.
1. BEFORE EACH USE, inspect
the general condition of the
Defroster. Check for:
• loose hardware,
• misalignment or binding
of moving parts,
• cracked or broken parts,
• damaged electrical wiring, and
• any other condition that may
affect its safe operation.
2. AFTER USE, wipe external surfaces
of the Defroster with clean cloth.
Do not use flammable liquids or harsh
detergents to clean the Defroster.
Do not submerge in fluid.
3. Store the Defroster in a dry
location out of direct sunlight and
out of the reach of children.
4. Replace Fuse with the same
type and rating only.
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only,
and are not available individually as replacement parts.

Page 7For technical questions, please call 1-888-866-5797.Item 62684
Parts List and Diagram
Part Description Qty.
1 Housing Cover 1
2 Upper Housing 1
3 Upper Handle 1
4 Lower Handle 1
5 PTC Heating Element 1
6 PTC Holder 1
7 Air Vent Grill 1
8 LED Cover 1
9 LED Switch 1
10 LED Reflector 1
11 LED Circuit Board 1
Part Description Qty.
12 Lower Housing Cover 1
13 Lower Housing 1
14 Fan Assembly 1
15 Fuse (15A) 1
16 Printed Circuit Board 1
17 Spline 1
18 12V Auxiliary Outlet Adapter 1
19 Base 1
20 Adhesive Strip (not shown) 1
21 Screw (not shown) 2
1
2
3
4
5
6
78910
12
13
14
15
19
16
17
18
11

PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • 1-888-866-5797
