Robe DT Series User manual

1
Version 2.0

2
3
Table of contents
1. Safety instructions ......................................................................................................... 4
2.Operating determinations............................................................................................... 5
3. Introduction..................................................................................................................... 5
4. Description of the device............................................................................................... 5
4.1 Video inputs ............................................................................................................... 6
5. Powering on the DigitalSpot 5000 DT........................................................................... 7
6. Shutting down the DigitalSpot 5000 DT ....................................................................... 7
7. Folders organization ...................................................................................................... 7
8. Rigging the xture.......................................................................................................... 8
9. DMX-512 connection .................................................................................................... 10
10. Ethernet connection................................................................................................... 11
11. DigitalSpot 5000 DT - DMX Protocol - version 3.5................................................... 12
12. DigitalSpot 5000 DT - DMX Protocol - version 4.3................................................... 23
13. DigitalSpot 5000 DT - DMX Protocol - version 5.1................................................... 34
14.DigitalSpot 5000 DT - Control menu map.................................................................. 48
15. Operating modes ....................................................................................................... 51
16. Control menu ............................................................................................................. 51
16.1 Fixture Address ..................................................................................................... 51
16.2 Fixture information ................................................................................................. 52
16.3 Personality ............................................................................................................. 52
16.4 Lamp On/Off .......................................................................................................... 53
16.5 Manual control........................................................................................................ 53
16.6 Stand-alone setting ............................................................................................... 53
16.7 Preview mode. ....................................................................................................... 54
16.8 Reset functions ...................................................................................................... 54
16.9 Service menu ......................................................................................................... 54
16.10 Special functions .................................................................................................. 55
16.11 Fixture Off ............................................................................................................ 56
17.Media Content management ...................................................................................... 57
18.Keystones ................................................................................................................... 58
19.In Frame and Out Frame parametres ........................................................................ 59
20.Playback modes ........................................................................................................ 59
21. Playback speed ........................................................................................................ 60
22. Picture merging .......................................................................................................... 60
22.1 Picture merging control channels........................................................................... 60
DigitalSpot 5000 DT

2
3
21.2 Picture merging example ...................................................................................... 62
23. Effect synchronization............................................................................................... 63
24. Remote conguration via the WWW browser.......................................................... 64
25. Technical specications............................................................................................ 65
26. Maintenance .............................................................................................................. 67
26.1 Cleaning ................................................................................................................. 67
26.2 Replacing the air lters........................................................................................... 67
26.3 Replacing the fuse ................................................................................................. 68
26.4 Changing the projector........................................................................................... 69

4
5
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!
1. Safety instructions
Every person involved with installation and maintenance of this device have to:
- be qualiled
- follow the instructions of this manual
CAUTION!
Be careful with your operations.
With a high voltage you can suffer
a dangerous electric shock when touching the wires!
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-
sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes
written in this manual.
Important:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
Make sure that the available voltage is not higher than stated on the rear panel.
Always plug in the power plug least. Make sure that the power-switch is set to off-position before you connect
the device to the mains. The power plug has to be accessable after installing the device.
Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and the power-
cord from time to time.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power-
cord by the plug. Never pull out the plug by tugging the power cord.
This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to
earth.
The electric connection, repairs and servicing must be carried out by a qualied employee.
Do not connect this device to a dimmer pack.
To switch the DigitalSpot 5000 DT off , always use the xture control panel(main menu,
option "Fixture Off") or DMX controller (channel 8, valus 240-249).
Never switch the xture off by pulling out the power plug from the socket otherwise
the device may be demaged (projector lamp, operating system...)

4
5
2.Operating determinations
If the device has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until
it has reached room temperature.
Do not shake the device. Avoid brute force when installing or operating the device.
When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture
or dust.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the x-
ture.
Always x the xture with an appropriate safety rope. Fix the safety rope at the correct holes only.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fas-
tened.
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the device. Most damages are the result of unprofessional operation!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, lamp explosion, crash etc.
3. Introduction
The DigitalSpot 5000 DT features moving head with a video projection and automated lighting technologies
including a DMX controllable digital media server installed in a xture´s base. The built-in 32-bit Graphics En-
gine utilizes Linux and DirectX application programming interface to provide extensive image control of graphic
objects.
The Digital spot 5000 DT uses DMX512 protocol to control hardware functions like pan, tilt, and zoom, as well
as media xture capabilities including loading images and movies. The graphics engine allows you manipulate
position, scale, rotation, apply visual effects and color mix each image.
S-Video and VGA inputs for direct input to data projectors are handy for perfoming presentations.
S-Video and Composite live inputs can be used in graphics effects of DigitalSpot 5000DT
1 - Yoke
2 - Pan lock/unlock lever
3 - Front panel
4 - Moving head
5 - Tilt lock button (red)
6 - Tilt unlock button (green)
7 - Base
8 - Handle
4. Description of the device

6
7
4.1 Video inputs
The VGA (8) and S-VIDEO (9) inputs provide direct connection to data projector.These inputs are allocated for
static presentation (standard using of the data projector) because data going through these inputs cannot be
processed in graphics engine ,it means that the most of graphics effects from DMX protocol are not active.In
this mode function Keystones from DMX protocol does not work.Nevertheless is possible to set keystones by
means of menu "Manual Control"(Manual Control ->Dataprojector Control and in this menu you have to select
Keystonning.After ending presentation is necessary to set Keystone into original state).
The S-VIDEO (13) and COMPOSITE (14) inputs enable to process data in graphics engine, it is means that
you can use all spectrum of effects that offer DMX protocol including digital Keystones.
Rear panel
1 - Power cord
2 - Power switch
3 - Fuse
4 - 5-pin DMX outputt
5 - 5-pin DMX input
6 - Ethernet input
7 - USB inputs
8 - 15-Pin VGA intput-dataprojec.
9 - S-video intput-dataprojector
10 - 3-pin DMX input
11 - 3-pin DMX output
12 - ATX switch
13 - S-video input- graphics engine
14 -Composite input-graphics engine
Front panel
1 - Display
2 - RNS control wheel
3 - Escape button
4 - Enter button
The head can be locked for transportation- the tilt lock button (5) is pushed and the pan lock/unlock lever (2)
is in lock position. To unlock the head, press the tilt unlock button (6) and move the pan lock/unlock lever to
unlock position.

6
7
5. Powering on the DigitalSpot 5000 DT
To power on the xture,simply connect it to the AC mains supply (the power switch on the rear side of the
xture has to be in "On" position).
6. Shutting down the DigitalSpot 5000 DT
There are two recommended ways to shutdown the xture:
1.A DMX controller can switch off the projector lamp and shut down the fixture with the "Lamp Off,Fixture
Off" option on the control channel 8 (see DMX protocol).
2.The option "Fixture Off" in main menu of DigitalSpot 5000 DT switches off the projector lamp and shuts down
the xture.
Removing power directly without the shutdown procedure
can reduce xture reliability!
7. Folders organization
The DigitalSpot 5000 DT has a le system that holds the images and movies .These les are saved in a Media
folder.This folder contains subfolders (000,001...240) and valid les may go into those subfolders.
The images and video clips can be in one of the following formats: .bmp;.jpg; .tga; .png; .mpg1; .mpg2.
The folder named "Update" contains subfolders with the update les and names of subfolders are deducated
from date when software update has been executed.
Folders structure:
Top level folder
Media
000
001
002
:
240
Update
13-08-06_09:15:33
14-07-06_12:16:45
:
01-03-06_14:23:50
All the above-mentioned folders are shared.

8
9
8. Rigging the xture
Please consider the respective national norms during the installation!
The installation must only be carried out by an authorized dealer!
The installation of the xture has to be built and constructed in a way that it can hold 10 times the weight for 1
hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down if
the main attachment fails.
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the rst time and after changes before taking into operation another time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
Allow the xture to cool for ten minutes before handling.
The projector should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all installation
material and theprojector. If you lack these qualications, do not attempt the installation yourself, but instead use
a professional structural rigger. Improper installation can result in bodily injury and or damage to property.
The xture has to be installed out of the reach of people.
If the xture shall be lowered from the ceiling or high joists, professional trussing systems have to be used. The
xture must never be xed swinging freely in the room.
Caution: Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do not install the xture.
Before rigging make sure that the installation area can hold a minimum point load of 10 times the xture’s
weight.
When installing the device, make sure there is no highly inamma ble
material (decoration articles, etc.) in between a distance of min. 0.5 m.
Use 2 appropriate clamps to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly!
Ensure that the structure (truss) to which you are attaching
the xtures is secure.
The device should be placed horizontally on a plain surface or upside down on a truss:
The Omega holders can be placed in 4 positions on the bottom of the base. Use the clamps (not supplied)
with screws M12.
For overhead use, always install a safety-rope that can hold at least 10 times the weight of the xture. You must
only use safety ropes with screw-on carabines. Pull the safety rope through the two apertures on the bottom of
the base and over the trussing system etc. Insert the end in the carabine and tighten the xation screw.

8
9
Fixation via the omega holders
1. Bolt each clamp (1) to the omega
holder (4) with M12 bolt and lock nut through the hole in the holder.
2. Fasten the omega holders on the
bottom of the base by inserting both quick-lock fasteners (3) into the holes of the base and tighten fully
clockwise.
3 . Fasten the safety-rope (2) through the
two apertures on the bottom of the base and over the trussing system.
1 - Clamp
2 - Safety-rope
3 - Quick-lock fastener
4 - Omega holder
Possible omega holder 4 positions:
Before taking into operation for the rst time,
the installation has to be approved by an expert!
1
2
3
4

10
11
1 - Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1 - Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
9. DMX-512 connection
The xture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired
in parallel.
Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in
order to connect the controller with the xture or one xture with another.
DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):
If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with
the DMX input of the rst xture in the DMX chain. If you wish to connect DMX controllers with other XLR-out-
puts, you need to use adapter cables.
Building a serial DMX chain:
1.Connect the DMX output of the rst xture in the DMX chain with the DMX input of the next xture. Always
connect one output with the input of the next xture until all xtures are connected.
2.Use menu "DMX Settings " to set the DMX start address on all xtures (see "Fixture address" menu).
3.The option “Activate DMX mode" has to be conrmed in “DMX Settings" menu on all xtures.
Example:
DMX Address=173 DMX Address=78 DMX Address=1
Caution: At the last xture, the DMX cable has to be terminated with a terminator. Solder a 120 Ω resistor
between Signal (–) and Signal (+) into a 3-pin (or 5pin) XLR plug and plug it into the DMX output of the last
xture.

10
11
10. Ethernet connection
The xtures on a data link are connected to the Ethernet with Art-Net communication protocol.The controlling
software from PC (or lighting console) has to support Art-Net protocol.
Art-Net communication protocol is based on the TCP/IP.Its purpose is to allow transfer of large amounts of
DMX 512 data over a wide area using standard network technology.
An IP address is the Internet protocol address.The IP uniquely identies any node (xture) on a network.
A Universe is a single DMX 512 frame of 512 channels.
The DigitalSpot 5000 DT is equipped with 8-pin RJ- 45 socket for Ethernet input.Use a network cable category
5 (with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect xtures to the hubs or LAN sockets are wired 1:1,that is,pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
If only the xture and the computer are to be interconnected,no hubs or other active components are needed.A
cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
Ethernet operation
Connect the Ethernet inputs of all xtures in the xture chain with the network.
Use menu "Artnet Settings " to set the IP address , artnet universe and the artnet subnet on all xtures (see
"Fixture address" menu).
The option “Activate Artnet mode" has to be conrmed in “Artnet Settings ” menu on all xtures.
(DMX address=173) (DMX address=87) (DMX address=1)
IP addres=002.168.002.004 IP addres=002.168.002.003 IP addres=002.168.002.002
Artnet Universe=1 Artnet Universe=1 Artnet Universe=1
Artnet Subnet=0 Artnet Subnet=0 Artnet Subnet=0

12
13
11. DigitalSpot 5000 DT - DMX Protocol - version 3.5
Channel Value Function Type of control
10 - 255
Pan
Pan movement by 530° proportional
20 - 255
Pan Fine
Fine control of pan movement proportional
30 - 255
Tilt
Tilt movement by 280° proportional
40 - 255
Tilt ne
Fine control of tilt movement proportional
5
0
1 - 255
1 - 255
Pan/Tilt speed , Pan/Tilt time
Max. speed (tracking mode)
P./T. speed-set Speed Mode in menu: Pan/Tilt Mode
Speed from max. to min. (vector mode)
P./T. time - set Time Mode in menu: Pan/Tilt Mode
Time from 0.1 s to 25.5 s.
step
proportional
proportional
6
0 - 9
10 - 31
32 - 63
64 - 95
96 - 127
128 - 159
160 - 191
192 - 223
224 - 255
Pan/Tilt macro selection
Disabled pan/tilt macro
Reserved
Figure of circle (from small to large)
Figure of horizontal eight (from small to large)
Figure of vertical eight (from small to large)
Figure of rectangle (from small to large)
Figure of triangle (from small to large)
Figure of star (from small to large)
Figure of cross (from small to large)
step
step
proportional
proportional
proportional
proportional
proportional
proportional
proportional
7
0
1 - 127
128 - 129
130 - 255
Pan/Tilt macro speed
No macro generation
Macro generation from fast to slow-forwards
No macro generation
Macro generation from slow to fast-backwards
step
proportional
step
proportional
8
0 - 49
50 - 59
60 - 69
70 - 79
80 - 89
90 - 94
95 - 99
100 - 104
105 - 109
110 - 114
115-119
120-129
130 - 139
140 - 149
180 - 189
190 - 199
200 - 209
210 - 215
216 - 229
230 - 239
240 - 249
250 - 255
Power/Special functions
Reserved
To activate following functions, hold DMX value 3 sec. and digital iris
must be closed at least 3 sec. (channel 75 must be at 255 DMX).Co-
rresponding menu items are temporarily overriden).
Pan/Tilt speed mode
Pan/Tilt time mode
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Ceiling projection On
Ceiling projection Off
Rear projection On
Rear Off
DMX In
Artnet In
Reserved
To activate following functions,hold DMX value 3 seconds.
Lamp On
Pan/Tilt reset
Focus/Zoom reset
Analog iris reset
Total reset
Graphic engine reset/software update executing
Reserved
Lamp Off
Lamp Off,Fixture Off (hold DMX value 5 seconds)
Reserved
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
9
0-63
64-127
128-191
192-255
Video input selection
Internal graphic engine to projector
External VGA to projector
External S-video to projector
Reserved
step
step
step
step

12
13
Channel Value Function Type of control
10 0-255
Zoom
Zoom from min. to max. (128-default) proportional
11 0-255
Focus
Continuous adjustment from far to near (128-default) proportional
12 0
0-255
Analog Iris
Open
From max. diameter to min. diameter
step
proportional
13 0-255
KeyStone Top Left X
Move top left corner X value to center (0-default) proportional
14 0-255
KeyStone Top Left Y
Move top left corner Y value to center (0-default) proportional
15 0-255
KeyStone Top Right X
Move top right corner X value to center (0-default) proportional
16 0-255
KeyStone Top Right Y
Move top right corner Y value to center (0-default) proportional
17 0-255
KeyStone Bottom Right X
Move bottom right corner X value to center (0-default) proportional
18 0-255
KeyStone Bottom Right Y
Move bottom right corner Y value to center (0-default) proportional
19 0-255
KeyStone Bottom Left X
Move bottom left corner X value to center (0-default) proportional
20 0-255
KeyStone Bottom Left Y
Move bottom left corner Y value to center (0-default) proportional
21 Reserved
Gobo layer 1
22 0 - 255
Dimmer
Dimmer intensity from 0% to 100% (255-default) proportional
23
0-20
21-240
241-250
251
252-255
Gobo Folder selection
Factory folders
User folders
Reserved
Live input (grab. card)-see channel 24
Reserved
step
step
step
step
step
24
0
1 - 255
0
1-20
21-40
41-60
61-80
81-100
101-120
121-255
Gobo selection
White
255 Gobos (one by one)
If Live input (251 DMX) is selected on channel 23:
White screen
Video composite input-PAL system
SVIDEO input- PAL system
Video composite input-NTSC system
SVIDEO input- NTSC system
Video composite input-SECAM system
SVIDEO input- SECAM system
Reserved
step
step
step
step
step
step
step
step
step
step
25 0-255
In Frame High
Denes the beginning of a media le segment as a percentage
of the movie length (0-default)
proportional
26 0-255
In Frame Low
Denes the beginning of a media le segment as a percentage
of the movie length (0-default)
proportional
27 0-255
Out Frame High
Denes the end of a media le segment as a percentage of
the movie length (255-default)
proportional
28 0-255
Out Frame Low
Denes the beginning of a media le segment as a percentage
of the movie length (255-default)
proportional

14
15
Channel Value Function Type of control
29
0
1
2
3
4
5
6
7
8
9
10-255
Gobo control
Play forward if dimmer (on layer 1) > 0, looping continuously
Play forward if dimmer (on layer 1) > 0, hold on last frame
Pause
Play forward in continuous loop
Play forward once and hold on the last frame
No function
Scrub (Display) the selected In Frame
Scrub (Display) the selected Out Frame
No function
No function
Reserved
step
step
step
step
step
step
step
30
0
1-127
128
129-255
Playback Speed
Normal Speed
Slow speeds from slowest ---> normal
Normal Speed
Faster than Normal ---> Fastest
step
proportional
step
proportional
31
0 - 63
64-127
128
129-192
193-255
Gobo rotation and indexing
Clockwise rotation from fast to slow
Indexing
No rotation-centre (128-default)
Indexing
Anticlockwise rotation from slow to fast
proportional
proportional
step
proportional
proportional
32 0 - 255
Gobo ne indexing (rotation)
Fine indexing (rotation) proportional
33
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
Gobo effect 1 Selection
No effect
Zoom sinus
Zoom bump in fade out
Zoom fade in bump out
Reserved
Zoom in fade
Zoom out fade
Scale xy sinus
Reserved
Reserved
Reserved
XY pos. circle counter-clockwise
XY pos. circle clockwise
XY pos. scroll up
XY pos. scroll down
XY pos. scroll left
XY pos.scroll right
Right-left diag. down scroll
Right-left diag. up scroll
Left-right diag. down scroll
Left-right diag. up scroll
X rotate
Y rotate
XY rotate
XY inv. rotate
X inv. y rotate
Tile xy
Tile xy
XYZ rot. cube
XYZ rot. sphere
X rot. cylinder
Y rot. cylinder
Reserved
Kaleidoscope
Type of effect control
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
amount
speed
speed
speed
speed
speed
none

14
15
Channel Value Function Type of control
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78-79
Squeeze in
Squeeze out
Bend X
Bend Y
Tile frame
Frame
Plane ip X
Plane ip Y
Plane ip XY
Plane mirror X top
Plane mirror X bottom
Plane mirror Y left
Plane mirror Y right
Plane mirror XY segment 1
Plane mirror XY segment 2
Plane mirror XY segment 3
Plane mirror XY segment 4
Plane tile 2x
Plane tile 3x
Plane tile 4x
Plane tile 5x
Plane cross tile 2x
Plane cross tile 2x inverse
Plane cross tile 3x
Plane cross tile 3x inverse
Plane cross tile 4x
Plane cross tile 4x inverse
Plane cross tile 5x
Plane cross tile 5x inverse
Plane cross tiler 5x
Plane cross tiler 5x inverse
Plane bar
Plane bar inverse
Plane bar left-righ
Plane bar top-bottom
Reserved
Reserved
Gobo disc
Gobo disc ip X
Gobo disc ip Y
Gobo disc ip XY
Gobo disc mirror X
Gobo disc mirror Y
Gobo disc mirror XY
Reserved
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
80
81
82
83
84
85
86
87-255
Plane mirror X top inverse
Plane mirror X bottom inverse
Plane mirror Y left inverse
Plane mirror Y right inverse
Plane mirror XY inverse
Plane mirror X-inverse,Y
Plane mirror X,Y-inverse
Reserved
none
none
none
none
none
none
none
34 0 - 255
Gobo effect 1 control
Control of amount/speed proportional
35
0
1
2
3
4
Gobo effect 2 Selection
No effect
Colour to black and white
Colour to black and white inverse
Black and white to black and white inverse
Inversion
Type of effect control
amount
amount
amount
amount

16
17
Channel Value Function Type of control
35
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33-39
40
41
42
43
44
45-255
Black Mask
Black Mask inverse
Contrast
Brightness
RGB to GBR
RGB to BRG
RGB to RBG
Black and white to black and white inverse timed
Colour to black and white timed
Colour to inverse timed
Cycle
Cycle inverse
Reserved
Reserved
Colour Key
Colour Key inverse
Key Black
Key Black inverse
Key White
Key White inverse
White ash
Black ash
Alpha ash
Invert ash
BW ash
Black and white to black and white inverse Flash
Gradient Wipe X
Gradient Wipe Y
Reserved
Gaussian lter
Mean lter
Laplacian lter
Emboss lter
Sharpness lter
Reserved
amount
amount
amount
amount
amount
amount
amount
speed
speed
speed
speed
speed
amount
amount
amount
amount
amount
amount
speed
speed
speed
speed
speed
speed
speed
speed
amount
amount
amount
amount
amount
36 0 - 255
Gobo effect 2 control
Control of amount/speed proportional
37 Reserved
38 Reserved
39 0-127
128
129-255
Gobo Position X coarse
Movement forward
Centre (128-default)
Movement backward
proportional
step
proportional
40 0-255
Gobo position X ne
Position X ne proportional
41 0-127
128
129-255
Gobo position Y coarse
Movement down
Centre (128-default)
Movement up
proportional
step
proportional
42 0-255
Gobo position Y ne
Position Y ne proportional
43 0-127
128
129-255
Gobo zoom X coarse
Narrowing
Centre (128-default)
Widening
proportional
step
proportional
44 0-255
Gobo zoom X ne
Zoom X ne proportional

16
17
Channel Value Function Type of control
45 0-127
128
129-255
Gobo zoom Y coarse
Narrowing
Centre (128-default)
Widening
proportional
step
proportional
46 0-255
Gobo zoom Y ne
Zoom Y ne proportional

18
19
Gobo layer 2
Channel Value Function Type of control
47 0-255
Dimmer
Dimmer intensity from 0% to 100% (255-default) proportional
48
0-20
21-240
241-250
251
252-255
Gobo Folder selection
Factory folders
User folders
Reserved
Live input (capture card)-see channel 49
Reserved
step
step
step
step
step
49
0
1-255
0
1-20
21-40
41-60
61-80
81-100
101-120
121-255
Gobo selection
White
255 Gobos (one by one)
If Live input (251 DMX) is selected on channel 48:
White screen
Video composite input-PAL system
SVIDEO input- PAL system
Video composite input-NTSC system
SVIDEO input- NTSC system
Video composite input-SECAM system
SVIDEO input- SECAM system
Reserved
step
step
step
step
step
step
step
step
step
step
50 0-255
In Frame High
Denes the beginning of a media le segment as a percentage
of the movie length (0-default)
proportional
51 0-255
In Frame Low
Denes the beginning of a media le segment as a percentage
of the movie length (0-default)
proportional
52 0-255
Out Frame High
Denes the end of a media le segment as a percentage of the
movie length (255-default)
proportional
53 0-255
Out Frame Low
Denes the end of a media le segment as a percentage of the
movie length (255-default)
proportional
54
0
1
2
3
4
5
6
7
8
9
10-255
Gobo control
Play forward if dimmer (on layer 2) > 0, looping continuously
Play forward if dimmer (on layer 2) > 0, hold on last frame
Pause
Play forward in continuous loop
Play forward once and hold on the last frame
No function
Scrub (Display) the selected In Frame
Scrub (Display) the selected Out Frame
No function
No function
Reserved
step
step
step
step
step
step
step
55
0
1-127
128
129-255
Playback Speed
Normal Speed
Slow speeds from slowest ---> normal
Normal Speed
Faster than Normal ---> Fastest
step
proportional
step
proportional
56
0 - 63
64-127
128
129-192
193-255
Gobo rotation and indexing
Clockwise rotation from fast to slow
Indexing
No rotation-centre (128-default)
Indexing
Anticlockwise rotation from slow to fast
proportional
proportional
step
proportional
proportional
57 0 - 255
Gobo ne indexing (rotation)
Fine indexing (rotation) proportional

18
19
Channel Value Function Type of control
58
0
1
2
3
4
5
6
7
8
9
Gobo effect 1 Selection
No effect
Zoom sinus
Zoom bump in fade out
Zoom fade in bump out
Reserved
Zoom in fade
Zoom out fade
Scale xy sinus
Reserved
Reserved
Type of effect control
speed
speed
speed
speed
speed
speed
speed
58
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
Reserved
XY pos. circle counter-clockwise
XY pos. circle clockwise
XY pos. scroll up
XY pos. scroll down
XY pos. scroll left
XY pos.scroll right
Right-left diag. down scroll
Right-left diag. up scroll
Left-right diag. down scroll
Left-right diag. up scroll
X rotate
Y rotate
XY rotate
XY inv. rotate
X inv. y rotate
Tile xy
Tile xy
XYZ rot. cube
XYZ rot. sphere
X rot. cylinder
Y rot. cylinder
Reserved
Kaleidoscope
Squeeze in
Squeeze out
Bend X
Bend Y
Tile frame
Frame
Plane ip X
Plane ip Y
Plane ip XY
Plane mirror X top
Plane mirror X bottom
Plane mirror Y left
Plane mirror Y right
Plane mirror XY segment 1
Plane mirror XY segment 2
Plane mirror XY segment 3
Plane mirror XY segment 4
Plane tile 2x
Plane tile 3x
Plane tile 4x
Plane tile 5x
Plane cross tile 2x
Plane cross tile 2x inverse
Plane cross tile 3x
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
speed
amount
speed
speed
speed
speed
speed
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none
none

20
21
Channel Value Function Type of control
58
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
73
Plane cross tile 3x inverse
Plane cross tile 4x
Plane cross tile 4x inverse
Plane cross tile 5x
Plane cross tile 5x inverse
Plane cross tiler 5x
Plane cross tiler 5x inverse
Plane bar
Plane bar inverse
Plane bar left-righ
Plane bar top-bottom
Reserved
Reserved
Gobo disc
Gobo disc ip X
Gobo disc ip Y
none
none
none
none
none
none
none
none
none
none
none
none
none
none
74
75
76
77
78-79
80
81
82
83
84
85
86
87-255
Gobo disc ip XY
Gobo disc mirror X
Gobo disc mirror Y
Gobo disc mirror XY
Reserved
Plane mirror X top inverse
Plane mirror X bottom inverse
Plane mirror Y left inverse
Plane mirror Y right inverse
Plane mirror XY inverse
Plane mirror X-inverse,Y
Plane mirror X,Y-inverse
Reserved
none
none
none
none
none
none
nine
none
none
none
none
59 0-255
Gobo effect 1 control
Control of amount/speed proportional
60
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
Gobo effect 2 Selection
No effect
Colour to black and white
Colour to black and white inverse
Black and white to black and white inverse
Inversion
Black Mask
Black Mask inverse
Contrast
Brightness
RGB to GBR
RGB to BRG
RGB to RBG
Black and white to black and white inverse timed
Colour to black and white timed
Colour to inverse timed
Cycle
Cycle inverse
Reserved
Reserved
Colour Key
Colour Key inverse
Key Black
Key Black inverse
Key White
Key White inverse
White ash
Black ash
Alpha ash
amount
amount
amount
amount
amount
amount
amount
amount
amount
amount
amount
speed
speed
speed
speed
speed
amount
amount
amount
amount
amount
amount
amount
amount
speed
speed
speed
