Robe Divine 160 RGBW User manual

Version 1
.
7
QR code for user manual

Divine 160 RGBW
2
Table of contents
1. Safety instructions ...................................................................................................................................................... 3
2. Fixture exterior view ................................................................................................................................................... 5
3. Installation .................................................................................................................................................................. 5
3.1 Connection to the mains ...................................................................................................................................... 5
3.2 Mounting the fixture ............................................................................................................................................ 6
3.3 Top hat and half top hat installation .................................................................................................................... 8
3.4 Barn door and Wire guard/anti-glare installation ............................................................................................... 9
3.5 DMX 512 connection ............................................................................................................................................ 9
4. Divine 160 RGBW - DMX protocol ........................................................................................................................... 11
5. Control menu ............................................................................................................................................................ 14
5.1 Fixture Address ................................................................................................................................................... 14
5.2 Fixture information ............................................................................................................................................. 14
5.3 Personality .......................................................................................................................................................... 15
5.4 Manual mode ...................................................................................................................................................... 17
5. 5 Test sequences................................................................................................................................................... 17
5.6 Stand-alone setting ............................................................................................................................................. 17
5.7 Special functions ................................................................................................................................................. 19
6. Technical specifications ............................................................................................................................................ 20
7. Cleaning and maintenance ....................................................................................................................................... 22
7.1 Replacing a fuse .................................................................................................................................................. 22
7.2 Disposing of the product .................................................................................................................................... 23

Divine 160 RGBW
3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR Divine 160 RGBW!
Save it for future reference.
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure
safe operation, it is absolutely necessary for the user to follow the safety instructions and warnings written in this
manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual
or any unauthorized modification to the device.
Unauthorized modification will void warranty.
This device is for professional use only. It is not for household use.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT!
Make sure that the available voltage is not higher than stated on the rear side of the fixture.
This fixture should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the fixture from AC power before servicing or cleaning internally.
Do not overload supply line as this can result in fire or electric shock.
Make sure the power/data cable is never crimped or damaged by sharp edges. Check the fixture and the
power/data cable from time to time.
Do not install the unit near an open flame.
Refer servicing to qualified service personnel.
This fixture falls under protection class I. Therefore, this fixture has to be connected to a mains socket outlet
with a protective earthing connection.
Do not connect this fixture to a dimmer pack.
Warning! Risk Group 2 LED product according to EN 62471 .
LED light emission. Risk of eye injury.
Do not look straight at the fixture´s LEDs during operation. The intense light beam may damage your eyes.
The light source contains blue LEDs.
Immunity of the equipment is designed for electromagnetic environments E1, E2, E3 according to the standard
EN55103-2 ed.2 Electromagnetic compatibility. Product family standard for audio, video, audiovisual and
entertainment lighting control apparatus for professional use. Part 2: Immunity.
The installation company should check levels of possible interferences above the tested levels E1,E2,E3 given by
this standard (e.g. transmitters in surrounding area) before installing the equipment.
Emission of the equipment complies with the standard EN55032 Electromagnetic compatibility of multimedia
equipment – Emission Requirements according to class B.

Divine 160 RGBW
4
Keep combustible materials at least 0.3 m away from the fixture.
If the fixture has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation of water might damage your device. Leave the device switched off until it
has reached room temperature.
Avoid brute force when installing or operating the fixture.
When choosing the installation spot, please make sure that the fixture is not exposed to extreme heat or dust.
Avoid using the unit in locations subject to possible impacts.
Only operate the fixture after having checked that the housing is firmly closed and all screws are tightly fastened.
Do not block the front glass cover with any object when the fixture is under operation.
The fixture body must never be covered with cloth or other materials.
The fixture becomes very hot during operation. Allow the fixture to cool approximately 30 minutes prior to
servicing or maintenance.
Operate the fixture only after having familiarized yoursef with its functions. Do not permit operation by persons
not qualified to operate the fixture. Most damages are the result of unprofessional operation!
Please consider that unauthorized modifications on the fixture are forbidden due to safety reasons!
Please use the original packaging if the fixture is to be transported.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the warranty becomes void. Furthermore, any other operation may lead to dangers like short-circuit,
burns, electric shock etc.

Divine 160 RGBW
5
2. Fixture exterior view
3. Installation
3.1 Connection to the mains
Fixture must be installed by a qualified electrician in accordance with all national
and local electrical and construction codes and regulations.
This device falls under class one and must be grounded!
The Divine 160 RGBW is equipped with auto-switching power supply that automatically adjusts to any 50-60Hz AC
power source from 100-240V (CE) or 100-277 V (US). The fixture must be connected to a non-dimmable power
source in order to avoid damage to its internal power supply and other electrical components.
Connect the fixture to the mains by means of inbuilt power cord with the plug.
1.
Head with LED array
2. Tilt lock
3. Base
4. Power and DMX connection
5. Attachment point for safety wire
6. Rubber feet
7. Openings for mounting brackets Omega CL assembled
8. Universal base adaptor for Strobe IP

Divine 160 RGBW
6
3.2 Mounting the fixture
Disconnect the fixture from mains prior to start any installation/assembly works.
The Divine 160 RGBW can be arranged in any position/orientation without altering its operation characteristics.
The LED module can be tilted to desired position by means of the tilt lock.
Universal base adaptor installation
Screw the universal base adaptor (8) to the base (3) of the fixture by means of six Allen head bolts M8x25 (12) with
six spring washers .
The Universal base adaptor of the fixture (8) is equipped with two pairs of rubber feet (6) for standing the fixture
on the floor and three pairs of openings (7) for installation of the mounting adaptors Omega CL (9) which allow to
rig the fixture to the truss.
For overhead installation, the fixture must be always secured with a safety wire.
A structure (truss) intended for installation of the fixture (s) must safely hold weight of the fixture(s) placed on it.
The structure has to be certificated to the purpose.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the first time and after changes before taking into operation another time.
IMPORTANT! Overhead installation requires extensive experience including calculating working load limits,
installation material being used, and periodic safety inspection of all installation material and fixtures.
Fixtures may cause severe injuries when crashing down! If you have doubts concerning the safety of a possible
installation, do not install the fixtures and consult installation with an expert.

Divine 160 RGBW
7
CAUTION!
Use 2 mounting brackets Omega CL and appropriate clamps to rig the fixture on the truss.
Make sure that the device is fixed properly!
Ensure that the structure (truss) to which you are attaching the fixtures is secure
.
The fixture must never be fixed swinging freely in the room.
For securing the fixture to the truss, install a safety wire which can hold at least 10 times the weight of the fixture.
Use only the safety wire with a snap hook with screw lock gate.
Truss installation
1.Bolt clamp to the Omega adaptor CL (9) with M12 bolts and lock nuts through the hole in the adaptor
Omega CL.
2.Fasten the Omega adaptors (adaptor) CL on the universal base adaptor (8) by means of the quick-lock fasteners
(10) and tighten them fully clockwise.
3. Fasten the safety wire (11) in the attachment point (5) and around the truss.

Divine 160 RGBW
8
Possible positions of the adaptors Omega adaptors CL with clamps:
2-bracket installation 2-bracket installation 1-bracket installation
3.3 Top hat and half top hat installation
Half top hat Top hat
1. Unscrew screws M3x5 (3) to remove the bottom part (2) of the top hat (half top hat).
2. Place the upper part (1) of the top hat (half top hat) on the fixture head and secure it by means of two
screws M5x8 (4) with spring washers to the two threaded holes (A) on the back side of the fixture head.
3. Place the bottom part (2) of the top hat (half top hat) on the bottom part of the fixture head and screw it
back to the upper part (1) of the top hat (half top hat) by means of the screws M3x5 (3).
4. Secure the bottom part of the top hat (half top hat) to the fixture head by means of two screws M5x8 (4)
with spring washers to the two threaded holes (A) on the back side of the fixture head.

Divine 160 RGBW
9
3.4 Barn door and Wire guard/anti-glare installation
Barn door Wire guard/anti-glare
1. Unscrew screws M3x5 (3) to remove the bottom part (2) of the barn door (wire guard/anti-glare).
2. Place the upper part (1) of the barn door (wire guard/anti-glare) on the fixture head and secure it by means
of two screws M5x10 (4) /M5x8 for wire guard/anti-glare/ with spring washers to the two threaded holes
(A) on the back side of the fixture head.
3. Place the bottom part (2) of the barn door (wire guard/anti-glare) on the bottom part of the fixture head
and screw it back to the upper part (1) of the barn door (wire guard/anti-glare) by means of the screws
M3x5 (3).
4. Secure the bottom part of the barn door (wire guard/anti-glare) to the fixture head by means of two
screws M5x10 (4) /M5x8 for wire guard/anti-glare/ with spring washers to the two threaded holes (A) on
the back side of the fixture head.
3.5 DMX 512 connection
The fixture is equipped with 5-pin XLR connectors for DMX input/output. Only use a shielded twisted-pair cable
designed for RS-485 and 5-pin XLR connectors in order to connect the controller with the fixture or one fixture
with another.
Wiring of the XLR connectors:
XLR socket: XLR plug:
To build a DMX chain
1. Connect the DMX output of the controller directly with the DMX input of the first fixture in the DMX chain.
2. Connect the DMX output of the first fixture in the DMX chain with the DMX input of the next fixture.
3. Always connect the DMX output with the input of the next fixture until all fixtures are connected.
Do not overload the link. Max. 32 fixtures may be connected on a DMX link.
1
–
Shield
2 - Signal (-)
3 - Signal (+)
4 – Not connected
5
–
Not connected

Divine 160 RGBW
10
Caution: Terminate the link by installing a termination plug in the output of the last fixture. The termination plug is
a male 5-pin XLR plug (IP 67 rating) with a 120 Ohm resistor soldered between Signal (–) and Signal (+).
Warning:
Fixture´s XLR connectors are dust and water protected according to IP 67 by mating with related XLR cable
connectors.
They cannot stay disconnected outdoor. DMX output connector (XLR female) at the last fixture in a DMX line
has to be covered with the rubber cap before inserting a terminator. The rubber cap does not supply the
terminator.
The XLR terminator (male) has to be dust and water protected.
If the fixture is to be outdoor without connecting to DMX line, always interconnect its DMX input with DMX output
to keep declared IP rating of XLR connectors.
