Robe Anolis ArcSource Outdoor 48 MC Integral RGBW User manual

Version 2.
9
US
QR code for user manual

ArcSource Outdoor 48 MC Integral
2
Table of contents
1. Safety instructions ...................................................................................................................................................... 3
2. Fixture exterior view ................................................................................................................................................... 5
3. Installation .................................................................................................................................................................. 5
3.1 Mounting the fixture ............................................................................................................................................ 5
3.2 Top hat (Half top hat ) installation ....................................................................................................................... 6
3.3 Connection to the mains ...................................................................................................................................... 7
4. Wireless DMX operation ............................................................................................................................................. 9
5. ArcSource Outdoor 48 MC Integral (RGBW) - DMX protocol ................................................................................... 10
6. ArcSource Outdoor 48 MC Integral (RGBA) - DMX protocol .................................................................................... 12
7. ArcSource Outdoor 48 MC Integral (SmartWhite) - DMX protocol .......................................................................... 14
8. ArcSource Outdoor 48 MC Integral (Single colour) - DMX protocol ......................................................................... 15
9. Control menu map .................................................................................................................................................... 16
10. Fixture menu ........................................................................................................................................................... 22
10.1 Fixture Address ................................................................................................................................................. 22
10.2 Fixture information ........................................................................................................................................... 22
10.3 Personality ........................................................................................................................................................ 23
10.4 Manual mode .................................................................................................................................................... 24
10. 5 Test sequences................................................................................................................................................. 24
10.6 Stand-alone setting ........................................................................................................................................... 25
10.7 Special functions ............................................................................................................................................... 26
11. RDM ........................................................................................................................................................................ 28
12. Technical specifications .......................................................................................................................................... 30
13. Cleaning and maintenance ..................................................................................................................................... 33

ArcSource Outdoor 48 MC Integral
3
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR ArcSource Outdoor 48 MC Integral !
Save it for future reference.
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to ensure a
safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes written in
this manual.
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual
or any unauthorized modification to the device.
Please consider that damages caused by manual modifications to the device are not subject to warranty.
1. Safety instructions
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT!
Make sure that the available voltage is not higher than stated on the rear panel of the fixture.
This fixture should be operated only from the type of power source indicated on the marking label. If you are not
sure of the type of power supplied, consult your authorized distributor or local power company.
Always disconnect the fixture from AC power before cleaning, removing or installing any part.
Do not overload wall outlets and extension cords as this can result in fire or electric shock.
Make sure that the power cord is never crimped or damaged by sharp edges. Check the fixture and the power cord
from time to time.
Do not install the unit near naked flames.
During the operation the housing becomes hot (up to 80°C)
Refer servicing to qualified service personnel.
This fixture falls under protection class I. Therefore this fixture has to be connected to a mains socket outlet with
a protective earthing connection.
Do not connect this fixture to a dimmer pack.
LED light emission. Risk of eye injury.
Do not look straight at the fixture´s LEDs during operation. The intense light beam may damage your eyes.
Keep compustible materials at least 20 cm away from the fixture.
If the fixture has been exposed to drastic temperature fluctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until it has
reached room temperature.
Avoid brute force when installing or operating the fixture.
The fixture was designed for outdoor use. This fixture must not be used for underwater installation.

ArcSource Outdoor 48 MC Integral
4
When choosing the installation spot, please make sure that the fixture is not exposed to extreme heat or dust.
Avoid using the unit in locations subject to possible impacts.
The fixture body never must be covered with cloth or other materials.
Only operate the fixture after having checked that the housing is firmly closed and all screws are tightly fastened.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the fixture.
Do not block the front objective LEDs with any object when the fixture is under operation.
The fixture becomes very hot during operation. Allow the fixture to cool approximately 30 minutes prior to
manipulate with it.
Operate the fixture only after having familiarized with its functions. Do not permit operation by persons not
qualified for operating the fixture. Most damages are the result of unprofessional operation!
Do not attempt to dismantle or modify the unit.
Please consider that unauthorized modifications on the fixture are forbidden due to safety reasons!
Please use the original packaging if the fixture is to be transported.
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock etc.
Immunity of the equipment is designed for electromagnetic environments E1, E2, E3 according to the standard
EN55103-2 ed.2 Electromagnetic compatibility. Product family standard for audio, video, audiovisual and
entertainment lighting control apparatus for professional use. Part 2: Immunity.
The product (covers and cables) must not be exposed to a high frequency electromagnetic field higher than 3V/m.
The installation company should check levels of possible interferences above the tested levels E1,E2,E3 given by
this standard (e.g. transmitters in surrounding area) before installing the equipment.
Emission of the equipment complies with the standard EN55032 Electromagnetic compatibility of multimedia
equipment – Emission Requirements according to class B.
Warning for fixtures with Harsh Environment Finish (HEF):
Handle with care!
Avoid any damage to the painted surface.
Damaging the paint may result in corrosion and loss of warranty.

ArcSource Outdoor 48 MC Integral
5
2. Fixture exterior view
3. Installation
3.1 Mounting the fixture
The ArcSource Outdoor 48 MC Integral can be arranged in any position orientation.
The LED module can be tilted to desired position by means of the tilt lock. Use an Allen key 8 to adjust desired
position (+35°/-90°).
Three slots in the fixture “U” holder serve for mounting on the non-flammable flat surface.
1. LED unit
2. Control unit
3. Antenna (only wireless DMX version)
4. Tilt adjusting locks
5. „U“ bracket
6. Control board with anti-vandal cover
7. Power/Data cable
8. LED unit connecting cable

ArcSource Outdoor 48 MC Integral
6
Ensure that the structure to which you are attaching
the fixture is secure
Caution: Overhead installation requires experience. Fixtures may cause severe injuries when crashing down! If you
have doubts concerning the safety of a possible installation, do not install the device and consult installation with
an expert.
Warning for wireless DMX version!
The fixture is supplied with the cap screwed on the antenna connector. This cap provides declared IP rating of the
fixture but when the cap is removed, the enclosed antenna must be installed on the fixture to keep declared IP
rating of the fixture!
There is a possibility to install the LED unit and the control unit separately. Four holes with diameter of 5.3mm in
the control unit are intended for mounting on a flat, non-flammable surface. The length of the connection cable
between the control unit and the LED unit should not exceed 20 m.
3.2 Top hat (Half top hat ) installation
Top hat Half top hat
1. Unscrew the four socket heads 6x12 (1) in ArcSource Outdoor 48 MC housing and slide the top hat (2) onto
ArcSource outdoor 48 MC Integral.
2. Secure it with four socket heads 6x12 through holes (3) in the top head.

ArcSource Outdoor 48 MC Integral
7
3.3 Connection to the mains
Fixtures must be installed by a qualified electrician in accordance with all national
and local electrical and construction codes and regulation.
This device falls under class one and must be grounded!
The ArcSource Outdoor 48 MC Integral is equiped with with a 5-cored power/data cable. The 3 cores serve for
the power supply and next 2 shielded cores are intended for DMX connection as shown the table.
Core
Connection
Core
Connection
B
lack
Live
Red
Data +
B
lue
Neutral
White
Data
-
Yellow/Green
Shielding
0
The power/data cable is connected to a junction box as shown on the picture below.
Connect the junction box acording to the tables below
Power connection
L
N
EU
Braun
Blue
Green/yellow
US
Black
White
Green
DMX connection
+
0
-
Data +
Data
ground(shielding)
Data
-
Remove end caps from cable glands before passing cables into the junction box. The four cable glands M20 with
standard seals serve for cable of diameter of 6-12mm, for smaller diameter of cable (4-8mm) you have to remove
original sealing from the cable gland M20 and use the enclosed reducing seal instead it. Four reducing seals for
diameter of cable 4-8mm (P/N 13051388) are enclosed.

ArcSource Outdoor 48 MC Integral
8
Fully tighten cable gland nuts and check that cables are properly fastened in the cable glands.
Note: To keep declared IP rating, every cable gland has to be covered with the end cap if this cable gland is not
used for cable passing.
The junction box allows to connect several fixtures in a daisy chain of the power/data cable. Use the 3 x 1.5mm2
power cable to connect the first junction box with the mains and the power/data cable for connecting fixtures
each other. Do not overload the supply line and the connecting leads.
The max. number of connected fixtures in a daisy chain depends on the input voltage:
14 fixtures at power supply= 230V (for power cable 3 x 1.5mm2)
7 fixtures at power supply= 120V (for power cable 3 x 1.5mm2)
You have to take into account the the length of power/data cable, circuit breaker etc. at projecting of the fixtures
installation.

ArcSource Outdoor 48 MC Integral
9
4. Wireless DMX operation
The wireless version of the ArcSource Outdoor 48 MC Integral is equipped with the Lumen Radio CRMX module
and antenna for receiving DMX signal. CRMX module operates on the 2.4 GHz band.
To link the fixture with the DMX transmitter
Select option “Wireless“ from the menu PErS (PErS-->DMX In.--> Wireless).
The fixture can be linked with the transmitter by running the link procedure at DMX transmitter .
After linking , the level of DMX signal (in %) is displayed in the menu item “Stat“ (Special-->Wireless-->Stat.)
To unlink the fixture from DMX transmitter.
The fixture can be unlinked from DMX transmitter via the menu item “Unlink“ (Special-->Wireless-->Unlink.)
Note: The ArcSource Outdoor 48 MC integral sends received wireless DMX signal to its wired DMX output. The
fixture behaves as a " Wireless/Wired" adaptor.
E.g. You have 5 fixtures, one fixture is equipped with the wireless DMX module and 4 fixtures are standard fixtures
without wireless DMX module. The first fixture receives wireless DMX and sents this signal to the rest of fixures,
which are connected to the first fixture by means of the DMX cable in a DMX chain.

ArcSource Outdoor 48 MC Integral
10
5. ArcSource Outdoor 48 MC Integral (RGBW) - DMX protocol
Version 1.1
Mode/Channel
Value Function Type of control
1
2
3
4
-
1
1
1
0 - 255
Red LEDs
Red LEDs saturation control (0-100%) proportional
-
2
2
2
0 - 255
Green LEDs
Green LEDs saturation control (0-100%) proportional
-
3
3
3
0 - 255
Blue LEDs
Blue LEDs saturation control (0-100%) proportional
-
-
4
4
0 - 255
White LEDs
White LEDs saturation control (0-100%) proportional
-
-
-
5
0
1-255
CT0
No function
Colour temperature correction (0-100%)
proportional
1
-
-
6
0
1-2
3
4-5
6
7-9
10-12
13-15
16
17-55
56
57 - 95
96
97 – 134
135
136 - 174
175
176 -214
215
216 – 246
247
248-251
252-255
Virtual colour wheel
No function (for DMX mode 4)
White (R+G+B+W=full for DMX mode 1)
White 2700 K
White 2700 K (Halogen lamp mode)
White 3200 K
White 3200 K (Halogen lamp mode)
White 4200 K
White 5600 K
White 8000 K
Blue (Blue=full, Red+Green+White=0)
Red=0, Greenup,Blue =full, White=0
Light Blue (Red=0, Green=full, Blue =full, White=0)
Red=0, Green=full, Bluedown, White=0
Green (Red=0, Green=full, Blue =0, White=0)
Redup, Green=full, Blue=0, White=0
Yellow-green (Red=full, Green=full, Blue=0, White=0)
Red=full, Greendown, Blue=0, White=0
Red(Red=full, Green=0, Blue=0, White=0)
Red=full, Green=0, Blueup, White=0
Magenta (Red=full, Green=0, Blue=full, White=0)
Reddown, Green=0, Blue=full, White=0
Blue (Red=0, Green=0, Blue=full, White=0)
Rainbow effect with fade time (fast-->slow)
Rainbow effect without fade time (fast-->slow)
step
step
step
step
step
step
step
step
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
proportional
-
-
-
7
0-31
32-63
64-95
96-127
128-143
144-159
160-191
Shutter/ Strobe
Shutter closed
Shutter open
Strobe-effect from slow to fast
Shutter open
Opening pulses in sequences slow--> fast
Closing pulses in sequences fast --> slow
Shutter open
step
step
proportional
step
proportional
proportional
step

ArcSource Outdoor 48 MC Integral
11
192
-
223
224-255
Random strobe
-
effects from slow
to fast
Shutter open
proportional
step
2
-
-
8
0 - 255
Dimmer
Dimmer intensity from 0% to 100% proportional
-
-
-
9
0 - 255
Dimmer fine
Fine dimmer intensity from low to high
Proportional

ArcSource Outdoor 48 MC Integral
12
6. ArcSource Outdoor 48 MC Integral (RGBA) - DMX protocol
Version 1.0
Mode/Channel
Value Function Type of control
1
2
3
4
-
1
1
1
0 - 255
Red LEDs
Red LEDs saturation control (0-100%) proportional
-
2
2
2
0 - 255
Green LEDs
Green LEDs saturation control (0-100%) proportional
-
3
3
3
0 - 255
Blue LEDs
Blue LEDs saturation control (0-100%) proportional
-
-
4
4
0 - 255
Amber
LEDs
Amber LEDs saturation control (0-100%) proportional
-
-
-
5
0
1-255
CT0
No function
Colour temperature correction (0-100%)
proportional
1
-
-
6
0
1-2
3
4-5
6
7-9
10-12
13-15
16
17-55
56
57 - 95
96
97 – 134
135
136 - 174
175
176 -214
215
216 – 246
247
248-251
252-255
Virtual colour wheel
No function (for DMX mode 4)
White (R+G+B=full for DMX mode 1)
White 2700 K
White 2700 K (Halogen lamp mode)
White 3200 K
White 3200 K (Halogen lamp mode)
White 4200 K
White 5600 K
White 8000 K
Blue (Blue=full, Red+Green+Amber=0)
Red=0, Greenup,Blue =full, Amber= 0
Light Blue (Red=0, Green=full, Blue =full, Amber =0)
Red=0, Green=full, Bluedown, Amber =0
Green (Red=0, Green=full, Blue =0, Amber =0)
Redup, Green=full, Blue=0, Amber =0
Yellow-green (Red=full, Green=full, Blue=0, Amber =0)
Red=full, Greendown, Blue=0, Amber =0
Red(Red=full, Green=0, Blue=0, Amber =0)
Red=full, Green=0, Blueup, Amber =0
Magenta (Red=full, Green=0, Blue=full, Amber =0)
Reddown, Green=0, Blue=full, Amber =0
Blue (Red=0, Green=0, Blue=full, Amber =0)
Rainbow effect with fade time (fast-->slow)
Rainbow effect without fade time (fast-->slow)
step
step
step
step
step
step
step
step
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
step
proportional
proportional
-
-
-
7
0-31
32-63
64-95
96-127
128-143
144-159
160-191
Shutter/ Strobe
Shutter closed
Shutter open
Strobe-effect from slow to fast
Shutter open
Opening pulses in sequences slow--> fast
Closing pulses in sequences fast --> slow
Shutter open
step
step
proportional
step
proportional
proportional
step

ArcSource Outdoor 48 MC Integral
13
192
-
223
224-255
Random strobe
-
effects from slow to fast
Shutter open
proportional
step
2
-
-
8
0 - 255
Dimmer
Dimmer intensity from 0% to 100% proportional
-
-
-
9
0 - 255
Dimmer fine
Fine dimmer intensity from low to high
Proportional

ArcSource Outdoor 48 MC Integral
14
7. ArcSource Outdoor 48 MC Integral (SmartWhite) - DMX protocol
Version 1.0
Mode/Channel
Value Function Type of control
1
2
3
1
-
1
0 - 255
Warm white
LEDs
Warm white LEDs saturation control (0-100%) proportional
2
-
2
0 - 255
Cool white
LEDs
Cool white LEDs saturation control (0-100%) proportional
-
1
3
0
1-2
3-4
5-6
7-8
9-10
11-12
13-14
15-16
17-247
248
249
250-255
Colour wheel
No function
White 2800 K
White 3200 K
White 3800 K
White 4200 K
White 4600 K
White 5000 K
White 5600 K
White 6300 K
Warm white --> Cool white
Rainbow effect (with fade time)
Rainbow effect
Reserved
step
step
step
step
step
step
Step
step
proportional
step
step
-
-
4
0-31
32-63
64-95
96-127
128-143
144-159
160-191
192-223
224-255
Strobe
Shutter closed
Shutter open
Strobe-effect from slow to fast
Shutter open
Opening pulses in sequences slow--> fast
Closing pulses in sequences fast --> slow
Shutter open
Random strobe-effects from slow to fast
Shutter open
step
step
proportional
step
proportional
proportional
step
proportional
step
-
2
5
0 - 255
Dimmer
Dimmer intensity from 0% to 100% proportional
- -
6
0 - 255
Dimmer fine
Fine dimmer intensity from low to high proportional

ArcSource Outdoor 48 MC Integral
15
8. ArcSource Outdoor 48 MC Integral (Single colour) - DMX protocol
Version 1.0
Mode/Channel
Value Function Type of control
1
2
-
1
0-31
32-63
64-95
96-127
128-143
144-159
160-191
192-223
224-255
Strobe
Shutter closed
Shutter open
Strobe-effect from slow to fast
Shutter open
Opening pulses in sequences slow--> fast
Closing pulses in sequences fast --> slow
Shutter open
Random strobe-effects from slow to fast
Shutter open
step
step
proportional
step
proportional
proportional
step
proportional
step
1
2
0 - 255
Dimmer
Dimmer intensity from 0% to 100% proportional
- 3 0 - 255
Dimmer fine
Fine dimmer intensity from low to high proportional

ArcSource Outdoor 48 MC Integral
16
9. Control menu map
Default settings=Bold print
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
DMXA
0001
Set DMXA
00
0
1
-
0512
InFo
P
On Time
.
Total
Reset
DM
X
In
REd
0
-
255
:
Dimmer F
0
-
255
Temp
.
Cur
rent
Led
Board
Hi
ghest
Led
Board
High Res.
Led
Board
Sw Ver.
IC
-
1
IC
-
2
PErS
DMX
Pres
Mod.1
Mod.2
Mod.3
Mod.4
DMX In
Wired
Wireless
Analog 0
-
10V
M. FTime
0.1
-
25.5
Display
Turn
On/Off T
On,
Off
Contrast
0
-
100%

ArcSource Outdoor 48 MC Integral
17
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Backlight
0
-
100%
Temp Uni
°
C
, °F
I
Ef
Po
s
Red
0
-
255
Green
0
-
255
Blue
0
-
255
White
(Amber)
0
-
255
CTC
0
-
255
C Wheel
0
-
255
Strobe
0
-
255
Dimmer
0
-
255
Dimmer F
0
-
255
Stor
e
Defaults
M
a
n
ual
Red
0
-
255
:
:
Dimmer F
0
-
255
Test Prg
St ALone
Auto Run
Off
Test
Prog 1
:
Prog 3
Pr Play
Test Prg
Prog 1
:
Prog 3
Pr Edit
Prog 1
Step 01
Prg End
1
-
40
:
:
Red
0
-
255

ArcSource Outdoor 48 MC Integral
18
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Prog 3
Step 40
:
:
F.Tim.
0
-
25.5 sec
Copy
S
pecial
rdM
L
ow
rdM
H
igh
LED type
RGBW
Sin. Col.
Smart. W.
RGBA
RGBA2
Wireless
Stat
Unlink
IniBlink
On,
Off
Hold DMX
On
,
Off
Flicker freeM
On
,
Off
Adjust
DMX Val
Red
0
-
255
:
Dimmer F
0
-
255
Cal Col
Red C
0
-
255
:
Store
Cal.temp
2700K
Red C
0
-
255
Grn C
0
-
255
Blu C
0
-
255
Whi C
0
-
255
Store
3200K
4200K
5600K
8000K

ArcSource Outdoor 48 MC Integral
19
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
Cal.Def.
Sw Upd
No/Yes
RDM menu (e.g. for the Robe Universal Interface WTX, because this device cannot display 2-row display of the
ArcSource Outdoor 48 MC Integral)
Default settings=Bold print
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
A001
Dm.Ad.
A001
InFo
P
oti
totl
rSEt
DM
.
In
rEd
0
-
255
:
dim
0
-
255
tEMP.
Cur
. t.
LEd
board
Hi
.tE.
LEd
board
rSEt.
LEd
board
VErS.
IC1
IC2
PErS
DM.Pr.
Mod.1
Mod.2
Mod.3
Mod.4
RGB Cnt
Active, Deactive
DM. In
Wird
rAdI
AnL.d

ArcSource Outdoor 48 MC Integral
20
Menu Level 1
Menu Level 2
Menu Level 3
Menu Level 4
Menu Level 5
Menu Level 6
M.F. ti.
0.1
-
25.5
tEM.u.
°
C
, °F
In.Po.
rEd
GrEn
bLuE
WhIt
CtC
C.vhE
Stro
dimr
F.dim
SAVE
dF. SE.
M
a
n
. M.
rEd
0
-
255
:
:
Dim F
0
-
255
tESt
St
. AL
Auto
O
FF
tESt
Pr
G
1
:
Pr
G
3
PLAY
tEst
Pr
G1
:
Pr
G3
Edit
Pr
G
1
St
.
01
P End
1
-
40
:
:
rEd
0
-
255
