Robe Color Wash 575E AT User manual

1
Version 1.5

2
Table of contents
1. Safety instructions ......................................................................................................... 3
2. Operating determinations.............................................................................................. 4
3. Description of the device............................................................................................... 5
4. Installation....................................................................................................................... 6
4.1Fitting the lamp............................................................................................................ 6
4.2 Lamp adjustment ....................................................................................................... 6
4.3 Inserting/Exchanging colours .................................................................................... 7
4.4 Installing top hats ...................................................................................................... 7
4.5 Changing the front and zoom lenses ........................................................................ 8
4.6 Connection to the mains ............................................................................................ 9
4.7 Changing the power supply settings .......................................................................... 9
4.8 Rigging the xture .................................................................................................... 10
4.9 DMX-512 connection................................................................................................ 12
4.10 Ethernet connection ............................................................................................... 13
5. ColorWash 575E AT-DMX Protocol-version 1.0......................................................... 15
6. Controller mode ........................................................................................................... 18
6.1 DMX addressing....................................................................................................... 18
6.2 Remotely controllable functions ............................................................................... 18
7.Control menu map......................................................................................................... 19
8. Control menu ............................................................................................................... 23
8.1 Fixture Address ....................................................................................................... 23
8.2 Fixture information ................................................................................................... 23
8.3 Personality ............................................................................................................... 24
8.4 Lamp On/Off ............................................................................................................ 26
8.5 Test sequences........................................................................................................ 26
8.6 Manual mode ........................................................................................................... 26
8.7 Stand-alone setting ................................................................................................. 26
8.8 Reset functions ........................................................................................................ 27
8.9 Special functions ...................................................................................................... 27
9. Low power mode .......................................................................................................... 28
10. RDM ............................................................................................................................. 29
11. Error and information messages .............................................................................. 30
12. Technical specications............................................................................................ 31
13. Maintenance and cleaning ........................................................................................ 34
ColorWash 575E AT

3
CAUTION!
Keep this device away from rain and moisture!
Unplug mains lead before opening the housing!
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE YOU INITIAL START - UP!
1. Safety instructions
Every person involved with installation and maintenance of this device have to:
- be qualiled
- follow the instructions of this manual
CAUTION!
Be careful with your operations.
With a high voltage you can suffer
a dangerous electric shock when touching the wires!
This device has left our premises in absolutely perfect condition. In order to maintain this condition and to en-
sure a safe operation, it is absolutely necessary for the user to follow the safety instructions and warning notes
written in this manual.
Important:
The manufacturer will not accept liability for any resulting damages caused by the non-observance of this
manual or any unauthorized modication to the device.
Please consider that damages caused by manual modications to the device are not subject to warranty.
Never let the power-cord come into contact with other cables! Handle the power cord and all connections with
the mains with particular caution!
Make sure that the available voltage is not higher than stated on the rear panel.
Always plug in the power plug least. Make sure that the power-switch is set to OFF-position before you connect
the device to the mains. The power plug has to be accessable after installing the device.
Make sure that the power-cord is never crimped or damaged by sharp edges. Check the device and the power-
cord from time to time.
Always disconnect from the mains, when the device is not in use or before cleaning it. Only handle the power-
cord by the plug. Never pull out the plug by tugging the power cord.
This device falls under protection class I. Therefore it is essential to connect the yellow/green conductor to
earth.
The electric connection, repairs and servicing must be carried out by a qualied employee.
Do not connect this device to a dimmer pack.
Do not switch the xture on and off in short intervals as this would reduce the lamp’s life.
During the initial start-up some smoke or smell may arise. This is a normal process and does not necessarily
mean that the device is defective.
Do not touch the device’s housing bare hands during its operation (housing becomes hot)!
For replacement use lamps and fuses of same type and rating only.
CAUTION ! EYEDAMAGES !
Avoid looking directly into the light source
(meant especially for epileptics) !

4
2.Operating determinations
This device is a moving-head for creating decorative effects and was designed for indoor use only.
If the device has been exposed to drastic temperature uctuation (e.g. after transportation), do not switch it on
immediately. The arising condensation water might damage your device. Leave the device switched off until
it has reached room temperature.
Never run the device without lamp!
Do not shake the device. Avoid brute force when installing or operating the device.
Never lift the xture by holding it at the projector-head, as the mechanics may be damaged. Always hold the
xture at the transport handles.
When choosing the installation-spot, please make sure that the device is not exposed to extreme heat, moisture
or dust. There should not be any cables lying around. You endanger your own and the safety of others!
The minimum distance between light output and the illuminated surface must be more than 2 meters.
Make sure that the area below the installation place is blocked when rigging, derigging or servicing the x-
ture.
Always x the xture with an appropriate safety rope. Fix the safety rope at the correct holes only.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fas-
tened.
The lamp must never be ignited if the objective-lens or any housing-cover is open, as discharge lamps may
explose and emit a high ultraviolet radiation, which may cause burns.
The maximum ambient temperature 40°C must never be exceeded. Otherwise, the lamp is switched off and
the xture is out of operation for 5 minutes.
CAUTION!
The lens has to be replaced when it is obviously damaged,
so that its function is impaired, e. g. due to cracks or deep scratches!
Operate the device only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the device. Most damages are the result of unprofessional operation!
CAUTION!
The lamp has to be replaced when it is damaged
or deformed due to the heat!
Please use the original packaging if the device is to be transported.
Please consider that unauthorized modications on the device are forbidden due to safety reasons!
If this device will be operated in any way different to the one described in this manual, the product may suffer
damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like short-
circuit, burns, electric shock, burns due to ultraviolet radiation, lamp explosion, crash etc.

5
3. Description of the device
1- Front lens
2- Moving head
3 - Yoke
4 - Base
Rear panel of the base:
1- 5-pin DMX output
2- 5-pin DMX input
3- 3-pin DMX output
4 - 3-pin DMX input
5 - Ethernet input
6 - Power switch
7 - Fuse holder-live
8 - Fuse holder-neutral
9 - Power cord
Front panel of the base:
1- Ethernet indicator
2- Display
3- Infra-red sensor
4- Data transfer indicator
5 - RNS control wheel
6 - Escape button
7 - Enter button

6
4. Installation
4.1Fitting the lamp
DANGER !
Install the lamps with the device switched off only.
Unplug from mains before !
To insert the lamp loosen the lamp cover at the rear of head (see the drawings ) by remowing the 3 fastening
screws which are marked "X,Y,Z".Carefully pull out the cover with the lamp socket assembly.If changing the
lamp, remove the old lamp from the socket. Insert the lamp to the socket.
Do not install a lamp with a higher wattage! A lamp like this generates temperatures the device is not de-
signed for.Damages caused by non-observance are not subject to warranty. Please follow the lamp manu-
facturer‘s notes!Do not touch the glass-bulb with bare hands during the installation! Make sure that the lamp
is installed tightly into the lampholder system.
Reclose the lamp cover and tighten the 3 screws.
Before striking the lamp, reset the "Lamp on Time "and "Lamp Strikes" counters s in the menu of the control
board.
Do not operate this xture with opened housing-cover!
4.2 Lamp adjustment
The ColorWash 575E AT lamp holder is aligned at the factory. Due to differences between lamps, ne adjust-
ment may improve light performance.
Strike the lamp,open the shutter and set the dimmer intensity onto 100% and aim the light on a at surface
(wall).Center a hot-spot(the brightest part of the image) by using the 3 adjustment screws "A,B,C".Turn one
screw after another a quarter-turn clokwise(counter-clokwise) to set the hot-spot in the center of the image.If
you cannot detect the hot-spot,adjust the lamp until the light is evenly distributed.
3 fastening screws "X,Y,Z"
Lamp cover
Lamp cover

7
4.3 Inserting/Exchanging colours
DANGER!
Install the colours with the device switched off only.
Unplug from mains before!
If you wish to change colours ,open the top cover of the head by loosening 4 quarter-turn fasteners on the top
cover.
Gently bend out the colour module to release it from the 3 distance slots and eject it from the pressing snap.
Put the new colour module back under the pressing snap and push it to the distance slots.
4.4 Installing top hats
The ColorWash 575E AT can be tted with various types of the top hats-see chapter "Technical specications".
If you wish to install a top hat (optional),follow the instructions:
Switch the device off before installing the top hat!
Installing the top hat on the front lens-holder of the xture:
1.Loosen 4 lens holder quarter-turn screws and hook both securing springs to the plastic projections in the front
lens-holder.Tighten the 4 lens holder quarter-turn screws again.
2.Put desired top hat onto a front lens-holder and fasten it by two fastening screws.
3.Snap both springs to the slots in the top hat.
3 adjustment screws "A,B,C"
colour-module
pressing snap
Slot
Securing spring
Plastic projection
Securing spring
Top hat
Fastening screw
Fastening screw
Lens-holder

8
4.5 Changing the front and zoom lenses
The ColorWash 575E AT is supplied with one type of the front lense(Fresnel lens) and one type of the zoom
lens(standard zoom lens). If you wish to extend the zoom range,you may need an optional module of wide-angle
lens D114 or a module of front wide-angle lens D200:
Front lens Zoom lens Beam angle
Standard Fresnel lens Without zoom lens 8°
Standard Fresnel lens Standard zoom lens 12°-34°
Standard Fresnel lens Wide-angle lens D114 24°-60°
Wide-angle lens D200 Without zoom lens 87°
Switch the device off before changing the lens.Be careful.Front lens is heavy!
Changing the font Fresnel lens:
1.Remove the front lens module using a athead screwdriver to unlock the four quarter-turn screws.
2.Unscrew the safety cabel from the lens holder
3.Screw up the safety cable to the module of front wide-angle lens D200.
4.Place the module and x it by locking the four quarter-turn screws.
Changing/removing the standard zoom lens:
1.Remove the front lens using a athead screwdriver to unlock the four quarter-turn screws.
2.Unscrew 2 lens xative screws and push out the standard zoom lens from the lens holder.
3.If you want to install the module of wide-angle lens D114,put it in to the lens holder and tighten
the 2 lens xative screws.
4.Place the front lens and fasten it by locking the four quarter-turn screws.
Quarter-turn screws
Quarter-turn
screws
Nut
Bolt
Securing cable
Quarter-turn screws
Quarter-turn screws
Standard zoom lens screws
Lens xative screws

9
4.6 Connection to the mains
Verify the power supply settings before applying power!
If you wish to change the power supply settings,see the chapter below.
Connect the xture to the mains with the power cord.
If the plug on the exible cord is not the right type for your socket outlets,do not use an adaptor,but remove the
plug from the cord and discard.Carefully prepare the end of the the supply cord and t a suitable plug.
The earth has to be connected!
Do not connect the xture to a dimmer system!
Cord plug connections:
Cable (EU) Cable (US) Pin International
Brown Black Live L
Light blue White Neutral N
Yellow/Green Green Earth
4.7 Changing the power supply settings
Electronic ballast
The operating range of the electronic ballast is 90 VAC-250 VAC,50-60Hz.The transformer has to be set to
the local AC voltage.
If you want to change the power supply settings,follow the instructions:
1.Disconnect the xture from AC power.
2.Remove the both top base covers by loosening the 12 screws.
3.Move the wire (3) on the transformer connection block to the position according to the desired voltage.
5.Close the xture base before applying AC power.
Example:

10
4.8 Rigging the xture
DANGER TO LIFE!
Please consider the respective national norms during the installation!
The installation must only be carried out by an authorized dealer!
The installation of the projector has to be built and constructed in a way that it can hold 10 times the weight for
1 hour without any harming deformation.
The installation must always be secured with a secondary safety attachment, e.g. an appropriate catch net.
This secondary safety attachment must be constructed in a way that no part of the installation can fall down if
the main attachment fails.
When rigging, derigging or servicing the xture staying in the area below the installation place, on bridges,
under high working places and other endangered areas is forbidden.
The operator has to make sure that safety-relating and machine-technical installations are approved by an expert
before taking into operation for the rst time and after changes before taking into operation another time.
The operator has to make sure that safety-relating and machine-technical installations are approved by an
expert after every four year in the course of an acceptance test.
The operator has to make sure that safety-relating and machine-technical installations are approved by a skilled
person once a year.
The projector should be installed outside areas where persons may walk by or be seated.
IMPORTANT! OVERHEAD RIGGING REQUIRES EXTENSIVE EXPERIENCE, including (but not limited to)
calculating working load limits, installation material being used, and periodic safety inspection of all installation
material and the projector. If you lack these qualications, do not attempt the installation yourself, but instead use
a professional structural rigger. Improper installation can result in bodily injury and.or damage to property.
The projector has to be installed out of the reach of people.
If the projector shall be lowered from the ceiling or high joists, professional trussing systems have to be used.
The projector must never be xed swinging freely in the room.
Caution: Projectors may cause severe injuries when crashing down! If you have doubts concerning the safety
of a possible installation, do NOT install the projector!
Before rigging make sure that the installation area can hold a minimum point load of 10 times the projector’s
weight.
Danger of re !
When installing the device, make sure there is no highly inammable
material (decoration articles, etc.) in a distance of min. 0.7 m.
CAUTION!
Use 2 appropriate clamps to rig the xture on the truss.
Follow the instructions mentioned at the bottom of the base.
Make sure that the device is xed properly! Ensure that the
structure (truss)to which you are attaching the xtures is secure.
The projector can be placed directly on the stage oor or rigged in any orientation on a truss without altering
its operation characteristics .

11
For overhead use, always install a safety-rope that can hold at least 10 times the weight of the xture. You must
only use safety-ropes with screw-on carabines. Pull the safety-rope through the two apertures on the bottom of
the base and over the trussing system etc. Insert the end in the carabine and tighten the xation screw.
Fixation via the omega holders
1.Bolt each clamp (1) to the omega holder (4) with M12 bolt and lock nut through the hole in the holder.
2.Fasten the omega holders on the bottom of the base by inserting both quick-lock fasteners (3) into the holes
of the base and tighten fully clockwise.
3.Fasten the safety-rope (2) through the two apertures on the bottom of the base and over the trussing sys-
tem.
When installing xtures side-by-side,
avoid illuminating one xture with another!
DANGER TO LIFE!
Before taking into operation for the rst time,the installation has to be ap-
proved by an expert!
1-Clamp
2-Safety-rope
3-Quick-lock fastener
4-Omega holder

12
4.9 DMX-512 connection
The xture is equipped with both 3-pin and 5-pin XLR sockets for DMX input and output.The sockets are wired
in
parallel.
Only use a shielded twisted-pair cable designed for RS-485 and 3-pin or 5-pin XLR-plugs and connectors in
order to connect the controller with the xture or one xture with another.
DMX - output DMX-input
XLR mounting-sockets (rear view): XLR mounting-plugs (rear view):
If you are using the standard DMX controllers, you can connect the DMX output of the controller directly with
the DMX input of the rst xture in the DMX-chain. If you wish to connect DMX-controllers with other XLR-out-
puts, you need to use adapter-cables.
Building a serial DMX-chain:
Connect the DMX-output of the rst xture in the DMX-chain with the DMX-input of the next xture. Always
connect one output with the input of the next xture until all xtures are connected.
Caution: At the last xture, the DMX-cable has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into a 3-pin XLR-plug and plug it in the DMX-output of the last xture.
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected
1- Shield
2 - Signal (-)
3 - Signal (+)
4 - Not connected
5 - Not connected

13
4.10 Ethernet connection
The xtures on a data link are connected to the Ethernet with Art-Net communication protocol.The controlling
software from PC (or lighting console) has to support Art-Net protocol.
Art-Net communication protocol is a 10 Base T Ethernet protocol based on the TCP/IP.Its purpose is to allow
transfer of large amounts of DMX 512 data over a wide area using standard network technology.
IP address is the Internet protocol address.The IP uniquely identies any node (xture) on a network.
The Universe is a single DMX 512 frame of 512 channels.
The ColorWash 575E AT is equipped with 8-pin RJ- 45 socket for Ethernet input.Use a network cable category
5 (with four “twisted” wire pairs) and standard RJ-45 plugs in order to connect the xture to the network.
RJ-45 socket (front view): RJ-45 plug (front view):
1- TD+ 5- Not connected
2- TD- 6- RX-
3- RX+ 7- Not connected
4- Not connected 8- Not connected
Patch cables that connect xtures to the hubs or LAN sockets are wired 1:1,that is,pins with the same numbers
are connected together:
1-1 2-2 3-3 4-4 5-5 6-6 7-7 8-8
If only the xture and the computer are to be interconnected,no hubs or other active components are needed.A
cross-cable has to be used:
1-3 2-6 3-1 4-8 5-7 6-2 7-5 8-4
Direct Ethernet operation
Connect the Ethernet-inputs of all xtures in the xture chain with the network.
Option “ Ethernet” has to be selected from “Set Ethernet Mode” menu on the xture.
Set IP address (002.xxx.xxx.xxx / 010.xxx.xxx.xxx) and the Universe.
Example:
(DMX address=49) (DMX address=25) (DMX address=1)
IP addres=002.168.002.004 IP addres=002.168.002.003 IP addres=002.168.002.002
Universe=1 Universe=1 Universe=1
An advised PC setting: IP address: 002.xxx.xxx.xxx / 010.xxx.xxx.xxx (Different from xture IP addresses)
NET mask: 255.0.0.0

14
Ethernet / DMX operation
Options “Ethernet/DMX” has to be selected from “Set Ethernet Mode” menu on the rst xture (connected to
the network) in the xture chain,next xtures have standard DMX addresses.
Connect the Ethernet-input of the rst xture in the data chain with the network. Connect the DMX output of
this xture with the input of the next xture until all xtures are connected to the DMX chain.
Caution: At the last xture, the DMX chain has to be terminated with a terminator. Solder a 120 Ωresistor
between Signal (–) and Signal (+) into a XLR-plug and connect it in the DMX-output of the last xture.
Example:
DMX address=73 DMX address=25 (DMX address=1)
IP addres=002.168.002.002
Universe=0
DMX address=217 DMX address=25 (DMX address=1)
IP addres=002.168.002.003
Universe=1

15
5. ColorWash 575E AT-DMX Protocol-version 1.0
Mode/Channel Value Function Type of
control
1 2 3 4
1 1 1 1 0 - 255 Pan
Pan movement by 530° proportional
2 2 2 2 0 - 255 Pan Fine
Fine control of pan movement proportional
3 3 3 3 0 - 255 Tilt
Tilt movement by 280° proportional
4 4 4 4 0 - 255 Tilt ne
Fine control of tilt movement proportional
5 5 5 5
0
1 - 255
1 - 255
Pan/Tilt speed , Pan/Tilt time
Max. speed (tracking mode)
P./T. speed-set Speed Mode in menu: Pan/Tilt Mode
Speed from max. to min. (vector mode)
P./T. time - set Time Mode in menu: Pan/Tilt Mode
Time from 0,1 s to 25,5 s. *
step
proportional
proportional
6 6 6 6
0 - 49
50 - 59
60 - 69
70 - 79
80 - 89
90 - 99
100 - 109
110 - 129
130 - 139
140 - 149
150 - 159
160 - 169
170 - 179
180 - 189
190 - 199
200 - 209
210 - 229
230 - 239
240 - 255
Power/Special functions
Reserved
To activate following functions, stop in DMX value for at
least 3 s and shutter must be closed at least 3 s. („Shut-
ter,Strobe” channel 20 (17,22,19) must be at range: 0-31
DMX).**
Pan/Tilt speed mode
Pan/Tilt time mode
Blackout while pan/tilt moving
Disabled blackout while pan/tilt moving
Blackout while colour wheel moving
Disabled blackout while colour wheel moving
Reserved
To activate following functions,
stop in DMX value for at least 3 s.
Lamp On,reset(total reset except pan/tilt reset)
Pan/Tilt reset
Colour system reset
Reserved
Dimmer/Strobe reset
Zoom/effect wheel reset
Reserved
Total reset
Reserved
Lamp Off
Reserved
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
7 7
0 - 9
10 - 31
32 - 63
64 - 95
96 - 127
128 - 159
160 - 191
192 - 223
224 - 255
Pan/Tilt macro selection
Disabled pan/tilt macro
Reserved
Figure of circle (from small to large)
Figure of horizontal eight (from small to large)
Figure of vertical eight (from small to large)
Figure of rectangle (from small to large)
Figure of triangle (from small to large)
Figure of star (from small to large)
Figure of cross (from small to large)
step
step
proportional
proportional
proportional
proportional
proportional
proportional
proportional
8 8 0
1 - 127
128 - 129
130 - 255
Pan/Tilt macro speed
(Set pan/tilt speed (channel 5) to 0)
No macro generation
Macro generation from fast to slow-forwards
No macro generation
Macro generation from slow to fast-backwards
step
proportional
step
proportional

16
Mode/Channel Value Function Type of
control
1 2 3 4
7 7 9 9
0
21
43
64
85
107
128-129
130-141
142-153
154-165
166-177
178-189
190 - 215
216 - 217
218 - 243
244 - 249
250 - 255
Colour wheel
Continual positioning
Open/white
Deep red
Deep blue
Green
6000K correction lter
UV lter
White
Positioning
Deep red
Deep blue
Green
6000K correction lter
UV lter
Forwards rainbow effect from fast to slow
No rotation
Backwards rainbow effect from slow to fast
Random colour selection by audio control
(Set microphone sensitivity in menu „Personality”)
Auto random colour selection from fast to slow
proportional
proportional
proportional
proportional
proportional
proportional
proportional
step
step
step
step
step
proportional
step
proportional
step
proportional
8 10 0 - 255
Colour wheel - ne positioning
Fine positioning proportional
9 8 11 10 0 - 255
Cyan
Cyan (0-white, 255-full cyan) proportional
10 9 12 11 0 - 255
Magenta
Magenta (0-white, 255-full magenta) proportional
11 10 13 12 0 - 255
Yellow
Yellow (0-white, 255-full yellow) proportional
12 11 14 13 0 - 255
Colour temperature lter
(0-7200K, 255-3200K) proportional
13 12 15 14 0 - 255
Speed of CMY and conv.temp. lter
Speed from max. (0) to min.(255) proportional
14 13 16 15
0 - 7
8 - 15
16 -23
24-31
32-39
40-47
48-55
56-63
64-71
72-79
80-87
88-95
96-103
104-111
112-119
120-127
128-135
136-143
144-151
152-159
160-167
168-175
176-183
CMY colour macros
No function
Macro 1
Macro 2
Macro 3
Macro 4
Macro 5
Macro 6
Macro 7
Macro 8
Macro 9
Macro 10
Macro 11
Macro 12
Macro 13
Macro 14
Macro 15
Macro 16
Macro 17
Macro 18
Macro 19
Macro 20
Macro 21
Macro 22
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step
step

17
Mode/Channel Value Function Type of
control
1 2 3 4
14 13 16 15
184-191
192-199
200 - 207
208 - 215
216 - 223
224 - 231
232 - 239
240 - 243
244 - 249
250 - 255
Macro 23
Macro 24
Macro 25
Macro 26
Macro 27
Macro 28
Macro 29
Macro 30 - Random rainbow effect from fast to slow
Random macro selection by audio control
(Set microphone sensitivity in menu "PErS")
Auto random macro selection from fast to slow
step
step
step
step
step
step
step
proportional
step
proportional
15 14 17 16
0-70
71-127
128-199
200-255
Effect wheel
Full beam
Beam shaper-Indexing
Beam shaper-Rotation
Frost lter
step
step
step
step
16 15 18 17
0 - 255
0
1 - 127
128 - 129
130 - 255
Beam shaper indexing and rotation
Shaper indexing - set position on channel15 (14,17,16)
Beam shaper indexing
Shaper rotation - set position on channel15 (14,17,16)
No rotation
Forwards shaper rotation from fast to slow
No rotation
Backwards shaper rotation from slow to fast
proportional
step
proportional
step
proportional
17 19
0 - 255
Beam shaper ne indexing
(set position on channel 16 (15,18,17))
Fine indexing propotional
18 16 20 18 0 - 255
Zoom
Coarse zoom from min. to max.beam angle proportional
19 21 0 - 255
Zoom ne
Fine zoom movement proportional
20 17 22 19
0 - 31
32 - 63
64 - 95
96 - 127
128 - 143
144 - 159
160 - 191
192 - 223
224 - 255
Shutter, strobe
Shutter closed, Lamp power reduced after 10 s to 400W
Shutter open, Full lamp power
Strobe-effect from slow to fast (max.15 ashes/s)
Shutter open, Lamp power reduced to 400 W
Opening pulse in sequences from slow to fast
Closing pulse in sequences from fast to slow
Shutter open, Electronic strobing „ZAP” from slow to fast
(from 7 to 33 ashes/s)
Random strobe-effect from slow to fast
Shutter open, Full lamp power
step
step
proportional
step
proportional
proportional
step
proportional
step
21 18 23 20 0 - 255
Dimmer intensity
Dimmer intensity from 0% to 100%
(In range of 0-8 DMX,lamp power reduced to 400W)
proportional
22 24 0 - 255
Fine dimmer intensity
Dimmer intensity ne proportional
Notes: * Short times are not used for long tracks (e.g. 0.5s for track 0-255 DMX). Times are restricted by
the me chanical parameters of the xture.
** The switch-functions have priority to the equivalent functions in menu "Personality"but the setting
by DMX is not saved to the memory( after switching the xture on,the setting from menu "Personal
ity" is loaded and after that can by changed with DMX value on the channel 6).
DMX protocol menu "Personality"
50-59 Pan/Tilt speed mode Pan/Tilt mode--->Speed Mode
60-69 Pan/Tilt time mode Pan/Tilt mode--->Time Mode
70-79 Blackout while pan/tilt moving Active blackout While-->Pan/Tilt Moving-->On
80-89 Disabled blackout while pan/tilt moving Active blackout While-->Pan/Tilt Moving-->Off
90-99 Blackout while colour wheel moving Active blackout While-->Colour Wheel Moving-->On
100-109 Disabled blackout while col. wheel mov. Active blackout While-->Colour Wheel Moving-->Off

18
6. Controller mode
The xtures are individually addressed on a data link and connected to the controller.The xtures respond to
the DMX signal from the controller.
6.1 DMX addressing
The control panel on the front panel of the xture allows you to assign the DMX xture address, which is dened
as the rst channel from which the ColorWash 575E AT will respond to the controller.
If you set, for example, the address to channel 23, the ColorWash 575E AT will use the channel 23 to 44 for
control (if mode 1 is selected).
Please, be sure that you don’t have any overlapping channels in order to control each ColorWash 575E AT
correctly and independently from any other xture on the DMX data link.
If two, three or more ColorWash 575E AT are addressed similarly, they will work similarly.
For address setting, please refer to the instructions under "Fixture Address".
Controlling:
After having addressed all ColorWash 575E AT , you may now start operating these via your lighting control-
ler.
Note:After switching it on, the ColorWash 575E AT will automatically detect whether DMX 512 data is received
or not.If there is no data received at the DMX-input, the display will start to ash "A001" with actually set ad-
dress.
This situation can occur if:
- the 3 PIN (5pin) XLR plug (cable with DMX signal from controller) is not connected with the input of the Color-
Wash 575E AT
- the controller is switched off or defective, the cable or connector is defective or the signal wires are swap in
the input connector.
Note:It’s necessary to insert the XLR termination plug (with 120 Ohm) to the last xture in the link in order to
ensure proper transmission on the DMX data link.
6.2 Remotely controllable functions
Lamp
The ColorWash 575E AT is to be operated with a Philips MSR 575/2 lamp.
A relay inside of the ColorWash 575E AT allows you to switch on and off the lamp via the control panel or via
your DMX-controller without affecting the rest of the lighting.
To switch On/Off the lamp, please refer to "Lamp On/Off ".
Note:It is also important to note, that the discharge lamp is cold restrike types, that means, that they have to be
cold before re-striking. For this reason, you have to wait 5 minutes (max. speed of fan must be adjusted) after
having switched Off the lamp before you can switch it back On again. If you try to switch On the lamp within 5
minutes after having switched it Off, the ColorWash 575E AT will store this information and automatically ignite
the lamp when the 5 minutes period has expired.If the ignition of the lamp is seven times unsuccessful, on the
display will appear "Lamp Error", meaning that the lamp could be damaged or even missed, or there could
be a failure on the ignitor or ballast.
Colour wheel
This wheel contains 5 replaceable 'SLOT&LOCK' dichroic lters + open.The colour-wheel can be positioned
between two adjacent colours in any position. It is also possible to rotate the colour wheel continuously at dif-
ferent speeds ("Rainbow effect“ in both directions).
Effect wheel
This wheel contains a frost lter and a rotating indexable beam shaper.
Zoom
Motorized zoom unit enables zoom between 12° and 34° beam angle.
Dimmer/Shutter/Strobe
Smooth 0 - 100 % dimming is provided by the combined mechanical dimmer/shutter unit. This unit may also
be used for strobe effect.

19
7.Control menu map
Default settings=Bold print
Default settings=Bold print
Fixture Address
DMX Address
001
:
512
Ethernet Settings
Set Ethernet Mode
Disable Ethernet
Ethernet
Ethernet/DMX
Set IP Address
Default IP Address
Custom IP Address
Set ArtNet Universe (0 -255)
Fixture information
Power On Time
Total Hours
Resetable Hours
Lamp On Time
Total Hours
Resetable Hours
Lamp Strikes
Total Hours
Resetable Hours
Fixture Temperatures
Current
Board Temp. [°C]
Head Temp.[°C]
Maximum Nonresetable
Board Temp. [°C]
Head Temp.[°C]
Maximum Resetable
Board Temp. [°C]
Head Temp.[°C]
DMX Values
Pan (0-255)
:
Dimmer Fine (0-255)
Software Version
IC1 B.
IC2 B.
IC3 B.
IC4 B.
IC1 L.
:
IC1 DS
IC2 DS
Product IDs
Mac Adr.
RDM UID

20
Personality
User Mode
User A Settings
User B Settings
User C Settings
DMX Presetting
Mode 1
Ch.1 Pan
:
Ch.22 Dimmer Fine
Set Active
Mode 2
Ch.1 Pan
:
Ch.18 Dimmer
Set Active
Mode 3
Ch.1 Pan
:
Ch.24 Dimmer Fine
Set Active
Mode 4
Ch.1 Pan
:
Ch.20 Dimmer
Set Active
Pan Reverse (On,Off)
Tilt Reverse (On,Off)
Lamp Presetting
Lamp On/Power On (On,Off)
Lamp Off via DMX (On,Off)
Lamp On if DMX Present (On,Off)
Lamp Off if not DMX (On,Off)
Lamp Ignition delay(0..1..90)s
Lamp Low Power Delay (10s-600s)
Lamp Light Sensor (On,Off)
Display Adjusting
Display Permanent On (On,Off)
Display Intensity (1..10)
Display Backlight (1..5..10)
Display Turned (On,Off)
Blackout d.M.C. (On,Off)
Pan/Tilt Feedback (On,Off)
Microphone Sensitivity (1..10..20)
Fan Modes
Auto Cooling
High Cooling
Pan/Tilt mode (Time mode,Speed Mode)
Active Blackout While:
Pan/Tilt Moving (On,Off)
Colour Wheels Moving (On,Off)
IR Sensor (On,Off)
Init Effect Positions
Pan (0-225)
:
Dimmer (0-255)
Dimmer ne (0-255)
Save
Default Setting
