Quality in Any LanguageTM
n Reduce dirt build-up on burners and
extend life of heat exchanger with
separated combustion units.
n Installation and operation exibilty
with rear or top air and ue connections
(Models UHA 30 - 125 only).
n Ideal for smaller spaces with low prole
design (Models UHA 30 - 125 only).
n Reliable ignition with direct spark
ignition burners.
n Minimize summer heat build-up
with remote fan operation.
n Longer life and less maintenance with
optional stainless steel heat exchangers.
n Variable air throw direction with adjustable
horizontal louvers and optional adjustable
vertical louvers.
UHA Models 150 - 400
t
UHA Models 30 - 125
t
Combat®UHA - Series
Axial Fan Tubular Unit Heaters
1.800.828.7450

Dimension Data - Low-Prole UHA Range (Models 30 - 125)
Model 30 45 60 75 100 125
'A' Height [in] 12 12 17.75 17.75 23 23
'C' Center of Flue [Top Option] [in] 5.2 5.2 5.2 5.2 6.9 6.9
'D' Center of Flue [in] 2.5 2.5 2.5 2.5 2.5 2.5
Recommended Mounting
Height to Heater Base [ft] 10 10 12 12 20 20
Clearances to Combustibles - Low Prole UHA Range (Models 30 - 125)
Above Heater
1"
Below Heater
0"
To Side of Heater
1"
To Rear of Heater
18" Airow Clearance
To Front of Heater
118"
Access Side Door
18" Access Clearance
To Flue
2"







 






















Combat®UHA 30 - UHA 125 Clearance and Dimension Data

Dimension Data - Standard UHA Range (Models 150 - 400)
Model 150 175 200 225 250 300 350 400
'A' Width [in] 43 43 43 43 43 50 50 50
'B' Height [in] 27 27 35.25 35.25 35.25 43.5 43.5 43.5
'C' Depth [in] 30 30 32 32 32 30 30 30
'D' Support Spacing [in] 17.6 17.6 17.6 17.6 17.6 24.7 24.7 24.7
'F' Center of Flue [in] 9.5 9.5 17 17 17 13.6 13.6 13.6
'G' Flue Center to Air Intake Center [in] 6 6 6 6 6 7 7 7
'H' Position of Flue [in] 4.5 4.5 4.75 4.75 4.75 4.9 4.9 4.9
'J' Gas Inlet Position [in] 5.9 5.9 5.9 5.9 5.9 8.7 8.7 8.7
'K' Electrical Supply Position [in] 3.4 3.4 3.4 3.4 3.4 6.2 6.2 6.2
Maximum Recommended
Mounting Height to Heater Base [ft] 20 20 25 25 25 30 30 30
Clearances to Combustibles - Standard UHA Range (Models 150 - 400)
Above Heater
6"
Below Heater
3"
To Side of Heater
6"
To Rear of Heater
24" Airow Clearance
To Front of Heater
118"
Access Side Door
31" Access Clearance
To Flue
2"







 





















Combat®UHA 150 - UHA 400 Clearance and Dimension Data

Model 30 45 60 75 100 125 150 175 200 225 250 300 350 400
Total Input [Btu/h] x [1000] 30 45 60 75 100 125 150 175 200 225 250 300 350 385
Total Output [Btu/h] x [1000] 24.6 36.9 49.2 61.5 82 102.5 123 143.5 164 184.5 205 246 288.6 315.7
Eciency 82% - All Models
Number of Burners 2 3 4 5 6 7 7 8 9 10 11 12 14 14
Gas Connection [in] 3
/83 /8½½½½½½½¾¾¾¾¾
Inlet Pressure [in wc] NG Min. 5 - All Models
LPG Propane Min. 12 - All Models
NG & LP Propane Max. 14 - All Models
Electrical Supply 115 V / 60 Hz / 1 Ø - All Models
Full Load Amps @ 115 V 3.0 3.0 4.1 4.1 5.8 5.8 7.1 7.1 10.6 10.6 10.6 11.6 11.6 11.6
Air Volume [CFM] 691 691 1376 1376 1902 1902 2245 2245 3716 3716 3716 4663 4663 4663
Recommended Maximum
Mounting Height [ft] 12 12 15 15 20 20 20 20 25 25 25 30 30 30
Number of Axial Fans 11111111111222
Axial Fan Diameter [in] 10 10 16 16 16 16 16 16 19.7 19.7 19.7 16 16 16
Horsepower .06 .06 .08 .08 .2 .2 .2 .2 .3 .3 .3 .4 .4 .4
Fan Motor Amps @ 115 V 1.8 1.8 2.6 2.6 4.3 4.3 4.3 4.3 4.7 4.7 4.7 8.6 8.6 8.6
Fan Motor RPM 1630 1630 1030 1030 1175 1175 1200 1200 1085 1085 1100 1155 1155 1155
Fan Motor Type SP SP SP SP PSC PSC PSC PSC PSC PSC PSC PSC PSC PSC
Flue Size [in] 4 - All Models
Combustion Air Size [in] 44444444444555
Weight [lb] 65 70 85 90 105 110 205 225 255 265 270 355 375 375
Printed in U.S.A. UHASNA 5M 1106 Rev. A
Roberts-Gordon, LLC
1250 William Street
P.O. Box 44
Bualo, NY 14240-0044 USA
Telephone: [phone]
Fax: [phone]
Toll Free: 800.828.7450
www.rg-inc.com
European Oce:
Roberts Gordon Europe Limited
Telephone: [phone]
Fax: [phone]
Important Notice
The equipment described in this Data Sheet is suitable for most commercial and industrial heating applications. However, in certain environments,
particularly where there is a chlorinated atmosphere (e.g. near degreasing plant or other solvent processes) or a particularly dusty atmosphere, specialist
advice should be sought at the design stage. Roberts-Gordon reserves the right to alter product specification details without notice.
Installation Code and Annual Inspections:
All installations and service of ROBERTS GORDON®products must be performed by a contractor qualified in the installation and service of products sold
and supplied by Roberts-Gordon and conform to all requirements set forth in the ROBERTS GORDON®manuals and all applicable governmental authorities
pertaining to the installation, service and operation of the equipment. To help facilitate optimum performance and safety, Roberts-Gordon recommends that a
qualified contractor annually inspect your ROBERTS GORDON®products and perform service where necessary, using only replacement parts sold and sup-
plied by Roberts-Gordon, LLC.
Further Information: Applications, engineering and detailed guidance on systems design, installation and product performance is available through
ROBERTS GORDON®representatives. Please contact us for any further information you may require, including the Installation, Operation and Service Manual.
This product is not for residential use.
This document is intended to assist licensed professionals in the exercise of their professional judgement.
© 2006 Roberts-Gordon, LLC All rights reserved. No part of this work covered by the copyrights herein may be reproduced or copied in any form or by any means
– graphic, electronic, or mechanical, including photocopying, recording, taping, or information storage and retrieval systems – without written
permission of Roberts-Gordon, LLC.
Combat®UHA-Series Technical Data
