Roborock G10
Read this user manual carefully before using this product and
store it properly for future reference.
Robotic Vacuum Cleaner User Manual

02
Contents
03 Safety Information
04 Product Overview
07 Installation
09 Instructions for Use
11 Routine Maintenance
15 Basic parameters
16 Errors
17 Common Issues
19 EU Declaration of Conformity
19 WEEE Information
19 Warranty Information

03
Restrictions
•This product is designed for indoor floor cleaning only, do not use it
outdoors (such as on an open-ended terrace), on any surface other than
the ground (such as a sofa), or in any commercial or industrial environment.
•Do not use this product on elevated surfaces without barriers such as the
floor of a loft, an open-ended terrace, or on top of furniture.
•Do not use the product when the ambient temperature is higher than 40°C
(104°F), lower than 4°C (39°F).
•Before using the product, move wires off the ground or place them to the
side to prevent them being pulled on by the cleaner.
•To prevent blocking the product and to avoid damage to valuables, remove
lightweight items (such as plastic bags) and fragile objects (such as vases)
from the floor before cleaning.
•Children should be supervised to ensure that they do not play with the
appliance.
•This product is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the product by a person responsible for their safety (CB).
•This product can be used by children aged from 8 years and above and
persons with reduced physical, sensory or mental capabilities or lack
of experience and knowledge if they have been given supervision or
instruction concerning use of the product in a safe way and understand
the hazards involved. Children shall not play with the product. Cleaning and
user maintenance shall not be made by children without supervision (EU).
•Do not place any object (including children and pets) on the product,
whether it is in operation or not.
•Keep hair, loose clothing, fingers, and all parts of the body away from
openings and moving parts.
•Do not use the product on burning objects (such as cigarette butts).
•Do not use the product on high pile carpets (product effectiveness may
also be reduced on dark carpets).
•Do not use the product to clean hard or sharp objects (such as decoration
wastes, glass and nails).
Safety Information •Do not carry the product using the vertical bumper, upper cover or bumper.
•The product must be switched off and the plug must be removed from
socket outlet before cleaning or maintaining the product.
•Do not use wet cloth or liquids for cleaning the product.
•This product contains batteries that are only replaceable by skilled persons.
•Do not operate the product in a room where an infant or child is sleeping.
•Do not charge non-rechargeable batteries.
•For the purposes of recharging the battery, only use the detachable supply
unit roborock WFD01HRR, EWFD01HRR or EWFD02HRR provided with this
product.
•Do not dismantle, repair or modify the battery or charging dock.
•Keep the charging dock away from heat (such as radiators).
•Do not wipe the charging contacts with wet cloth or wet hands.
•If the power cord is damaged, stop using it immediately. It must be
replaced by the manufacturer, its service agent, or similarly qualified
persons to avoid a hazard.
•Make sure the product is powered off before shipment.
•Use of the original packaging is advised.
•If placing the robot into storage, charge it fully and turn it off before placing
it in a cool dry place. Recharge it at least every three months to prevent the
battery over discharging.
•To satisfy RF exposure requirements, a separation distance of 20 cm or
more should be maintained between this device and persons during device
operation. To ensure compliance, operations at closer than this distance is
not recommended.
•The antenna used for this transmitter must not be co-located in
conjunction with any other antenna or transmitter.
•Only use the power cable provided with the product to prevent potential
smoke, heat or fire.
•Do not use the product with any type of power adapter, as this may cause
danger and void the warranty.
•If the dock is placed in an area susceptible to thunderstorms or with
unstable voltage, take protection measures.
•Unplug the power cable before placing the dock into storage.
Battery and Charging
WARNING

04
Accessories
Power Cable
Dock
Press any button to stop the robot during operation.Note:
•Press to start spot cleaning
•Press and hold for 3 seconds to
turn the child lock on or off
•Press to return to dock
•Press and hold to wash mop
•White: Battery level ≥ 20%
•Red: Battery level < 20%
•Breathing: Charging or starting up
•Flashing red: Error
Power Indicator
Spot Clean/Child Lock
Dock
Robot
•Press and hold to turn the
robot on or off
•Press to start cleaning
Power/Clean
Product Overview
Dock Base

05
Product Overview
Robot
WiFi Indicator
Reset Button
Bumper
Dustbin
Water Tank
Water Tank Latch
LiDAR Sensor
Air Outlet
Mop Wash Sensor
Vertical Bumper
VibraRise Module
Dock Locator
Omni-Directional
Wheel
Side Brush
Main Brush
Cliff Sensors
Main Brush
Cover Latches
Charging Contacts
Wall Sensor
Main Wheel
Positioning Button
Carpet Sensor

06
DustbinVibraRise Module
Product Overview
Filter Cover
Washable Filter
Cover Latch
Electric Water Tank
VibraRise Mop Mount
VibraRise Mop
Hook and
Loop Pads
Stopper
Water Tank Latch
Vibration Module
Self-Filling Port
Mop Attachment Slot
Water Filter
The VibraRise mop mount is non-detachable.Note:
Dock
Dock Back
Power Port
Cable Slot
Handle
Cable Outlet
Cable Outlet

07
Water Tank Latch
Top Cover
Dock
Water Filling Port
Clean Water Tank
Water Tank Handle
Dock Base
Dirty Water
Tank
•Pulsing: Mop washing
•Red: Dock error
•Light off: Charging/
Powered Off
Status Indicator Light
Dock Location
Beacon
Charging
Contacts
Water Filter
Product Overview
High-Speed
Maintenance Brush
Maintenance Brush
Components
Washing Strip
High-Speed
Maintenance
Brush Latch
Installation
Important Information
1. Tidy cables, hard or sharp objects (such as nails and glass), and
loose items from the ground and move any unstable, fragile,
precious, or dangerous items to prevent personal injury or
property damage due to items becoming tangled in, struck by,
or knocked over by the robot.
2. When using the robot in a raised area, always use a secure
physical barrier to prevent accidental falls that may result in
personal injury or property damage.
Note: When using the robot for the first time, follow it throughout its whole cleaning route
and watch for potential problems. The robot will be able to clean by itself in future uses.

Installation
Assembly
1. Place the dock on a hard and flat
surface, and remove the foam
used to secure the high-speed
maintenance brush components in
shipment at the bottom.
2. Attach the base by pressing down
both sides of the base firmly, and then
pressing the connecting part in the
middle until you hear a click.
3. Connect the power cable to the back
of the dock, and keep excess cable
inside the storage slot.
Step 1
Step 1
Step 2
Power cable can be pulled out at both sides.Note:
> 0.5 m (1.6 ft)
> 0.5 m (1.6 ft)
> 1 m (3.3 ft)
> 1.5 m (4.9 ft)
Placement of the Dock
Place the dock on a hard and flat floor (wood/tile/concrete etc.),
flat against a wall. Keep at least 0.5 m (1.6 ft) of clearance on
either side, 1.5 m (4.9 ft) in front, and 1 m (3 ft) above. Check the
location has good WiFi for a better experience with the mobile
app, and then plug it in.
Notes:
•If the power cable hangs vertically to the ground, it may be caught by the robot, causing
the dock to be moved or disconnected.
•The dock indicator is on when the dock is powered on, and off when the robot is charging.
•The dock indicator turns red if an error occurs.
•Place the dock on a flat floor away from fire, heat, and water. Avoid narrow spaces or
locations where the robot may be suspended in the air.
•Placing the dock on a soft surface (carpet/mat) may cause the dock to tilt over and cause
problems docking and departing.
•Keep the dock away from direct sunlight or anything that may block the dock location
beacon; otherwise, the robot may fail to return to the dock.
•Do not use the dock without clean water tank, dirty water tank, high-speed maintenance
brush, or water filter.
•Maintain the dock according to the maintenance instructions. Do not clean the dock with
a wet cloth or tissue.
•All docks are subject to water-based tests before leaving the factory. It is normal that a
small amount of water remains in the waterway of the dock.
Powering On & Charging
Press and hold the button to power
on the robot. When the power light
goes on, place the robot on the dock
to charge. Make sure the charging
dock power indicator turns off and
a “charging" voice alert sounds. To
maintain the performance of the high-
performance lithium-ion rechargeable
battery pack, keep the robot charged.
Note: The robot may not be turned on when the battery is low. In this case, connect the
robot to the dock.
Power
Indicator
Breathing:
Charging

09
Option 2: Search for "Xiaomi Home" in the
App Store or Google Play or scan the QR
code to download and install the app.
Instructions for Use
The robot supports the Roborock or Xiaomi Home app. Choose
the one that best meets your needs.
Option 1: Search for "Roborock" in the
App Store or Google Play or scan the QR
code to download and install the app.
1. Download App
Connecting to the App
1. Open the top cover and find the WiFi indicator.
2. Press and hold the and buttons until you hear the
"Resetting WiFi" voice alert. The reset is complete when the
WiFi indicator flashes slowly. The robot will then wait for a
connection.
2. Reset WiFi
•Off: WiFi disabled
•Flashing slowly: Waiting for
connection
•Flashing quickly: Connecting
•Steady: WiFi connected
WiFi Indicator
If the mobile phone fails to connect to the robot because your router configuration
changes or you forget your password or for any other reason, reset the WiFi and add the
robot again when it is waiting for a connection.
Note:
On the homepage of the app, tap "+" in the top right corner
and add the device according to the in-app guide.
Notes:
•The actual process may vary due to ongoing app updates. Follow the instructions provided
in the app.
•Only 2.4 GHz WiFi is supported.
•If the robot waits more than 1 hour for a connection, WiFi will be automatically disabled. If
you want to reconnect, reset the WiFi before proceeding.
3. Add Device
On/Off
Press and hold the button to turn on the robot. The power
indicator will turn on and the robot will enter standby mode.
Press and hold the button to turn off the robot and complete
the cleaning cycle.
Note: The robot cannot be turned off when it is being charged.
Notes:
•To prevent corrosion or damage, only use Roborock branded floor cleaner in the water tank.
•To avoid deformation, only use cold water.
•If any water stains remain on the outside of the water tank, wipe them with a soft dry cloth
before reinstalling the tank.
Filling the Clean Water Tank
Take out the clean water tank and remove the water filling port
cover. Add water below the Max line. Tighten the port cover
and fit the water tank back in place.
MAX

10
Instructions for Use
Starting Cleaning
Press the button to start cleaning. The robot will plan its
cleaning route according to its scan of the room. It splits a room
into zones, first draws out zone edges, and then fills the zone in
a zigzag pattern. In doing so, the robot cleans all zones one by
one, efficiently cleaning the house. During cleaning, the robot
automatically determines when it should wash the mop and fill
the water tank to maximize its washing performance.
Notes:
•To allow the robot to wash the mop automatically, start the robot from the dock once it is fully
charged. Do not move the dock during cleaning.
•Cleaning cannot start when the battery is low. Allow the robot to charge before starting cleanup.
•If cleaning is completed in less than 10 minutes, the area will be cleaned twice.
•If the battery runs low during the cleaning cycle, the robot will automatically return to the dock.
After charging, the robot will resume where it left off.
•Automatic mop washing will not work if the dock encounters an error during cleaning. Wash the
mop manually to restore.
•The robot will retract the mop mount to clean the carpet. You can also set the carpet as a No-Go
Zone in the app to avoid it.
•Before starting each mopping task, make sure that the VibraRise mop has been properly
installed.
Spot Cleaning
Press the button to start spot cleaning.
Cleaning range: The robot cleans a 1.5 m (4.9 ft) x 1.5 m (4.9 ft)
square area centered on itself.
Note: After spot cleaning, the robot will automatically return to the starting point and enter
Standby mode.
Pause
When the robot is running, press any button to pause it, press the
button to resume cleaning, press the button to send it back
to the dock, hold and press the button to wash the mop.
Note: Placing a paused robot on the dock manually will end the current cleanup.
Child Lock
Press and hold the button to enable/disable the child lock. You
can also set it in the app. Once enabled, the robot will not react to
button presses when it is stationary. When the robot is cleaning
or docking, press any button to stop it.
DND Mode
The default Do Not Disturb (DND) period is from 22:00 to 08:00.
You can use the app to disable the DND mode or modify the DND
period. When DND is on, the auto top-up is canceled, indicator
lights are dimmed, and voice alerts are quietened.
Sleep
If the robot is paused for over 10 minutes, it will go to sleep, and
the power indicator will flash every few seconds. Press any button
to wake the robot up.
Notes:
•The robot will not go to sleep when it is charging.
•The robot will automatically shut down if left in sleep mode for more than 12 hours.
Charging
After cleaning, the robot will automatically return to the dock to
charge.
In Pause mode, press the button to send the robot back to the
dock. The power indicator will pulse as the robot charges.
Note: If the robot fails to find the dock, it will automatically return to its starting location.
Place the robot on the dock manually to recharge.
Resetting
If the robot does not respond when a button is pressed or cannot
be turned off, reset the system. Press the Reset button, and the
robot will reset automatically.
Note: After resetting the system, scheduled cleaning, WiFi, etc. will be restored to factory
settings.

11
Instructions for Use
Error
If an error occurs, the power indicator will flash red and a voice
alert will sound. See “Errors” for solutions.
Notes:
•The robot will go to sleep automatically if left in a malfunctioning state for over 10 minutes.
•Placing a malfunctioning robot on the dock manually will end the current cleanup.
Restoring Factory Settings
If the robot does not function properly after a system reset, switch
it on. Press and hold the button and at the same time press
Reset button until you hear the “Restoring factory settings” voice
prompt. The robot will then be restored to factory settings.
Cleaning Map
Multi-Map Management｜ Real-time Vacuum and Mop Route｜
Carpet Display｜Map Zoning｜Map Editing
Custom Cleaning Modes
Scheduled｜Selective Room｜Zone｜No-Go Zones & Invisible
Walls｜Custom｜Carpet Boost｜Mop Wash Interval Settings
Note: Functions and details of the app may vary slightly due to the continuous app
development and updates.
Cleaning Mode Switch
Suction Power｜Washing Intensity｜Mop Washing Modes｜
Custom Modes
Robot Information
Cleaning History｜Battery Level｜Care & Maintenance
More Features
Firmware Update｜Volume Adjustment｜Language Selection｜
Do Not Disturb Mode｜Voice Assistant Support
App Features
Routine Maintenance
To ensure optimal performance of the robot, refer to the following
table for routine maintenance:
The frequency of replacement may vary depending on the situation. If abnormal wear
occurs, replace the parts immediately.
Note:
Parts Clean
Frequency
Replacement
Frequency
Omni-Directional Wheel As needed /
Dustbin As needed /
Water Tank As needed /
Main Brush Every two weeks Every 6-12 months
Side Brush Monthly Every 3-6 months
Washable Filter Every two weeks Every 6-12 months
VibraRise Mop After each use Every 3-6 months
Dock Locator Monthly /
Cliff Sensor Monthly /
Wall Sensor Monthly /
Carpet Sensor Monthly /
Main Wheel Monthly /
Charging Contacts Monthly /
Dock Charging Contacts,
Location Beacon, and Robot Body Monthly /
Water Filter As needed /
Clean Water Tank and Dirty Water Tank As needed /
High-Speed Maintenance Brush As needed Every 6-12 months

12
1. Turn over the robot and press the
latches to remove the main brush
cover.
Routine Maintenance
Main Brush
2. Pull out the main brush and remove
the main brush bearing.
Latches
Main Brush Caps
Main Brush Bearing
Main Brush Cover
Main Brush
3. Rotate the main brush caps in the
indicated unlock direction to remove
the caps. Clean the caps and reinstall
them in the indicated lock direction.
4. Clean caps and remove
entagled hair before
reinstalling in the indicated
lock direction.
Notes:
•Main brush should be wiped down with wet cloth and left to dry away from direct sunlight.
•Do not use corrosive cleaning fluid or disinfectant to clean the main brush.
5. Reinstall the main brush cover, making
sure that the four teeth are fully seated
in the slots before pressing the main
brush cover.
Side Brush
1. Unscrew the side brush screw.
2. Remove and clean the side brush.
Reinstall the brush and tighten the
screw.
1. Use a tool, such as a small
screwdriver, to pry out
the axle and take out the
wheel.
Omni-Directional Wheel
Note: The omni-directional wheel bracket cannot be removed.
2. Rinse the wheel and the axle with water to
remove any hair and dirt.
3. Air-dry, reinstall, and press the wheel and axle back in place.

13
Routine Maintenance
Clean the main wheel with a soft,
dry cloth.
Main Wheel
1. Remove the dustbin.
Dustbin
2. Open the dustbin cover
and empty the dustbin.
3. Fill the dustbin with clean
water and close the cover.
Gently shake the dustbin, and
then pour out the dirty water.
To prevent blockage, only use clean water without
any cleaning liquid.
Note:
4. Leave the dustbin and the washable filter to dry.
2. Rinse the filter repeatedly and tap it
to remove as much dirt as possible.
Washable Filter
1. Open the filter cover and remove
the filter.
3. Allow 24 hours for the filter to dry
thoroughly and reinstall it.
Notes:
•Make sure that the filter is completely dry before use.
•Purchase an additional filter and alternate if necessary.
Do not touch the surface of the filter with your hands, brush, or hard objects to avoid
potential damage.
Note:
VibraRise Mop
1. Remove the mop from the
mop mount.
2. Clean the mop and air-dry it.
3. Slide the mop cloth in from the
opening of the attachment slot
then stick it flat in place.
A dirty mop will affect the washing performance.
Clean it before use.
Note:

14
Routine Maintenance
Robot Sensors
Use a soft, dry cloth to wipe and clean all sensors, including:
1. The dock locator and charging contacts in the front.
2. The wall sensor on the right.
3. The carpet sensor and six cliff sensors on the bottom.
4. The mop wash sensor in the rear.
Carpet
Sensor
Six Cliff
Sensors
Dock Locator
Wall Sensor
Mop Wash Sensor
Charging
Contacts
Moving the Dock
To move the dock, grip the handle on the
back with one hand and the inner side of
the front board with the other hand, as
shown below. Do not grip the base as it is
not designed for lifting.
Notes:
•To prevent corrosion or damage, only use the Roborock
branded floor cleaner in the water tank.
•To avoid deformation, only use cold water.
•If any water stains remain on the outside of the water tank, wipe
them with a soft dry cloth before reinstalling the tank.
Dirty Water Tank
Clean the dirty water tank as needed.
Open the dirty water tank lid and pour
out the dirty water. Fill the tank with clean
water, close the lid, lock it, and shake.
Pour out the dirty water. Close the lid and
then re-install.
Charging Contact Areas
Use a soft, dry cloth to wipe the charging contacts on the dock.

15
Routine Maintenance
High-Speed Maintenance Brush
1. Lift the high-speed maintenance brush latch and remove the
brush, as shown below.
2. Remove any entangled objects in the high-speed maintenance
brush and rinse it clean. Reinstall the brush and latch it in place.
Water Filter
Unlock the water filter and remove it for washing. Use a soft, dry
cloth to wipe the cleaning tank, and then reinstall the filter. Press
down the filter until you hear it lock with a click.
Battery
The robot is equipped with a built-in high-performance lithium-ion
rechargeable battery pack. To maintain battery performance, keep
the robot charged during normal use.
Note: If the robot will be left unused for a long period, turn it off and charge it at least every
three months to avoid battery damage caused by over-discharge.
Basic parameters
Note: The serial number is on a sticker on the underside of the robot.
Model S300RR
Battery 14.4 V/5200 mAh lithium-ion battery
Rated Input 20VDC 1.8A
Charging Time < 6 hours
Name Wash and Fill Dock
Model WFD01HRR
Rated Input 100-240VAC 50-60Hz 0.8A
Rated Output 20VDC 1.8A
Charging Battery 14.4 V/5200mAh lithium-ion battery
Dock
Robot

16
Errors
If an error occurs while the robot is cleaning, the power indicator
will flash red quickly, and a voice alert will sound. Refer to the
following table for troubleshooting.
1. After resolving any of the following errors, relocate your robot
and restart cleaning.
2. After any sensor errors, clean the sensor and retry.
3. If the battery is at an abnormal temperature, wait for it to
return to normal before use.
If the problem persists after using the recommendations in the table above,
please email our after-sales service team:
Europe Support: [e-mail]
Australia Support: [e-mail]
Note: A system reset may resolve some problems.
Error 1: LiDAR turret or laser blocked. Check for obstruction
and retry.
Error 2: Bumper stuck. Clean it and lightly tap to release it.
Error 3: Wheels suspended. Move robot and restart.
Error 4: Cliff sensor error. Clean cliff sensors, move robot away
from drops and restart.
Error 5: Main brush jammed. Clean main brush and bearings.
Error 6: Side brush jammed. Remove and clean side brush.
Error 7: Wheels jammed. Move the robot and restart.
Error 8: Robot trapped. Clear obstacles surrounding robot.
Error 9: No dustbin. Install dustbin and filter.
Error 12: Low battery. Recharge and retry.
Error 13: Charging error. Clean charging contacts and retry.
Error 14: Battery error.
Error 15: Wall sensor dirty. Clean wall sensor.
Error 16: Robot tilted. Move to level ground and restart.
Error 17: Side brush error. Reset robot.
Error 18: Fan error. Reset robot.
Error 21: Vertical bumper pressed. Move robot and retry.
Error 22: Dock locator error. Clean and retry .
Error 23: Could not return to dock. Clean dock location beacon
and retry.
Error 27: VibraRise system jammed. Check for obstructions.
Error 28: Robot on carpet. Move robot to floor and retry.
Filter blocked or wet. Clean, dry, and retry.
No-go zone or Invisible Wall detected. Move robot from this area.
Cannot cross carpet. Move robot across carpet and restart.
Internal error. Reset the robot.

17
Common Issues
Problem Solution
Unable to power on
•Battery low. Put the robot on the dock and charge it before use.
•Battery temperature too low or too high. Only use the robot within the range of 0-40°C (32-
104°F).
Unable to charge
•Dock not connected to power: Check that both ends of the power cable are properly connected.
•Poor contact: Clean the charging contacts of the dock and the robot.
•Confirm that the dock indicator is on.
Slow charging speed
•To maintain the battery life, the robot automatically reduces the charging speed when it is
charged in an environment at a high or low temperature.
•Charging contacts dirty. Clean them with a dry cloth.
Unable to return to dock
•Too many obstacles near the dock. Move it to an open area.
•Robot too far from the dock. Place it closer and retry.
Abnormal behavior •Restart the robot.
Noise during cleaning
•The main brush, side brush, or main wheel may be jammed. Turn off the robot and clean them.
•The omni-directional wheel is jammed. Use a screwdriver to remove it for cleaning.
Poor cleaning performance and/
or leaking dust
•The dustbin is full and needs emptying.
•The filter is blocked and needs cleaning.
•The main brush is tangled up. Clean the main brush.
The robot cannot return to the
dock after spot cleaning or when
it has been moved manually
•After spot cleaning or a significant position change, the robot will re-generate the map. If the
dock is too far away, the robot may not be able to return for charging and must be placed on the
dock manually.

18
Common Issues
Problem Solution
Unable to connect
to WiFi
•WiFi disabled. Reset the WiFi and try again.
•Poor WiFi signal. Move the robot to an area with good WiFi reception.
•Abnormal WiFi connection. Reset the WiFi, download the latest mobile app and retry.
•Current device not supported. Find the supported models in the app.
•Unable to connect to WiFi. There may be an error with your router settings. Contact Roborock
Customer Service for help with troubleshooting.
Scheduled cleaning is not
working
•Battery low. Scheduled cleaning can only begin when the battery level is above 20%.
Is power always being drawn
when the robot is on the dock?
•The robot will draw power while it is docked to maintain battery performance, but the power
consumption is extremely low.
Does the robot need to be
charged for at least 16 hours for
the first three uses?
•No. Lithium-ion batteries have no memory effect. The robot can be used once fully charged.
Cleaning does not resume after
recharging
•Make sure that the robot is not in DND mode. DND mode will prevent auto top-up.
•If the robot is placed manually on the dock, it will not be able to continue cleanup.
The robot begins to miss certain
spots
•The wall sensor, cliff sensor, or carpet sensor may be dirty. Clean them with a soft, dry cloth.

19
Laser Safety
The laser distance sensor of this product meets the standards for Class 1 Laser Products in IEC 60825-1:2014 and will not generate hazardous laser radiation.
EU Declaration of Conformity
We Beijing Roborock Technology Co., Ltd., hereby, declares that this equipment is in compliance with the applicable Directives and European Norms, and
amendments. The full text of the EU declaration of conformity is available at the following internet address:
https://global.roborock.com/pages/compliance.
WEEE Information
Correct Disposal of this product . This marking indicates that this product should not be disposed with other household wastes throughout
the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the
sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where
the product was purchased. They can take this product for environmental safe recycling.
WiFi Specication
Service Protocol Frequency Range Max. Output Power
WiFi 802.11b/g/n 2400-2483.5 MHz ≤20dBm
Warranty Information
The warranty period depends on the laws of the country in which the product is sold, and the warranty is the responsibility of the seller.
The warranty only covers defects in material or workmanship.
The repairs under warranty may only be carried out by an authorized service centre. When making a claim under the warranty, the original bill of purchase (with
purchase date) must be submitted.
The warranty will not apply in cases of:
•Normal wear and tear.
•Incorrect use, e.g. overloading of the appliance, use of non-approved accessories, use of force.
•Damage caused by external influences.
•Damage caused by non-observance of the user manual, e.g. connection to an unsuitable mains supply or non-compliance with the installation instructions.
•Partially or completely dismantled appliances.
