Robotina HIQ Home User manual

User Manual v1.3.1
HIQ Home

Sales and management
Robotina d.o.o.
OIC-Hrpelje 38
6240 Kozina
Slovenia
[phone]
[email protected]
www.robotina.com
Manufacturing and service
Cybrotech Ltd.
14 Brinell Way
Harfreys Industrial Estate
Norfolk, NR31 0LU
United Kingdom
[phone]
[email protected]
www.cybrotech.com

Content
Features
Software
Hardware
Outline
Features
Utility
Concept
Devices
Expansion
Background
Lights and blinds
RGB dimmer
Scene
Automatic lights
Ready light
Evo light
Heating and cooling
Timetable
Key concepts
Automation
Alarm
Access control
Energy
Customization
4
5
6
7
8
9
10
11
12
13
15
17
18
19
20
21
22
24
25
26
27
HIQ Configurator
HIQ Commander
HIQ Universe
28
29
30
PS-IQ power supply
HC-IQ home controller
LC-10-IQ light controller
LD-P4-IQ universal dimmer
LD-V4-IQ LED dimmer
LD-D8-IQ DALI dimmer
BC-5-IQ blinds controller
SC-4-IQ scene controller
TH-1-IQ thermostat
TH-2-IQ thermostat
TH-3-IQ thermostat
FC-1-IQ fan-coil actuator
Power meter
Motion, door and light sensor
Temperature sensor
Touchless switch
Wiring
Schematic diagram
Switch panel
Dimensions
Order code
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51

HIQ is a home automation system, including
lights, blinds, heating and cooling; temperature
monitoring, energy management, timetable,
evant-based automation and security alarm.
HIQ consists both of hardware and software.
Although basically simple, expansion
capabilities are virtually unlimited. System is
configurable, programmable, and allow
integration of multiple HIQ installations into a
single functional unit.
HIQ can be used for both a new project and
renovation. Most of the work is done by a
electrician, no specialized expert is needed.
Configuration can be done by end-user.
System design is straight forward, there are no
complicated compatibility or dependency rules.
HIQ is open to other home devices, either by
integrating them in the system (e.g. touchless
buttons), or cooperate on the signal level (e.g.
professional alarm).
4
Outline
home automation system
comfort
simplicity
security
safety
flexibility
Features

integration with other systems independent of internet connection
manual or automatic operation
extremely simple to use
unlimited expansion possibilities full user control over all parameters
smartphone controls everything
separate thermostat for each room
Features
unique concept and style
Multiple timetables
Things running up to your schedule. Select active hours, and devices to
which they relate. Output can be manually overridden at any time.
Advanced RGB control
RGB mode allows control of hue, saturation and
brightness; instead of individual red, green and blue
channels.
White temperature mode goes between different
shades of white, from cool daylight to warm
incandescent tone.
Evo light synchronize light temperature with time of
the day. At the evening, lights will smoothly slide into
a warmer, cosy tone.
5
Features

Utility
small house apartment building
new house
urban house farm house bungalow
full renovation
large house
HIQ system is suitable for h mall or large,
residence or weekend house. However, it is not the best choice
for a partial retrofit, where a wireless solution may be prefered.
ouse or apartment, s
various lodging solutions
6
Features

Concept
system architecture
7
Features
distribution board
HIQ devices
configuration and control
buttons
scenes and
thermostats
heating, ventilation and air-conditioningcontrolled devices
HIQ Universe

Devices
what are devices used for
8
SC-4T-IQ
scene controller
LC-10-IQ
light controller
Device Used for
BC-5-IQ
blinds controller
LD-P4-IQ
LD-D8-IQ
universal dimmer
LD-V4-IQ
LED dimmer
FC-1-IQ
fan-coil controller
TH-1-IQ
TH-2-IQ
TH-3-IQ
electronic thermostat
heating, cooling and fan control
halogen and LED downlighters,
all kinds of general-purpose lights
window blinds, shutters and jalousies,
driven by a common up/down motor
user-selectable arrangement of lights and blinds
smartphone and PC connection, automation,
timetable, alarm, energy and other functions
dimmable lights of all kinds
LED stripes
managed socket for floor lamp,
table fan, hi-fi system, projector,
and all kinds of appliances
HC-IQ
master controller
SC-4S-IQ
scene controller
Features

Expansion
out-of-the-box vs project-based features
HIQ system offer many out-of-the-box functions. However, modern home automation is
all about integration, and that is where the HIQ excels. HIQ is capable of connecting
various devices into a functional system. Integration is project-based, each building is
attuned to investor requirements.
Advanced system
out-of-the-box
features
project-based
features
building
integration
audio/video
integration
KNX
bridge
smart grid
integration
LON
bridge
supervision
appliance
control
X10
bridge
Zigbee
bridge
DIY devices
energy
management
surveillancesafetysecurity
access
control
9
One home controller covers approximately 200m2, or one level in a multistory building.
switchboard
router
desktop PC
laptop
smartphone
tablet
Wi-Fi
Ethernet Ethernet
IEX bus
switches
230VAC
Basic configuration
Features

Background
experience behind the product
We don’t sell switches, luminaries, computers, portable devices, tablets or phones; you
have a freedom to select anything you like, buget models or expensive designer items.
What we do sell is electronics, software and home automation experience at it’s finest.
No hidden costs at any level - everything
is simple and elegant (and beautiful, too).
Programming tools are free, everybody
is welcome to give it a try. Only a basic
programming skills are needed. Join our
group and discover how fun and simple
house automation can be.
Addressing
Devices are addressed automatically,
not a single address is set by user.
Responsive
From keypress to action, typical
reaction time is 10 milliseconds.
Design
Cybrotech originate from industry control
and automation, all devices are designed
and build up to a much higher standards
then usually expected in home automation.
Features
- hardware watch-dog
- transient supression
- short circuit tolerant outputs
- reverse polarity tolerant supply
- wide temperature range
Power consumption
HIQ take a great care to use
as little electricity as possible.
Firmware
All devices are build to implement
firmware upgrade, so the future for
your investment is assured.
CAN bus is a multi-master,
deterministic bus which offer
optimum between performance,
network architecture and cost.
Autorange inputs always
ensure a full scale motion.
No batteries
The whole system is operated
from a single 24V power supply.
Wire vs. wireless
- no batteries
- more reliable
- faster response
- less EMI pollution
- simpler setup
- lower price
10
Features

Lights and blinds
control anything from anywhere
11
Features
blinds control with an
intermediate position
Light type
incandescent/halogen
compact fluorescent
compact LED E27/E14
LED strip 12/24V
on/off
40x 16x 10x
dimmer
0..100%
blinds position
0..100%
Outputs
managed socket for a
floor lamp, table fan,
dehumidifier, electric
mosquito repellent,
hi-fi system
Blinds type
classic blinds
slatted blinds
Roman shades
Scene
control a group with a single command

RGB dimmer
hue, saturation and brightness
12
Features
In RGB mode, dimmer channels are connected to red,
green, blue and white lights. White channel is
optional. Instead of individual channels, user controls
total brightness, hue and saturation.
In RGB mode, saturation goes from white to selected
color (0..100%). In white temperature mode,
saturation goes from natural white (white strip) to
selected white (0..100%).
RGB dimmer may be used in white temperature
mode. Here, user controls brightness and white
temperature. White light is obtained by mixing all four
channels. For best result, use
(warm white) and RGB strip 5600K (cool white).
white strip 2700K
white temperature modeRGB mode
Color picker
Color picker is a quick way to choose a color, available
with the HIQ Commander application. To control the
RGB, just touch a color or slide finger over the screen.
brightness
color
Color cycling
Automatically rotate through the available colors.
Brightness and saturation are selected manually.
1200K 2000K 3000K 4000K 5000K 6000K
0% 50% 75%25% 100%
White temperature

Scene
one key to rule them all
Each controller has up to
4 fully selectable scenes.
Scene mapping
SC0
SC1
SC2
SC3
0
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
outputs
on/off dimmer blinds
output on
On/off action
output off
not affected
dimmer 100%
10 to 90%
Dimmer action
dimmer off
not affected
blinds up
10 to 90%
Blinds action
blinds down
not affected
Scene is an user-defined memory to control lights,
dimmers and blinds. Each output can be on, off or
not affected by the scene.
13
Features
inputs timetable automation scene matrix

14
Features
How to change a scene
Open Scene editor and set
the corresponding outputs
Press and hold scene button,
then select Memorize Press and hold a button,
until a short beep
Using Scene controllerUsing HIQ CommanderUsing HIQ Configurator
Living room all
This procedure does not change which outputs are affected, only what each output does (on, off).
How to set a new scene
1. Identify lights that will be controlled by the scene
2. Open HIQ Configurator / Scene editor and set the corresponding outputs
This procedure does two things: select which outputs are affected, and what to do with each output (on, off).
If you have scene controller,
press write button to transfer
new scene to the controller
Press and hold until pop-up
dialog appears, Information
Using HIQ Commander
Open Lights+blinds page,
check the output number
Using HIQ Configurator
out 0 out 2
out 3
Scene
Lights
0
0
1
2
3
1234567
Write
Front left reflector

Automatic lights
where and how to use automatic lights
15
Features
Smart light is based on presence and low light signal. It is
used for living room and it can be combined with evo light.
Ready light take advantage of motion and door sensors. It
is suitable for occasionally used spaces, such as bathroom.
Motion sensor automation cover hallway, stairs and porch.
Light goes off after timeout.
Door sensor cover small rooms used temporary, like a
closet, cloak or wardrobe.
Other areas, like a bedroom, can't be automated and must
be handled manually.
HIQ system offers several ways to automate lights. The
appropriate configuration is selected based on the way
how the space is intended to be used.
ready light
door sensor
motion sensor
smart light
manual control

16
Features
press on, press off
input modeusage
Input mode and output mode settings
functionoutput mode
press on, press off
when timer expires, light goes off
press on
press again to reload the timer
when timer expires, light goes off
press on, release off
press to set multiple lights
press again to turn them all off
movement is keeping the light on
when timer expires, light goes off
movement is keeping the light on
when timer expires, light goes off
active only during the night
open door to turn the light on
close door to turn the light off
open door to turn the light on
close door to turn the light off
active only during the night
fully automatic light control
disabled, output not affected
on/off
on/off + timer
staircase
doorbell
scene
motion sensor
door sensor
ready light
not used
ready light
door sensor
motion sensor
manual control

Ready light
advanced automatic light control
Input setup
Sensors are connected to
spare inputs of light controller.
Input must be configured to
ready light mode.
Sensor placement
For a best result, sensor must
be activated just after person
closes the door.
Short timeout
Time from closing the door to
light off. If time is too short,
light may turn off after
entering the room.
Long timeout
Time from leaving the room to
light off, without closing the
door.
How does it work
When door begins to open, reed sensor is activated and the light turns on. When a person enters the room and
closes the door, PIR activation means person is surely in the room. As long as door is closed, light will stay on.
When person leaves room and closes door, system will wait for a short time, then turn the light off. If the door is
left open, long timeout is active. If the PIR sensor is not activated during that time, light switches off.
Features:
- instant on as soon as door begins to open
- never turn off while somebody is inside
- quickly turns off when everybody is out
Ready light is an advanced lighting
system, based on motion and door
sensors. It is best suited for closed
spaces that residents don’t occupy
permanently.
17
Features
Patent rights granted
2016-04-29 by patent
office Slovenia, number
24867, class G06F 9/00.
light and sensor position
short and long timeout
door sensor
long timeout
motion sensor
short timeout
light output
enable ready light
room has a natural light
occupancy status
motion sensor
door sensor
timer
only by night
room enable

Evo light
automatic transition to warm evening lights
18
Features
Evo light is a half-automatic system for controlling light temperature. It uses RGB dimmer in
white temperature mode. Brightness is controlled by user, hue and saturation are controlled
by the system.
During the selected period, lights are going from a cool white to warm white, perfectly
matching our natural daily cycle.
System can be combined with smart lights. In that case, operation is fully automatic, smart
lights control brightness, and evo light control light temperature.
controlled manuallybrightness
temperature
saturation controlled by evo light
12
cold white
warm white
temperature
time
start hoursunrise
Operation
To configure evo light, first experimentally the best light for
early and late evening. Start hour and transition time should be
configured so the warm light is reached at least one hour before
bedtime.
When dimmer is switched back to RGB mode, evo light will
automatically stop. Enabling again, it will catch on correctly,
recalculating the new parameters.
find
Note: evo light
setup is located
on RGB page.
Term evo is a short for ‘evolution’. During the
most of our evolutionary past, our ancestors
were using no artifical lighting, so daily rhythm
was synchronized by sunlight. Evo light is an
attempt to mimic that natural conditions.

Heating and cooling
general features of heating/cooling system
Heating/cooling
19
Features
hot water
radiator
electric
radiator
electric
fan heater
floor heating fan-coil
convector
air condition
direct external 16A relay fan coil actuator
Actuator
System is versatile enough to handle most actuator options. Hot water valve is connected directly,
others require either external power relay, or fan coil actuator. Different actuator types can be mixed.
Energy demand
allow termostat to start boiler
configurable delay
Up to five regulation zones
are supported, each with
their own thermostat.
Generally, energy comes
from boiler for heating and
chiller for cooling, but other
combinations are possible.
Examples
electric heatingfan coil heating and coolingair condition heating and cooling radiator heating, air condition cooling
Thermostat
TH-1M-IQ TH-1T-IQ TH-2-IQ TH-3-IQ

Timetable
weekly event scheduler
20
Features
timetable 0 timetable 1 timetable 2 timetable 3
Selected part is a period when heating system is active. Each rectangle represents a half hour.
Tables are fully independent of each other. To set multiple fields, hold left button and drag mouse.
Each timetable can directly control one output or apply a scene.
Timetable can be used to control
mostly anything. Use a managed
socket to create a time plan for
your devices.
timetable managed socket
user input
timetable
output
When timetable controls an output, manual override is possible
at any time, timetable will catch on with the next transition.
on
off
Each block create
on and off event.
A list of hollidays can be configured.
On a holliday, timetable is running
as it is a Sunday.
