Roc Hobby F-16 Falcon User manual

Email:[e-mail]
Http://www.motionrc.com

F-16 Falcon
OPERATING MANUAL

Read the ENTIRE instruction manual to become familiar with the features of the product WARNING:
before operating. Failure to operate the product correctly can result in damage to the product, personal
property and cause serious injury.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense
and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner
could result in injury or damage to the product or other property. This product is not intended for use by
children without direct adult supervision.
This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in this manual prior to assembly, setup, or use, in order to operate
correctly
and avoid damage or serious injury.
!
Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating in a manner that does not endanger
yourself and others or result in damage to the product or the property of others. This model is controlled
by a radio signal subject to interference from many sources outside your control. This interference can
cause momentary loss of control so it is advisable to always keep a safe distance in all directions around
your model, as this margin will help avoid collisions or injury.
Age Recommendation: Not for children under 14years. This is not a toy.
• Never operate your model with low transmitter batteries.
•Always operate your model in an open area away from cars, traffic or people.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate the model in the street or in populated areas for any reason.
• Carefully follow the directions and warnings for this and any optional support equipment (chargers,
rechargeable battery packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Moisture causes damage to electronics. Avoid water exposure to all equipment not specifically designed
• Never lick or place any portion of your model in your mouth as it could cause serious injury or even death.
and protected for this purpose.
WARNING!
ROCHOBBY Friendly Reminder
Thank you for purchasing a RocHobby product.
Our goal is to provide high quality products and
offer great customer service. If you have any
problems with your product or want to offer
suggestions for improvements (such as plane
design, packaging, building instructions, etc.)
please feel free to contact us at
[e-mail]
For More Info Vist: www.motionrc.com

Table ofcontents
Kit contents 1
The spare parts list 1
The illustration of the spare parts
Spare parts list content
Kit Inspection 3
Charging the Flight Battery 3
Low Voltage Cutoff 6
Assemble the plane 6
Install the landing gear
Install the main wing
Install the horizontal stabilizer
Install the vertical fin
Install the nose cone
Install the ventral fin
Install the linkage rods
Install the battery
The receiver department
Check the C.G. (Center of Gravity)
Before the model flying 18
Find a suitable flying site
Perform the range check of your plane
Monitor your flight time
Flying course 19
Take off
Flying
Landing
Maintenance
Troubleshooting 20
AMA 21
Get your model ready to fly 14
Important ESC information
The transmitter and model setup
Check the control throws
Check the motor rotor direction
Load the aircraft

Kit contents
ReplacementpartsfortheROCHobby F16 Falcon are available using the order numbers
in the Spare parts list that follows. The fastest, most economical service can be provided
by your hobby dealer or mail-order company.
The spare parts list
page1
Kit contents
Spare parts list content
Spare parts list content
KC 101 Fuselage (With all the plastic parts installed)
KC 102 Main wing set (With the control surface hinged)
KC 103 Horizontal stabilizer (With the control surface hinged)
KC 104 Vertical stabilizer
KC 105 Nose cone
KC 106 Canopy (With the foam cockpit and pilot)
KC 107 Ventral fin
KC 108 Fuel tanks
1. The fuselage assembly (With the fin, the canopy, the electronic parts, ESC)
2. Vertical stabilizer assembly
3. Horizontal stabilizer with the elevator hinged
4. Nose cone
5. Oil tanks and the Missiles
For More Info Vist: www.motionrc.com

page2
The illustration of the spare parts
KC-101 KC-102 KC-103 KC-104
KC-105
KC-109
KC-113
KC-106
KC-110
KC-114
KC-107
KC-111
KC-115
KC-108
KC-112
KC-116
KC 109 Missile A (Wing tip loading)
KC 110 Missile B (Hang under the wing)
KC 111 Pilot
KC 112 Linkage rod (With the clevis and securing ring)
KC 113 Landing gear set (The main and the front landing gear)
KC 114 Air speed head
KC 115 Motor (2627 KV 4600)
KC 116 Ducted fan (64mm: The fan tube and the rotor)
KC 117 Battery (11.1V 1800mAh 25C)
KC 118 Servo (9g)
KC 119 ESC (35A with 4 A BEC)
KC-117 KC-118 KC-119
For More Info Vist: www.motionrc.com

page3
Kit inspection
Caution: All instructions and warnings must be followed exactly. Mishandling of Li-Po
batteries can result in fire, personal injury, or property damage.
Battery warning:
By handling, charging or using the included Li-Po battery
you assume all risks associated with lithium batteries.
If at any time the batteries begin to swell, or balloon, discontinue use immediately!
Charging or discharging a swelling or ballooning battery can result in fire.
Always store the batteries at room temperature in a dry area to extend the life of
the battery. Always transport or temporarily store the battery in a temperature range of
o
40-120 F. Do not store battery or model in a car or in direct sunlight. If stored in a hot car,
the battery can be damaged or even catch fire.
Never use a Ni-Mh charger. Failure to charge the battery with a compatible charger may
cause fire resulting in personal injury and property damage.
Never discharge Li-Po cells to below 3V.
Never leave charging batteries unattended.
Never charge damaged batteries.
BC-3S10 Balance Charger
To correctly use the charger, please read the instructions before use.
Before starting to build, inspect the parts to make sure they are acceptable quality. If any
parts are missing or are not in good shape or acceptable quality, or if you need assistance
with setup and assembly, please feel free to contact Motion RC. Please write down the
name of the parts when you are reporting defective or missing of them.
Motion RC Product Support
ADDRESS: 28W039 Commercial Ave, Unit 8
Lake Barrington, IL 60010
Tel [phone]:
Email: [e-mail]
Web: www.motionrc.com
The Battery Charger included with your aircraft is designed to safely charge the Li-Po battery,
Charging the flight battery
RTF kits come with a DC balancing charger. You must charge the battery with
a Li-Po specific charger only (such as the included BC-3S10 DC charger). When charging
the battery, make certain the battery is on a heat-resistent surface, charge the battery
before assembly of the airplane. Install the fully charged battery to perform control tests
and binding.
Charging the Flight Battery
For More Info Vist: www.motionrc.com

Electrical Parameters
Parameter Min Type Max Unit
WorkingVoltage91 2 1 6 V
InputPower 1 5 W
WorkTemperature - 2 0 4 5 ℃
StoreTemperature - 2 0 6 5 ℃
ChargingStopVoltage 4 . 1 9 4 . 2 0 4.21 V
ChargingCurrent1000 mA
BalancingCurrent 1 5 0 200 mA
ActivateCurrent 80 120 mA
page4
Charging the Flight Battery
For More Info Vist: www.motionrc.com

Using Steps:
1. Connect the charger to adapter with enough voltage and wattage, then the Power LED will
turn on;
2. Connect 2S/3S battery pack to the corresponding balance port (Do not connect two battery
packs at the same time), then the Charge LED will flicker (1Hz) and start charging.
3. When the Charge LED stops flickering, charging is complete, and the batteries can be
unplugged.
Charging Function Description
1. If all voltage of the installed battery pack is higher than 4.18V, charging will not start and the
charge LED will shine.
2. If the voltage of one battery or some batteries is lower than 0.7V, charging will not start. If the
voltage of the first battery of a 3S battery pack is lower than 0.7V, the charger will charge the
battery pack as if it was a 2S battery pack.
3. If the voltage of one battery or some batteries is lower than 2.8V, the charger will activate the
battery pack with a small current. If the voltage can’t be increased above 2.8V after half an
hour, the charger will judge the battery pack as bad. The charge LED will then flicker rapidly
(0.5Hz), and charging will stop.
Self Checking Function
1. Charger will perform a self test before each charge. The charge LED will rapidly flicker (0.5Hz)
if the charging function is abnormal;
2. Accuracy checking Function: Connect a fully charged 3S battery pack (all voltage at least 4.2V),
the charge LED will flicker twice then shine always. This means that the accuracy is normal.
Protection Function
1. Reverse connection protection of input
2. Reverse connection protection of output
3. Short circuit protection of output
4. Over voltage protection of output
Troubleshooting
1. Power LED does not shine – Adapter isn’t connected correctly. Please check the polarity
and reconnect adapter.
2. Charging abruptly stops and tries to restart constantly during charging – Output power
of the adapter is not sufficient, please replace the adapter.
3. Charge LED does not shine – Reconnect the battery pack; Check the voltage of batteries.
4. Charge LED rapidly flickers – Battery is bad or charging function is abnormal. Replace
battery or contact technical support.
page5
Charging the Flight Battery
For More Info Vist: www.motionrc.com

page6
WhenaLi-Poisdischarged below 3V per cell, it will not hold a charge. The ESC protects
the flight battery from over-discharge using Low Voltage Cutoff. Before the battery charge
decreases too much, LVC removes power from motor in two ways: (1) Reduces power -
ESC reduces motor power (recommended), (2) Hard cutoff - ESC instantly cuts motor
power when the pre-set Low Voltage Protection Threshold value is reached. These
settings can be changed using the ESC programing guide (available on-line).
Low voltage cut off (LVC)
Assemble the plane
Install the landing gear
2
3
1. Slide L bend end of the landing gear
strut into the pre-notched slot on the
gear mounting base. Each strut should
installed so that the wheel faces
outwards when installed.
1.1
1.2
2. Rotate the strut as picture 1.2 shows
till the strut is fully seated into the slot.
3. Snap the plastic latch to secure the landing gear
into place.
For More Info Vist: www.motionrc.com

page7
Assemble the plane
Install the main wing
4. Install the front landing gear. The flat
spot of the strut will be used to hold the
strut firmly into place (step 6 below).
5. Check the socket inside the air intake to
ensure the screw side of the socket faces
the nose of the plane.
6. Insert the front strut into the socket from
the bottom of the air intake with the flat spot
side toward the screws side of the socket.
1. Remove any paint (Tip - use strong
adhesive tape to easily remove paint)
where the main wing and the horizontal
stabilizer will fit together with the
fuselage.
2. Apply equal parts of quick dry epoxy into
the mixing plate and stir with a stick.
Note: Epoxy will dry in approx 3 to 5 min so
be sure you have adequate time to apply
glue and position parts.
5
6
1.1
1.2
2
4
For More Info Vist: www.motionrc.com

page8
Assemble the plane
3. Apply the mixed epoxy to the starboard
wing and fuselage mating edge using
a brush or other applicator.
4. Fit the wing into place promptly (before
the epoxy begins to cure).
5. Make sure the top surface of the main
wing is level with the fuselage body.
Install the port side main wing following
the same method as steps 3 through 5.
3
4
5.1
For More Info Vist: www.motionrc.com

page9
Assemble the plane
Install the horizontal stabilizer
1. Install the control horns on the bottom
side of the stabilizer as shown.
2. Glue the port side horizontal stabilizer
into place.
3. Fully seat the stabilizer into place,
make sure there is no gap left between
the stabilizer and the fuselage.
4. Make sure the stabilizer horizontal axis
is parallel to the wing as shown. Adjust
any misalignment before the glue dries
throughly.
1
2
3
4
For More Info Vist: www.motionrc.com

page10
Assemble the plane
Install the vertical fin
1. Glue the vertical stabilizer into place.
2. The wrong way to mount the air speed
head.
4. The wrong way to mount the nose cone.
1. Glue the air speed head to the nose
cone. Ensure the air speed head and
nose cone are in perfect alignment.
Note: Use epoxy or other foam safe
adhesive when gluing to avoid damaging
the foam.
Install the nose cone
3
2
4
1
1
3. The nose cone is attached to the
fuselage using two pieces of magnets.
Figure 3 shows the right way to attach
the nose.
For More Info Vist: www.motionrc.com

1. Put the Z-bend end of the linkage into
the desired servo control horn hole. It is
a tight fit and should allow the linkage to
move just slightly within the hole to avoid
binding up.
2. Snap the clevis into the surface control
horn.
3. The provided piece of fuel tubing keeps
the clevis closed during flight. Repeat
steps 1&2 for the remaining linkage rods.
Note: Do not over slide the securing
tube or it will impede the movement
of the surface control horn.
page11
Assemble the plane
Install the ventral fin Install the linkage rod
1. Fit one of the fins into place, the higher
side towards the front of the plane.
Higher
2. The fin will angle towards the outboard
of the plane as the picture shows.
3. This picture shows the WRONG way to
mount the fin. Glue the fin into place
after verifying the positioning is correct.
1
2
3
1
2
3
For More Info Vist: www.motionrc.com

page12
Assemble the plane
1. Attach aileron servo to the Aileron channel
of your receiver. Elevator harness goes to
elevator channel of your receiver. Steering
servo goes to the Rudder channel. Attach
the ESC connector
to the throttle channel
of the receiver.
Installing the receiver
Receiver
Throttle
Channel-1
— Aile
Channel-2
— Elev
Channel-3
— Thro
Channel-4
— Rudd
1
2
3
4
Aileron
Elevator
Steering
2. Tuck the wire leads into the recessed cavity
at the rear end of the canopy hatch.
Note: Keep wires clear from notched area
at the rear of the hatch (highlighted) to
ensure canopy stays secure in flight.
3. Mount the receiver into place and make sure
it will not impede the canopy mounting.
2. Fit the power connector into place and
make sure the power supply wire does
not interfere with the canopy’s closure.
1. Slide the battery into the battery hatch
with the power supply cable toward the
rear end of the plane. Secure the battery
using the hook and loop strip.
Note: You may need to relocate the battery
position to achieve the correct CG for
your F16 model.
Install the battery
1.1
1.2
1
2
2
3
For More Info Vist: www.motionrc.com

Center of Gravity
When balancing your model, adjust the motor battery as necessary so the model is level or
slightly nose down. This the correct balance point for your model. After the first flights, the CG
position can be adjusted for your personal preference.
1. The recommended Center of Gravity (CG) location for your model is ( ) forward from170-172mm
the trailing edge of the main wing (as shown) with the battery pack installed. Mark the location of the
CG on top of the wing.
2. When balancing your model, support the plane inverted at the marks made on the top of the
main wing with your fingers or a commercially available balancing stand. This is the correct
balance point for your model. Make sure the model is assembled and ready for flight before
balancing.
page13
Assemble the plane
Check the C.G. (Center of Gravity)
170-172mm
For More Info Vist: www.motionrc.com

page14
Get your model ready to fly
Important ESC information
1. The ESC included with the F-16 has a safe start. If the motor battery is connected to
the ESC and the throttle stick is not in the low throttle or off position, the motor will not
start until the throttle stick is moved to the low throttle or off position. Once the throttle
stick is moved to the low throttle or off position, the motor will emit a series of beeps.
Several beeps with the same tune means the ESC has detect the cells of the battery.
The count of the beeps equal the cells of the battery. The motor is now armed and will
start when the throttle is moved.
2. The motor and ESC come pre-connected and the motor rotation should be correct.
If for any reason the motor is rotating in the wrong direction, simply reverse two of the
three motor wires to change the direction of rotation.
3. The motor has an optional brake setting. The ESC comes with the brake switched off
and we recommended that the F-16 be flown with the brake off . However, the brake
could be accidentally switched on if the motor battery is connected to the ESC while the
throttle stick is set at full throttle. To switch the brake off, move the throttle stick to full
throttle and plug in the motor battery. The motor will beep Move the throttle one time.
stick to low throttle or the off position. The motor is ready to run and the brake will be
switched off.
We recommend the 11.1V 1800mAh 25C Li-Po 4. Battery Selection and Installation.
battery. If using another battery, the battery must be at least a 11.1V 1800mAh 25C
battery. Your battery should be approximately the same capacity ,dimension and
weight as the 11.1V 1800mAh 25C Li-Po battery to fit in the fuselage without changing
the center of gravity significantly.
For More Info Vist: www.motionrc.com

The transmitter and model setup
page15
Get your model ready to fly
Before getting started, bind your receiver with your transmitter. Please refer to your
Transmitter Manual for proper operation.
CAUTION: To prevent personal injury, DO NOT install the propeller assembly onto the
motor shaft while testing the control surfaces . DO NOT arm the ESC and do not turn on
the transmitter until the Transmitter Manual instructs you to do so.
Tips: Make sure all control sticks on your radio are in the neutral position (rudder,
elevator, ailerons) and the throttle in the OFF position. Make sure both ailerons
move up and down (travel) the same amount. This model tracks well when the
left and right ailerons travel the same amount in response to the control stick.
1. Move the controls on the transmitter to make sure aircraft control surface move
correctly. See diagrams below.
Aileron
Elevator
Left
steering
Right
steering
Steering
Bank Left
Bank Right
Climb
Descend
Steer Left
Steer Right
For More Info Vist: www.motionrc.com

page16
Get your model ready to fly
2. Make sure all servo arms are fully vertical. If not, adjust the servo arm by using the trim
function on your radio. Note: For computerized transmitters, use the servo/channel
sub-trim feature to make each servo arm fully vertical.
3. The standard hole settings for linkage connections are shown by the black arrows in the
the diagram below. You can move the linkage to different hole positions to increase
control surface travel and increase the aerobatics of the airplane.
4. Align the control surface with the wing root by turning the clevis clockwise and
counterclockwise on the linkage, carefully open the clevis fork and put the clevis pin in
the desired hole of the control horn.
Note: Please secure the clevis with provided piece of tube after the alignment of the
surface is completed.
Check the control throws
The suggested control throw settings for ROC HOBBY are as follows (Dual rate setting):
High Rate Low Rate
Elevator 15mm up/down 10mm up/down
Aileron 17mm up/down 11mm up/down
Front landing gear steering: left/right 30 degree
Tips: At first flight, fly the model in low rate. The first time you use high rates, be sure to fly
at low to medium speeds. High rates, as listed, are only for EXTREME maneuvering.
4.1 4.2
For More Info Vist: www.motionrc.com
