Roc Hobby WACO User manual

I
OPERATING MANUAL
f

-'
 ·

WARNING!
·
before operating. Failure to operate the product correctly can result in damage to the product, personal
 WARNING: Read the ENTIRE instruction manual to become familiar with the features of the product
property and cause serious injury.
This is a sophisticated hobby product and NOT a toy. It must be operated with caution and common sense
and requires some basic mechanical ability. Failure to operate this Product in a safe and responsible manner
could result in injury or damage to the product or other property. This product is not intended for use by
children without direct adult supervision.
This manual contains instructions for safety, operation and maintenance. It is essential to read and follow
all the instructions and warnings in this manual prior to assembly, setup, or use, in order to operate
correctly and avoid damage or serious injury.
Safety Precautions and Warnings
As the user of this product, you are solely responsible for operating in a manner that does not endanger
yourself and others or result in damage to the product or the property of others. This model is controlled
by a radio signal subject to interference from many sources outside your control.
This interference can
cause momentary loss of control so
it is advisable to always keep a safe distance in all directions around
your model, as this margin will heip avoid collisions or injury.
Age Recommendation: Not for children under 14years. This is not a toy.
• Never operate your model with low transmitter batteries.
• Always operate your model in an open area away from cars, traffic or people.
• Avoid operating your model in the street where injury or damage can occur.
• Never operate the model in the street or in populated areas for any reason.
• Carefully follow the directions and warnings for this and any optional support equipment (chargers,
rechargeable battery packs, etc.) you use.
• Keep all chemicals, small parts and anything electrical out of the reach of children.
• Moisture causes damage to electronics. Avoid water exposure to all equipment not specifically designed
and protected for this purpose.
• Never lick or place any portion of your model in your mouth as it could cause serious injury or even death.
  -' .
- ROCHOBBY Friendly Reminder
�
Thank you for purchasing a ROC HOBBY product.
Our goal is to provide high quality products and offer
great customer service. If you have any problems
with your product or want to offer suggestions for
improvements (such as plane design, packaging,
building instructions, etc.), please feel free to contact
us at :
[e-mail]
�--
,
,

J
Index
1. Photo of Unassembled Kit 1
2. Kit Contents 1
3. Spare Parts List/ Item Numbers 2
4. Illustration of Spare Parts 2
5. Kit Inspection 3
6. Electrical Parameters 4
7. Charging the Flight Battery 5
8. Low Voltage Cut Off (LVC) 6
9. Airplane Assembly:
10.Control Horn Installation 6
11.Installing the Lower Wing 7
12.Main Landing Gear Installation 8
13.Mounting the Top Wing 8
14.Arranging the LED Wires 10
15.Mounting the Horizontal Stabilizer 10
16.Installing the Receiver and Battery 12
17.Installing the pushrods 12
18.PreFlight:
19.Important ESC and model Information 14
20.How to calibrate the throttle 14
21.How to restore the ESC settings 14
22.The Transmitter and model setup 15
23.Check the Control Throws 17
24.Check the motor's rotational direction 17
25.Propeller installation 17
26.Aileron Linkage installation 17
27.Flying Wires and Pilots Installation 18
28.Center of Gravity (CG) 19
29.Preflight Recommendations 20
30.Trouble Shooting 22
31.AMA 23

Kit contents J
Kit contents
1. The fuselage assembly (With the motor, the canopy, the electronic parts, ESC)
2. Main wing set (The top wing and the lower wing)
3. Horizontal stabilizer with the elevator
4. Main landing gear set
5. Propeller and spinner
6. Spare parts bag and pilot figures
7. lnterplane struts and cabane
Spare Parts List J
Replacement parts for the ROCHOBBY WACO are available using the order
numbers in the Spare parts list that follows. The fastest, most economical
service can be provided by your hobby dealer or mail-order company.
Spare parts list /Item numbers
KE-101.
Fuselage Yellow/Red (Painted with all the plastic parts installed)
KE-102.
Top wing Yellow/Red (Painted with all the plastic parts installed)
KE-103.
Lower wing Yellow/Red( Painted with all the plastic parts installed)
KE-104.
Elevator Yellow/Red
KE-105.
Cockpit Yellow/Red
KE-106.
Cowl Yellow/Red
KE-107.
Wind shield Yellow/Red
KE-108.
Main landing gear Yellow/Red(With the auxiliary stay bar)
KE-109.
Rear landing Gear Yellow/Red(With wheel)


KE-110. MotorBoard
KE-111. Spinner (Propeller hub and spinner)
KE-112. Propeller(11*7)
KE-113. Cabane
Yellow/Red
KE-114. lnterwing strut
Yellow/Red
KE-115. Pushrods
KE-116. MotorShaft
KE-117. Motor(D3536-KV850)
KE-118. 9g Servo (With arm)
KE-119. ESC(35A/4ASBEC)
KE-120. Battery(11.1v, 1800mAh,25C)
KE-121. Decal sheet
Yellow/Red
The illustration of the spare parts
 �?
' 

KE 101 KE 102 KE 103
 '.
 1
•
KE 105 KE 106 KE 107
KE 109 KE 110 KE 111
KE 113 KE 115
KE 117 KE 118 KE 119
=
-
 
KE 121
 page2 
KE 104
-�


KE 108
KE 112

KE 116
KE 120
KE 114

Kit Inspection J
Before beginning assembly, inspect all of the parts for any damage or defects. If any parts are
missing or defective or damaged, or if you need assistance with setup and assembly, please feel
free to contact the ROC TEAM. Please write down the name and item number of the parts when you
are reporting a damaged, defective or missing item.
ROC TEAM Product Support
ADDRESS: 3/F, Building B, 3rd Industry Zone, Matigang, Dalingshan Town, Dongguan
City, P.R.C
Tel: [phone]
Email: [email protected]
Web: www.rochobby.com
Ch arging the Flight Battery
The Battery Charger included(depending on the type of kit you purchased) with your aircraft is designed to
safely charge the Li-Po battery,
Caution:
All instructions and warnings must be followed exactly. Mishandling of Li-Po batteries can result in
fire, personal injury, or property damage.
Battery warning:
By handling, charging or using the included Li-Po battery (depending on the type of kit purchased)
you assume all risks associated with lithium batteries.
If at any time the batteries begin to swell, or balloon, discontinue use immediately! Charging or
discharging a swelling or ballooning battery can result in fire.
Always store the batteries at room temperature in a dry area to extend the life of
the battery. Always transport or temporarily store the battery in a temperature range of
40-12QOF. Do not store the battery or the model in a car or in direct sunlight. If stored in a hot car,
the battery can be damaged or even catch fire.
Never use a Ni-Mh charger. Failure to charge the battery with a compatible charger may cause fire
resulting in personal injury and property damage.
Never discharge Li-Po cells to below 3V.
Never leave charging batteries unattended.
Never charge damaged batteries.
Charging the flight battery
RTF kits come with a DC balancing charger. You must charge the battery with
a Li-Po specific charger only (such as the included BC-3S10 DC charger). When charging the
battery, make certain the battery is on a heat-resistent surface, charge the battery
before assembly of the airplane. Install the fully charged battery to perform control tests and binding.
BC-3S10 Balance Charger
To correctly use the charger, please read the instructions before use.
I�--

Charging the Flight Battery
J
Electrical Parameters
Parameter Min Type Max Unit
Working Voltage
9 12 16
V
Input Power
15
w
Work Temperature
-20 45
oc
Store Temperature
-20 65
oc
Charging Stop Voltage
4. 19 4.20 4.21
V
Charging Current
1000
mA
Balancing Current
150 200
mA
Activate Current
80 120
mA
Using Steps:
1. Connect the charger to adapter with enough voltage and wattage, then the Power LED will turn on;
2. Connect 2S/3S battery pack to the corresponding balance port (Do not connect two battery
packs at the same time), then the Charge LED will flicker (1 Hz) and start charging.
3. When the Charge LED stops flickering, charging is complete, and the batteries can be unplugged.
Charging Function Description
1. If total voltage of the installed battery pack is higher than 4.18V, charging will not start and the charge
LED will shine.
2. If the voltage of one or battery cells is lower than O. 7V, charging will not start. If the voltage of the
first cell of a 3S battery pack is lower than O.
7V, the charger will charge the battery pack as if it was a
2S battery pack.
3. If the voltage of one or more battery cells is lower than 2.8V, the charger will activate the battery
pack with a small current. If the voltage can't be increased above 2.8V after half an hour, the charger
will read the battery pack as bad. The charge LED will then flicker rapidly (0.5Hz}, and charging will
stop.
Self Checking Function
1. Charger will perform a self test before each charge. The charge LED will rapidly flicker
(O.SHz) if the charging function is abnormal;
2. Accuracy checking Function: Connect a fully charged 3S battery pack (all voltage at least 4.2V),
the charge LED will flicker twice then shine always. This means that the accuracy is normal.
Page 4

Protection Function
1. Reverse connection protection of input
2. Reverse connection protection of output
3. Short circuit protection of output
4. Over voltage protection of output
Troubleshooting
Charging the Flight Battery
J
1. Power LED does not shine-Adapter isn't connected correctly. Please check the polarity
and reconnect adapter.
2. Charging abruptly stops and tries to restart constantly during charging- Output power
of the adapter is not sufficient, please replace the adapter.
3. Charge LED does not shine- Reconnect the battery pack; Check the voltage of batteries.
4. Charge LED rapidly flickers -Battery is bad or charging function is abnormal. Replace
battery or contact technical support.


Low voltage cut off (LVC)
J
When a Li-Po is discharged below 3V per cell, it will not hold a charge. The ESC protects
the flight battery from over-discharge using Low Voltage Cutoff. Before the battery charge
decreases too much, LVC removes power from motor in two ways: (1) Reduces power -
ESC reduces motor power (recommended), (2) Hard cutoff - ESC instantly cuts motor
power when the pre-set Low Voltage Protection Threshold value is reached. These settings
can be changed using the ESC programing guide (available on-line).
Airplane Assembly
Control Horn Installation
1. The control surface horns for the rudder are
included in the bag marked 'rudder', do not
accidentally discard them. �
J
3. Mount the control horn backplate into the
opposite side of the surface and secure
the horn from the plate side.
Note: The longer screws used to secure the horns
are always used at the leading edge position of the
control surface
2. Attach the rudder control horn on the starboard
(Right) side of the rudder, toward the hinge line.
4. Make sure the two securing screws are firmly
mounted into the control horn base.
---�I  

5. The aileron control horns are contained in
the spare parts bag with the linkage rod.
•
6. Attach the control horn of the ailerons to the
servo side of the lower wing with the
horn toward the hinge line.
7. Secure the control horns using the same with
method used when installing the rudder control
horn.
OSBY
Airplane Assembly J
Installing the lower wing
1. Insert the Leads of the main wing from the
hole on the bottom of the wing mounting bay
to the cockpit hatch before mounting the
lower wing into the bay.
•
2. Pull the leads from the hatch slightly before
seating the lower wing into place to avoid
any tangling that would stop the main wing
from fully seating into the bay.
3. Secure the lower wing into place using the
provided self tapping screws. (Screws:
A. PA2.6*30 2PCS, B. PA2.6*40 2PCS)
---

BY
Main Landing Gear Installation
1. Fully insert the landing gear strut into the
slot on the landing gear base .
2.
Place the landing gear securing fairing
plate in place, facing the right direction.
J
3. Secure the plate using the provided self
tapping screws.
•
Mount the top wing
1. Test to make sure the port side LED is
red and the starboard LED is green.
2. Install the interwing strut with a label
L to the port side of the top wing.
---1 

3. Secure the strut using two self tapping
screws with the LED wire slot toward the
leading edge of the wing. Repeat this step
for the other strut installation.
(Screws: PA 2.0*8 4PCS)

4. Fit the LED wire into the slot on the strut
and secure it using tape. Repeat this
step to install the other interwing strut.
5. Install the wing ca bane with a label L to
the mounting base on port side of the
fuselage.

Airplane Assembly J
5. Secure the strut using two self tapping screws
as shown in the picture, repeat this step for
mounting the other cabane.
6. Properly mount the top wing to the ca bane .
@ [
7.
Secure the interwing strut to the top of the
lower wing.


Airplane Assembly
8. Turn the plane over, so the bottom of the
plane faces up and secure the top wing
to the
ca
bane using self tapping screws.
(Screws: PA2.0*8 4PCS)
Arranging the LED Wires
1.
Thread the leads from the top of the lower
wing to the bottom and fix them in the pre
notched slot. Insert the leads from the hole
on bot
tom of the wing to the cockpit hatch.
I
J
,


2. Secure the wire into the slot using the
included wire tape covering.
Mounting the Horizontal stabilizer
1. Turn the plane over and fully insert the right
side (starboard) stabilizer into place.
li . · 
0
---�I  

2. Insert the left (port) side stabilizer into place.
Make sure the elevator joiners interlock
to each other before fully sliding the
stabilizer into place.
•
3. Secure the stabilizer into place using
the provided screws. (PA2.6*10 2PCS)
r
Airplane Assembly J
4. Secure the wing joiner to the bottom of
the
elevator. (PA2.0*8 1 PCS)
e�;
' ,
5. Install the main landing gear auxiliary
star bar using screws. (PA2.3*5 2PCS)




Airplane Assembly
1. Plug the leads to the receiver as shown
in the diagram.
• Receiver
Aileron
1
Channel-1
Elevator
2
-
Ailerons
Channel-2
-Elev
Throttle
3
Channel-3
-Throttle
Steering/Rudder 4
Channel-4
-Rudder
LED
LED
/
2 .Tuck the wire leads into the recessed
cavity at the rear of the servo hatch.
Make sure the wires do not interfere
with the servo arm's arc of travel.

J
3. Open the battery hatch cover by raising
the tape at the front, install the battery with
the cable toward the rear of the plane .
Installing the Pushrods
Before getting started, bind your receiver
with your transmitter. Please refer to your
Transmitter Manual for proper operation.
CAUTION: To prevent personal injury, DO
NOT install the propeller assembly onto the
motor shaft while testing the control surfaces.
DO NOT arm the ESC and do not turn on
the transmitter until the Transmitter Manual
instructs you to do so.
1. Set all of the trim or sub trims in the neutral
position before connecting the pushrod,
then connect the battery to the ESC, adjust the
servo arm using a proper screw driver to make
sure the arm is perpendicular to the servo case.
Installing the Receiver and Battery

2. Put the Z-bend end of the of the aileron
pushrods into the desired servo control
horn hole. It is a tight fit and should allow
the linkage to move just slightly within
the hole to avoid binding up.
3. Snap the clevis into the surface control
horn.
4. The provided piece of O ring tubing keeps
the clevis closed during flight. Secure all
the linkages using the same method.
Note: Do not slide the O ring tube too far
forward or it will impede the movement
of the control horn.
Airplane Assembly J
Tip: Snap the clevis shut and locked,
then make sure to secure the it with the
rubber O ring to keep it from coming
loose.
 





Preflight.
J
Important ESC and model information
1. The ESC included with the WACO has a safe start. If the motor battery is connected to
the ESC and the throttle stick is not in the low throttle or off position, the motor will
not
start until the throttle stick is moved to the low throttle or off position. Once the throttle
stick is moved to the low throttle or off position, the motor will emit a series of beeps.
Several beeps with the same tune means the ESC has detect the cells of the battery.
The count of the beeps equal the cells of the battery. The motor is now armed and will
start when the throttle is moved.
2. The motor and ESC come pre-connected and the motor rotation should be correct.
If for any reason the motor is rotating in the wrong direction, simply reverse two of the
three motor wires to change the direction of rotation.
3. The motor has an optional brake setting. The ESC comes with the brake switched off
and we recommended that the WACO be flown with the brake off. However, the brake
could be accidentally switched on if the motor battery is connected to the ESC while the throttle
stick is set at full throttle. To switch the brake off, move the throttle stick to full
throttle and plug in the motor battery. The motor will beep one time. Move the throttle
stick to low throttle or the off position. The motor is ready to run and the brake will be
switched off.
4. Battery Selection and Installation. We recommend the 11.1 V 1800mAh 25C(150g/5.3oz)
Li-Po battery. If using another battery, the battery must be at least a 11.1 V 1800mAh 25C
battery. Your battery should be approximately the same capacity, dimension and
weight as the 11.1V1800mAh 25C Li-Po battery to fit in the fuselage without changing
the center of gravity significantly.
5. No beeps from the motor means you need to calibrate the throttle or restore the factory setup
defaults.
How to calibrate the throttle:
1. Power on your Transmitter
2. Set the Throttle stick all the way up to 100%
3. Power up your aircraft.
4. Wait about 2 seconds and you will hear 2 beeps, immediately after the first beep,
bring your throttle stick all the way down to 0%.
5. You will hear a single initializing beep.
6. Power down your Aircraft then Transmitter.
7. Power on your Transmitter first then the Aircraft and you should be all set.
How to restore ESC settings:
Repeat the
How to calibrate setting, but the restoring step holds
more audible tone accounts, please refers to ESC manual to set the ESC, every signal means a
tone in the manual. For example, the mark"* ___ *" means a tone. When you hear the fourth tone
in the restore step, bring your throttle stick all the way down to 0%.
Caution: If you try to weld a new connecter 3.5 Golden plug, XT 60 or a Dean plug. Please refer
to the polarity on your battery and make sure you do not weld the connector pole in reverse, or
the short circuit will ruin your battery and the ESC.
6. The specification list of the model is as follows:
:
1030mm /40.6 in
:
810mm /32.3 in
:
1080g/38.1oz
:
11.1V 1800mAh Li-Po Battery
Wingspan
Length
Weight
Battery
ESC
:
35A
Motor
:
Wing Area
Wing Load
RC System:
3536-850kv
30.0dm'
36.0g/dm'
4 Channel, 4 Servos
And 1 ESC/BEC


Preflight
J
The transmitter and model setup
CAUTION: To prevent personal injury, DO NOT install the propeller assembly onto the
motor shaft while testing the control surfaces . DO NOT arm the ESC and do not turn on
the transmitter until the Transmitter Manual instructs you to do so.
Tips:
Make sure all control sticks on your radio are in the neutral position (rudder,
elevator, ailerons) and the throttle in the OFF position. Make sure both ailerons
deflect up and down (travel) equally. This model tracks well when the left and
right ailerons travel equally in response to the control stick.
1. Move the controls on the transmitter to make sure aircraft control surfaces move in
correct direction. See diagrams below. You may have to reverse the channel.
Refer the Transmitter's Manual.
Bank Left
Bank Right
Climb
Descend
Steer/Yaw Left
(')
Steer/Yaw Right
I «
AiIerons
Elevator
Steering
Rudder


Preflight
J
2. Make sure all servo arms are fully vertical. If not, adjust the servo arm by using the trim
function on your radio. Note: For computerized transmitters, use the servo/channel
sub-trim feature to make each servo arm fully vertical.
3. The standard hole settings for linkage connections are shown by the black arrows in the
the diagram below. You can move the linkage to different hole positions to
increase
control surface travel and increase the aerobatics of the airplane.
 

0
0
 


4. Align ailerons with the wing root by turning the clevis clockwise and counterclockwise
on the linkage, carefully open the clevis fork and put the clevis pin in the desired hole
of the control horn.
Note: Please secure the clevis with provided piece of tube after the alignment of the
surface is completed.
Adjust the control connector on the servo arm to align the elevator and the rudder well.
Note: Make sure the tail wheel align with the fuselage centerline by adjusting the
connector on the linkage rod.
\
\
e 1,

/',
I
,I I
I •


OSBY
Preflight J
Check the control throws : The suggested control throw settings for RocHOBBY Waco
are as follows (Dual rate settings):
High Rate Low Rate
Elevator
Aileron
Rudder
15mm up/down
18mm up/down
12mm left/right
10mm up/down
12mm up/down
8mm left/right
Tips: For the first flight, fly the model in low rate. The first time you use high rates, be sure to
fly at low to medium speeds. High rates, as listed, are only for EXTREME
maneuvering.
Check the motor 's Rotational Direction
1. The motor should rotate counter clockwise
when viewing the plane from the front.
0 1
Propeller Installation
1. Key the propeller assembly onto the motor
shaft. Make sure the hub is fully keyed
on to the hex base of the prop shaft.
0
2. Hand tighten the spinner, make sure it
is tight enough.
Aileron Linkage Installation
1. Put the Z-bend end of the aileron linkage
into the eyelet on top of lower wing
aileron, it is a tight fit and should allow
the linkage to move just slightly within
the hole to avoid binding up.
0

