Rocker MultiVac 310-MS User manual

INSTRUCTION MANUAL
Multi-Branch Manifold and Filtration System
Model No.
                                 
MultiVac 310 / 610 - MS
MultiVac 300 / 600 - MS
MultiVac 300 / 301 / 600 / 601 - MB
MultiVac 310 / 610 - MS - T / A
MultiVac 301 / 601 - MB - T / A

1
Important Notice
This instrument is designed for laboratory usage only. Please read this manual carefully before
installing and operating. The instrument shall not be modified in any way. Any modification will void
the warranty and may result in potential hazard. We are not responsible for any injury or damage
caused by any non-intended purposes and modifying the instrument without authorization.
1. Check the voltage specified on the name plate and ensure it matches the line voltage in your
location.
2. Install the instrument in a clean, dust-less and ventilated area under 40°C.
3. Never use the pump with any chemical, corrosive, flammable or toxic material.
4. Please use liquid pump with manifold and membrane to prevent clogging.
5. The protection device of Rocker 400 vacuum pump:
- To ensure proper function of the ProteTM protection device, the pump must be installing on a
flat level surface and should not be moved when operation. If the buoy closes during operation,
it must be manually reset by uninstalling and reinstalling the filter cartridge.
- The filter cartridge is used to absorb moisture and dust. Please replace the cartridge to maintain
pumping efficiency when it becomes dirty or color-changing.
- The pump has a thermal protection device that automatically shuts off when overheated.
6. Do not use any lubricant, which may damage the pump.
7. In case of any damage, please contact the manufacturer or your service agent for service to
avoid hazard.
8. Please discard packing material according to local related regulations.
9. Operating condition
(a) Ambient temperature: 5~ 40 °C
(b) Relative humidity: 80% RH Max.
(c) Power supply of Alligator 200: 100-240V~, 50/60Hz, 44W
Power supply of Rocker 400: 100-120V~, 50/60Hz or 200-240V~, 50/60Hz
(d) Altitude: up to 2000 m
(e) Pollution degree: II
(f ) Alligator 200: IP64, Rocker 400: IP30
(g) Overvoltage category: I
(h) Indoor use

2
Unpacking
Please check if the package is complete without any damage before unpacking. When unpacking,
please make sure you have all accessories that indicated on the list. If there is any problem, please
keep the serial number along with packing case and contact your local distributor immediately for
assistance.
MultiVac 300 / 310 - MS MultiVac 600 / 610 - MS
MultiVac 300 - MB MultiVac 600 - MB
MultiVac 310 - MS
MultiVac 610 - MS
MultiVac 300 - MS
MultiVac 600 - MS
MultiVac 300 - MB
MultiVac 600 - MB
V
V
V
V
V
V
3 Places Aluminum Manifold
6 Places Aluminum Manifold
3 Places Stainless Steel Manifold
6 Places Stainless Steel Manifold
3 Places Stainless Steel Manifold
6 Places Stainless Steel Manifold
Stopper
Adaptor
Standard Package Includes:
SF
Adaptor
I. Multi-Branch Manifold
Branches / Material

3
MultiVac 301 - MB
MultiVac 301 / 601 - MB - A MultiVac 310 / 610 - MS - A
MultiVac 601 - MB
MultiVac 301 - MB
MultiVac 601 - MB
V
V
100 ml * 3
100 ml * 6
3 Places Stainless Steel Manifold
6 Places Stainless Steel Manifold
Stainless Steel
Funnel
Standard Package Includes:
SF
Adaptor
Branches / Material
MultiVac 301 - MB - A
MultiVac 601 - MB - A
x 1
x 1
x 1
x 1
x 1
x 1
MultiVac 301 / 601 - MB, 3 / 6 Places Stainless Steel Manifold
Alligator 200, Diaphragm Liquid Pump
Dragon 100, Torch Burner
Pall, MCE Membrane, 47 mm, 0.45 μm, 200/PK
Silicone Tube
Instruction Manual
Standard Package Includes:Model
Model
II. Multi-Branch Manifold with Funnels
III. Vacuum Filtration System
• Manifold with Alligator 200 Diaphragm Liquid Pump

4
MultiVac 301 / 601 - MB - T MultiVac 310 / 610 - MS - T
• Manifold with Rocker 400 Vacuum Pump
MultiVac 310 - MS - A
MultiVac 610 - MS - A
x 1
x 3 / 6
x 1
x 1
x 1
MultiVac 310 / 610 - MS, 3 / 6 Places Aluminum Manifold
MF 3, 300 ml Magnetic Filter Holder with Lid Kit
Alligator 200, Diaphragm Liquid Pump
Silicone Tube
Instruction Manual
Standard Package Includes:Model
MultiVac 301 - MB - T
MultiVac 601 - MB - T
x 1
x 1
x 1
x 1
x 1
x 2
x 1
MultiVac 301 / 601 - MB, 3 / 6 Places Stainless Steel Manifold
Rocker 400, Oil Free Vacuum Pump
4000 ml PP Vacuum Bottle with drain
Dragon 100, Torch Burner
Pall, MCE Membrane, 47 mm, 0.45 μm, 200/PK
Silicone Tube
Instruction Manual
Standard Package Includes:Model
MultiVac 310 - MS - T
MultiVac 610 - MS - T
x 1
x 3 / 6
x 1
x 1
x 2
x 1
MultiVac 310 / 610 - MS, 3 / 6 Places Aluminum Manifold
MF 3, 300 ml Magnetic Filter Holder with Lid Kit
Rocker 400, Oil Free Vacuum Pump
4000 ml PP Vacuum Bottle with drain
Silicone Tube
Instruction Manual
Standard Package Includes:Model

5
Stainless Steel Multi-Branch Manifold
Rocker 400 Oil Free Vacuum Pump Alligator 200 Diaphragm Liquid Pump
Aluminum Multi-Branch Manifold
• Adjustable vent valve exits only on stainless steel manifold.
Main Part Diagram
Control Valve
Handle
Adjustable Vent Valve
1
2
3
DesignationPosition
Quick-Fit Hose Barb
Funnel Adaptor
4
5
DesignationPosition
Power Switch
Air Outlet
Air Inlet
Liquid Inlet (IN)
Liquid Outlet (OUT)
1
2
3
4
5
DesignationPosition
Vacuum Gauge
Moisture Trap
Vacuum Regulator
ProteTM Filter Cartridge
Power Adaptor
6
7
8
9
10
DesignationPosition
3
44
44
2
1
26 3 1
4 5
10
9
7
8
2
11
55

Preparation and Installation of Manifold
Installation and Operation
A. Make sure all control valves are off before use, rotate the control valves
counterclockwise to vertical position for filtration.
B. Change the funnel adaptor to fit the desired funnel or filter holder if necessary.
• Various kind of funnel adaptors are only compatible for Stainless Steel Manifold.
1. No. 8 Stopper Funnel Adaptor
-Compatible with various kinds of filter holders with No. 8 silicone stopper.
2. Rocker SF Funnel Adaptor (Stainless Steel Manifold only)
- Fitting to (left) Rocker SF 100 / 300 / 500 ml funnel and (right) Pall, Sentino® 4870 (100 ml),
4871 (250 ml) plastic funnel.
3. SS316 Adaptor for Millipore Disposable Funnel (Stainless Steel Manifold only)
- Fitting to Millipore, Microfil® disposable plastic funnel 100 / 250 ml.
4. SS316 Adaptor for Sartorius Disposable Funnel (Stainless Steel Manifold only)
- Fitting to Sartorius, Microsart® disposable plastic funnel 16A07.
• How to change the funnel adaptor(s)
1. Loosen the fixing screw on the rear of control valve by L-Type hex key (2 mm).
2. Unscrew the funnel adaptor and change to the desired one.
3. Tighten the fixing screw to prevent new funnel adaptor from rotation.
21
Installation of Various Filter Holder and Funnel
43
6

7
Preparation and Installation of Manifold (continued)
Vacuum Filtration System Operation
C. Connect installed MultiVac manifold to either vacuum pump or liquid pump for filtration.
• Please ensure to install a vacuum bottle between the manifold and vacuum pump to capture the
waste liquid and prevent liquid from being sucked into the vacuum pump.
• The inlet and outlet direction of MultiVac manifold is interchangeable. Please disassembled inlet and
outlet by hands or tool and change to desired direction.
D. The adjustable vent valve can help drain residual liquid in tube and avoid “Water Hammer”.
• Turn the vent valve counterclockwise to drain the remaining liquid out if necessary.
A. Connect the outlet of installed manifold to inlet (IN) of Alligator 200 liquid pump together with silicone
tube as shown below.
• The tube length between manifold and liquid pump should be as short as possible.
• The length of silicone tube can be cut as your needed.
B. Connect a long tube to outlet (OUT) of Alligator 200 and put the other side of tube into sink or a
container to drain and collect the waste liquid.
C. After sample preparation, install the appropriate membrane in filter holder or funnel.
D. Switch on the pump and pour the sample liquid into the funnel and open the control valve to “vertical”
position to start filtration.
E. After finishing filtration, close the control valve and retrieval the membrane.
F. SF stainless steel funnel can be fast flame-sterilized by Dragon 100 torch burner or autoclaved before
proceeding next filtration.
* Warning:
(1) Do not bend silicone tube or squeeze it with heavy objects to avoid poor drainage.
(2) Do not pump dirty or impure solution before ltration to avoid clogging or damaging.
Filtration System Assembly Diagram (Left: Alligator 200; Right: Rocker 400)
I. With Alligator 200 Diaphragm Liquid Pump

A. Connect the installed manifold, vacuum bottle and Rocker 400 vacuum pump with 2 silicone tubes as
shown above.
B. After sample preparation, install the appropriate membrane in filter holder or funnel.
C. Switch on the pump and pour the sample liquid into the funnel and open the control valve to “vertical”
position to start filtration.
D. After finishing filtration, close the control valve and retrieval the membrane.
E. SF stainless steel funnel can be fast flame-sterilized by Dragon 100 torch burner or autoclaved before
proceeding next filtration.
1. The pump is not autoclavable. Please clean the surface by pure water or 75% ethanol.
2. While doing filtration with Alligator 200 liquid pump, please pump the pure water to clean the tubing
after every use to prevent any dirty is left over. Keep pumping the air for at least 2 minutes to eliminate
the liquid.
3. While doing filtration with Rocker vacuum pump, please remove the liquid in the moisture trap and
keep pumping the air for at least 2 minutes to withdraw the residual steam.
• Please refer to manual of Rocker Series Vacuum Pump to see how to reset the ProteTM protection
device and replace cartridge.
4. MultiVac manifold, filter holder and vacuum bottle are autoclavable (121°C, 1 bar, 20 min). Please make
sure to rinse manifold with pure water and keep all control valves and vent valve at“OPEN” position to
make a complete sterilization. You can also clean the surface of manifold with pure water or 75%
ethanol.
5. Funnels, support base and membrane support of stainless steel manifold are made of SS316 which can
be fast sterilized by flame or autoclaved.
6. Valve plate(s), O-ring(s), silicone tube(s), muffler and diaphragm are consumables, it is recommended
to replace it on a yearly basis or as needed to ensure good operation.
* Warning: Please ensure the liquid level of moisture trap and vacuum bottle do not exceed safety level.
Failure to comply could result in serious damage to the pump and void the warranty. If it occurs, please
contact the distributor immediately for service.
II. With Rocker 400 Vacuum Pump
Maintenance
8

O-ring of
Funnel Adaptor
O-ring of
Control Valve
O-ring of
Plug
O-ring of
Outlet
Troubleshooting
Problem Reason and Solution
Failed to start
Poor vacuum
Low
ltration speed
Loose plug Reconnect plug to socket firmly.
Wrong voltage Reconnect to power specified on name plate.
Vacuum exists Release vacuum and restart the pump.
Switch is broken Contact distributor for assistance.
Funnel adaptor O-ring is broken Replace the O-ring.
Outlet is blocked Clean or stretch the outlet tube.
Improperly vacuum setting Adjust the vacuum regulator.
Clogged muffler Replace a new muffler.
Air leakage Replace or tighten the tubing and accessories that
possible leaks.
Internal wiring loose Contact distributor for assistance.
Funnel adaptor O-ring is broken Replace the O-ring
Air leakage Replace or tighten the tubing and accessories that
possible leaks.
Unsuitable membrane Change an appropriate membrane.
Membrane is blocked Replace a new membrane.
Improperly vacuum setting Adjust the vacuum regulator.
Silicone tube is bent too much Replace or stretch silicone tube.
Internal wiring loose Contact distributor for assistance.
9

Ordering Information
RO-OPE180-EN202211-A02
180301-02
180601-02
180300-01
180600-01
180310-01
180610-01
180100-01/03/05
180100-31
181200-01(02)
181200-62
167400-11(22)
167301-06
167301-07
167300-42
167200-48
200300-01
200300-01-P
200500-01
200500-01-P
167120-31
180300-68
167200-38
177100-00
167100-20
167100-52
MultiVac 301-MB, 3 Places SS Manifold with Rocker SF funnel adaptor, 100 ml SF funnel x 3
MultiVac 601-MB, 6 Places SS Manifold with Rocker SF funnel adaptor, 100 ml SF funnel x 6
MultiVac 300-MS, 3 Places SS Manifold with No.8 stopper funnel adaptor
MultiVac 600-MS, 6 Places SS Manifold with No.8 stopper funnel adaptor
MultiVac 310-MS, 3 Places Aluminum Manifold with No.8 stopper funnel adaptor
MultiVac 610-MS, 6 Places Aluminum Manifold with No.8 stopper funnel adaptor
SF Stainless Steel Funnel 100 ml / 300 ml / 500 ml
Stainless Steel Support Screen
Alligator 200, Diaphragm Liquid Pump, AC100-240V, 50/60Hz, US plug (EU plug)
60W Diaphragm Liquid Pump Repair Kit
Rocker 400, Vacuum Pump, AC110V,60Hz (AC 220V,50Hz)
Moisture Trap / Vacuum Regulator for Rocker 300 / 400 / 410
ProteTM Filter Cartridge for Rocker 300 / 400 / 410
Muffler (Air Outlet) for Rocker 300 / 400 / 410
4000 ml Heavy Duty PP Vacuum Bottle with drain
MF 3, Magnetic Filter Holder (300 ml)
MF 3 Pro, Magnetic Filter Holder (300 ml)
MF 5, Magnetic Filter Holder (500 ml)
MF 5 Pro, Magnetic Filter Holder (500 ml)
300 ml Glass Filter Holder for VF 6 / VF 12
Silicone Tube, Ø 8 x 14 mm, 2 m
Silicone Tube, Ø 6 x 12 mm, 1 m
Dragon 100, Torch Burner
PALL, Type A/ E Glass Fiber Discs, 1 um, 100/PK
Pall, GN-6 Metricel® Membrane Disc Filter, grid, 0.45 um, 200/PK

Rocker Scientic Co., Ltd.
Tel: [phone] Fax: [phone]
E-mail:[e-mail] https://www.rocker.com.tw
