The Allen-Bradley Bulletin 1608P ProDySC Dynamic Sag Corrector is
engineered to provide years of trouble-free voltage sag (dip) protection. The
patented ProDySC technology does not use batteries, requires only routine
maintenance, includes three-stage transient voltage surge suppression, and has
unparalleled energy efficiency. Most electronic devices found in industry today
are susceptible to power disturbances. A momentary sag in line voltage can reset
or damage sensitive production equipment. The ProDySC provides
instantaneous dynamic sag correction to help your equipment ride through these
common events. The ProDySC connects normal utility power directly to the
load until a voltage sag occurs. During a sag, the ProDySC inverter is activated-
adding missing voltage to keep the load voltage within the normal range. When
utility power returns to normal, the inverter is deactivated and the ProDySC is
quickly ready to correct the next sag.
The ProDySC reports these voltage sag events through its integrated touch
screen display and provides system status, voltage sag notification and history,
runtime statistics and system history in a simple and intuitive touch-based user
interface.
Safety Considerations The ProDySC is designed to operate in industrial applications. Follow these
guidelines to ensure that the safety and installation of the ProDySC are handled
with appropriate care.
SHOCK HAZARD: The ProDySC has high voltage remaining up to 5 minutes
after disconnection from the AC line. Touching exposed or disconnected
terminals, cables or parts of the ProDySC can lead to serious injuries or even
death. Wait for a minimum of 5 minutes before performing any service or
testing on the ProDySC after power is removed.
Keep the cabinet doors closed to ensure proper cooling airflow and to protect
personnel from dangerous voltages inside the ProDySC.
ATTENTION: To reduce the risk of fire or electric shock, install this ProDySC in a
temperature and humidity controlled, indoor environment, free of conductive
contaminants.
•Avoid installing the ProDySC directly near heat-emitting equipment such as ovens, heaters, or
furnaces.
•Ambient temperature must not exceed 40°C (104°F).
•Do not operate near water or excessive humidity (95% max).
•When punching or drilling holes for conduit fittings, take care to avoid dropping metallic particles
inside the enclosure as this can result in electrical damage.
•The system is not intended for outdoor use.
•The operating environment should be maintained within the parameters stated in this manual.
•Only authorized service personnel should perform service on the ProDySC.
•Ensure all power is disconnected before performing installation or service.

6Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 1 Introduction
ATTENTION: Internal components can be easily damaged by electrostatic
discharge (ESD). Do not touch circuit boards or electronic components with
hands or metal objects. Use an insulated screw driver when connecting the
lines.
•The ProDySC is not rated to directly power life support equipment.
•Ensure the area around the ProDySC is clean and uncluttered.
•Observe all DANGER, CAUTION, and WARNING notices affixed to the inside and outside of the
equipment.

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 7
Chapter 2
Installation
Installation Check List Before proceeding, please take a few minutes to review the necessary steps to
install your ProDySC.
•All packing materials and restraints have been removed.
•The ProDySC is placed in its installed location.
•All conduits and cables are properly routed to the ProDySC.
•All power cables are properly terminated.
•A ground conductor is properly installed and terminated.
•If neutral connection is required that it is properly terminated on the
ProDySC.
•The area around the installed ProDySC is clean and dust-free.
•Adequate work space exists around the ProDySC.
•Adequate lighting is provided around the ProDySC.
•Operational checks have been reviewed and completed.
Inspecting and Unpacking •Carefully inspect the outer packaging for evidence of damage during
transit. Do not install a damaged cabinet. Report any damage to the carrier
and contact your local sales or service immediately.
•Check the ProDySC label for correct model number with the packaging
list to ensure you have received the correct voltage, current, and wiring
configurations.
•After removing the packaging material, inspect the contents for any
evidence of physical damage, and compare each item with the Bill of
Lading. If damage has occurred or shortages are evident contact your
carrier immediately.
Location (Environment) The ProDySC must be installed in a protected environment. The location must
provide adequate airflow around the ProDySC in an atmosphere free from
excessive dust, corrosive fumes, or conductive contaminants. Do not operate the
ProDySC in an environment where the ambient temperature or humidity is
beyond the specified limits given in this manual.
Mounting Considerations The ProDySC must be mounted vertically, as shown in the figures, and may be
mounted inside another enclosure if the ProDySC inlet temperature remains at
or below specified limits. Read this entire user manual to understand the
additional space requirements around the ProDySC for power conductor entry,
communications conductors, and airflow. Refer to Specifications and
Dimensions on page 19 for temperature ratings and heat dissipation.

8Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 2 Installation
Mounting the ProDySC Using the 3/8" hardware and four (4) wall mounting brackets supplied, mount
the wall mount brackets to the back of the ProDySC. Mount each bracket to the
back of the ProDySC with a single 3/8"-16 x 1" hex cap head screw. Mount the
brackets so the flat portion of the mounting bracket is against the back of the
ProDySC. Bolt two 2 x 4 pieces of lumber horizontally to the wall using 3/8" by
4" hex-head lag bolts.
Make certain that:
1. The lag bolts line up with the wall studs.
2. The distance between the centers of the pieces of lumber is equal to the
distance between the centers of the mounting holes. Refer to Figure 1.
3. Bolt unit to the 2 x 4 pieces of lumber with (4) 3/8" by 2" long hex-head lag
bolts.
NOTICE: Weights and complete mounting dimensions are provided in Chapter 5
Figure 1 - 25 A Mounting dimensions, in. [mm]
21.00
533
22.50
572
24.00
610
25.35
644
30.00
762
21.00
533
22.50
572
31.13
791
A
12.80
325
13.21
336
13.39
340
.57
14
TYP.
.75
19
1.50
38
.41
10
TYP.
DETAIL A
4 PLACES

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 9
Installation Chapter 2
Figure 2 - 50A Mounting dimensions, in. [mm]
33.00
838
34.50
876
36.00
914
37.36
949
36.00
914
33.00
838
34.50
876
37.13
943
A
12.80
325
13.21
336
13.39
340
.75
19
1.50
38
.57
14
TYP.
.41
10
TYP.
DETAIL A
4 PLACES

10 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 2 Installation
Bypass Switch Installation of the ProDySC with an external maintenance bypass is required to
avoid power interruptions to the critical loads during maintenance, service, or
testing. Mount the bypass close to the ProDySC to provide quick access and
visual coordination when testing or providing service. The 1608P bypass is a wall
mounted enclosure with a 3 position rotary switch. Its dimensions and mounting
locations are shown in Figure 3.
Figure 3 - 25A and 50A bypass mounting dimensions
Bypass Switch Modes The 1608P bypass switch has three modes of operation and is configured as
shown in Figure 4
Figure 4 - Bypass switch and mode operation
NORMAL Mode - Power flows from the utility source
through the ProDySC to the load.
TEST Mode - Power flows directly from the utility to
the load. ProDySC outputs are not connected to the
load. ProDySC inputs have power provided for testing
by a qualified technician.
BYPASS Mode - Power flows directly from the utility
to the load. No power is present on ProDySC inputs or
outputs.
NOTICE: The 1608P bypass switch contacts are designed to make-before-break and will not
disrupt power to the load during any mode transitions. The switch has lockout/tagout (LOTO)
provisions.
12.00
305
16.75
425
4X
.30
8
14.00
356
8.00
203
17.50
445

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 11
Installation Chapter 2
Bypass Switch
Wiring Diagram
The maintenance bypass has input and output terminals labeled and located
inside the bypass enclosure as shown in Figure 5. The neutral connection is
available for 4-wire ProDySC configurations.
NOTICE: All electrical connections must be completed by a qualified electrician, in compliance
with all local codes and the National Electric Code.
Figure 5 - Bypass wiring diagram
Circuit Breaker
Recommendations
Branch circuit protection upstream of the ProDySC is required. Recommended
circuit breakers and maximum allowed circuit breaker ratings are listed in
Table 1 . Branch circuit protection rated less than the ProDySC current rating
may result in nuisance tripping.
Table 1 - Recommended Branch Circuit Protection
Accessing ProDySC
Terminations
Two holes are provided for punch-out locations to provide the appropriate hole
size for conduit fittings in the ProDySC. Take care to avoid dropping any metal
filings inside the enclosure. Metallic contamination will void the product
warranty. See Figure 6 for preferred Input/Output wiring locations.
Figure 6 - Knockout Hole Locations
ProDySC Rating Recommended MCCB
Cat. No. Max. MCCB Rating
25 A 140U-H3C3-C35 35 A
50 A 140U-H6C3-C70 70 A
2X
1.12
28
TOP VIEW

12 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 2 Installation
ProDySC Terminations and
Ratings
A qualified electrician must install the units. To access the ProDySC Electrical
Terminations, turn the two ¼ - turn latches CCW and swing open the door. The
unit is furnished with one of the terminal block configurations as shown in
Figure 7. For power cable termination specifications see Ta ble 2 for the 25A rated
units andTable 3 for the 50A rated units.
Figure 7 - Input/Output terminal locations
Input:
•Ground (Earth): Connect the safety ground conductor to the ground stud.
•3-Wire Input: Connect source L1, L2, and L3 to terminals labeled L1, L2, and L3
respectively.
•4-Wire Input: Connect source L1, L2, L3, and Neutral to terminals labeled L1,
L2, L3, N respectively.
Output:
•Terminal blocks are provided marked X1, X2, X3 and N (if used) as shown
inFigure 7 If there are multiple loads, a separate distribution box must be provided
so that there is only one set of output wires terminated inside the ProDySC
enclosure.
USER INTERFACE
TOUCHSCREEN DISPLAY
AC INPUT AND LOAD CONNECTIONS
LOCATED BEHIND DOOR ON MAIN
ELECTRICAL PANEL IN THIS AREA.
GROUND STUD LOCATED
BEHIND DOOR ON MAIN
ELECTRICAL PANEL IN THIS AREA.
3-WIRE CONFIGURATION
X1 X2 X3 L1 L2 L3 GR
4-WIRE CONFIGURATION
X1 X2 X3 N N L1 L2 L3 GR
ATTENTION: All electrical connections must be completed by a qualified
electrician, in compliance with all local codes and the National Electric Code
IMPORTANT
4-wire ProDySCs (units with “… V4” in their part number) must also have a
neutral connected to the neutral terminal block. The neutral terminal block
is labeled “N”. Neutral must be connected for these units to operate properly.
IMPORTANT
The 480V 3 phase 3W ProDySC has not been evaluated by Underwriter's
Laboratories, Inc.® for connection to a corner-grounded delta power source.

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 13
Installation Chapter 2
Table 2 - ProDySC 25 Amp Power Cable Terminations
Table 3 - ProDySC 50Amp Power Cable Terminations
3 Wire with a Ground
Terminal
Connection Function Terminal Marking Wire Range AWG (mm)
Torque lb-in
(Nm)
AC Input Phase A, B, C L1, L2, L3 24- 8 (0.5-6) 7.1- 8.9
(0.8-1)
Ground ¼-20 Stud 65
(7.3)
AC Output Phase A, B, C X1, X2, X3 24-8 (0.5-6) 7.1- 8.9
(0.8-1)
Ground ¼-20 Stud 65
(7.3)
4 Wire with a Ground
AC Input Phase A, B, C L1, L2, L3 24- 8 (0.5-6) 7.1- 8.9
(0.8-1)
Ground ¼-20 Stud 65
(7.3)
Neutral N 10-0 (6-50) 24.9- 26.7
(2.8-3)
AC Output Phase A, B, C X1, X2, X3 24- 8 (0.5-6) 7.1- 8.9
(0.8-1)
Neutral N 10-0 (6-50) 24.9- 26.7
(2.8-3)
Ground ¼-20 Stud 65
(7.3)
3 Wire with a Ground
Terminal
Connection Function Terminal Marking Wire Range
AWG (mm)
Torque lb-in
(Nm)
AC Input
Phase A, B, C L1, L2, L3 10-0 (6-50) 24.9-26.7
(2.8-3)
Ground ¼-20 Stud 65 (7.3)
AC Output
Phase A, B, C, X1, X2, X3 10-0 (6-50) 24.9-26.7
(2.8-3)
Ground ¼-20 Stud 65 (7.3)
4 Wire with a Ground
AC Input
Phase A, B, C
and Neutral L1, L2, L3, N 10-0 (6-50) 24.9-26.7 (2.8-3)
Ground ¼-20 Stud 65 (7.3)
AC Output
Phase A, B, C
and Neutral X1, X2, X3, N 10-0 (6-50) 24.9-26.7 (2.8-3)
Ground ¼-20 Stud 65 (7.3)
WARNING: The ProDySC must be safety-grounded according to the National
Code. In addition, all local, state, and federal regulations applicable to the
installation of electrical systems as well as accident prevention regulations
must be strictly observed.

14 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 2 Installation
Notes:

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 15
Chapter 3
Communications
Both dry contacts (relays) that indicate status and a Serial Communications Port
(RS-232) are available for monitoring the ProDySC.
Dry Contacts Three relay contacts indicate ProDySC status. The contacts are form A and close
upon occurrence of the named event: (a) any SAG EVENT, when rms input
voltage drops below 88.5% of rated value; (b) OUTPUT OK, when output
voltage remains between 87% and 110%; and (c) a system ALARM event. The
relay contact ratings are 24V at 1 amp.
•For access, remove the Communications Port cover (See Figure 8).
•A removable connector (plug) is provided to facilitate wiring.
•All wiring is to be Class 2, limited to 24 Volts, AC or DC.
•Acceptable wire gauges range from 24AWG to 12AWG (0.2-2.5 mm2).
•Torque connections to 4.5-5.3 lb-in (0.5 - 0.6 N-m).
•For permanent installations, a standard conduit knockout is located within
the wiring area (SeeFigure 8).
Figure 8 - Access Cover Location
.875
22
CONDUIT
KNOCKOUT
COMMUNICATIONS
PORT COVER.

16 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 3 Communications
Serial Communications Port The ProDySC serial port is a DE-9 female connector. The pin-out follows
standard RS-232 protocol: pin 2 is RxD, pin 3 is TxD and pin 5 is common
(return). All other pins are unused. Contacts are galvanically isolated from the
system power and grounds.
•Protection: The RS-232 port is ESD-protected to 15kV
•Protocol: 57.6k bps, 8 data bits, one stop bit, no parity, flow control off
•Data packets are SLIP encoded (with 2 byte length field)
•Data accessible through this port includes line and load voltages, line and
load currents, status, and event and diagnostic logs.
•Consult Rockwell Automation technical support for specifications to the
ProDySC SLIP protocol.
Figure 9 - Serial Communications Port

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 17
Chapter 4
Applying Power
•Verify that the ProDySC voltage rating matches the source voltage.
•Before applying power to the ProDySC, make certain there are no metal
filings or any conductive debris in or on any components inside the
ProDySC.
•Ensure that all input/output wiring including grounding has been
completed and that all access doors are closed.
•Place the maintenance bypass in “Bypass” mode.
•Apply power from the upstream branch protection device. Power will flow
through the maintenance bypass directly to the load.
•Place the maintenance bypass in “Test” mode. The ProDySC touchscreen
will become active but the load will still be powered through the bypass.
•Ensure that the touchscreen displays “OK” in the upper left corner and
that the nominal voltage, current, and frequency in the status display are
correct
•If a “Critical” or “Fatal” system event appears on the touch screen (1) place
the maintenance bypass switch in BYPASS and (2) call for technical
support
•Place the maintenance bypass in “Normal” mode.
•Verify that the output (load) voltage is present and within its nominal
rating.
•If a “Critical” or “Fatal” system event appears on the touch screen (1) place
the maintenance bypass switch in BYPASS and (2) call for technical
support.
ATTENTION: For Information regarding the operation of ProDySC, including information on
the display screen and maintenance, see Publication 1608P-UM001_-EN-P.

18 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 4 Applying Power
Notes:

Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014 19
Chapter 5
Specifications and Dimensions
Table 4 - Technical Specifications
Electrical Input/Output (Normal Mode—Static Switch)
Connection Configuration Series-connected with load. Under normal line condition, the static switch passes utility voltage directly to the load
Standard Input Voltages 3 : 208, 380, 400, 415, 480V1
Voltage Range ± 10%
Current Overload (Static Switch) 150% @ 30Sec., 400% @ 5 Sec., 600% @ 0.5 Sec.
Frequency 50/60 Hz Auto Sensing
Frequency Range (tracking) 45 to 65 Hz
TVSS Built-in 3-Layers consisting of MOVs & Capacitors
Efficiency > 99% @ 480V
Electrical Output (Sag Correction Mode - Inverter)
Output Voltage Pre-sag rms voltage
Voltage Regulation +5%-13% of nominal
Output Current 2Rated RMS (25A or 50A). Not rated for DC loads: max. allowable 2% DC loading
Crest Factor (at nameplate rms load) 1.45
Voltage Waveform Sine wave
Voltage Sag Correction Times
Single Event
3 phase 87% to 50% Voltage Remaining 5 seconds
All three phases to zero voltage remaining 50ms or 200ms (SR or ER). Based on load at nameplate ratings with a power factor of 0.7
Multiple Event
Max Sag Correction Time 5 seconds cumulative usage
Sequential Sag Recovery 0 seconds (assuming cumulative run-time available)
Full Recovery Time Max 5 minutes
Mechanical
Enclosure Ratings NEMA 1 (IP20)
Cable Entry Top
Cooling Filtered Forced Air
Access Front for servicing and connections
Bypass (External) Panel mounted for PM or servicing ProDySC
Environmental
Ambient Temperature 0 to 40°C
Storage Temperature -40°C to 75°C
Relative Humidity 0 to 95% non-condensing
Altitude Rated current available to 1000m (3300ft). De-rate output current 10% per 1000m, from 1000m to 3000m (9900ft).
Safety
Agency Approvals cULus Listed
1. ProDySC has not been evaluated for use in Corner Grounded or Ungrounded Delta Power Systems
2. When using ProDySC with motor drive loads, either insert 3% to 5% line reactance at ProDySC output or limit motor drive loads to 60% of ProDySC rating

20 Rockwell Automation Publication 1608P-IN001B-EN-P - May 2014
Chapter 5 Specifications and Dimensions
Heat Dissipation
Approximate Dimensions
Dimensions are shown in inches (millimeters). Dimensions are not intended to be used for
manufacturing purposes.
Rating
(A) Heat Loss (W) Heat Loss (Btu/h) Efficiency (%)
Standard Run-time (SR)
25 280 957 97.8%
50 350 1196 97.2%
Extended Run-time (ER)
25 420 1435 98.2%
50 560 1913 97.7%
Rating
(A) H x W x D
in. [mm]
Weight
lbs.[kg]
Standard Run-time (SR)
25 32 x 26 x 14 [813 x 660 x 356] 277 [126]
50 38 x 38 x 14 [965 x 965 x 356] 330 [150]
Extended Run-time (ER)
Voltage independent; may be either 3 or 4 wire
25 32 x 26 x 14 [813 x 660 x 356] 307 [140]
50 38 x 38 x 14 [965 x 965 x 356] 398 [181]
