Rockwell Automation Allen-Bradley CENTERLINE 2500 User manual

CENTERLINE 2500 Low
Voltage Motor Control Centers
Bulletin Number 2500
Installation Instructions Original Instructions

2Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
CENTERLINE 2500 Low Voltage Motor Control Centers Installation Instructions
Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to familiarize
themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws, and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required to
be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use
or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or liability for
actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or software
described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation, Inc., is
prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 3
Table of Contents
Preface
About This Publication . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Download Firmware, AOP, EDS, and Other Files . . . . . . . . . . . . . . . . . . . . 7
Summary of Changes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Chapter 1
System Overview ArcShield Rating . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
IntelliCENTER Software. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
IntelliCENTER Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
IntelliCENTER Software . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Structure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Typical Column Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Technical Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Nameplate Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
MCC Column-number Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
ArcShield Labels . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Chapter 2
Receiving, Handling, and Storage Receiving . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Handling. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Chapter 3
Install Columns Location Planning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
ArcShield™ Clearance Space . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Remove Packing Materials . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Locate Bus Splice Kits . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Removing the Covers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Position the Motor Control Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Secure a Motor Control Center . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Securing Methods . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Seal IP54 Enclosures Before Connection . . . . . . . . . . . . . . . . . . . . . . . 27
Secure Single Front, One Column-wide Shipping Blocks . . . . . . . . 27
Secure Single Front, Two Column-wide Shipping Blocks . . . . . . . . 28
Secure Double Front, One Column-wide Shipping Blocks. . . . . . . . 29
Secure Multiple Column-wide Shipping Blocks . . . . . . . . . . . . . . . . . 30
Join Columns . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Join Back-to-back Columns in a Double Front Configuration . . . . 34
Join Side Columns in Single Front and Double Front
Applications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Seismic Capabilities . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36

4Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Splice the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Access the Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Splicing The Power Bus . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Splice the Protective Earth (PE) Conductor. . . . . . . . . . . . . . . . . . . . . 46
Control and Network Cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Torque Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Chapter 4
Install Cable Install ArcShield Protection After Wiring. . . . . . . . . . . . . . . . . . . . . . . . . . 49
Lugs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Incoming Line Lug Compartment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Main Disconnecting Means . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Cable Bracing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Secure Load Wires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
Chapter 5
Door Latches, Operator Handles,
and Unit Interlocks
Height Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Door Latches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Quarter-turn Door Latches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
ArcShield Door Latches . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Rotary-operator Handles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
Small Rotary-operator Handles (Cat. Nos. 140M-SB and
140M-SY) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Medium Rotary-operator Handles (Cat. Nos. 140U-PB and
140U-PY). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Large Rotary-operator Handles (Cat. Nos. 140U-HM4 and
140U-HM4E) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Unit Interlocks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Chapter 6
Install and Remove Units Unit Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Withdrawable Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Components of Withdrawable Units with SecureConnect . . . . . . . 68
Withdrawable Unit Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Operating Positions for All Withdrawable Units . . . . . . . . . . . . . . . . 72
Safety Guidelines to Install and Remove All Withdrawable Units . . . . 75
Insert a Withdrawable Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Remove a Withdrawable Unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Remove the Unit Door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Multiple Module Unit Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
One Module Unit Doors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Chapter 7
Commissioning Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Pre-commissioning Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Commissioning Procedure. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 5
Chapter 8
Maintenance Establish a Maintenance Program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Suggested Maintenance Guidelines. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Chapter 9
IntelliCENTER Options EtherNet/IP Motor Control Centers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Connection Count . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Cable Length Limitations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Cable Routing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Add an MCC Unit to an EtherNet/IP System . . . . . . . . . . . . . . . . . . . 91
Ethernet Power Supply. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Connect Power Supplies–Remote or in the MCC Lineup . . . . . . . . . 92
Network Power Supply and the Protective Earth Circuit . . . . . . . . . 92
Connecting Two Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
System Design Installation Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . 93
EtherNet/IP Software Installation Checklist. . . . . . . . . . . . . . . . . . . . 93
DeviceNet Motor Control Centers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Preparing a DeviceNet System for Commission . . . . . . . . . . . . . . . . 94
Terminating Resistors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Joining DeviceNet Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
DeviceNet Power Supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Connect Power Supplies–Remote or in the MCC Lineup . . . . . . . . . 96
Network Power Supply and the Protective Earth Circuit . . . . . . . . . 97
Connecting Two Power Supplies . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Electronic Data Sheets (EDS). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Where to Find EDS Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Installing EDS Files . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Finding EDS Files for Other Devices. . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Uploading EDS Files from the Device. . . . . . . . . . . . . . . . . . . . . . . . . . 99
Appendix A
Worksheets Sample MCC Layout Worksheet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Appendix B
Cable Entry and Exit Points . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

6Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Notes:

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 7
Preface
About This Publication This publication provides procedures to the following:
• How to receive and handle a CENTERLINE® 2500 shipment.
• How to install the received columns.
• How to install cables.
• How to access internal components.
• How to install and remove units.
• How to start up (commission) a newly installed motor control center.
• How to maintain the motor control center.
Download Firmware, AOP,
EDS, and Other Files
Download firmware, associated files (such as AOP, EDS, and DTM), and access
product release notes from the Product Compatibility and Download Center at
rok.auto/pcdc.
Summary of Changes This publication contains the following new or updated information. This list
includes substantive updates only and is not intended to reflect all changes.
Topic Page
Replaced E1 Plus and E3 Plus with E100™ as an available electronic overload relay. 10
Added last sentence to Locate the Bus Splice Kits subsection. 23
Added step 4 to the Remove the Covers subsection. 24
Added the Important table to step 4 of the Position the Motor Control Center subsection. 25
Swapped dimensions between columns A and B in Figure 10. 26
Removed IP42 from the Seal IP54 Enclosures Before Connection title and added it to the Tip table. 27
Added the introductory sentence to the Join Columns section. 34
Added the Join Back-to-back Columns in a Double Front Configuration subsection. 34
Revised step 4 to include the cross-reference to more information. 35
Added Table 7 to the Splice Kit Contents subsection. 41
Added Important information about crowfoot socket wrenches recommended in Figures 20 and 21. 44, 45
Changed the Tip table to another Important table in the Lug section, and added the second sentence. 50
Reduced maximum torque from 4.5 to 4 Nm for M6 bolts in Table 9. 52
Added SecureConnect™ content to Withdrawable Units section. 67
Added Components of Withdrawable Units with SecureConnect subsection. 68
Added SecureConnect information to Operating Positions for All Withdrawable Units subsection. 72
Revised step 11 to check factory-set trip settings for application requirements. 81
Added sub-steps b and c to step 18. 81
Updated the website URL address and tool to estimate the EtherNet/IP connections for a network. 89

8Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
You can view or download publications at rok.auto/literature.
Resource Description
Receiving, Handling, and Storing CENTERLINE® 2500 motor control centers,
publication 2500-IN002 Provides information to receive, handle, and store CENTERLINE 2500 Motor Control Centers
(MCCs).
CENTERLINE 2500 EtherNet/IP™ Motor Control Centers, publication 2500-TD003 Provides information about EtherNet/IP MCCs.
EtherNet/IP Network Devices User Manual, ENET-UM006 Describes how to configure and use EtherNet/IP devices to communicate on the EtherNet/IP
network.
Ethernet Reference Manual, ENET-RM002 Describes basic Ethernet concepts, infrastructure components, and infrastructure features.
CENTERLINE 2500 DeviceNet™ Motor Control Centers, publication 2500-TD002 Provides information about DeviceNet MCCs.
System Security Design Guidelines Reference Manual, SECURE-RM001 Provides guidance on how to conduct security assessments, implement Rockwell Automation products in a secure system, harden the control system, manage user access, and dispose of
equipment.
DeviceNet Media Design User Manual, publication DNET-UM072 Provides information to design, install, and troubleshoot a DeviceNet cable system.
IntelliCENTER® Software User Manual, publication MCC-UM002Provides information to install and use IntelliCENTER software on CENTERLINE MCCs.
Industrial Automation Wiring and Grounding Guidelines, publication 1770-4.1 Provides general guidelines for installing a Rockwell Automation™ industrial system.
Safety Guidelines for the Application, Installation and Maintenance of
Solid-state Controls, publication SGI-1.1 Provides general guidelines to install and maintain solid-state control components.
Product Certifications website, rok.auto/certifications Provides declarations of conformity, certificates, and other certification details.

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 9
Chapter 1
System Overview
CENTERLINE® 2500 motor control centers (MCCs) are designed for
applications
that must comply with international standards and practices for
low-voltage motor
control centers. The CENTERLINE 2500 MCC is ideal for
tough
industrial applications where uptime and ease of maintenance is
required.
The CENTERLINE power bus structure distributes line power throughout the
MCC via an isolated bus work structure. A standard, center-fed,
300 A vertical bus supplies power to units above and below the horizontal bus,
which results in an effective 600 A capacity and unrestricted unit
arrangement. An optional 600 A vertical bus provides an effective rating of
1200 A.
ArcShield Rating The CENTERLINE MCC is also available with an ArcShield™ rating. This rating
includes arc-resistant features for enhanced protection if internal arcing faults
happen.
With the standard safety features of the CENTERLINE 2500 MCC, the
ArcShield option provides the following:
•Springlatches
• Reinforced structure
• Pressure relief vent system through the top of the enclosure
• Protection up 300 ms at 480V/65 kA
An ArcShield label is provided on the MCC with information about the
accessibility level and arc fault ratings. See Figure 8 on page 18 for an example
of this rating label and its location.
See Figure 4 on page 14 for the location of ArcShield structure protection and
page 54 for ArcShield door latches.
Table 1 - Conformity Ratings for CENTERLINE 2500 MCC with ArcShield
Value Description
Ratings:
Ue
lp arc
tarc
lpc arc
480V
65 kA
300 ms
65 kA
Protection Personal and assembly protection suitable for limited continued operation; assembly protection is
limited to outgoing units tested for conditional current under arcing conditions.
Requirements
Tested with third-party validation against the IEC/TR 61641 standard that defines tests under
conditions of arcing due to internal fault. Comprehensive tests conducted under Edition 3.0, 2014-1
have passed the requirements for Class A (meets Criteria1…5) for the main bus and unit line side,
and Class C (meets Criteria 1…7) for all unit load side tests.

10 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 1 System Overview
IntelliCENTER Software CENTERLINE 2500 MCCs with IntelliCENTER® software provide an
integrated hardware, software, and communication solution. Its
preconfigured software provides real-time data, trending, component history,
wiring diagrams, user manuals, and spare parts. IntelliCENTER offers plug
and play setup, troubleshooting, hardware configuration changes without
opening enclosure doors, and convenient change tracking. It also provides
intelligent diagnostic and predictive failure information.
IntelliCENTER technology improves the intelligence of your MCC by using
built-in networking to capture information used for predictive maintenance,
process monitoring, and advanced diagnostics.
IntelliCENTER Features
• Built-in networking
- EtherNet/IP™ or DeviceNet™
- Media helps protected behind barriers
- Access ports in wireways
- Topology lets you add and remove devices without interrupting any
other device on the network
• Intelligent motor controls
- PowerFlex® drives
- SMC™-3 and SMC-Flex soft starters
- E100™ and E300™ Electronic Overload Relays
• IntelliCENTER software
- Distributed I/O
- POINT I/O™ system/DSA
- Virtual MCC
- Parameter editor
- Status dashboards
- Documentation management
- Spare parts information
• Factory configuration
- IP address network media validation
- IP address node configuration
- Communication check
- Network commissioning
IntelliCENTER Software
IntelliCENTER MCCs can be provided with preconfigured IntelliCENTER
software. This software views, manages, and configures multiple MCC lineups.
The IntelliCENTER software communication driver lets the software be
installed and operated on EtherNet/IP or DeviceNet. The IntelliCENTER
software can function as a standalone software package or as an ActiveX
control in a Human Machine Interface (HMI).

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 11
Chapter 1 System Overview
Structure CENTERLINE 2500 MCCs offer units with a full complement of AC drives, soft
starters, and other devices. Pluggable power connections on the back of the
unit plug into the vertical bus. A mechanical interlock helps prevent the unit
door from being opened while the main switch is in the ON/I position. An
additional mechanical interlock helps prevent the unit from being withdrawn
or inserted when the unit main switch is closed. Separate vertical wireways
isolate control and network cables from power wiring. Units are available as
fixed or withdrawable.
Figure 1 - CENTERLINE 2500 MCC
Dimensions
CENTERLINE 2500 MCCs columns are designed in widths between 500…1000
mm. Each column is 2300 mm high and either 600 mm or 800 mm deep.
Double front
columns are also available. For additional options, see the tables
in Figure 2.
Unit size is described in terms of modules. Each module is approximately 80
mm high. Columns can accommodate 24 modules of different unit
combinations.

12 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 1 System Overview
Figure 2 - Typical Column Dimensions
Table 2 - Widths
Column
with Wireway
Column without
Wireway
Fixed or
Withdrawable
Unit Width(1)
Vertical
Wireway
Width(2)
Total
Column
Width
Fixed
Unit
Width(3)
Total
Column
Width
500
200 700 500 500
300 800 600 600
400 900 700 700
500 1000 800 800
900 900
1000 1000
(1) Available from 1…24 modules.
(2) Recommended minimum wireway widths
for the various forms of separation:
• For 3B, 300 mm wide
• For 4B Type 5, 400 mm wide
• For 4B Type 7, 500 mm wide
(3) Applies to a full column (24 modules).
Table 3 - Depth
Single-front Double Front
600 1200
800(1)
(1) Single-front IP42 configurations with
a 3200 A bus (air circuit breaker
units only) or 4000 A bus (all unit
types) require a 100 mm air gap
behind the column. In these
instances, the overall depth is 900
mm.
1600(2)
(2) Double front IP42 configurations
with a 3200 A bus (air circuit
breaker units only) or 4000 A bus
(all unit types) require a 400 mm air
gap between the rear of the
columns. In these instances, the
overall depth is 2000 mm.
Table 4 - Thickness, Nominal
Description Measurement
Side plates (all depths) 2
Back plates (all widths) 2.5
Bottom mounting channel(1)
(1) Front and rear.
3.5
Top plates (all widths) 2
Bottom plates 2
Horizontal wireway covers 2
Wireway doors 2
Doors(2)
(2) 2 mm for 1…22 modules, 2.5 mm for 24 modules.
2, 2.5
ArcShield 480V doors(3)
(3) 2.5 mm for 1…22 modules, 3 mm for 24 modules.
2.5, 3
Table 5 - Weight, kg(1)
Column Depth
Column Width 600 mm 800 mm
600, 700 350 450
800 400 525
900 450 575
1000 500 650
(1) Weights that are shown are for an MCC column
with six units. Many factors (number of units,
horizontal power bus, wireway width, column
depth, and shipment packaging) affect the
actual weight. The packing slip shipped with an
MCC unit shows the exact shipping weights.
Table 6 - Height
Dimension Measurement
Total unit height
• With top gland plate
• With ventilation hood
•Withliftangle
• With lift angle on gland
plate
2300
2306
2370
2375
2387
Available unit height 1980
Top horizontal wireway 170
Bottom horizontal wireway 115
External mounting channel 35
All measurements are in mm unless
otherwise specified.
600 mm Deep Withdrawable Column
with a 200 mm Wireway Shown.
170
1980
35
115
500…1000
600 or 800
2300
200…500
500

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 13
Chapter 1 System Overview
Typical Column Construction Columns are rigid, freestanding structures with heavy-duty, external
mounting channels. Columns are secured at the installation site by bolting
through clearance holes in the mounting channel or by welding.
The standard for internal sheet metal parts is Z275 galvanized metal for
Series D CENTERLINE 2500 motor control centers.
Figure 3 - Typical Column
Lifting Angle
Network Wireway
Top Wireway
End Plates
Left Side Plate
Center End
Closing Plate
Bottom Wireway
End Plates
Mounting Channels
Bottom Plates
Bottom Wireway Cover
Right Unit Support and
Vertical Wireway Assembly
Vertical Wireway Door
Top Wireway Cover
Top Wireway Pan
Top Wireway Barrier
Top Plate
Optional ArcShield
Center End Closing
Plate Insulator
Horizontal
Power Bus
Single Unit
Support Pan

14 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 1 System Overview
Additional bracing is provided for ArcShield columns.
Figure 4 - ArcShield Column Protection Hardware
Figure 5 - Column Configuration
Door Latch Brackets
See page 49 for more information.
Pressure Relief Plate
See page 21 for more information.
Detail A
Detail B
Detail C
A
B
C
Detail D
D
Center End Closing
Plate with Insulator
Only on end-of-lineup
columns.
See Figure 3 on page 13
for more details.
Frame-mounted Brackets
See page 49 for more
information.
Columns Installed in a Single-front Configuration Columns Installed in a double front Configuration
NOTE: Double front IP42 configurations with a 3200 A bus (air circuit
breaker units only) or 4000 A bus (all unit types) require a 400 mm air
gap between the rear of the columns.
NOTE: Single-front IP42 configurations with a 3200 A bus (air circuit breaker units only)
or 4000 A bus (all unit types) require a 100 mm air gap behind the column.

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 15
Chapter 1 System Overview
Technical Data This table provides the technical specifications for the 2500 MCC.
The following certifications (2500-CT0xx) can be found at the Rockwell
Automation Literature Library: https://www.rockwellautomation.com/global/
literature-library/overview.page.
Standards
EN 60204-1:2006 + A1:2009 Safety of machinery – Electrical equipment of machines; Part 1: General requirements
IEC 61439-1 Low-voltage switchgear and controlgear assemblies; Part 1: General requirements
IEC 61439-2 Low-voltage switchgear and controlgear assemblies; Part 2: Power switchgear and controlgear assemblies
IEC/TR 61641 Ed. 3.0, 2014-1,
parts 1…7 Enclosed low-voltage switchgear and controlgear assemblies; Guide for testing under conditions of arcing due to internal fault
EC Directives
2011/65/EU RoHS Directive
2004/108/EC EMC Directive
2006/95/EEC Low Voltage Directive
Certifications and
Markings
ABS and ABS shipboard 2500-CT015, 2500-CT016, and 2500-CT017
CE Conformance Marked 2500-CT008 and 2500-CT009
China Compulsory Certificate (CCC) 2500-CT010, 2500-CT011, 2500-CT012, 2500-CT013, and 2500-CT022
DEKRA 2500-CT018, 2500-CT019, 2500-CT020, and 2500-CT021
EAC MCC-CT001
SII Approval 2500-CT014
Rated Voltages
Rated operating voltage, UeUp to 690V, 3-phase
Rated frequency, fn50…60 Hz
Rated insulation voltage, Ui1000V, 3-phase
Rated Currents
Continuous current rating, IeHorizontal bus up to 4000 A; vertical bus up to 1200 A per column(1)
Short circuit peak withstand, Ipk Horizontal bus up to 210 kA
Short time withstand rating, Icw Horizontal bus up to 100 kA for 1 second
Neutral (N) Full or half-rated
Creepage Distances
and Clearances
Rated impulse withstand voltage, Uimp 6 kV, 8 kV, or 12 kV
Material group (overvoltage category) IIIa (175 </= CTI < 400)
Pollution degree 3
Bus Material and
Plating
Horizontal power bus Copper (optional tin plating)
Vertical distribution bus Copper with tin plating
Protective earth conductor (PE) Copper (optional tin plating)
Degrees of
Protection IEC 60529 IP20, IP42, or IP54
Forms of Separation IEC 61439-2 Forms 2b, 3b, 4b, or 4b Type 7
Column Dimensions Height, width, and depth See page 12
Units
Module size (approx) 80 mm high x 500 mm wide = 1 module
Modules per column, max 24 of varied unit combinations
Withdrawable unit sizes 1, 2, 4, 6, 8, 10, and 12 modules
Structural Surface
Treatments
Interior Z275 galvanized metal (painted interior available as custom option)
Exterior RAL 7032 Pebble Grey paint (additional colors available by request)
Environment
Storage temperature -25…+55 °C
Operating (ambient) temperature -5…+40 °C(2) with up to 95% noncondensing humidity
Altitude Up to 1000 m without derating: derating over 1000 m
(1) Up to 600 A top and bottom, effective 1200 A per column.
(2) The average temperature over a 24-hour period must not exceed 35 °C.

16 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 1 System Overview
Nameplate Data In compliance with EN 61439-1, each CENTERLINE 2500 MCC column is
supplied with a nameplate on the enclosure or vertical wireway door.
Figure 6 - Column Nameplate
Each unit also has an identification label. On withdrawable units, the unit
identification label is on the interior of the bottom plate of the unit. On fixed
units, the unit identification label is on the interior right side plate.
Figure 7 - Unit Identification Label
MCC Column-number
Sequence
Each CENTERLINE 2500 MCC column nameplate identifies column-number
sequence, for example, MCC column 1 of 1 or 1 of 5. See Figure 6 for where to
find column-number sequence information.
Columns are numbered to match factory-supplied MCC elevation drawings
and to identify MCC columns and units easily. If there are questions about
column numbering during field installation, inspection, or operation, the
following instructions can provide guidance.
Catalog Number/Serial Number
Power Bus Voltage
and Current Rating
Enclosure
Type
Series
Letter
Identifies Column
Sequence Numbering
Catalog Number/Serial Number Unit LocationDevice Type and Rating
Voltage Rating
Order Number
The catalog number or serial number and series letter are required to identify the
equipment properly to sales or factory personnel.
IMPORTANT CENTERLINE 2500 MCCs are designed to function in any column-number
sequence. However, we recommend that columns be installed in
sequential order.
IMPORTANT Leftmost column must be installed in the proper location for the bus to
splice. (Both ends of double-front MCCs must be installed as ends for
splicing.)

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 17
Chapter 1 System Overview
The most important criteria for additions of columns to existing MCCs is
matching the horizontal bus, enclosure type, and network capabilities for the
complete MCC line up. The voltage, current rating, short circuit withstand,
and IP rating for all columns must be consistent.
ArcShield Labels MCC columns with arc proof assembly have a rating label (Detail E in Figure 8
on page 18) below the nameplate. There are also labels on other parts that must
be in place before operating an MCC with ArcShield; see Figure 8 on page 18.
At the end of a lineup, CENTERLINE 2500 MCCs with ArcShield have a back-
corner baffle and insulation on the center side closing-plate; see Figure 4 on
page 14 for more details. They also have external vertical support angles at each
end of the lineup.

18 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 1
Figure 8 - ArcShield Label Locations
C
E
A
B
Top View
Front View – Frame Mount Front View – Withdrawable
E
NOTE: All labels are external except for ‘E.’
A
B
C
D
F
C
DD
F
F
DD E

Rockwell Automation Publication 2500-IN001F-EN-P - April 2021 19
Chapter 2
Receiving, Handling, and Storage
See Receiving, Handling, and Storing CENTERLINE® 2500 Motor Control
Centers Instructions, publication 2500-IN002, for additional instructions.
This publication is shipped with each MCC, attached to the outside of the MCC
within the layer of clear polyethylene encasement (polywrap).
Receiving CENTERLINE 2500 MCCs are shipped upright as one or two column shipping
blocks or two or four double front column shipping blocks. Each CENTERLINE
2500 MCC shipping block is provided with a lifting angle. Each column in a
shipping block is bolted to the shipping skid with removable shipping angles
and covered with clear plastic wrap. Protection is for upright shipping and is
not waterproof or water-resistant. Equipment that extends from the
structures is also protected.
Heavy-duty export packaging is similar to standard packaging, but uses a
polywrap suitable for occasional water spray. In addition, wood framing and
sheeting surround the columns. The heavy-duty export packaging is not
water-resistant, waterproof, or intended for long-term storage.
Upon delivery of the MCC, see the packing slip shipped with your MCC for
sizes and exact shipping weights. Inspect the shipment for lost or damaged
items. If lost or damaged items are detected, see the steps that are described in
publication 2500-IN002.
Handling The following are acceptable methods of handling MCC columns within the
receiving facility. These methods are described in publication 2500-IN002.
• Use of a forklift
• Overhead lifting (crane or hoist)
• Sling lifting
MCC columns must be handled in the upright vertical position. Failure to
comply with this method can lead to busbar, unit, and enclosure damage.
ATTENTION: MCCs are top and front heavy. To avoid personal injury or
structural damage, lift or move the MCC by only the methods that are outlined in
Receiving, Handling, and Storing CENTERLINE 2500 Motor Control Centers,
publication 2500-IN002.

20 Rockwell Automation Publication 2500-IN001F-EN-P - April 2021
Chapter 2
The MCC must remain bolted to the shipping skid until delivered to its final
installation area.
Storage Store CENTERLINE 2500 MCCs, units, and related equipment in a clean, dry
environment with ambient temperatures ranging from -25…+55 °C
(-13…+131 °F).
For short periods (less than 24 hours), temperatures of up to 70 °C (158 °F) are
allowed. Take care to help prevent damage from exposure to excessive
humidity, vibration, and shock.
Store MCCs with the plastic covering in place to help prevent dirt and dust
from entering the structure. Check periodically for condensation build-up and,
if necessary, install space heaters. To order space heaters,
contact your
Rockwell Automation representative
.
ATTENTION: MCCs are top and front heavy. To avoid personal injury or
structural damage, never attempt to lift or move the MCC by any means other
than the methods outlined in Receiving, Handling, and Storing CENTERLINE 2500
Motor Control Centers, publication 2500-IN002.
