Rockwell Automation Allen-Bradley CENTERLINE 2100 User manual

Installation Instructions
CENTERLINE 2100 Low Voltage Motor Control
Centers
Catalog Number 2100

Important User Information
Solid-state equipment has operational characteristics differing from those of electromechanical equipment. Safety
Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication SGI-1.1 available from
your local Rockwell Automation sales office or online at http://www.rockwellautomation.com/literature/) describes some
important differences between solid-state equipment and hard-wired electromechanical devices. Because of this difference,
and also because of the wide variety of uses for solid-state equipment, all persons responsible for applying this equipment
must satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from
the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Allen-Bradley, Rockwell Automation, CENTERLINE, CENTERLINE 2100, ArcShield, and TechConnect are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous
environment, which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death,
property damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the
consequence
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that
dangerous voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that
surfaces may reach dangerous temperatures.
IMPORTANT Identifies information that is critical for successful application and understanding of the product.

Rockwell Automation Publication 2100-IN012D-EN-P - September 2010 3
Summary of Changes
This manual contains new and updated information. Changes throughout this
revision are marked by change bars, as shown to the right of this paragraph.
New and Updated
Information
This table contains the changes made to this revision.
Topic Page
Added information about ArcShield rating Throughout
Added illustrated checklist for ArcShield components 81

4Rockwell Automation Publication 2100-IN012D-EN-P - September 2010
Summary of Changes
Notes:

Rockwell Automation Publication 2100-IN012D-EN-P - September 2010 5
Table of Contents
Preface
About this Publication. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Who Should Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Purchased Components and Additional Instruction Sheets . . . . . . . . . . . 8
Chapter 1
General Information
General Description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Nameplate Data. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
MCC Sequence Numbering. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
UL/CSA Marking. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Short-circuit Rating Label. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
ArcShield Rating Labels. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Series Number and Series ID as Manufactured in the United States. . . 14
Series Lettering - Units and Sections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Receiving, Handling, and Storage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Chapter 2
Installation Procedures
Location Planning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Height Considerations. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Securing an MCC . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Seismic Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Joining and Splicing New MCCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Joining and Splicing Existing MCCs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Joining and Splicing MCCs with ArcShield. . . . . . . . . . . . . . . . . . . . . . . . . 38
Installing and Joining Pull Boxes. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Joining and Splicing NEMA Type 12 MCCs . . . . . . . . . . . . . . . . . . . . . . . 38
Joining and Splicing NEMA Type 3R and Type 4 MCCs . . . . . . . . . . . . 38
Bus Torque Specifications. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Chapter 3
Installing Conduit and Cable
Installing Conduit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Installing Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Chapter 4
Installingand Removing Plug-in
Units
Installing Plug-in Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Remove a Plug-in Unit with a Vertical Operating Handle
from a Section . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Remove a Plug-in Unit with a Horizontal Operating Handle
from a Section. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Remove the Support Pan. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57

6Rockwell Automation Publication 2100-IN012D-EN-P - September 2010
Table of Contents
Chapter 5
Arc Flash Protection Marking
as Required by the National
Electrical Code
Flash Protection Marking Requirement . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Arc Flash Marking Clarification . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Rockwell Automation Services . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Chapter 6
Operator Handle and Unit
Interlock
Defeating the Unit Door Interlock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Defeating the Unit Interlock Lever . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Locking Provisions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Chapter 7
Final Checklist Before
Energizing
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Pre-energizing Check Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Perform the Pre-energizing Check Procedure . . . . . . . . . . . . . . . . . . . . . . . 72
ArcShield Components Checklist . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Required Minimum Electrical Spacing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Chapter 8
Energizing the Equipment
Energize the Equipment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 87
Chapter 9
Maintenance
Maintain the MCC. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Disconnect the Switch and Contact Lubrication . . . . . . . . . . . . . . . . . . . . 91
Use Thermal Infrared or Other Temperature Measurement
Techniques for Preventive Maintenance. . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Chapter 10
Maintenance After Fault
Condition
Maintain the MCC After a Fault Condition. . . . . . . . . . . . . . . . . . . . . . . . 95
Chapter 11
Renewal Parts
Order Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Chapter 12
Parts Illustrations
Typical Section Construction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 99
Typical Construction of a Unit with a Vertical Operating Handle . . . 100
Typical Construction of a Half Space Factor Unit with a Horizontal
Operating Handle and Door Mounted Pilot Devices . . . . . . . . . . . . . . . 101
Typical Construction of a Unit with a Horizontal Operating
Handle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 102
Index

Rockwell Automation Publication 2100-IN012D-EN-P - September 2010 7
Preface
About this Publication
This manual provides detailed installation instructions for installing, using the
operator handle, energizing, and maintaining your CENTERLINE 2100 Motor
Control Center.
Who Should Use This
Manual
This manual is intended for engineers or technicians directly involved in the
installation, connection, energizing, and maintenance of the
CENTERLINE 2100 Motor Control Center.
If you do not have a basic understanding of the CENTERLINE 2100 Motor
Control Center, contact your local Rockwell Automation sales representative for
information on available training courses.
Additional Resources
The following publications supplement this manual. For more information and
further reference, please use these available publications.
Publication Name Publication No.
Arc-Flash Resistant Low Voltage Motor Control Center Designs White
Paper 2100-AP003
Power Factor Correction Capacitors for Bulletin 2100 MCC Starter Units
Application Techniques 2100-AT001
CENTERLINE 2100 Motor Control Centers Joining and Splicing Vertical
Sections Instructions 2100-IN010
CENTERLINE 2100 Motor Control Centers (MCC) Units with Vertical
Operating Handles Installation Instructions 2100-IN014
CENTERLINE Motor Control Centers NEMA Type 12 Sealing Instructions 2100-IN037
Receiving, Handling, and Storing Motor Control Centers Instructions 2100-IN040
CENTERLINE 2100 MCC Instantaneous Trip Motor Circuit Protectors
(MCP) in Combination NEMA Starter, Soft Starter (SMC), and Variable
Frequency AC Drive Units Technical Data
2100-TD001
CENTERLINE 2100 MCC Inverse Time Circuit Breakers in Combination
NEMA Starter, Soft Starter (SMC), and Variable Frequency AC Drive
Units Technical Data
2100-TD002
CENTERLINE Motor Control Centers Power Fuses Product Data 2100-TD003
DeviceNet Motor Control Centers (MCC) Technical Data 2100-TD019
CENTERLINE 2100 Motor Control Center End Closing Plates Installation
Instructions 2100-IN069
CENTERLINE 2100 Motor Control Center (MCC) Units with Horizontal
Operating Handles Installation Instructions 2100-IN060
CENTERLINE Motor Control Centers Mains and Incoming Lines
Dimensions Reference 2100-4.2
CENTERLINE Motor Control Centers Mains and Incoming Lines
Dimensions Reference Document Update 2100-4.2DU1
CENTERLINE Motor Control Centers Installing a Pull Box on a Bulletin
2100 Vertical Section Installation Instructions 2100-5.28
Safety Guidelines for the Application, Installation, and Maintenance of
Solid-state Control Installation Instructions SGI-1.1

8Rockwell Automation Publication 2100-IN012D-EN-P - September 2010
Preface
You can view or download publications at
http://www.rockwellautomation.com/literature. To order paper copies of
technical documents, contact your local Rockwell Automation distributor or
sales representative.
The documents in the following table are referenced in this document and can be
obtained from their respective organizations.
PurchasedComponentsand
Additional Instruction
Sheets
When equipment such as transformers, metering, programmable controllers, or
drives are supplied with the motor control center (MCC), specific manuals and
data sheets are also supplied. These documents should be read and understood
before installing and operating the MCC. Refer to the unit locations of these
devices for their manuals or data sheets.
Resource Website
National Electrical Manufacturer’s Association (NEMA)
•NEMA ICS 1-2000 Industrial Control and Systems: General
Requirements
•NEMA ICS 2.3-1995, Instructions for Handling, Operation and
Maintenance of Motor Control Centers Rated Not More Than 600V
www.nema.org
National Fire Protection Association (NFPA)
•NFPA 70 - National Electrical Code
•NFPA 70A - Recommended Practice for Electrical Equipment
Maintenance
•NFPA 70E - Standard for Electrical Safety in the Workplace
www.nfpa.org
Institute of Electrical and Electronic Engineers (IEEE)
IEEE standard C37.20.7 - IEEE Guide for Testing Metal-Enclosed
Switchgear Rated Up to 38 kV for Internal Arcing Faults
www.ieee.org

Rockwell Automation Publication 2100-IN012D-EN-P - September 2010 9
Chapter 1
General Information
General Description
Allen-Bradley CENTERLINE Motor Control Centers (MCCs) consist of one
or more vertical sections containing electromagnetic or solid state control devices
that are prewired and tested within modular (plug-in) or frame mounted (hard-
wired) units.
CENTERLINE MCCs are designed in standard widths of 20 in. (508 mm), 25
in. (635 mm), 30 in. (762 mm), 35 in. (789 mm), and 40 in. (1016 mm). The
standard front-mounted depths of an MCC are 15 in. (381 mm) and 20 in.
(508 mm), in addition back-to-back mounted depths of 30 in. (762 mm) and
40 in. (1016 mm) are also offered. The standard height of an MCC is 90 in.
(2286 mm). A 70.5 in. (1791 mm) high section is also available. All MCC
sections are supplied with top and bottom horizontal wireways. Sections that are
designed to accommodate plug-in units include a vertical wireway. Each 90 in.
(2286 mm) vertical section can accommodate up to 6.0 space factors or 78 in.
(1981 mm) for units.
Units (buckets) are designed in increments of 0.5 space factors. Each 0.5 space
factor is approximately 6.5 in. (165.1 mm) high. Units are designed as either
removable (plug-in) or frame-mounted (non-plug-in).
Individual units house a wide variety of power and logic devices. Plug-in units are
mounted on unit support pans within the section. Stab assemblies on the back of
the unit plug onto the vertical bus. A mechanical interlock prevents the unit door
from being opened when the disconnect is not in the OFF position. An
additional mechanical interlock prevents the unit from being plugged-in or
unplugged when the disconnect is not in the OFF position.
Line power is distributed throughout the MCC via an isolated bus work
structure. The main horizontal bus is in the center of each section. Standard,
center-fed, 300 A rated vertical bus supplies power to the individual units above
and below the horizontal bus for an effective 600 A capacity, allowing virtually
unrestricted unit arrangement. An optional 600 A vertical bus provides 1200 A
effective rating.
The CENTERLINE MCC is also available with an ArcShield rating. The
ArcShield rating includes arc-resistant features that are intended to help provide
enhanced protection to you during internal arcing faults (when compared to
MCCs that are only designed to meet UL 845 requirements). Arcing faults can
be caused, for example, by accidental touching, closing into faulted lines, or loose
connections. Depending on the application, MCCs with the ArcShield rating can
provide up to Type 2 accessibility per IEEE standard C37.20.7, which helps
protect you when you are at the front, sides, and rear of the enclosure in the
unlikely event of an arcing fault.

10 Rockwell Automation Publication 2100-IN012D-EN-P - September 2010
Chapter 1 General Information
A label on the MCC with the ArcShield rating provides information in regard to
the accessibility level and arc fault ratings.
For more information about accessibility levels, performance, and testing
requirements, refer to IEEE standard C37.20.7, IEEE Guide for Testing Metal-
Enclosed Switchgear Rated up to 38 kV for Internal Arcing Faults.
MCCs with the ArcShield rating provide a reinforced structure and arc-
containment latches on all doors. To help protect you during an arc-fault, arc-
containment latches, when closed and latched properly, allow pressure relief and
help keep the doors from unlatching or detaching from the structure.
Nameplate Data
Each MCC section has a nameplate on the enclosure or vertical wireway door.
The nameplate includes:
•catalog number/serial number.
•series letter of section.
•bus bar voltage and current rating.
•section number.
•UL and cUL certification marking.
•UL registration number.
•enclosure type.
Figure 1 - Section Nameplate
Section Number
UL and cUL Certification Marking
Catalog Number/Serial Number
Series Letter of Section
Bus Bar Voltage
and Current Rating
UL Registration Number
Enclosure Type
