Installation Instructions
SmartGuard 600 Controllers
Catalog Numbers 1752-L24BBB, 1752-L24BBBE
Topic Page
Important User Information 2
North American Hazardous Location Approval 3
General Safety Information 3
About the SmartGuard 600 Controller 5
Before You Begin 7
Set the Node Address 7
Setting the Communication Rate 7
Set the IP Address for Ethernet Communication 8
Install the SmartGuard 600 Controller 9
Mount the SmartGuard 600 Controller 9
Grounding the SmartGuard 600 Controller 10
Connecting a Power Supply 11
Wiring the SmartGuard 600 Controller 12
Making Communication Connections 15
Interpreting the Status Indicators 17
Alphanumeric Status Display 18
Status Indicators 18
Specifications 24
Additional Resources 28

2 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical equipment.
Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls (publication
SGI-1.1 available from your local Rockwell Automation sales office or online at
http://literature.rockwellautomation.com) describes some important differences between solid state
equipment and hard-wired electromechanical devices. Because of this difference, and also because of the
wide variety of uses for solid state equipment, all persons responsible for applying this equipment must
satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many
variables and requirements associated with any particular installation, Rockwell Automation, Inc. cannot
assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application and understanding of
the product.
ATTENTION Identifies information about practices or circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard and recognize the consequences.
SHOCK HAZARD
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that dangerous voltage may be present.
BURN HAZARD
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that surfaces may reach dangerous temperatures.

SmartGuard 600 Controllers 3
Publication 1752-IN001C-EN-P - January 2009
North American Hazardous Location Approval
General Safety Information
The following information applies when operating
this equipment in hazardous locations.
Informations sur l’utilisation de cet équipement en
environnements dangereux.
Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for use in
Class I Division 2 Groups A, B, C, D, Hazardous Locations and
nonhazardous locations only. Each product is supplied with
markings on the rating nameplate indicating the hazardous
location temperature code. When combining products within a
system, the most adverse temperature code (lowest "T" number)
may be used to help determine the overall temperature code of
the system. Combinations of equipment in your system are subject
to investigation by the local Authority Having Jurisdiction at the
time of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne conviennent
qu'à une utilisation en environnements de Classe I Division 2
Groupes A, B, C, D dangereux et non dangereux. Chaque produit
est livré avec des marquages sur sa plaque d'identification qui
indiquent le code de température pour les environnements
dangereux. Lorsque plusieurs produits sont combinés dans un
système, le code de température le plus défavorable (code de
température le plus faible) peut être utilisé pour déterminer le
code de température global du système. Les combinaisons
d'équipements dans le système sont sujettes à inspection par les
autorités locales qualifiées au moment de l'installation.
WARNING EXPLOSION HAZARD -
• Do not disconnect equipment
unless power has been removed
or the area is known to be
nonhazardous.
• Do not disconnect connections to
this equipment unless power has
been removed or the area is
known to be nonhazardous.
Secure any external connections
that mate to this equipment by
using screws, sliding latches,
threaded connectors, or other
means provided with this product.
• Substitution of components may
impair suitability for Class I,
Division 2.
• If this product contains batteries,
they must only be changed in an
area known to be nonhazardous.
AVERTISSEMENT RISQUE D’EXPLOSION –
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher l'équipement.
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher les connecteurs. Fixer
tous les connecteurs externes
reliés à cet équipement à l'aide
de vis, loquets coulissants,
connecteurs filetés ou autres
moyens fournis avec ce produit.
• La substitution de composants
peut rendre cet équipement
inadapté à une utilisation en
environnement de Classe I,
Division 2.
• S'assurer que l'environnement est
classé non dangereux avant de
changer les piles.
ATTENTION Safety Programmable Electronic Systems (PES)
Personnel responsible for the application of safety-related programmable electronic
systems (PES) shall be aware of the safety requirements in the application of the system
and shall be trained in using the system.

4 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
ATTENTION Environment and Enclosure
This equipment is intended for use in Pollution Degree 2 Industrial environment, in
Overvoltage Category II applications (as defined in IEC publication 60664-1), at altitudes
up to 2000 m (6562 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according to
IEC/CISPR Publication 11. Without appropriate precautions, there may be potential
difficulties ensuring electromagnetic compatibility in other environments due to
conducted as well as radiated disturbance.
This equipment is supplied as open type equipment. It must be mounted within an
enclosure that is suitably designed for those specific environmental conditions that will
be present and appropriately designed to prevent personal injury resulting from
accessibility to live parts. The enclosure must have suitable flame-retardant properties to
prevent or minimize the spread of flame, complying with flame spread rating or 5VA, V2,
V1, V0 (or equivalent) if non-metallic. The interior of the enclosure must be accessible
only by the use of a tool. Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings that are required to comply with
certain product safety certifications.
In addition to this publication, see:
•Industrial Automation Wiring and Grounding Guidelines, Allen-Bradley publication
1770-4.1.
•NEMA Standards publication 250 and IEC publication 60529, as applicable, for
explanations of the degrees of protection provided by different types of enclosure.
ATTENTION Prevent Electrostatic Discharge
This equipment is sensitive to electrostatic discharge, which can cause internal damage
and affect normal operation. Follow these guidelines when you handle this equipment:
•Touch a grounded object to discharge potential static.
•Wear an approved wrist grounding strap.
•Do not touch connectors or pins on component boards.
•Do not touch circuit components inside the equipment.
•Use a static-safe workstation, if available.
•Store the equipment in appropriate static-safe packaging when not in use.

SmartGuard 600 Controllers 5
Publication 1752-IN001C-EN-P - January 2009
About the SmartGuard 600 Controller
SmartGuard 600 controllers, catalog numbers 1752-L24BBB and 1752-L24BBBE, are
programmable electronic systems featuring 16 digital inputs, 8 digital outputs, 4 test
pulse sources, and connections for USB and DeviceNet safety communication. In
addition, the 1752-L24BBBE controller offers EtherNet/IP connectivity.
SmartGuard 600 controllers are certified for use in safety applications up to and
including Safety Integrity Level (SIL) 3, according to IEC 61508,
Performance Level PL(e) according to ISO 13849-1, and Category (CAT) 4,
according to EN 954-1.
ATTENTION
T
Protective Debris Strip
Do not remove the protective debris strip until after the controller and all the other
equipment near the controller is mounted and wiring is complete.
Once wiring is complete, remove the protective debris strip. Failure to remove the strip
before operating can cause overheating.
ATTENTION Serious injury may occur due to the loss of required safety function.
•Do not use test outputs as safety outputs.
•Do not use DeviceNet standard I/O data or explicit message data as safety data.
•Do not use the safety indicators for safety operations.
•Do not connect loads beyond the rated value to safety outputs or test outputs.
•Wire the controller properly so that the 24V DC line does not accidentally touch the
outputs.
•Ground the 0V line of the power supply for external output devices so that the
devices do not turn on when the safety output line or test output line is grounded.
•Do not dismantle, repair, or modify the controller. Doing so may impair the safety
functions.

6 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
1752-L24BBB Controller
1752-L24BBBE Controller
Number Feature
1 Module status indicators
2 Alphanumeric display
3 Node address switches
4 Baud rate switches
5 USB port
6 DeviceNet communication
connector
7 Terminal connectors
8 Input status indicators
9 Output status indicators
10 Service switch
Number Feature
1 Module status indicators
2 Alphanumeric display
3 Node address switches
4 Baud rate switches
5 USB port
6 DeviceNet communication
connector
7 Terminal connectors
8 Input status indicators
9 Output status indicators
10 IP address display switch
11 Ethernet connector
12 Service switch
1
3
4
6
10
5
27
8
9
7
3
46
10
5
27
8
9
7
12
11
1

SmartGuard 600 Controllers 7
Publication 1752-IN001C-EN-P - January 2009
Before You Begin
Before you install the controller, set its DeviceNet node address and communication
rate.
Set the Node Address
Use a small screwdriver to set the DeviceNet node address by using the two rotary
switches on the front panel of the controller. Use care not to scratch the switches.
Values from 00…63 are valid. The default setting is 63.
Follow these steps to set the node address.
1. Set the tens digit of the node address (decimal) by turning the left rotary
switch.
2. Set the ones digit by turning the right rotary switch.
3. To set the node address by using RSNetWorx for DeviceNet software, set the
rotary switches to a value from 64…99.
Setting the Communication Rate
The default communication rate for a DeviceNet network is 125 Kbps.
If you choose to use a different communication rate, the length of the trunkline and
types of cable determine which communication rates your application can support.
IMPORTANT Turn off power to the controller before setting the node address or communication rate
via the switches.
Do not change the switch settings while the power supply is on. The controller will detect
this as a change in the configuration and will switch to the ABORT mode.
IMPORTANT A node address duplication error will occur if the same node address is set for more than
one node.
DeviceNet Communication Rates and Cable Lengths
Communication
Rate
Distance, Max Cumulative Drop
Line Length
Flat Cable Thick Cable Thin Cable
125 Kbps 420 m (1378 ft) 500 m (1640 ft) 100 m (328 ft) 156 m (512 ft)
250 Kbps 200 m (656 ft) 250 m (820 ft) 100 m (328 ft) 78 m (256 ft)
500 Kbps 75 m (246 ft) 100 m (328 ft) 100 m (328 ft) 39 m (128 ft)

8 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Set the communication rate by using the DIP switch on the front of the controller.
Set the IP Address for Ethernet Communication
Connect the 1752-L24BBBE controller to the network via a 100 Mbps Ethernet
switch, which will help reduce collisions and lost packets, and increase bandwidth.
The 1752-L24BBBE controller is shipped with BOOTP enabled for setting the IP
address. You can use any commercially available BOOTP server. If you do not have
BOOTP Server capabilities on your network, download the free Rockwell
Automation BOOTP server from http://www.ab.com/networks/bootp.html.
To set the IP address by using the Rockwell Automation BOOTP utility, follow
these steps.
1. Run the BOOTP utility.
2. Double-click the hardware address of the device you want to configure.
DIP Switch Settings
DIP Switch
Pin
1 2 3 4 Communication Rate
OFF OFF OFF OFF 125 Kbps
ON OFF OFF OFF 250 Kbps
OFF ON OFF OFF 500 Kbps
ON ON OFF OFF Set by software
ON or OFF ON or OFF ON OFF Set by software
ON or OFF ON or OFF ON or OFF ON Automatic baud-rate detection
IMPORTANT If you change the communication rate of your network, make sure that all devices change
to the new communication rate. Mixed communication rates produce communication
errors.

SmartGuard 600 Controllers 9
Publication 1752-IN001C-EN-P - January 2009
3. In the the New Entry pop-up dialog box, type the IP address you want to
assign to the device, and click OK.
The controller appears in the Relation List.
For detailed information on EtherNet/IP communication, refer to the EtherNet/IP
Performance and Application Solution, publication ENET-AP001.
Install the SmartGuard 600 Controller
To install the SmartGuard 600 controller, you must mount it on the DIN rail, wire
the terminals, and make communication connections.
Mount the SmartGuard 600 Controller
IMPORTANT For effective cooling:
•mount the controller on a horizontal DIN rail. Do not mount the controller vertically.
•provide a gap of at least 50 mm (2.0 in.) above and below the controller and 5 mm
(0.20 in.) on each side.
•select a location where air flows freely or use an additional fan.
•do not mount the controller over a heating device.

10 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Mount the controller only to a DIN rail. Follow these steps to mount the controller
to an EN 50022-35x7.5 or EN 50022-35x15 DIN rail.
1. Hook the top slot over the DIN rail.
2. Snap the bottom of the controller into position while pressing the controller
down against the top of the rail.
3. Attach end plates to each end of the DIN rail.
To remove the controller from the DIN rail, use a screwdriver to pull down the
latch and lift the controller off of the rail. The 1752-L24BBB controller has one latch
and the 1752-L24BBBE controller has two latches on the bottom of the controller.
Grounding the SmartGuard 600 Controller
You must provide an acceptable grounding path for each device in your
application. Functionally ground the controller through its V0/G0 power
connection.
In addition, if you are using the 1752-L24BBBE controller, you should connect the
Ethernet ground terminal to an acceptable ground.
ATTENTION This product is grounded through the DIN rail to chassis ground. Use zinc plated
yellow-chromate steel DIN rail to assure proper grounding. The use of other DIN rail
materials (for example, aluminum or plastic) that can corrode, oxidize, or are poor
conductors, can result in improper or intermittent grounding. Secure DIN rail to mounting
surface approximately every 200 mm (7.8 in.) and use end anchors appropriately.
Latch
Top Slot
DIN Rail

SmartGuard 600 Controllers 11
Publication 1752-IN001C-EN-P - January 2009
Ethernet Ground
Refer to the Industrial Automation Wiring and Grounding Guidelines, publication
1770-4.1, for additional information.
Connecting a Power Supply
Power for the controller is provided via an external 24V DC power source. The
output hold time must be 20 ms or longer.
To comply with the CE Low Voltage Directive (LVD), DeviceNet connections and
I/O must be powered by a DC source compliant with safety extra low voltage
(SELV) or protected extra low voltage (PELV).
To comply with UL restrictions, DeviceNet connections and I/O must be powered
by DC sources whose secondary circuits are isolated from the primary circuit by
double insulation or reinforced insulation. The DC power supply must satisfy the
requirements for Class 2 circuits or limited voltage/current circuits defined in
UL 508.
The SmartGuard controller has three V/G terminal pairs that require a power
connection. There are two V0/G0 pairs, but because they are internally connected,
you need to only connect one V0/G0 pair. You can use the other pair to distribute
power to other devices.
TIP
R
The following Rockwell Automation 1606 power supplies are Class 2, SELV- and
PELV-compliant, and they meet the isolation and output hold-off time requirements of the
SmartGuard 600 controller:
•1606-XLP30E
•1606-XLP50E
•1606-XLP50EZ
•1606-XLP72E
•1606-XLP95E
•1606-XLDNET4
•1606-XL60DR
•1606-XLSDNET4

12 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Power Supply Connections
Wiring the SmartGuard 600 Controller
See page 24 for appropriate wire size and torque specifications.
Controller Terminal Descriptions
Terminal Designation Description
V0 Power terminal for internal circuit (logic).
G0 Power terminal for internal circuit (logic).
V1 Power terminal for input circuits and test outputs.
G1 Power terminal for input circuits and test outputs.
V2 Power terminal for safety outputs.
G2 Power terminal for safety outputs.
IN0…IN15 Terminals for safety inputs.
T0…T3 These are test output terminals that can provide pulse test sources for safety
inputs IN0...IN15. T3 can also support wire off detection and burned out bulb
detection for a load such as a muting lamp.
OUT0…OUT7 Terminals for safety outputs.
WARNING If you connect or disconnect wiring while the field-side power is applied, an electrical arc
can occur. This could cause an explosion in hazardous location installations. Be sure that
power is removed or the area is nonhazardous before proceeding.
+-
+-
+-

SmartGuard 600 Controllers 13
Publication 1752-IN001C-EN-P - January 2009
Wiring Input Devices
Input devices with mechanical contact outputs, such as emergency stop buttons
and safety limit switches, use both a safety input terminal and a test output
terminal. This enables the circuit to reach a Category 4 rating.
When safety devices are connected via test outputs to an input circuit on the
SmartGuard controller, we recommend the length of the wire to be 30 m (98.4 ft) or
less.
Input Devices with Mechanical Contact Outputs
WARNING If you connect or disconnect the removable terminal block (RTB) while the field-side
power is applied, an electrical arc can occur. This could cause an explosion in hazardous
location installations. Be sure that power is removed or the area is nonhazardous before
proceeding.
IMPORTANT Prepare stranded wires by attaching ferrules with plastic insulation covers (compliant
with the DIN 46228-4 standard). Ferrules similar in appearance but not compliant may not
match the terminal block on the controller.
ATTENTION Applying an inappropriate DC or any AC voltage may result in a loss of safety function,
product damage, or serious injury. Properly apply only the specified voltage to controller
inputs.
SmartGuard 600
Controller
V1
Tx
INx
G1
24V DC
4.5 mA Typical

14 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Devices, such as light curtains, with current-sourcing PNP semiconductor outputs
send a signal to the SmartGuard 600 controller safety-input terminal and do not use
a test output.
Input Devices with PNP Semiconductor Outputs
Wiring Output Devices
ATTENTION Serious injury may occur due to a loss of required safety functions.
Do not connect loads beyond the rated value of safety or test outputs.
Do not use test outputs as safety outputs.
Wire the controller properly so that the 24V DC lines do not touch the safety or test
outputs.
Do not apply the power supply to the test output terminals.
Ground the 0V line of the power supply for external output devices so that the devices do
not turn on when the safety output line or the test output line is grounded.
Separate I/O cables from high voltage or high current lines.
SmartGuard 600
Controller
V1
Tx
INx
G1
24V DC
24V DC
OSSDx
GND
4.5 mA Typical

SmartGuard 600 Controllers 15
Publication 1752-IN001C-EN-P - January 2009
Output Device Wiring
Making Communication Connections
You can configure the network and controller on the DeviceNet network by using a
1784-PCD card inside your personal computer and RSNetWorx for DeviceNet
software. You can also configure the network and controller by using the
controller’s USB port and RSNetWorx for DeviceNet software.
In addition, you can communicate via the EtherNet/IP network. The EtherNet/IP
address and subnet mask are configured with the RSLinx module configuration. The
1752-L24BBBE controller is shipped with BOOTP enabled for setting the
IP Address. See page 8 for details.
WARNING Do not connect or disconnect the communication cable with power applied to this
controller or any device on the network, because an electrical arc can occur. This could
cause an explosion in hazardous location installations. Be sure that power is removed or
the area is nonhazardous before proceeding.
SmartGuard
600 Controller
V2
G2
0.5 A Max
OUTx 24V DC
Load

16 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Connect to the DeviceNet Port
Follow these steps to connect to the DeviceNet port.
1. Wire the connector according to the colors on the connector.
2. Attach the connector to the DeviceNet port.
3. Tighten the screws to 0.25…0.3 N•m (2.21…2.65 lb•in).
For detailed DeviceNet connection information, refer to the DeviceNet Media
Design Installation Guide, publication DNET-UM072. Also refer to the Industrial
Automation Wiring and Grounding Guidelines, publication 1770-4.1.
Connecting to the USB Port
Connect the USB communication connector to your personal computer when you
want to configure the network and controller by using RSNetWorx for DeviceNet
software. Use a commercially available USB-A to USB-B male/male cable to make
the connection.
Wire No. Wire Color Connects to
1Red V+
2WhiteCAN H
3— Drain
4Blue CAN L
5BlackV-
ATTENTION The USB cable length must be less than 3 m (10 ft).
The USB port is intended for temporary programming purposes only and is not intended for
permanent connection.
WARNING If you connect or disconnect the USB cable with power applied to this module or any
device on the USB network, an electrical arc could occur. This could cause an explosion in
hazardous location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
D
D
D
D
D
1
2
3
4
5

SmartGuard 600 Controllers 17
Publication 1752-IN001C-EN-P - January 2009
Connecting to the Ethernet Port
Use an RJ45 connector to connect the controller to the EtherNet/IP network.
Interpreting the Status Indicators
The SmartGuard 600 controller features status indicators for module, DeviceNet and
EtherNet/IP network status, lock, USB and EtherNet/IP communication, individual
input and output status, as well as an alphanumeric status display for DeviceNet
error codes, DeviceNet node address, and EtherNet/IP address information.
ATTENTION The cable length must be less then 100 m (328 ft) between hub and nodes.
WARNING If you connect or disconnect the Ethernet cable with power applied to this controller or any
other device on this network, an electrical arc can occur. This could cause an explosion in
hazardous location installations. Be sure that power is removed or the area is
nonhazardous before proceeding.
Ethernet Pin Placement
Pin No. Pin Name Pin Placement
8 Not used
7 Not used
6RD-
5 Not used
4 Not used
3RD+
2TD-
1TD+
8
1

18 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
Alphanumeric Status Display
The controller’s alphanumeric display provides information about the module’s
status. Under normal operating conditions, the display shows the node address of
the module, 00…63 in decimal format. If the controller is operating in a standalone
configuration (not networked), the display shows ‘nd’. The display flashes when
the controller is self-testing, configuring, or in Idle mode. If a fault exists, the
display alternates between the error code and the node address where the error
occurred. If a fatal error has occurred, the display shows the error code only.
When the service switch is pressed, the display shows the controller’s
safety-configuration signature two digits at a time. The configuration signature can
also be viewed on the Safety tab of the Controller Properties dialog box in
RSNetWorx for DeviceNet software. You can use the configuration signature to
verify that the program and configuration of the controller has not been changed.
When the IP address display switch is pressed for 1 second or longer, the display
shows the EtherNet/IP address that is set. The error code ‘n4’ is displayed if an error
occurs in the EtherNet/IP configuration.
Status Indicators
Use these tables to interpret the color and status combinations of the status
indicators and take recommended actions where applicable.
If your Module Status indicator is off, follow these steps.
1. Cycle the power supply.
2. Take corrective actions for noise.
Module Status (MS) Indicator Descriptions
If the Module Status
(MS) indicator is
It means Take this action
Off No power. Refer to the corrective action following this
table.
Green, on The controller is operating in Run
mode and under normal conditions.
No action required.
Green, flashing The controller is idle.
Red, flashing A recoverable fault exists. Refer to the corrective action following this
table.
Red, on An unrecoverable fault exists.
Red/green flashing Self-test in progress. Or, the
controller’s configuration is being
downloaded or is incomplete or
incorrect.

SmartGuard 600 Controllers 19
Publication 1752-IN001C-EN-P - January 2009
3. Contact Rockwell Automation.
If your Module Status indicator is flashing red, follow these steps.
1. Configure the switches properly.
2. Reset the configuration data.
If your Module Status indicator is solid red (on), follow these steps.
1. Cycle the power supply.
2. Check external wiring.
3. Take corrective actions for noise.
4. Contact Rockwell Automation.
If your Module Staus indicator is flashing red and green, follow these steps.
1. Configure the switches properly.
2. Set the safety network number.
3. Reconfigure the device.
DeviceNet Network Status (NS D) Indicator Descriptions
If the DeviceNet
Network Status
(NS D) indicator is
It means Take this action
Off The controller is not online or may not
have power from the DeviceNet
network.
Refer to the corrective action following this
table.
Green, on The controller is online; connections
are established.
No action required.
Green, flashing The controller is online; no
connections are established.
Red, on Communication failure due to
duplicate MAC ID (error code F0) or
Bus OFF (error code F1).
Refer to the corrective action following this
table
Red, flashing Communication timeout.
Red/green flashing The Safety Network Number (SNN) is
being set.
No action required.

20 SmartGuard 600 Controllers
Publication 1752-IN001C-EN-P - January 2009
If your Network Status indicator is off, follow these steps.
1. Cycle the power supply.
2. Check external wiring.
3. Take corrective actions for noise.
4. Contact Rockwell Automation.
If your Network Status indicator is on or flashing red, follow these steps.
1. View the Alphanumeric display for the node address of the error and error
code.
2. Check that node addresses have not been duplicated.
3. Make sure the communication rate is the same for all nodes.
4. Check that cables are not loose, disconnected or too long.
5. Verify that terminating resistors have been installed only at both ends of the
main line.
6. Take corrective action for noise.
7. Make sure target devices are configured, verified, and in normal operating
state.
Lock Configuration (Lock) Status Indicator Descriptions
If the Lock
Configuration (Lock)
status indicator is
It means Take this action
Yellow, on A locked valid configuration exists. No action required.
Yellow, flashing An unlocked valid configuration exists. Lock the configuration before operating the
safety system.
Off The configuration is invalid. Reconfigure the controller.
