Rockwell Automation Allen-Bradley PowerFlex 6000 Quick start guide

PowerFlex 6000 Medium Voltage Variable Frequency Drive
Commissioning Manual
Publication 6000-IN007B-EN-P
Commissioning Manual

Important User Information
Read this document and the documents listed in the additional resources section about installation, configuration, and
operation of this equipment before you install, configure, operate, or maintain this product. Users are required to
familiarize themselves with installation and wiring instructions in addition to requirements of all applicable codes, laws,
and standards.
Activities including installation, adjustments, putting into service, use, assembly, disassembly, and maintenance are required
to be carried out by suitably trained personnel in accordance with applicable code of practice.
If this equipment is used in a manner not specified by the manufacturer, the protection provided by the equipment may be
impaired.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the
use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the many variables and
requirements associated with any particular installation, Rockwell Automation, Inc. cannot assume responsibility or
liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits, equipment, or
software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell Automation,
Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
Labels may also be on or inside the equipment to provide specific precautions.
Allen-Bradley, Rockwell Software, Rockwell Automation, PowerFlex, and TechConnect are trademarks of Rockwell Automation, Inc.
Trademarks not belonging to Rockwell Automation are property of their respective companies.
WARNING: Identifies information about practices or circumstances that can cause an explosion in a hazardous environment,
which may lead to personal injury or death, property damage, or economic loss.
ATTENTION: Identifies information about practices or circumstances that can lead to personal injury or death, property
damage, or economic loss. Attentions help you identify a hazard, avoid a hazard, and recognize the consequence.
IMPORTANT
Identifies information that is critical for successful application and understanding of the product.
SHOCK HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that dangerous
voltage may be present.
BURN HAZARD: Labels may be on or inside the equipment, for example, a drive or motor, to alert people that surfaces may
reach dangerous temperatures.
ARC FLASH HAZARD: Labels may be on or inside the equipment, for example, a motor control center, to alert people to
potential Arc Flash. Arc Flash will cause severe injury or death. Wear proper Personal Protective Equipment (PPE). Follow ALL
Regulatory requirements for safe work practices and for Personal Protective Equipment (PPE).

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 3
Table of Contents
Preface Introduction. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Who Should Use This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
What Is Not in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Required Supplemental Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Dimensional Drawings and Electrical Drawings. . . . . . . . . . . . . . . . . . . 7
Shipping, Handling, and Installation Manual . . . . . . . . . . . . . . . . . . . . . 8
General Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Additional Resources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Chapter 1
Introduction
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Documentation and Application Review. . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Review all Rockwell Automation Supplied Documentation . . . . . . 12
Pre-commissioning Customer Meeting. . . . . . . . . . . . . . . . . . . . . . . . . 13
Review Drive Application . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Chapter 2
Preparation and Inspection (For IEC)
Gather Required Tools and Test Equipment . . . . . . . . . . . . . . . . . . . . . . . 15
Lockout and Tagout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Inspect Drive Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Functional Assessment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Interconnection Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Installation Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Mechanical Installation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Electrical Installation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Power Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Drive Megger Check . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Isolate the Power and Control Circuits. . . . . . . . . . . . . . . . . . . . . . . . . 23
Connect the Insulation Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Final Steps before Equipment is Ready for Energization . . . . . . . . . . . . . 29
Seal the Cabinet Plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Chapter 3
Preparation and Inspection (For UL)
Gather Required Tools and Test Equipment . . . . . . . . . . . . . . . . . . . . . . . 31
Lockout and Tagout. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Inspect Drive Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Functional Assessment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Interconnection Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Installation Review . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Mechanical Installation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Electrical Installation Inspection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Power Cabling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39

4Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Table of Contents
Drive Megger Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Isolate the Power and Control Circuits . . . . . . . . . . . . . . . . . . . . . . . . . 39
Connect the Insulation Meter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Final Steps before Equipment is Ready for Energization . . . . . . . . . . . . . 46
Seal the Cabinet Plates . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Chapter 4
Commissioning
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Control System Check Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Simulate Closed Input Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . 48
Energize Control Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Control System Check. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Verify Factory Default Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Set P Parameters to Enable Testing. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Verify Settings for Low-Voltage Testing . . . . . . . . . . . . . . . . . . . . . . . . 58
Verify Operation of Frequency Steps . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Verify Operation to Set Frequency . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Simulate Warnings and Faults . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Verify E-Stop Functionality . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Verify Switching from Local Control to Remote Control . . . . . . . . 73
Verify Operation of Input/Output and Bypass Isolation Switches
(Manual Bypass). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Verify Operation of Input/Output and Bypass Contactors
(Automatic Bypass) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Verify Operation of DCS Input and Output Signals . . . . . . . . . . . . . 83
Restore P Parameter Settings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Set Date and Time Zone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Access T Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Change Time/Date/Regional Settings. . . . . . . . . . . . . . . . . . . . . . . . . . 87
Chapter 5
No-load Test
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
No-load Test. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Energize Drive Control Circuit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Configure P and T Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Change Parameters T11...T13 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
Close Isolation Switches in Bypass Cabinet . . . . . . . . . . . . . . . . . . . . 102
Close Input Circuit Breaker . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Check Cooling Fan Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Operate Motor by HMI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 104
Load Test of Drive System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Appendix A
Torque Requirements
Torque Requirements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 5
Table of Contents
Appendix B
Single Line Diagrams
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Appendix C
Special Function Parameter Settings
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
System Setting Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
Number of Power Modules Per Phase . . . . . . . . . . . . . . . . . . . . . . . . . 117
Switch Control Sources . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Rated/Maximum Output Frequency. . . . . . . . . . . . . . . . . . . . . . . . . . 118
Motor Parameter Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Hall Effect Current Sensor Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
Analog Output Display Parameter Setting . . . . . . . . . . . . . . . . . . . . . 119
Restore Factory Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
Speed Command Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Set Frequency Command Source . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Set Frequency Correction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120
Frequency Command Deadband Upper Limit . . . . . . . . . . . . . . . . . 120
Frequency Amplitude Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Frequency Skip. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
Speed Reference Functions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
V/F Curve Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Set Maximum Modulation Index and Limit Output Voltage
Amplitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Set Flux Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 122
Analog Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Stop Mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Flying Start Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Restart the Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 124
Index

6Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Table of Contents
Notes:

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 7
Preface
Introduction This document provides procedural information for commissioning
PowerFlex® 6000 medium voltage drives with version 4.001 firmware.
Who Should Use This Manual This manual is intended for Rockwell Automation Field Service Engineers with
Medium Voltage Drive factory training and field experience commissioning
medium voltage solid-state variable speed drive equipment.
What Is Not in This Manual This manual is generic and does not include project-specific or drive-specific
information. Contact the Start-up Project Manager for required project-specific
or drive-specific information such as:
•Dimensional Drawings and Electrical Drawings generated for the
customer’s order.
•Spare parts lists compiled for the customer’s order.
•Drive-specific technical specifications.
•Pre-commissioning Checklist
•PLC program for standard, integral PLC
Required Supplemental
Information
Dimensional Drawings and Electrical Drawings
Thoroughly review the project-specific Dimensional Drawings (DDs) and
Electrical Drawings (EDs) to understand the specific drive system being
commissioned, before performing any mechanical or electrical work.
Within these drawings is detailed information which is important to understand
for the commissioning and installation of the equipment.
WARNING: This document is for internal use only (for Rockwell CSM/field
support Engineers). DO NOT disclose this document to customers or any non-
Rockwell Automation employee. Disclosure of sensitive information in this
document may cause dire consequences to the drive.
Table 1 - Electrical Drawings
Contactor Locations (electrically)
Drive Topology
General Notes
Minimum Power Cable Insulation Ratings
Component Designations
Customer Power and Control Wiring Locations (electrically)
Control and Medium Voltage Power Ratings
Fuse Locations (electrically)

8Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Preface
If the drawings require changes to suit the installation and application of the
system, fax or e-mail the marked up drawings to the Start-up Project Manager.
Shipping, Handling, and Installation Manual
Review publication 6000-IN006_-EN-P, PowerFlex 6000 Medium Voltage
Variable Frequency Drive Shipping, Handling, and Installation manual.
The customer/contractor has the option to perform the electrical
interconnection work between cabinet shipping splits, as shown in this manual,
or contract Rockwell Automation to perform this work. This will be reflected in
the Services Purchase Order and the pre-commissioning checklist. Verify that the
documentation matches the actual scope of work done by the customer/
contractor. You will be required to either perform this interconnection work
immediately prior to the commissioning process or to verify the work was done
correctly by the contractor. It is very important to confirm the alignment of the
paperwork with the actual scope of work.
It is also extremely important to understand the contractor’s basic scope of work,
preceding the commissioning process. Part of the overall commissioning process
is to ensure this work has been done correctly. If this work has not been done
properly, this must be brought to the attention of the customer immediately. Do
not proceed with commissioning until this issue is resolved.
Additional required information about the PowerFlex 6000 can be downloaded
from http:/www.rockwellautomation.com/literature/.
•6000-IN006_-EN-P: PowerFlex 6000 Medium Voltage Variable
Frequency Drive Shipping, Handling, and Installation Instructions
•6000-UM002_-EN-P: PowerFlex 6000 Medium Voltage Variable
Frequency Drive User Manual (operating the HMI, full parameter listing)
You must review these publications thoroughly before beginning the
commissioning process. They contain supplemental information that will aid in
the commissioning process.
Table 2 - Dimensional Drawings
Control and Medium Voltage Power Ratings
Drive Options
Motor Ratings
Drive Power Component Selection Ratings

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 9
Preface
General Precautions
Additional Resources These documents contain additional information concerning related products
from Rockwell Automation.
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts
and assemblies. Static control precautions are required when installing, testing,
servicing or repairing this assembly. Component damage may result if ESD
control procedures are not followed. If you are not familiar with static control
procedures, reference Allen-Bradley publication 8000-4.5.2, “Guarding Against
Electrostatic Damage” or any other applicable ESD protection handbook.
ATTENTION: An incorrectly applied or installed drive can result in component
damage or a reduction in product life. Wiring or application errors, such as,
undersizing the motor, incorrect or inadequate AC supply, or excessive ambient
temperatures may result in malfunction of the system.
ATTENTION: Only personnel familiar with the PowerFlex 6000 Adjustable
Speed Drive (ASD) and associated machinery should plan or implement the
installation, start-up and subsequent maintenance of the system. Failure to
comply may result in personal injury and/or equipment damage.
Resource Description
Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1
Provides general guidelines for installing a Rockwell
Automation industrial system.
Product Certifications website, http://www.ab.com Provides declarations of conformity, certificates, and
other certification details.

10 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Preface
Notes:

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 11
Chapter 1
Introduction
Overview Information contained in this chapter will assist in commissioning a
PowerFlex 6000 medium voltage AC drive.
Review the information contained in this chapter prior to commissioning the
drive and use it as a reference while the drive commissioning is performed.
Prior to commissioning, the following work will have been performed by the
customer or the customer’s electrical contractor:
This work will be reviewed during the pre-commissioning customer meeting and
validated during the commissioning process; see Installaion Review on page 21 or
page 37.
WARNING: Perform the commissioning checks illustrated in the sequence that
they have been presented. Failure to do so may result in equipment failure,
personal injury, or death.
Connect External Cabling and Wiring
Connect System Ground Cable(1)
(1) If an optional bypass unit is supplied, the system ground cable, incoming line power cables, and outgoing motor power cables are
connected to the bypass unit.
Megger Test of Power Cables
Connect Incoming Line and Outgoing Motor Power Cables(1)
Connect Control Power Wiring
Connect External Control Signal Wiring
Connect Electrical Safety Interlock Control Signal Wiring Circuit to Input Circuit Breaker
Connect Internal Cabling and Wiring(2)
(2) Interconnection of power cables and low voltage control wiring bundles, between separately shipped cabinets, can be done by the
contractor or Rockwell Automation. The commissioning quote from Rockwell Automation reflects this and will contain two options:
a) the base quote, reflecting the power cable and control wiring interconnection work being done by the contractor
b) the optional quote adder, reflecting the additional time and cost for Rockwell Automation to perform the power cable and
control wiring interconnection work immediately prior to the commissioning process.
Connect Isolation Transformer Secondary Power Cables to Power Modules
Connect Motor Cables and Voltage Sensing Board Cables to U, V, and W Output Phase Buses
Connect LV Control and Fan Wiring Bundles
Connect Ground Bus Splices

12 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Chapter 1 Introduction
Process Flowcharts
Documentation and
Application Review
Review all Rockwell Automation Supplied Documentation
Each drive is shipped with the technical publications required to assist in
commissioning and troubleshooting the drive. Request copies or revisions of
these documents from the Start-up Project Manager. However, you will have
received e-copies of this information prior to commissioning by the Start-up
Project Manager.
Before commissioning the drive, ensure you have the following resources:
•Project-specific Electrical Drawings and Dimensional Drawings
•PowerFlex 6000 Medium Voltage Variable Frequency Drive Shipping,
Handling, and Installation Manual 6000-IN006_-EN-P): provides
procedural information for physically unloading, moving, and installing
equipment
•PowerFlex 6000 Medium Voltage Variable Frequency Drive
Commissioning Manual (6000-IN007_-EN-P): required procedures and
checklists for Rockwell Automation Field Service Engineers.
•PowerFlex 6000 Medium Voltage Variable Frequency Drive User Manual
(6000-UM002_-EN-P): instructions for daily recurring drive usage, HMI
interface, and maintenance tasks
Lockout
andTagout
Functional
Assessment
Interconnection
Review
Installation
Review
Control
System Check
(LV Only)
No-load Test
of Drive
System
(MV)
Load Test of
Drive System
(MV)
Documentation and Application Review
Preparation and Inspection
Review
Rockwell
Automation
Supplied
Documentation
Pre-commissioning
Customer Meeting
Gather
Required Tools
and Test
Equipment
Review Drive
Application
Commissioning
Inspect Drive
Components Meggering Final Review
and Preparation

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 13
Introduction Chapter 1
•PLC Program: The PLC I/O processes control signals within the drive
and I/O signals to and from the customer’s control system and input
circuit breaker. The PLC program is standardized. However, it may be
customized to address specific customer requirements by Rockwell
Automation during the Application Engineering phase of order execution.
Pre-commissioning Customer Meeting
Before commissioning the drive, it is recommended to schedule a meeting with
the customer.
1. Discuss the activities and documentation needed to review the drive
application
2. Review the start-up activities and timelines
3. Review the Pre-commissioning Checklist (see 6000-IN006_-EN-P)
4. Review the drive application
Review Drive Application
To ensure trouble-free commissioning, it is necessary for all personnel involved in
the start-up to familiarize themselves with the drive and actual application.
Service on the equipment should not be performed without a clear
understanding of how the equipment has been designed to function and how the
equipment has been applied.
Before commissioning the drive, inspect the process that the drive is intended to
control. This identifies how the equipment is designed to suit the application,
and any potential hazards. Determine what measures must be taken to ensure that
commissioning the equipment does not expose anyone to hazardous situations or
damage to the equipment. Verify that the load is not turning due to the process,
as a freewheeling motor can generate voltage that will be back-fed to the
equipment being serviced. Take all actions necessary to ensure that motor
regeneration into the drive does not occur while the equipment is being started
up or being serviced.
Review Electrical System One-line Diagram
Identify all relevant equipment Tag Identification names and numbers. Study the
system for sources of power and parallel paths of medium voltage power. Retain a
copy of the one-line diagram for commissioning the drive. If applicable, send a
copy of the one-line diagram to the Start-up Project Manager to be archived and
used for future customer assistance.

14 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Chapter 1 Introduction
On-site Verification of Electrical System One-line Diagram
Once all documentation has been reviewed, an on-site inspection of the drive is
required. Identify the physical locations of the connections to the drive using Tag
Identification names or numbers from the one-line diagram and Rockwell
Automation Electrical Drawings.
All customer power and control wiring required for the drive line-up installation
has been identified on the Rockwell Automation Electrical Drawings by a dashed
line.
Installation of all external power cabling and control wiring interfacing with the
drive is completed by the customer or their electrical contractor. Verify that this
wiring is installed correctly and meets electrical voltage and current capacity
requirements. Trace the power cables point-to-point from the input circuit
breaker to the drive, and from the drive to the motor using the Electrical
Drawings as a reference for proper drive power cable termination locations. Any
discrepancy between the physical installation and the Electrical Drawings of the
following items should be reviewed prior to commissioning the drive:
•Medium voltage power cabling in from the input circuit breaker to drive
•Medium voltage power cabling out from drive to motor
•Low Voltage control power cables from LV MCC or circuit breaker to
drive
•Ground connection from system ground to drive
•Control signal wires and communication cables from remote DCS/PLC
or other remote device to drive
•Electrical safety interlock/control wiring from the drive to the input
circuit breaker
ATTENTION: Make sure the medium voltage input circuit breaker feeding the
drive is locked out and tagged out. Make sure the LV circuit breaker feeding
control power to the drive is locked out and tagged out. Make sure the drive is
de-energized before conducting the drive inspection process.
ATTENTION: Do not change wiring or remove terminal wiring.

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 15
Chapter 2
Preparation and Inspection (For IEC)
Gather Required Tools and
Test Equipment
Hand Tools
•Metric wrenches and sockets
•To r q u e w r e n c h
•Assortment of screw drivers
•Wire stripper/cutter
Electrical Equipment
•High voltage gloves – 17 kV insulation rating (minimum)
•Anti-static strap
•Live-line tool (Hot stick)
•5 kV Insulation Tester
Test Equipment
•600V (1000V rating) digital multimeter with assorted clip leads
Computer Requirements and Software
•Laptop computer
•USB cable
•PLC program
•CCW software
Lockout and Tagout SHOCK HAZARD: Servicing energized industrial control equipment can be
dangerous. Severe injury or death can result from electrical shock, burn, or
unintended actuation of control equipment. Hazardous voltages may exist in
the cabinet even with the input circuit breaker in the off position. Required
practice is to disconnect and lock out control equipment from power sources,
and confirm discharge of stored energy in capacitors. If it is necessary to work in
the vicinity of energized equipment, the safety related work practices outlined
in Electrical Safety requirements for Employee Work places must be followed.
Before attempting any work, verify the system has been locked out and tested
to have no potential.

16 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Chapter 2 Preparation and Inspection (For IEC)
Lockout and tagout the input circuit breaker before opening the doors to the
drive system cabinets. After the cabinet doors are opened, immediately test the
incoming and outgoing power cables and any components connected to medium
voltage with a live-line tool (hot stick) while wearing high voltage gloves. Pay
special attention to any capacitors connected to medium voltage that can retain a
charge for a period of time. Only after the equipment has been verified as isolated
and de-energized can subsequent work be performed. Even though the input to
the drive may be open, it is still possible for hazardous voltage to be present.
Refer to local safety guidelines for detailed procedures on how to safely isolate
the equipment from hazards.
Safety Test
Complete every point included in this section prior to continuing with the drive
commissioning, to ensure that the commissioning continues in an environment
safe to all those involved in servicing the drive. Ensure that commissioning of this
drive is performed in accordance with local safety standards.
Inspect Drive Components After performing the lockout and tagout procedure (see page 15), open all of the
cabinet doors. Inspect each component for signs of shipping damage (see Tab le 3
on page 18). An initial inspection would have been done by the customer when
the equipment was received. However, this would have been done from the front
only and was just looking for obvious signs of damage (see publication 6000-
IN006_-EN-P). Record the part number and description of any damaged
components and immediately contact the Start-up Project Manager to order
replacement components, if required.
Verify that all components are securely affixed to the cabinet.
Most components will be easily visible on the doors or from the front of the
cabinets after the doors are opened. Some components are best viewed from the
rear of the cabinet.
For rear inspection, remove top and bottom rear access plates from the drive and
bypass cabinet (if supplied). See publication 6000-IN006_-EN-P.
ATTENTION: Verify the equipment against any damage. Do not install a
damaged drive.
IMPORTANT
The Inspect Drive Components Checklist (see page 18) mentions the principal
base components supplied in the drive and bypass units. It is not
comprehensive, as customer-required options may be supplied and three
different bypass configurations are available.
Perform the shipping damage inspection for all components mounted in the
drive cabinets and specific bypass unit cabinet (if supplied).

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 17
Preparation and Inspection (For IEC) Chapter 2
Functional Assessment After the components are visually inspected to identify any shipping damage, a
thorough functional assessment should be performed (see Table 4 on page 19).
The main purpose of this assessment is to ensure that all movable parts and
assemblies operate properly, connect properly, and components are wired
properly and securely.
The Functional Assessment procedure can be combined with the “Inspect Drive
Components” checklist on page 18.
Descriptions of the Power Cable Connections to be inspected and torqued to
specifications are in the Interconnection Review and Installation Review
sections.

18 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Chapter 2 Preparation and Inspection (For IEC)
Table 3 - Inspect Drive Components Checklist (IEC)
Bypass Cabinet (if supplied) Isolation Transformer Cabinet Power Module Cabinet Low Voltage Control Cabinet
Front
Door: Pilot Lights Voltage Indicator Relay Cabinet: Insulators Switch assemblies Vacuum contactors Mechanical linkages
Door: Transformer Temperature monitor LV Cabinet components
–Fan control circuit breakers
Cabinet: Transformer Plastic Baffle Outgoing Motor Power Cable standoffs on Cabinet Sidesheet(1)
Outgoing Motor Power Cable Terminal Insulators on transformer (1) Voltage Sensing Board Incoming Line Power Cable Terminal Insulators on transformer Motor Cable Braces Fixed Mounted Power Module Configuration: Transformer Secondary Windings (2 sets)
–Inspect nomex wrap –Verify windings from core are undamaged –Check for debris in top of core
Fixed Mounted Power Module Configuration: Power Module retaining tabs Check for debris Output Bus Supports Fuse Mounting Supports Drawout Power Module Configuration: Support frame Power Modules
Door: Pilot lights Push buttons Selector switches HMI Interface board (on the back of the LV door) Panel: DIN rail mounted components UPS Fiber optic cables PLC Control Unit
Rear
Fixed Mounted Power Module Configuration: Transformer Secondary Windings (1)
–Inspect nomex wrap –Verify windings from core are undamaged –Check for debris in top of core
Drawout Power Module Configuration: Transformer Secondary Windings (3)
–Inspect nomex wrap –Verify windings from core are undamaged –Check for debris in top of core
Fixed Mounted Power Module: Heat sink
–Verify orientation relative to barrier plates
Drawout Power Module: Power In/Power Out connections
UPS connections
(1) Motor Cable terminations could be on the transformer structure or cabinet sidesheet, depending on the power rating.

Rockwell Automation Publication 6000-IN007B-EN-P - March 2016 19
Preparation and Inspection (For IEC) Chapter 2
Table 4 - Functional Assessment Checklist (IEC)
Bypass Cabinet (if supplied) Isolation Transformer Cabinet Power Module Cabinet Low Voltage Control Cabinet
Front
Electrical Door Interlock
–Verify proper operation of auxiliary contacts
with an ohmmeter
Isolation switch auxiliary contacts
–Verify proper operation with an ohmmeter
Isolation switches
–Verify proper operation –Outer jaws must securely contact the center
stab in the closed position
Secondary Wiring and Low Voltage Fuses
–Check all connections per Electrical Drawings
Door Grounding Straps
Transformer Secondary Cables
–Verify cables are properly fed through the
glanding plate and are undamaged
Voltage Sensing Board cables
–Verify the primary and secondary connections
to the board are secure
Door Interlock Limit Switches
–Test auxiliary switch contacts wired back to
terminal blocks in LV panel with ohmmeter
Temperature Sensing Wires (3 places)
–Verify wires are intact and properly inserted
Bottom-mounted Auxiliary Fan power from Isolation Transformer Auxiliary Winding
–Check connections
Door Grounding Straps Transformer Temperature Protection Relay
–Tug test on all cable connections
Auxiliary Cooling Fans (3)
–Check electrical connection
HECS (2)
–Check plug connectors
Door Interlock Limit Switches (2)
–Test switch contacts wired back to terminal
blocks in LV panel with ohmmeter
Power Modules fiber optic cables
–Check all connections
Power Modules Fuses
–Test each fuse with multimeter
Door Grounding Straps
Control Unit
–Check connection of all fiber optic cables –Check connection of HMI interface board –HMI
Low Voltage wires
–Tug test all wires on door, panel, and relays
and terminal blocks
Circuit Breakers and Contactors
–Verify operation
Vertical Ground Bus
–Check connections from all attached
components
Low Voltage Door
–Verify operation of all operator interface
devices
AC/DC Power Supplies
–Check connections
Door Grounding Straps
Rear
Surge Arrestors
–Check braided copper connections
Voltage Sensing Relay Cables
–Perform tug test
Line and Load side power cables
–Verify phasing and torque
Top Ground Bus
–Verify braided connections
Transformer Secondary Cables
–Verify cables are properly fed through the
glanding plate are undamaged
Tap Changer
–Verify connection
Top Mounted Cooling Fans
–Check electrical connection
Fan Housings
–Assembly must be affixed properly to
structure
Auxiliary Cooling Fans (3)
–Check electrical connection
Top Mounted Cooling Fans
–Check electrical connection
UPS
–Check connection

20 Rockwell Automation Publication 6000-IN007B-EN-P - March 2016
Chapter 2 Preparation and Inspection (For IEC)
Interconnection Review The interconnection checklist summarizes the required items to review to
validate the reconnection of power, ground, and control cables between cabinets
within the drive system, that were disconnected for shipment. Power and control
cables that pass from one cabinet to another are bundled in the appropriate
cabinet. These cables are connected for system test at the factory but
disconnected and coiled up for shipment. If this interconnection work was done
by the contractor, use this checklist to review and ensure the work was done
correctly. If the interconnection work was not done by the contractor, the scope
of work required to be performed is described in 6000-IN006_-EN-P.
.
IMPORTANT
Check torque on all power and ground cable connections per specifications
listed in Torque Requirements on page 109.
Table 5 - Interconnection Review Checklist (IEC)
Bypass Cabinet (if supplied) Isolation Transformer Cabinet Power Module Cabinet Low Voltage Control Cabinet
Front Inspection
Verify the braided ground
connection to adjacent cabinet(s)
is properly installed
Review the braided ground
connection to adjacent cabinet
Verify line and load power
cables from Isolation Transformer
Cabinet are properly connected
Verify all control wires per
Electrical Drawing
Verify the braided ground
connection to adjacent cabinet(s)
is properly installed
Review all isolation
transformer secondary wiring
from Power Module cabinet
(2 sets)
Verify that the shields of all
of the system’s connecting wires
are properly grounded
Verify all control wires per
Electrical Drawing
–Cables are run in LV cable
sections along front and
back of cabinet
Verify the braided ground
connection to adjacent cabinet(s)
is properly installed
Verify that the shields of all
of the system’s connecting wires
are properly grounded
Review load power cable
connection from Isolation
Transformer Cabinet
Verify Voltage Sensing
Boardpowercables fromIsolation
Transformer Cabinet are properly
installed
Verify control signal wiring
bundles from LV Control cabinet
to LV panel in Isolation
Transformer cabinet and LV panel
in the Bypass Cabinet (if supplied)
are routed correctly
Rear Inspection
Fixed Mounted Power
Module:
Verify all isolation
transformer secondary windings
from Power Module Cabinet are
properly connected (1 set)
Drawout Power Module:
Verify all isolation
transformer secondary windings
from Power Module Cabinet are
properly connected (3 sets)
Verify all power supply
cables for main cooling fans for
Isolation Transformer Cabinet are
properly connected(3 sets)
