Trusted High Integrity Power Supply System
(110-240 Vac and 24 Vdc)
Product Overview
The Trusted® power supply assembly converts redundant main line voltages of either 110 Vac / 240
Vac or 24 Vdc, to +15 Vdc or +24 Vdc output power for system and field power requirements.
Features:
•Redundant power inputs.
•250 W.
•Hot replaceable.
•Current sharing.
•Power factor correction.
•Front panel indicators for input, output voltage status and output current level on each
module.
•External status signals.
•TϋV Certified IEC 61508 SIL 3.

Trusted PD_T8200
Rockwell Automation Publication PD_T8200 Issue 11
Page intentionally left blank

Trusted High Integrity Power Supply System PREFACE
Rockwell Automation Publication PD_T8200 Issue 11 i
PREFACE
In no event will Rockwell Automation be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment. The examples given in this manual are
included solely for illustrative purposes. Because of the many variables and requirements related to
any particular installation, Rockwell Automation does not assume responsibility or reliability for
actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, with respect to use of information, circuits,
equipment, or software described in this manual.
All trademarks are acknowledged.
DISCLAIMER
It is not intended that the information in this publication covers every possible detail about the
construction, operation, or maintenance of a control system installation. You should also refer to
your own local (or supplied) system safety manual, installation and operator/maintenance manuals.
REVISION AND UPDATING POLICY
This document is based on information available at the time of its publication. The document
contents are subject to change from time to time. The latest versions of the manuals are available at
the Rockwell Automation Literature Library under "Product Information" information "Critical
Process Control & Safety Systems".
TRUSTED RELEASE
This technical manual applies to Trusted Release: 3.6.1.
LATEST PRODUCT INFORMATION
For the latest information about this product review the Product Notifications and Technical Notes
issued by technical support. Product Notifications and product support are available at the Rockwell
Automation Support Centre at
http://rockwellautomation.custhelp.com
At the Search Knowledgebase tab select the option "By Product" then scroll down and select the
Trusted product.
Some of the Answer ID’s in the Knowledge Base require a TechConnect Support Contract. For more
information about TechConnect Support Contract Access Level and Features please click on the
following link:
https://rockwellautomation.custhelp.com/app/answers/detail/a_id/50871
This will get you to the login page where you must enter your login details.
IMPORTANT A login is required to access the link. If you do not have an account then you can create one
using the "Sign Up" link at the top right of the web page.

PREFACE Trusted High Integrity Power Supply System
ii Issue 11 Rockwell Automation Publication PD_T8200
DOCUMENTATION FEEDBACK
Your comments help us to write better user documentation. If you discover an error, or have a
suggestion on how to make this publication better, send your comment to our technical support
group at http://rockwellautomation.custhelp.com

Trusted High Integrity Power Supply System PREFACE
Rockwell Automation Publication PD_T8200 Issue 11 iii
SCOPE
This manual specifies the maintenance requirements and describes the procedures to assist
troubleshooting and maintenance of a Trusted system.
WHO SHOULD USE THIS MANUAL
This manual is for plant maintenance personnel who are experienced in the operation and
maintenance of electronic equipment and are trained to work with safety systems.
SYMBOLS
In this manual we will use these notices to tell you about safety considerations.
SHOCK HAZARD: Identifies an electrical shock hazard. If a warning label is fitted, it
can be on or inside the equipment.
WARNING: Identifies information about practices or circumstances that can cause
an explosion in a hazardous environment, which can cause injury or death,
property damage or economic loss.
ATTENTION: Identifies information about practices or circumstances that can cause
injury or death.
CAUTION: Identifies information about practices or circumstances that can cause
property damage or economic loss.
BURN HAZARD: Identifies where a surface can reach dangerous temperatures. If a
warning label is fitted, it can be on or inside the equipment.
This symbol identifies items which must be thought about and put in place when
designing and assembling a Trusted controller for use in a Safety Instrumented
Function (SIF). It appears extensively in the Trusted Safety Manual.
IMPORTANT Identifies information that is critical for successful application and understanding of
the product.
NOTE Provides key information about the product or service.
TIP Tips give helpful information about using or setting up the equipment.

PREFACE Trusted High Integrity Power Supply System
iv Issue 11 Rockwell Automation Publication PD_T8200
WARNINGS AND CAUTIONS
WARNING: EXPLOSION RISK
Do not connect or disconnect equipment while the circuit is live or unless the area is
known to be free of ignitable concentrations or equivalent
AVERTISSEMENT - RISQUE D’EXPLOSION
Ne pas connecter ou déconnecter l’équipement alors qu’il est sous tension, sauf si
l’environnement est exempt de concentrations inflammables ou équivalente
MAINTENANCE
Maintenance must be carried out only by qualified personnel. Failure to follow these
instructions may result in personal injury.
CAUTION: RADIO FREQUENCY INTERFERENCE
Most electronic equipment is influenced by Radio Frequency Interference. Caution
should be exercised with regard to the use of portable communications equipment
around such equipment. Signs should be posted in the vicinity of the equipment
cautioning against the use of portable communications equipment.
CAUTION:
The module PCBs contains static sensitive components. Static handling precautions
must be observed. DO NOT touch exposed connector pins or attempt to dismantle a
module.

Trusted High Integrity Power Supply System PREFACE
Rockwell Automation Publication PD_T8200 Issue 11 v
ISSUE RECORD
Issue Date Comments
8 Sep 05 Format
9 Mar 06 Removed hidden characters
10 Sep 15 Rebranded and reformatted
11 Apr 16 Standardisation of Operating Temperature and Relative Humidity Range
Statements in the Specification section

PREFACE Trusted High Integrity Power Supply System
vi Issue 11 Rockwell Automation Publication PD_T8200
Page intentionally left blank

Trusted High Integrity Power Supply System Table of Contents
Rockwell Automation Publication PD_T8200 Issue 11 1
Table of Contents
1. Description .............................................................................................................3
1.1. Power Supply Chassis..................................................................................................................3
1.2. Power Supply Modules ............................................................................................................... 4
1.3. Input Power Regulation .............................................................................................................. 4
1.4. Front Panel Indicators .................................................................................................................7
1.4.1. Input Power Voltage Indicator ............................................................................................7
1.4.2. Output Power Display ......................................................................................................... 7
1.4.3. Output Power Indicator.......................................................................................................7
2. Installation.............................................................................................................9
2.1. Chassis Mounting ........................................................................................................................ 9
2.2. Backplane Versions and Module Keying ...................................................................................10
2.2.1. Input Power Terminals: TB1, TB2 (#8 Screw Terminals) ...................................................10
2.2.2. Output Power Terminals: TB3, TB4 (#6 Screw Terminals) ................................................11
2.2.3. Status Connectors: J14, J15 ...............................................................................................11
2.2.4. Monitor Connector: J13 ....................................................................................................12
3. Configuration ....................................................................................................... 13
3.1. Current Sharing .........................................................................................................................13
3.2. REGENT Power Supply Load Units ............................................................................................13
3.3. Regent I/O Triplicated Power Distribution................................................................................13
4. Maintenance.........................................................................................................15
5. Specifications........................................................................................................17

Table of Contents Trusted High Integrity Power Supply System
2 Issue 11 Rockwell Automation Publication PD_T8200
Page intentionally left blank

Trusted High Integrity Power Supply System 1. Description
Rockwell Automation Publication PD_T8200 Issue 11 3
1. Description
The Power Supply Assembly consists of a Power Supply Chassis containing up to six Power
Supply Modules. The Chassis may be configured to distribute power in various
combinations. For example, a Chassis containing six Power Supply Modules may be set up
with three Modules providing triplicated power for Regent+Plus Input/Output (I/O)
assemblies and three Modules providing field power in a N+1 configuration. Alternatively,
the Chassis may be set up to provide separate dual 24 Vdc supplies for both a Trusted
System and associated field devices.
Figure 1 Power Supply Assembly
1.1. Power Supply Chassis
The Power Supply Chassis houses a maximum of six Power Supply Modules. It may be
mounted in a 19-inch rack or flush mounted on a panel. Table 1 identifies the available types
of Chassis.
Catalogue No. Chassis Unit Input Power Voltage Configuration
T8200 I/O Power Supply Chassis 110-240 Vac, 50/60 Hz Straight Bussed
T8201 I/O Power Supply Chassis 110-240 Vac, 50/60 Hz Cross Bussed
T8202 I/O Power Supply Chassis 24 Vdc
Table 1 Chassis Types

1. Description Trusted High Integrity Power Supply System
4 Issue 11 Rockwell Automation Publication PD_T8200
1.2. Power Supply Modules
The Power Supply Assembly Modules are single (if redundant inputs are not required) and
dual input, hot swap, user-replaceable ac and dc units. Table 2 identifies the available types
of Modules.
Catalogue No. Input Type Input Power Voltage Output Power Voltage
T8220 Dual 110-240 Vac 15 Vdc
T8222 Dual 24 Vdc 15 Vdc
T8223 Single 110-240 Vac 24 Vdc
T8224 Single 110-240 Vac 15 Vdc
T8225 Dual 110-240 Vac 24 Vdc
T8226 Dual 24 Vdc 24 Vdc
Table 2 Module Types
The dual inputs on the ac Modules are galvanically isolated from each other. The inputs on
the dc Modules are diode isolated and share a common return.
1.3. Input Power Regulation
A block diagram of a typical dual ac input I/O Power Supply Module is shown in Figure 2. A
block diagram of a typical dual dc input I/O Power Supply Module is shown in Figure 3.
Figure 2 Block Diagram of a Dual ac I/O Power Supply Module
PFC
PFC
Power Supply Module
PWM
Switching Regulator
T1:a
T1:c
T1:b
Rectifier
Rectifier
DC
Output
I/P Filter & Protection
I/P Filter & Protection
PFC A Off
I/P A Fail
PFC A Fail
Source
A
Source
B
Fail
High Tempterature
Reset
O/P Current
Status & Control
Remote Off
PFC B Off
I/P B Fail
PFC B Fail
Status & Control

Trusted High Integrity Power Supply System 1. Description
Rockwell Automation Publication PD_T8200 Issue 11 5
Figure 3 Block Diagram of a Dual dc I/O Power Supply Module
Each primary power input is individually fused and filtered with both standard line filters
and metal oxide varistors (MOVs). The filters attenuate any high frequency common mode
and normal mode noise present in the power distribution system. The MOVs clamp high
voltage transients.
Filter, rectifier, and power factor correction circuits convert primary ac input power to bulk
dc voltage. The switching regulator converts bulk dc power to regulated dc output voltage.
Sensing, status, control and timing circuits provide for the following:
•Input power failure - Active low status output. Indicates when the input voltage is
below 85 Vac or 18 Vdc. There is a separate signal for each input.
•Bulk power failure - Active high status output on ac input modules only. Indicates
the dc bulk voltage (power factor correction (PFC output)) is outside the specified
range. There is a separate signal for each input.
•High temperature warning alarm - Both an active high and active low status output
are provided. Indicates when the module temperature exceeds 75 °C. The
temperature is sensed near the air inlet (bottom) of the module.
•High temperature shutdown - Internal signal that will shut down the switching
regulator if module temperature is above 85 °C. The temperature is sensed near the
air inlet (bottom) of the module.
•Output over-voltage - Internal signal that will shut down the switching regulator if
the output voltage exceeds +18 Vdc for the 15 volt module and +28 Vdc for the
24 volt module. Over-voltage protection circuitry activation is a permanent error
condition, requiring manual intervention to return module to normal operation.
Power Supply Module
DC
Output
I/P Filter & Protection
I/P Filter & Protection
PWM
Switching Regulator
T1:a
T1:b
I/P A Fail Fail
High Tempterature
Reset
O/P Current
Status & Control
Remote Off
I/P B Fail
Status & Control
Source
A
Source
B

1. Description Trusted High Integrity Power Supply System
6 Issue 11 Rockwell Automation Publication PD_T8200
•dc output fail - Active high status output indicates the dc output voltage has gone
out of regulation. The dc output fail threshold is 13.75 Vdc (±0.25 Vdc) for the 15 volt
module, and 21.75 Vdc (±0.25 Vdc) for the 24 volt module.
•Output current limiting - Internal signal limits output current in excessive current
demand situations.
•POWER FAIL - Active high status signal that indicates impending loss of output power
due to one of the following:
oBoth inputs have indicated power failure.
oRemote off control signal activated.
oThermal shutdown.
oOutput over-voltage.
•RESET - Active high status signal that is generated a minimum of 10 ms (ac input
module) or 0.5 ms (dc input module) after a POWER FAIL signal. RESET remains
asserted for 200 ms (minimum) after module power-up.
•PFC off - Active low input that turns off the power factor correction of an individual
input. This signal provides the capability to test the input circuitry of a module by
turning off each input independently while monitoring the module fail signal.
•Remote off - Active low input that turns off the output power of a module.
Note: Bulk Power Fail, PFC Off and Remote Off are accessed through the Monitor Module Connector on the
chassis backplane. The Monitor Module Connector allows for a future development of a monitor card that
would provide remote control and enhanced monitoring of the Power Supply Chassis.
Active low signals are not maintained while RESET is active. All status signals are open
collector and require external pull-up resistors.
RESET is used in the Regent I/O Transceivers for power system interlocking within the I/O
system. A power failure (either input power or module fault) activates RESET and turns off
the dc output Front Panel Indicator.
The POWER FAIL and RESET signals are required for proper operation of Regent I/O
Transceivers and I/O modules during power-up, power down, and loss of power. Refer to
Assembly Installation in the associated Regent Product Description for details of connecting
these signals to a Regent I/O Chassis.

Trusted High Integrity Power Supply System 1. Description
Rockwell Automation Publication PD_T8200 Issue 11 7
1.4. Front Panel Indicators
The Front Panel of each I/O Power Supply Module supports three Light Emitting Diode (LED)
indicators detailed in the following sub-paragraphs
1.4.1. Input Power Voltage Indicator
Each green INPUT POWER indicator is lit when the associated input (Input A, Input B) is
above the lower input voltage threshold.
1.4.2. Output Power Display
The 10-segment LED indicator bar displays the approximate output current level percentage
(0 % - 100 %)
1.4.3. Output Power Indicator
The DC Output indicator is lit when the I/O Power Supply Module's dc output is within
tolerance. Out-of-tolerance conditions, loss of input power or brown-out, and module
failures turn off this indicator.

1. Description Trusted High Integrity Power Supply System
8 Issue 11 Rockwell Automation Publication PD_T8200
Page intentionally left blank

Trusted High Integrity Power Supply System 2. Installation
Rockwell Automation Publication PD_T8200 Issue 11 9
2. Installation
2.1. Chassis Mounting
Figure 4 and Figure 5 show the front and rear views of the Power Supply Chassis.
TB3
J13
J15
TB1
J14
19"
10.5"
J1 J2 J3 J4 J6J5
J7 J8 J12J11J9 J10
Input
Crossover
Patch
Figure 4 Power Supply Chassis Front View
Figure 5 Power Supply Chassis Rear View
TB4
TB2

2. Installation Trusted High Integrity Power Supply System
10 Issue 11 Rockwell Automation Publication PD_T8200
Mounting flanges can be attached to either the rear or the front of the Chassis. This allows
flush mounting the Chassis to a panel or mounting in a 19-inch rack.
The Input Crossover Patch is on the T8200 chassis only.
Input Crossover Patch configured for no crossover,
source 1 and source 2 are connected to input A and
input B respectively for all modules slots.
6E5 6E6
6E7 6E8
6E3 6E4
6E1 6E2
Input Crossover Patch configured to swap source 1
and source 2 for modules slots 4 through 6.
Source 1 and source 2 are connected to input A and
input B respectively for slots 1-3.
Source 1 and source 2 are connected to input B and
input A respectively for slots 4-6.
2.2. Backplane Versions and Module Keying
Connector placement on ac Input Modules and backplanes differ from dc modules and
backplanes. This prohibits insertion of the wrong Input Module type into a backplane.
Module slots in a chassis can be individually keyed to only accept a Module of a particular
output voltage.
2.2.1. Input Power Terminals: TB1, TB2 (#8 Screw Terminals)
Terminal No. T8200 T8202 Source
1 N DC- B
2 L DC+
3 N DC- A
4 L DC+
Table 3 Input Power Terminals
6E6
6E5
6E7
6E8
6E3
6E4
6E1
6E2

Trusted High Integrity Power Supply System 2. Installation
Rockwell Automation Publication PD_T8200 Issue 11 11
2.2.2. Output Power Terminals: TB3, TB4 (#6 Screw Terminals)
Terminal No. Module Slot T8200, T8202
12 6
+ DC Output
11 5
10 4
9 3
8 2
7 1
6
5
4 1-6
DC Return (terminals 1-6
are connected together on
Backplane)
3
2
1
Table 4 Output Power Terminals
2.2.3. Status Connectors: J14, J15
•Type: 10 pin shrouded header, double row, 0.100 x 0.100 Centres
•Manufacturer: AMP
•Manufacturer Part No: 102618-3
•Mating Connector: AMP 87631-5
•Pin Out:
Pin J14 J15
Slot Signal Slot Signal
1
2 All Input ‘A’ Fail
3 All Input ‘B’ Fail

2. Installation Trusted High Integrity Power Supply System
12 Issue 11 Rockwell Automation Publication PD_T8200
Pin J14 J15
Slot Signal Slot Signal
4 All Hi Temperature
5 1 Reset 4 Reset
6 1 Power Fail 6 Reset
7 2 Reset 4 Power Fail
8 3 Power Fail 6 Power Fail
9 2 Power Fail 5 Power Fail
10 3 Reset 5 Reset
Table 5 Status Connectors
2.2.4. Monitor Connector: J13
•Type: 72 pin Edge Connector, 0.125 in centreline
•Manufacture: AMP
•Manufacturer Part No: 1-530844-9
•Pin-out: Not Configured
