USER MANUAL
Bulletin 900-TC8, 900-TC16, & 900-TC32
Series B
Temperature Controllers

2

3
Important User Information
Because of the variety of uses for the products described in this publication,
those responsible for the application and use of this control equipment must
satisfy themselves that all necessary steps have been taken to assure that
each application and use meets all performance and safety requirements,
including any applicable laws, regulations, codes and standards.
The illustrations, charts, sample programs and layout examples shown in
this guide are intended solely for purposes of example. Since there are many
variables and requirements associated with any particular installation,
Rockwell Automation does not assume responsibility or liability (to include
intellectual property liability) for actual use based upon the examples shown
in this publication.
Rockwell Automation publication SGI-1.1, Safety Guidelines for the
Application, Installation and Maintenance of Solid-State Control (available
from your local Allen-Bradley sales office), describes some important
differences between solid-state equipment and electromechanical devices
that should be taken into consideration when applying products such as
those described in this publication.
Reproduction of the contents of this copyrighted publication, in whole or
part, without written permission of Rockwell Automation, is prohibited.
Safety Precautions
Safety Signal Words
This manual uses the following signal word to mark safety precautions for the
Bulletin 900-TC8, 900-TC16, and 900-TC32 Temperature/Process
Controllers.
These precautions provide important information for the safe application of
the Temperature/Process Controller. You must make sure to follow the
instructions provided in all safety precautions.:
ATTENTION
!
Identifies information about practices or circumstances
that can lead to personal injury or death, property damage
or economic loss

4
Attention statements help you to:
•identify a hazard
•avoid a hazard
•recognize the consequences
Trademark List
900Builder and 900BuilderLite are registered trademarks of Rockwell Automation, Inc.
European Communities (EC) Directive Compliance
If this product has the CE mark it is approved for installation within the
European Union and EEA regions. It has been designed and tested to meet
the following directives.
EMC Directive
This product is tested to meet the Council Directive 89/336/EC
Electromagnetic Compatibility (EMC) by applying the following standards,
in whole or in part, documented in a technical construction file:
EN 61326 EMC Requirements — Electrical Equipment for Control,
Measurement and Laboratory Use
This product is intended for use in an industrial environment.
Low Voltage Directive
This product is tested to meet Council Directive 73/23/EEC Low Voltage,
by applying the safety requirements of EN 61010-1 Safety Requirements
for Electrical Equipment for Control, Measurement and Laboratory Use —
General Requirements. For specific information, see the appropriate
sections in this publication, as well as the Allen-Bradley publication
Industrial Automation Wiring and Grounding Guidelines For Noise
Immunity, Publication 1770-4.1.
This equipment is classified as open equipment and must be mounted in an
enclosure during operation to provide safety protection.
IMPORTANT
Identifies information that is critical for successful
application and understanding of the product.

1-1 Publication 900-UM007D-EN-E - January 2011
Table of Contents
Important User Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Safety Signal Words . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
European Communities (EC) Directive Compliance . . . . . . . . . 1-4
Low Voltage Directive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Table of Contents
Preface
Conventions Used in This Manual . . . . . . . . . . . . . . . . . . . . . . . . . . . P-i
Meanings of Abbreviations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-i
Series B Controllers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ii
Series B Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ii
900-TC8x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ii
900-TC16x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ii
900-TC32x . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ii
Terminal Arrangements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-iv
Body Removal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-v
900-TC8, 900-TC16, & 900-TC32 Ratings . . . . . . . . . . . . . . . . . . . . P-vi
Characteristics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-vi
Communications Characteristics . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-vii
Other Upgrades . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-viii
Option Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-ix
How to Read Display Symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . P-x
Chapter 1
Bulletin 900 Input & Output
Overview
I/O Configurations & Main Functions. . . . . . . . . . . . . . . . . . . . . . . . 1-1
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Main Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Controller Hardware Versions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
900-TC8 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
900-TC16 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
900-TC32 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Front Panels & General Functions . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Display Meanings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Operation Indicators 1,2,3... . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-13
Basic Keypad Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-14
Chapter 2
Preparations
Hardware Installation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Approximate Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-1
Panel Cutout Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-2
System Wiring and Installation Guidelines. . . . . . . . . . . . . . . . . . 2-4
Panel Mounting — 900-TC8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-7
Setting Up the 900-TC8 Controller with the Optional Units . . . 2-9

Publication 900-UM007D-EN-E - January 2011
1-2 Table of Contents
Panel Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-13
Bulletin 900 Wiring Terminals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-15
Wiring Guidelines and Precautions. . . . . . . . . . . . . . . . . . . . . . . 2-17
Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-18
Using the Direct PC Communications Port . . . . . . . . . . . . . . . . . . . 2-30
Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2-30
Chapter 3
Configuration & Basic Operation
How Function Groups Are Configured and Operating the Keys on the
Front Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-3
Selecting Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-7
Changing Parameters/Loading Values into Controller Memory. 3-7
Communications Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-8
Setting Up Communications Parameter Data . . . . . . . . . . . . . . . 3-9
Initial Setup Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-9
Configuring the Input Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Input Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-12
Selecting °C/°F . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Temperature Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-14
Configuring the SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Changing the SP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-15
Selecting PID Control or ON/OFF Control . . . . . . . . . . . . . . . . . . 3-16
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
2-PID Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
ON/OFF Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-16
Configuring the Output Parameters . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Control Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Direct/Reverse Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-17
Assigned Output Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-20
Auxiliary Output Opening or Closing in Alarm . . . . . . . . . . . . . . . . 3-25
Executing the ON/OFF Control Method . . . . . . . . . . . . . . . . . . . . 3-25
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
ON/OFF Control Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . 3-25
ON/OFF Control Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-27
Determining PID Constants (AT, ST, Manual Setup) . . . . . . . . . . . 3-30
AT (Auto-Tuning) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-30
ST (Self-Tuning). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-33
Conditions that Start Self-Tuning (SRT) . . . . . . . . . . . . . . . . . . 3-34
Self-Tuning (ST) Stable Range . . . . . . . . . . . . . . . . . . . . . . . . . . 3-35
RT (Robust Tuning). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-36
Manual PID Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-39
Alarm Outputs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
Alarm Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-42
Alarm Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-44

Publication 900-UM007D-EN-E - January 2011
Table of Contents 1-3
PV Change Rate Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-45
Precaution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
Heater Burnout Alarm (HBA), Heater Short Alarm (HSA), and Heater
Overcurrent Alarm (HOA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-46
HBA, HSA, and HOA Alarm Detection . . . . . . . . . . . . . . . . . . 3-46
Installing Current Transformers (CT). . . . . . . . . . . . . . . . . . . . . 3-48
How to Calculate Heater Current Detection Values . . . . . . . . . 3-50
Application Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-51
Heater Burnout Alarm (HBA) Setup . . . . . . . . . . . . . . . . . . . . . 3-55
HS Alarm Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-58
Heater Overcurrent Alarm Set-up. . . . . . . . . . . . . . . . . . . . . . . . . . . 3-60
Moving to the Advanced Setting Function Group . . . . . . . . . . 3-60
Configure Overcurrent Detection. . . . . . . . . . . . . . . . . . . . . . . . 3-61
Set-up of the No. 3 Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-62
MV Display for Heating and Cooling Control . . . . . . . . . . . . . . . . . 3-63
System Setup/Operational Considerations. . . . . . . . . . . . . . . . . . . . 3-65
Chapter 4
Parameter Adjustments &
Application Considerations
Shifting Input Values . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
1-Point (Uniform) Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-1
2-Point Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-3
How to Calculate Input Shift Values . . . . . . . . . . . . . . . . . . . . . . 4-3
Using the 1-Point Shift Method . . . . . . . . . . . . . . . . . . . . . . . . . . 4-4
Using the 2-Point Shift Method . . . . . . . . . . . . . . . . . . . . . . . . . . 4-5
Alarm Functions/Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Alarm Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Standby Alarm Sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-8
Alarm Latch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Summary of Alarm Operations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-9
Configuration of Scaling Upper-Limits and Scaling Lower-Limits for
Analog Input. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-10
Executing the Heating and Cooling Control Mode . . . . . . . . . . . . . 4-12
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-12
Dead Band (Heating and Cooling Control) . . . . . . . . . . . . . . . . 4-13
Setup of Heating and Cooling. . . . . . . . . . . . . . . . . . . . . . . . . . . 4-15
Using the Event Input Feature — 900-TC8 & 900-TC16. . . . . . . . 4-16
Multi-SP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-19
Selecting Multi-SP by Keypad Operation . . . . . . . . . . . . . . . . . . 4-19
Multi-SP Setup . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-20
Executing RUN/STOP Controller Mode Change. . . . . . . . . . . 4-23
Switching Between Auto and Manual Control . . . . . . . . . . . . . . 4-23
Controlling the Start of the Simple Program Function . . . . . . . 4-23
Control by Inverting Direct/Reverse Operation . . . . . . . . . . . . 4-24

Publication 900-UM007D-EN-E - January 2011
1-4 Table of Contents
Switching 100% AT Execute/Cancel . . . . . . . . . . . . . . . . . . . . . 4-24
Switching 40% ATExecute/Cancel . . . . . . . . . . . . . . . . . . . . . . 4-25
Switching Setting Change Enable/Disable. . . . . . . . . . . . . . . . . 4-25
Switching Alarm Latch Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . 4-25
Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Configuring the SP Upper- and Lower-Limit Values. . . . . . . . . . . . 4-26
Set Point Limiter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-26
Application Considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Set Point Limit Setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-27
Executing the SP Ramp Function to Limit the SP Rate of Change 4-29
SP Ramp. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-29
SP Ramp Application Considerations. . . . . . . . . . . . . . . . . . . . . 4-30
To Move to the Advanced Setting Function Group . . . . . . . . . . . . 4-31
Using the Key Protect Function Group . . . . . . . . . . . . . . . . . . . . . . 4-33
Key Protect . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-33
PV Color Change . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
PV Color Change Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-39
Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-42
Alarm Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Alarm Delays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-44
Loop Break Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Loop Break Alarm (LBA) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-47
Performing Manual Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-53
Manual Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-53
Manual MV Limit Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-54
Using the Transfer Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-62
Transfer Output Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-62
Using the Simple Program Function . . . . . . . . . . . . . . . . . . . . . . . . . 4-66
Simple Program Function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-66
Operation at the Program End . . . . . . . . . . . . . . . . . . . . . . . . . . 4-69
Output Adjustment Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-75
Output Limits. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-75
MV at Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-75
MV at PV Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-76
Using the Extraction of Square Root Parameter . . . . . . . . . . . . 4-77
Setting the Rate of MV Variation . . . . . . . . . . . . . . . . . . . . . . . . 4-80
Setting the PF Key . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-82
Monitor/Setting Item. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-83
Monitor/Setting Item . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-83
Counting Control Output ON/OFF Operations . . . . . . . . . . . . . . 4-87
Control Output ON/OFF Count Function. . . . . . . . . . . . . . . . 4-87
Displaying PV/SV Status . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4-90

Publication 900-UM007D-EN-E - January 2011
Table of Contents 1-5
Chapter 5
Parameter Functions & Definitions
Conventions Used in This Chapter . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
About the Parameter Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Alarms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Protect Function Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-1
Move to Protect Function Group. . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Operation/Adjustment Protection . . . . . . . . . . . . . . . . . . . . . . . . 5-3
Initial Setting/Communications Protection . . . . . . . . . . . . . . . . . 5-4
Setting/Configuration Change Protection . . . . . . . . . . . . . . . . . . 5-4
PF Key Protect. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Parameter Mask Enable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-5
Password to Move to Protect Function Group . . . . . . . . . . . . . . 5-5
Operation Function Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-6
PV (Process Value) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-7
PV/SP – Process Value/Set Point – No. 1 Display
PV/SP – Process Value/Set Point – No. 2 Display (900-TC8) . 5-8
No. 3 Display (900-TC8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-8
Auto Manual Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Multi-SP (Set Point 0…3) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Set Point During SP Ramp . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-10
Heater Current 1 Value Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 5-11
Heater Current 2 Value Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 5-12
Leakage Current 1 Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-13
Leakage Current 2 Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-14
Program Start . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
Soak Time Remain. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-15
RUN/STOP. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Alarm Value 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-16
Alarm Value 2 (900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . 5-17
Alarm Value 3 (900-TC8) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Upper-Limit Alarm Value 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Lower-Limit Alarm Value 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-18
Upper-Limit Alarm Value 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-19
Lower-Limit Alarm Value 2 (900-TC8, 900-TC16) . . . . . . . . . . 5-19
Upper-Limit Alarm Value 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-20
Lower-Limit Alarm Value 3 (900-TC8 only) . . . . . . . . . . . . . . . 5-20
MV Monitor (Heating) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-21
MV Monitor (Cooling) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
Adjustment Function Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-22
Adjustment Function Group Display . . . . . . . . . . . . . . . . . . . . . 5-24
AT Execute/Cancel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-25
Communications Writing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-26
Heater Current 1 Value Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 5-26
Heater Current 1 Value Monitor. . . . . . . . . . . . . . . . . . . . . . . . . 5-27
Leakage Current 1 Monitor (900-TC8, 900-TC16) . . . . . . . . . . 5-28

Publication 900-UM007D-EN-E - January 2011
1-6 Table of Contents
Leakage Current 2 Monitor (900-TC8, 900-TC16) . . . . . . . . . . 5-29
Heater Burnout Detection 1 (900-TC8, 900-TC16). . . . . . . . . . 5-30
Heater Burnout Detection 2 (900-TC8, 900-TC16). . . . . . . . . . 5-31
HS Alarm 1 (900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . 5-31
HS Alarm 2 (900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . 5-32
Set Point 0 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
Set Point 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
Set Point 2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
Set Point 3 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-33
Temperature Input Shift . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-34
Upper-Limit Temperature Input Shift Value,
Lower-Limit Temperature Input Shift Value . . . . . . . . . . . . . . . 5-35
Proportional Band, Integral Time, Derivative Time . . . . . . . . . 5-35
Cooling Coefficient . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-36
Dead Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-37
Manual Reset Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-38
Hysteresis (Heating)
Hysteresis (Cooling). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-38
Soak Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-39
Wait Band. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-40
MV at Stop . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-40
MV at PV Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-41
SP Ramp Set Value . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-41
MV (Manipulated Variable) Upper-Limit,
MV (Manipulated Variable) Lower-Limit . . . . . . . . . . . . . . . . . . 5-42
MV Upper-Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-42
MV Lower-Limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-43
MV (Manipulated Variable) Change Rate Limit, . . . . . . . . . . . . 5-43
Extraction of Square Root Low-cut Point,. . . . . . . . . . . . . . . . . 5-44
Monitor/Setting Item Level (900-TC8) . . . . . . . . . . . . . . . . . . . . . . 5-45
Monitor/Setting Item Display 1 to 5 . . . . . . . . . . . . . . . . . . . . . 5-45
Manual Control Function Group . . . . . . . . . . . . . . . . . . . . . . . . 5-46
PV/MV (Manual MV) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-47
Initial Setting Function Group . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-48
Input Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-50
Scaling Upper-Limit, Scaling Lower-Limit, Decimal Point . . . . 5-52
Temperature Units (°C/°F) Selection. . . . . . . . . . . . . . . . . . . . . 5-53
Set Point Upper-Limit, Set Point Lower-Limit . . . . . . . . . . . . . 5-54
PID ON/OFF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-55
Standard or Heating/Cooling . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-55
ST Self-Tuning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-56
Program Pattern. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-57
Control Period (Heat) ,Control Period (Cool) . . . . . . . . . . . . . . 5-57
Direct/Reverse Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-58
Alarm Type for Alarm 1 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-59

Publication 900-UM007D-EN-E - January 2011
Table of Contents 1-7
Alarm Type for Alarm 2 (900-TC8 & 900-TC16) . . . . . . . . . . . 5-59
Alarm Type for Alarm 3 (900-TC8) . . . . . . . . . . . . . . . . . . . . . . 5-59
Alarm 1 Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-61
Alarm 2 Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-62
Alarm 3 Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-62
Transfer Output Type (900-TC8, 900-TC16). . . . . . . . . . . . . . . 5-62
Transfer Output Upper-Limit
Transfer Output Lower-Limit. . . . . . . . . . . . . . . . . . . . . . . . . . . 5-63
Linear Current Output (900-TC8, 900-TC16) . . . . . . . . . . . . . . 5-64
Number of Multi-SP Uses (900-TC8, 900-TC16) . . . . . . . . . . . 5-65
Event Input Assignment (* 1 and 2) (900-TC8, 900-TC16) . . . 5-66
Extraction of Square Root Enable (900-TC8, 900-TC16) . . . . . 5-68
Move to Advanced Setting Function Group . . . . . . . . . . . . . . . 5-68
Advanced Setting Function Group . . . . . . . . . . . . . . . . . . . . . . . . . . 5-69
Parameter Initialize . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-71
Multi-SP Uses. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-71
SP Ramp Time Units . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-71
Standby Sequence Reset Method . . . . . . . . . . . . . . . . . . . . . . . . 5-72
Auxiliary Output * Open in Alarm . . . . . . . . . . . . .(* = 1 to 3) 5-73
HB ON/OFF (900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . 5-74
Heater Burnout Latch (900-TC8, 900-TC16). . . . . . . . . . . . . . . 5-74
Heater Burnout Hysteresis (900-TC8, 900-TC16) . . . . . . . . . . . 5-75
ST (Self-Tuning) Stable Range . . . . . . . . . . . . . . . . . . . . . . . . . . 5-75
α. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-76
AT Calculated Gain . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-77
AT Hysteresis. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-77
Limit Cycle MV Amplitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-77
Input Digital Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-77
Additional PV Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-78
Manipulated Variable (MV) Display . . . . . . . . . . . . . . . . . . . . . . 5-78
Automatic Display Return Time . . . . . . . . . . . . . . . . . . . . . . . . . 5-79
Alarm 1 Latch, Alarm 2 Latch, Alarm 3 Latch. . . . . . . . . . . . . . 5-79
Protect Function Group Move Time . . . . . . . . . . . . . . . . . . . . . 5-80
Input Error Output . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-81
Cold Junction Compensation Method . . . . . . . . . . . . . . . . . . . . 5-82
MB Command Logic Switching . . . . . . . . . . . . . . . . . . . . . . . . . 5-82
PV Color Change. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-82
PV Stable Band . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-84
Alarm 1 ON Delay, Alarm 2 ON Delay, Alarm 3 ON Delay . . 5-85
Alarm 1 OFF Delay, Alarm 2 OFF Delay, Alarm 3 OFF Delay 5-86
Input Shift Type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-86
MV at Stop and Error Addition . . . . . . . . . . . . . . . . . . . . . . . . . 5-87
Auto/Manual Selection Addition . . . . . . . . . . . . . . . . . . . . . . . . 5-87
Robust Tuning (RT). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-88
Heater Short Alarm (HSA) Use (900-TC8, 900-TC16) . . . . . . . 5-88
Heater Short Alarm (HSA) Latch (900-TC8, 900-TC16). . . . . . 5-89

Publication 900-UM007D-EN-E - January 2011
1-8 Table of Contents
Heater Short Alarm (HSA) Hysteresis
(900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-89
Loop Break Alarm (LBA) Detection Time. . . . . . . . . . . . . . . . . 5-90
Loop Break Alarm (LBA) Level . . . . . . . . . . . . . . . . . . . . . . . . . 5-90
Loop Break Alarm (LBA) Band . . . . . . . . . . . . . . . . . . . . . . . . . 5-91
Control Output 1 Assignment . . . . . . . . . . . . . . . . . . . . . . . . . . 5-92
Control Output 2 Assignment (900-TC8 & 900-TC16) . . . . . . 5-93
Auxiliary Output 1 Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . 5-93
Auxiliary Output 2 Assignment (900-TC8, 900-TC16) . . . . . . . 5-94
Auxillary Output 3 Assignment. . . . . . . . . . . . . . . . . . . . . . . . . . 5-95
Character Select LED . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
Soak Time Units. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-96
Alarm SP Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-97
Manual MV Limit Enable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-97
PV Rate of Change Calculation Period. . . . . . . . . . . . . . . . . . . . 5-98
Automatic Cooling Coefficient Adjustment. . . . . . . . . . . . . . . . 5-98
Heater Overcurrent Use (900-TC8, 900-TC16) . . . . . . . . . . . . . 5-99
Heater Overcurrent Latch (900-TC8, 900-TC16) . . . . . . . . . . . 5-99
Heater Overcurrent Hysteresis . . . . . . . . . . . . . . . . . . . . . . . . . 5-100
(900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-100
PF Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-101
Monitor/ Setting Item * (*: 1 to 5) . . . . . . . . . . . . . . . . . . . . . . 5-102
PV/SP Display Screen Selection. . . . . . . . . . . . . . . . . . . . . . . . 5-103
MV Display Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-103
PV Decimal Point Display. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-104
PV Status Display Function . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-105
SV Status Display Function. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-106
Display Refresh Period . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-106
Control Output 1 ON/OFF Count Monitor. . . . . . . . . . . . . . 5-107
Control Output 2 ON/OFF Count Monitor
(900-TC8 & 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-107
Control Output 1 ON/OFF Count Alarm Set Value
(900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-107
Control Output 2 ON/OFF Count Alarm Set Value
(900-TC8, 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-108
ON/OFF Counter Reset. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-108
Move to Calibration Group. . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-109
Communications Setting Function Group . . . . . . . . . . . . . . . . . . . 5-109
Protocol Setting
Communications Unit No.
Communications Baud Rate
Communications Data Length
Communications Stop Bits
Communications Parity
Send Data Wait Time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5-110

Publication 900-UM007D-EN-E - January 2011
Table of Contents 1-9
Chapter 6
Troubleshooting & Error
Indication
Error Displays . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Input Error. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-1
Display Range Exceeded . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-2
AD Converter Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-3
Memory Error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Current Value Exceeds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-4
Heater Burnout Alarm (HBA)
Heater Short Alarm (HSA)
Heater Overcurrent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6-5
Appendix A
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-1
Heater Burnout Alarm (HBA), Heater Short Alarm (HSA), and
Heater Overcurrent Alarm . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-5
900-CPOEM1 USB-Serial Conversion Cable. . . . . . . . . . . . . . . A-5
Current Transformer (CT). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-7
Approximate External Dimensions . . . . . . . . . . . . . . . . . . . . . . A-7
Sensor Input Setting
and Indication Ranges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-9
Control Range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . A-10
Appendix B
Parameter Operations List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Function Groups . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-1
Setup Function Group Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . B-16
Parameter Flow . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . B-17
Appendix C
Calibration
Parameter Structure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-1
Registering Calibration Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-3
User Calibration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Calibrating Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Registering Calibration Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-4
Calibrating Thermocouples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Preparations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-5
Calibrating 0…50 mV Analog Input. . . . . . . . . . . . . . . . . . . . . . . . . C-10
Calibrating Platinum Resistance Thermometers. . . . . . . . . . . . . . . . C-12
Calibrating Analog Input (e.g., 4…20 mA Analog Input) . . . . . . . . C-14
Calibrating an Analog Current Input (900-TC8 & 900-TC16) . C-14

Publication 900-UM007D-EN-E - January 2011
1-10 Table of Contents
Calibrating an Analog Voltage (e.g., 1…5V DC) Input
(900-TC8 & 900-TC16) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-16
Checking Indication Accuracy . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-18
Checking Accuracy of a Thermocouple or Non-Contact
Temperature Sensor. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-18
Checking Indication Accuracy of a Platinum Resistance
Thermometer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . C-19
Analog Input (900-TC & 900-TC16) . . . . . . . . . . . . . . . . . . . . . C-20
Appendix D
Glossary
Definition of Terms . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . D-1
Index

P-i Publication 900-UM007C-EN-E - January 2011
Preface
Conventions Used in This
Manual
Meanings of Abbreviations
The following abbreviations are used in parameter names, figures, and in text
explanations. These abbreviations mean the following:
➊A heater short indicates that the heater remains ON even when the control output from the Temperature
Controller is OFF because the SSR has failed or for any other reason.
➋“EU” stands for Engineering Unit. EU is used as the minimum unit for engineering units such as °C, m, and g.
The size of EU varies according to the Input Type.
For example, when the input temperature setting range is –200…+1300°C, 1 EU is 1°C, and when the input
temperature setting range is –20.0…+500.0°C, 1 EU is 0.1°C.
For analog inputs, the size of EU varies according to the decimal point position of the scaling setting, and 1 EU
becomes the minimum scaling unit.
Note: For additional definitions of terms used in this manual, refer to
Appendix D, Glossary.
Table P.A
Symbol Term
PV Process value
SP Set point
SV Set value
AT Auto-tuning
ST Self-tuning
HB Heater Burnout
HS Heater Short ➊
EU Engineering unit ➋
OC Overcurrent
LBA Loop Burnout Alarm

Publication 900-UM007C-EN-E - January 2011
P-ii Preface
Series B Controllers
Series B Upgrades
Series B controllers have the following upgrades.
900-TC8x
Although the upgraded controllers are compatible with the previous
controllers, terminal arrangements have been changed. Terminal sizes and
panel mounting depth have not been changed.
Other changes are outlined in the following tables. Refer to the relevant pages
in the manual for details.
900-TC16x
The upgraded controllers are basically compatible with the previous
controllers. Terminal arrangements, terminal sizes, and panel mounting depth
have not been changed.
900-TC32x
Model numbers have changed accompanying the introduction of universal
input capability. The default setting of the input type parameter of the
900-TC32x (models with resistance thermometers) has been changed from a
Pt100 resistance thermometer to a K thermocouple. Make sure the setting of
the input type parameter agrees with the temperature sensor that is being used.
The terminal block has also been changed, which means the wiring methods
and terminal arrangement are different.

Publication 900-UM007C-EN-E - January 2011
Preface P-iii
➊ A 2-level display is configured when shipped from the factory. A 3-level display is activated if parameters are
initialized.
Table P.B
Series A Series B
900-TC16
• ALM indicator was changed to SUB indicator
900-TC8
• Number of displays: 2 (PV and SV) • Number of displays: 3 (PV, SV, and MV) ➊
• ALM indicator was changed to SUB indicator.
900-TC32
• Display Segments – PV: 7 segments, SV: 7
segments
• Character Heights – PV: 7 mm, SV: 3.5 mm
• Display Segments – PV: 11 segments, SV: 11
segments
• Character Heights – PV: 7.5 mm, SV: 3.6 mm
• Changes to Display Contents – “AL” LED indicator
eliminated, LED indicators and key indicator added
HA
ALM3
ALM2
ALM1
OUT1
OUT2
STOP
CMW
MANU
HA
ALM3
ALM2
ALM1
OUT1
OUT2
STOP
CMW MANU
STOP
OUT1
MANU
CMW
OUT2
ALM2
ALM3
ALM1
HA
STOPOUT1
MANU CMWOUT2
SUB2
SUB3
SUB1
HA
CMW STOP OUT
SUB1
CMW STOP OUT
MANU

Publication 900-UM007C-EN-E - January 2011
P-iv Preface
Terminal Arrangements
Table P.C — Terminal Arrangements
Series A Series B
900-TC8
Terminals 16...20 were changed and 1...15 were not.
900-TC16 --- No change for terminal layout
900-TC32
Number of terminals: 9 (1 to 9)
Input terminals: 7 to 9
RS-485 communication terminals: 5 & 6
• 100 to 240 VAC
• 24 VAC/DC (no polarity)
Number of terminals: 14 (1 to 14)
Input terminals: 10 to 12
RS-485 communication terminals: 7 & 8
CT2
One CT
Two CTs
Voltage output Long-life relay
output
−
+
CT1
12 VDC, 21mA
+
−
A
B
B
+
V
mA
−
250 VAC, 3 A
Analog input
TC/Pt universal input
Control Output 2 Control Output 2
(Resistive load)
+
−
14
15
14
15
14
15
16
17
18
19 19
++
−
B
+
V
mA
−
−
CT1
CT2
+
−
DO NOT
USE
DO NOT
USE
B
A
DO NOT
USE DO NOT USE
DO NOT
USE
One CT
Two CTs
Analo
g
in
p
utTC/Pt universal in
p
ut
Control Output 2
Control Output 2
14
15
16
17
18
19
20
1
71212
1111
1010
9
8
24
3 5 6
InputInput
PowerPower
SupplySupply
ControlControl
Output 1Output 1
AuxillaryAuxillary
Output 1Output 1
DO NOTDO NOT
USEUSE
AB
BUniversal
TC/Pt Input
DO NOTDO NOT
USEUSE
B(+) A(-)
RS-495
Communications
+
-

Publication 900-UM007C-EN-E - January 2011
Preface P-v
Body Removal
900-TC8, 900-TC16, &
900-TC32 Ratings
Table P.D — Body Removal
Series A Series B
900-TC8
• Removal using screws • Removal using hooks
900-TC16 --- • No change for body removal
900-TC32 --- • No change for body removal
Table P.E — 900-TC8, 900-TC16, & 900-TC32 Ratings
Series A Series B
Input sensor types for thermocouple inputs
--- The following types of thermocouple input
were added: W and PLII.
Input range for E thermocouple: 0...600 ºC Input range increased for E thermocouple:
-200...600 ºC
Input accuracy
• Thermocouple: ±0.5% PV or ±1ºC,
whichever is greater) ±1 digit
• Platinum resistance thermometer:
(±0.5%PV or ±1ºC, whichever is
greater) ± 1 digit
• Analog input: ±0.5% FS ± digit
• Thermocouple: ±0.3% PV or ±1ºC,
whichever is greater) ±1 digit
• Platinum resistance thermometer:
(±0.2%PV or ±.08ºC, whichever is
greater) ± 1 digit
• Analog input: ±0.2% FS ± digit

Publication 900-UM007C-EN-E - January 2011
P-vi Preface
900-TC8, 900-TC16, &
900-TC32 Ratings
Characteristics
Table P.E — 900-TC8, 900-TC16, & 900-TC32 Ratings
Series A Series B
Input sensor types for thermocouple inputs
--- The following types of thermocouple input
were added: W and PLII.
Input range for E thermocouple: 0...600 ºC Input range increased for E thermocouple:
-200...600 ºC
Input accuracy
• Thermocouple: ±0.5% PV or ±1ºC,
whichever is greater) ±1 digit
• Platinum resistance thermometer:
(±0.5%PV or ±1ºC, whichever is
greater) ± 1 digit
• Analog input: ±0.5% FS ± digit
• Thermocouple: ±0.3% PV or ±1ºC,
whichever is greater) ±1 digit
• Platinum resistance thermometer:
(±0.2%PV or ±.08ºC, whichever is
greater) ± 1 digit
• Analog input: ±0.2% FS ± digit
Influence of signal source resistance
• Thermocouple: 0.1ºC/Ω(except B,
R, S), 0.2ºC/Ω(B, R, S)
• Platinum resistance thermometer:
0.4ºC/Ω
• Thermocouple: 0.1ºC/Ω(for all
specifications)
• Platinum resistance thermometer:
0.1ºC/Ω
Current outputs • Current output resolution, approx.:
2,700 • Current output resolution, approx.: 10,000
Alarm outputs • 250 VAC, 1A (900-TC16 & 900-TC32) • 250VAC, 3A (900-TC16)
• 250VAC, 2A (900-TC32)
Table P.F — Characteristics
Series A Series B
Front Panel
(900-TC8)
--- PV Status Display
PF Key Added
--- PV/SP display selection for
three-level display
Inputs --- Square root extraction (for models
with analog inputs)
PF Key
