WT sensor PCT10 User manual

April 2023 1www.wtsensor.com
PCT10 Industrial Temperature Sensor
Features
■Long-term stable work
■Fast response
■easy to install
■High level of protection
■Integrated structure
Applications
■Equipment support
■Automatic temperature measurement
and control systems such as pumps,
compressors, natural gas pipelines,
etc.
■Temperature measurement of water or
oil in petroleum, chemical, electric
power, textile, and environmental
protection fields, etc.
Notes:
1 When measuring temperature, the
temperature measuring element should
reach thermal equilibrium with the
measured object.
2Makesuretheinsertionlengthis
accurate.
3 Please read the Instruction Manual of
the product carefully before installation
and check the relevant information of the
product.
4 Strictly follow the wiring method for
wiring, otherwise it may cause product
damage or other potential faults.
5 Misuse of the product may cause danger
or personal injury.
Product overview
PCT10 Industrial Temperature Sensor measures medium
temperature by using the characteristics of platinum resistance,
which changes with temperature change in a certain functional
relationship. It adopts imported high-performance, high-reliability
platinum resistance, could satisfy the long-term stable work.
Notes:
1 Do not misuse documentation.
2 The information presented in this product sheet is for reference
only. Do not use this document as a product installation guide.
3 Complete installation, operation, and maintenance information
is provided in the instructions of the product.
4 Misuse of the product may cause danger or personal injury.

April 2023 2www.wtsensor.com
Performance parameter
Temperature range -50℃to 150℃
Sensitive element Pt100 Grade A、Pt1000 Grade A
Insulation strength 100MΩ/250VDC
Response time ≤30s
Long-term stability ≤0.2%FS/year
Insert diameter Φ5mm
Storage temperature -40℃～85℃
Electrical connections Cable outlet
Protection grade IP67
The probe material 304
Structure
PCT10 - （-50～150℃）Z1 Y2 L050 2M
For example:PCT10-(-50～150)Z1Y2L050-2M
The model is PCT10, (-50～150): temperature range -50℃～150℃, Z1: Platinum resistance Pt100,
Y2:Electrical connection 3 wires, L050: Insert length 50mm, 2M: Cable length 2 meters
Dimension
Unit: mm
How to order
Insert length
L030:30mm
L050:50mm
L070:70mm
L100:100mm
Item No.
PCT10
Temperature range
(-50～150）:-50℃～150℃
Platinum resistance
Z1:Pt100
Z2:Pt1000 Electrical connection
Y1: 2 wires
Y2: 3 wires
Cable length
2M:2 meters
3M:3 meters
5M:5 meters

April 2023 3www.wtsensor.com
Ordering tips
1.Please ensure compatibility between measured medium and the contacting part of product when
placing an order.
2.For special requirements for product appearance or performance parameters, our company can
provide customization.
Wotian reserves the right to make changes to any product in this publication without notice. The
information we supply is believed to be accurate and reliable as of this printing.
