Powerplay Owner’s Manual
1
ENGLISH
Introduction
This manual contains important safety, maintenance, and use information. Be sure
to read it carefully and understand it thoroughly before your rst ride on your new
PowerplayTM bicycle.
This material applies only to the PowerplayTM Drive and should be used in conjunction
with your Rocky Mountain Owner’s Manual.
Please read the Owner’s Manual before your rst ride on your PowerplayTM bicycle.
If you do not have a copy of your Owner’s Manual, you can get it from your nearest
authorized Rocky Mountain dealer.
Register
Registering your bike is the ocial way for us to welcome you into the Rocky Mountain
family. It’s also an important step in activating your bike’s warranty. If you ever have an
issue, we’ll be able to handle your case eciently and get you back riding as soon as
possible. It’s easy and only takes a few minutes.
Register your bike: bikes.com/register

Powerplay Owner’s Manual
2
ENGLISH
Warnings
Power
Your PowerplayTM bicycle features a powerful pedal assist when force is applied to the
pedals. Familiarize yourself with your bike’s ride and pedal assist characteristics in
safe, at surroundings before riding it o road.
Instant start
Your PowerplayTM bicycle features “Instant Start” technology, which uses a
sophisticated torque sensing circuit to deliver smooth, instant, natural feeling power.
This circuit is very sensitive, so care must be taken to ensure the bike does not
accelerate from a stop in an unexpected or uncontrolled manner.
Use caution on trails
Your PowerplayTM bicycle accelerates more quickly and handles dierently than
traditional non-assist bicycles. Use appropriate caution on trails and be aware of your
bike’s unique handling and acceleration characteristics.
Keep your fingers away
Do not place your ngers or tools near the Drive unit. Maintenance and repair of the
drive unit should only be performed by an Authorized Rocky Mountain Service Centre.
Do not modify
Do not modify the PowerplayTM Drive unit or any components directly connected to
the drive unit. Maintenance and repair of the drive unit should only be performed by an
Authorized Rocky Mountain Service Centre. Any attempt to modify the PowerplayTM
Drive unit may result in serious personal injury or death, and will immediately void the
bicycle’s warranty.

Powerplay Owner’s Manual
3
ENGLISH
Shrediquette
Users
Always be courteous to other trail users. Use extra caution around domestic animals,
such as dogs and horses. Give other trail users right-of-way in all situations, during
both climbing and descending.
Trail
Only ride your PowerplayTM bicycle on trails and paths sanctioned for motorized
vehicle use. Follow all local laws and regulations. As with all trail users, care should
be taken by all cyclists to avoid impacts to the trail or environment. Do not skid on or
modify trails.

Powerplay Owner’s Manual
4
ENGLISH
Getting to know your bike
Technical details
• Reduced size and weight
- The Dyname 4.0 motor is 18.5% lighter
than the previous generation, Dyname 3.0.
- We’ve given our motor a weight
reduction while also increasing reliability.
The Dyname 4.0 motor features oversized
bearings for increased drive durability.
• A quiet drive system
- The Dyname 4.0 features a reduced
motor rpm that lowers the amount of
the electrical whine compared to other
systems.
- We’ve removed the upper chain slider
that was seen on the Dyname 3.0 drive
system to reduce the mechanical noise,
as well as the drag when pedalling.
• A responsive, natural power delivery
- Our system’s torque sensor reads the
tension that is being applied directly to
the chain, and removes unwanted lag
time to give an instantaneous and natural
response when the power is applied.
- We’ve developed a new torque curve
that is designed to gradually apply power
that achieves a maximum power of 770w
at optimal cadence (85rpm). By having
a variable power curve, you’ll have more
control of your bike on the trail including
scenarios like steep, technical hill starts.
• Torque and power
- The Dyname 4.0 drive system packs the
same 108Nm of class-leading torque that
the Dyname
3.0 brought to our previous generation
of bikes.
- Our drive system has 770W of peak
output, meaning that more watts are
delivered when you really need them.
• Jumbotron
- The Jumbotron is our display screen,
seamlessly integrated into the top tube
of our new Powerplay bikes. Positioned
to show all key data and information in
a convenient, easy to see location, the
screens can be navigated through using
the handlebar remote or the buttons on
the Jumbotron itself.
• Battery Size
- We’ve increased the capacity of the
Powerplay battery from 672Wh to 720Wh,
allowing you to spend more time riding.

Powerplay Owner’s Manual
5
ENGLISH
Technical details
• Smaller Remote
- We’ve replaced the iWoc that was
featured on our previous generation of
Powerplay’s with a new, smaller remote.
Designed by us, our new remote has
better ergonomics for you as the rider and
is focused on keeping the cockpit clean
and uncluttered. The smaller design also
allows it to be used in combination with
more shifter and brake options.
• Charging
- We have a 4-amp charger and a 2-amp
charger for the all-new Powerplay models,
both of which quickly refuel your battery
to get you back out there, faster. The less
powerful of the two, the 2-amp charger,
will charge the battery from 0-100% in 7
hours and 35 minutes which out paces the
competition.
• Mid-High Pivot Kinematics and Wheelpath
- Our revised suspension design features
a mid-high main pivot location that
seamlessly integrates with our Dyname 4.0
drive. The kinematics have better support
in both leverage rate and anti-squat, this
translates to smoother power delivery
to the ground with less energy loss. The
mid-high main pivot also creates a more
rearward wheel trajectory which all but
eliminates small to medium trail chatter.
• RIDE-4 adjustment system
- The RIDE-4 adjustment system allows

and suspension with a single Allen key.

two small chips.
• Adjustable Chainstay Length
- The chainstay length is adjustable by

and 200mm direct mount brake adapter.
The short position encourages a playful
and agile setting while the longer position
favours high speed stability. The Rocky
Mountain hanger is UDH compatible in the
long position as well.
• Secure and Internal Routing - There are
internal cable trays with secure tie downs
to ensure a rattle free ride while making it
easy to run cables and housing, even if you
prefer a Moto-Style setup with the front
brake on the right hand side.
Getting to know your bike

Powerplay Owner’s Manual
6
ENGLISH
Technical details
• Added protection, guards, and chainguide
- The frames feature downtube protection,
noise cancelling chainstay protection, and
downtube shuttle guards.
• Modular shock mount - Our modular
shock mount, available only on the carbon
models, allows for future suspension
kinematic updates.
• Updated Pivot Design
- Our chainstay and seatstay pivots feature

durability. There are shielded bearings
featured on all pivots including at the lower
shock mount (compatible with aftermarket
shocks as well).
Getting to know your bike

Powerplay Owner’s Manual
7
ENGLISH
Fork sag
We recommend approximately 15–20% sag for this platform.
ALTITUDE POWERPLAY INSTINCT POWERPLAY
Shock sag
We recommend approximately 30–35% sag for this platform.
ALTITUDE POWERPLAY INSTINCT POWERPLAY
Shock stroke
230x62.5mm
Sag
30% 19mm
35% 22mm
Sag
15%: 26mm
20%: 34mm
Fork travel
170mm
Shock stroke
210x55mm
Sag
30% 16mm
35% 19mm
Sag
15%: 23mm
20%: 30mm
Fork travel
150mm
Compatible with 160mm fork
Basic Setup
There are several variables that can be modied to ne-tune the setup of your
suspension. These are some basic guidelines to get you in the ballpark, and you can
experiment to see what suits you best from there. The rst step is to set your sag. Sag
refers to how much the suspension moves under just the weight of the rider (including
all riding accessories). Air pressure or coil spring rate and preload is adjusted until the
desired amount of sag is measured.
Please observe the minimum and maximum amount of preload recommended by the
manufacturer for a given coil spring. If you need to change the spring rate, please note
you must remove the eyelet bearings to remove the coil spring.

Powerplay Owner’s Manual
8
ENGLISH
Altitude Powerplay Spring Chart
Rebound
Rebound damping adjustment controls how quickly your suspension returns to full extension after it
hits a bump. Too much rebound damping, which means clicking the rebound knob towards the slow
setting, the fork or shock will move too slowly. This will cause the suspension to sink deeper and
deeper into its travel under repeated hits, which will feel harsh. Too little rebound damping, which
means clicking the rebound knob towards the fast setting, and the suspension can spring back too
quickly, causing a loss of traction and control. Follow the manufacturer’s recommendations for base
settings, and experiment to nd your happy place.
Compression
Low speed compression (LSC) controls rider weight shifts, pumping through terrain, G-outs, and
other slow inputs. Too much LSC will result in a harsher ride feel; too little LSC will result in a ride
feel that’s too soft and unresponsive.
2022 ALTITUDE POWERPLAY 230x62.5 FOX DHX2 COIL SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG
STEEL SPRING
WEIGHT
FOX SLS
SPRING WEIGHT SHOCK SAG RECOMMENDED
LSC SETTING *IF AVAILABLE
RECOMMENDED
HSR SETTING
RECOMMENDED
LSC SETTING
“RECOMMENDED
HSC SETTING”
100 / 45 300 300 19 - 22 mm 10 -11 6-7 14-15 6-7
110 / 50 300 325 19 - 22 mm 9 --11 6 -7 14-15 6-7
120 / 55 350 350 19 - 22 mm 8-9 6-7 14 -15 6-7
130 / 59 350 375 19 - 22 mm 8-10 6 -7 13-14 6-7
140 / 64 400 400 19 - 22 mm 6-7 5-6 12-13 5-6
150 / 68 400 425 19 - 22 mm 6-7 5-7 11-13 5-6
160 / 73 *Size MD 450 450 19 - 22 mm 5-6 4-5 9-10 5-6
170 / 77 450 475 19 - 22 mm 5-6 4-5 9-11 4-6
180 / 82 *Size LG 500 500 19 - 22 mm 4-5 4-5 9-10 4-5
190 / 86 500 525 19 - 22 mm 4-5 3-5 7-9 3-4
200 / 91 *Size XL 550 550 19 - 22 mm 3-4 3-4 6-7 3-4
210 / 95 600
Not Available
19 - 22 mm 2-3 2-3 5-6 2-3
220 / 100 600 19 - 22 mm 2-3 2-3 5-6 2-3
230 / 105 650 19 - 22 mm 1-2 1-2 4-5 1-2
240 / 109 700 19 - 22 mm 1-2 0 -1 3-4 0-1
250 / 114 Not Available 19 - 22 mm Not Available Not Available Not Available Not Available
2022 ALTITUDE POWERPLAY 230x62.5 FOX FLOAT X2 AIR SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG FOX FLOAT X2 PSI SHOCK SAG RECOMMENDED
LSR SETTING
RECOMMENDED
HSR SETTING
RECOMMENDED
LSC SETTING
RECOMMENDED
HSC SETTING
100 / 45 135 19 - 22 mm 11-14 5-6 14-16 6 -7
110 / 50 145 19 - 22 mm 11-13 5-6 14-16 6-7
120 / 55 155 19 - 22 mm 10 -12 5-6 13-15 6-7
130 / 59 165 19 - 22 mm 9 -11 4-5 13-15 6-7
140 / 64 175 19 - 22 mm 8-10 4-5 12-14 5-6
150 / 68 190 19 - 22 mm 7-9 4-5 11-13 5-6
160 / 73 200 19 - 22 mm 7-9 3-4 10 -12 5-6
170 / 77 210 19 - 22 mm 6-8 3-4 9-11 4-5
180 / 82 220 19 - 22 mm 6-8 3-4 8 -10 4-5
190 / 86 230 19 - 22 mm 5-7 2-3 7-9 4-5
200 / 91 240 19 - 22 mm 4-6 2-3 6-8 4-5
210 / 95 255 19 - 22 mm 3-5 2-3 5-7 3-4
220 / 100 265 19 - 22 mm 2-4 2-3 4-6 3-4
230 / 105 275 19 - 22 mm 2-4 1-2 2-4 3-4
240 / 109 285 19 - 22 mm 1-3 1-2 2-4 3-4
250 / 114 295 19 - 22 mm 1-3 1-2 2-4 2-3

Powerplay Owner’s Manual
9
ENGLISH
2022 ALTITUDE POWERPLAY 230x62.5 FOX FLOAT X AIR SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG FOX FLOAT X PSI SHOCK SAG RECOMMENDED
LSR SETTING
RECOMMENDED
LSC SETTING *IF AVAILABLE
100 / 45 140 19 - 22 mm 12 Start open / Adjust to suit
110 / 50 145 19 - 22 mm 11-12 Star t open / Adjust to suit
120 / 55 155 19 - 22 mm 11 Start open / Adjust to suit
130 / 59 165 19 - 22 mm 1 0 -11 Start open / Adjust to suit
140 / 64 175 19 - 22 mm 10 Star t open / Adjust to suit
150 / 68 185 19 - 22 mm 8-10 Start open / Adjust to suit
160 / 73 190 19 - 22 mm 8 Start open / Adjust to suit
170 / 77 200 19 - 22 mm 7-8 Start open / Adjust to suit
180 / 82 210 19 - 22 mm 7 Start open / Adjust to suit
190 / 86 220 19 - 22 mm 7 Start open / Adjust to suit
200 / 91 230 19 - 22 mm 7 Start open / Adjust to suit
210 / 95 240 19 - 22 mm 5-6 Start open / Adjust to suit
220 / 100 250 19 - 22 mm 5 Start open / Adjust to suit
230 / 105 260 19 - 22 mm 2-3 Start open / Adjust to suit
240 / 109 270 19 - 22 mm 2 Start open / Adjust to suit
250 / 114 280 19 - 22 mm 2 Start open / Adjust to suit
2022 ALTITUDE POWERPLAY 230x62.5 FOX DHX2 COIL SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG
STEEL SPRING
WEIGHT "FOX SLS SPRING SHOCK SAG RECOMMENDED
LSR SETTING
RECOMMENDED
HSR SETTING
RECOMMENDED
LSC SETTING
RECOMMENDED
HSC SETTING
100 / 45 300 300 19 - 22 mm 11-12
Not Available
14-15
Not Available
110 / 50 300 325 19 - 22 mm 10 -11 14-15
120 / 55 350 350 19 - 22 mm 9 -11 14-15
130 / 59 350 350 19 - 22 mm 8-9 14-15
140 / 64 400 400 19 - 22 mm 8-10 14 -15
150 / 68 400 425 19 - 22 mm 6-7 13 -14
160 / 73 *Size MD 450 450 19 - 22 mm 6-7 12-13
170 / 77 450 475 19 - 22 mm 5-6 11-13
180 / 82 *Size LG 500 500 19 - 22 mm 5-6 9-10
190 / 86 500 525 19 - 22 mm 4-5 9-11
200 / 91 *Size XL 550 550 19 - 22 mm 4-5 9-10
210 / 95 600
Not Available
19 - 22 mm 3-4 7-9
220 / 100 600 19 - 22 mm 2-3 6-7
230 / 105 650 19 - 22 mm 2-3 5-6
240 / 109 700 19 - 22 mm 1-2 5-6
250 / 114 Not Available 19 - 22 mm Not Available 6-7
Altitude Powerplay Spring Chart

Powerplay Owner’s Manual
10
ENGLISH
2022 INSTINCT POWERPLAY 210X55 FOX FLOAT X AIR SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG FOX FLOAT X PSI SHOCK SAG RECOMMENDED
LSR SETTING
RECOMMENDED
LSC SETTING *IF AVAILABLE
100 / 45 130 16 - 19 mm 12 Start open / Adjust to suit
110 / 50 140 16 - 19 mm 11-12 Start open / Adjust to suit
120 / 55 150 16 - 19 mm 11 Start open / Adjust to suit
130 / 59 160 16 - 19 mm 1 0 -11 Start open / Adjust to suit
140 / 64 170 16 - 19 mm 10 Start open / Adjust to suit
150 / 68 180 16 - 19 mm 8-10 Start open / Adjust to suit
160 / 73 190 16 - 19 mm 8 Start open / Adjust to suit
170 / 77 200 16 - 19 mm 7-8 Start open / Adjust to suit
180 / 82 210 16 - 19 mm 7 Start open / Adjust to suit
190 / 86 220 16 - 19 mm 7 Start open / Adjust to suit
200 / 91 230 16 - 19 mm 7 Start open / Adjust to suit
210 / 95 240 16 - 19 mm 5-6 Start open / Adjust to suit
220 / 100 250 16 - 19 mm 5 Start open / Adjust to suit
230 / 105 260 16 - 19 mm 2-3 Start open / Adjust to suit
240 / 109 270 16 - 19 mm 2 Start open / Adjust to suit
250 / 114 280 16 - 19 mm 2 Start open / Adjust to suit
2022 INSTINCT POWERPLAY 210X55 ROCK SHOX DELUXE AIR SHOCK *Count clicks from Closed: 0 Clicks = Closed*
RIDER WEIGHT
LBS / KG FOX FLOAT X PSI SHOCK SAG RECOMMENDED
LSR SETTING
RECOMMENDED
LSC SETTING *IF AVAILABLE
100 / 45 110 16 - 19 mm 8 Start open / Adjust to suit
110 / 50 12 0 16 - 19 mm 7-8 Start open / Adjust to suit
120 / 55 130 16 - 19 mm 7-8 Start open / Adjust to suit
130 / 59 140 16 - 19 mm 7 Star t open / Adjust to suit
140 / 64 150 16 - 19 mm 6 -7 Start open / Adjust to suit
150 / 68 160 16 - 19 mm 6-7 Start open / Adjust to suit
160 / 73 170 16 - 19 mm 6 Start open / Adjust to suit
170 / 77 180 16 - 19 mm 5-6 Start open / Adjust to suit
180 / 82 190 16 - 19 mm 5-6 Start open / Adjust to suit
190 / 86 200 16 - 19 mm 5 Start open / Adjust to suit
200 / 91 210 16 - 19 mm 4-5 Start open / Adjust to suit
210 / 95 220 16 - 19 mm 4-5 Start open / Adjust to suit
220 / 100 230 16 - 19 mm 4 Start open / Adjust to suit
230 / 105 240 16 - 19 mm 3-4 Start open / Adjust to suit
240 / 109 250 16 - 19 mm 3-4 Start open / Adjust to suit
250 / 114 260 16 - 19 mm 3 Start open / Adjust to suit
Instinct Powerplay Spring Chart

Powerplay Owner’s Manual
11
ENGLISH
Shock Eyelet Bearing
If you have your shock serviced, we highly
recommend removing these components, as
suspension service centres cannot guarantee
they will be returned. To remove the system,
follow these steps:
• Use the Rocky Mountain Bearing Eyelet
Tool Kit (Part# 1810031)
• Install the top hat piece on one side of the
bearing eyelet
• Next, install one of the cup removal tools
over the bearing cup with the top hat piece
installed.
• Thread the M8 screw snuggly against the
top hat piece
• Install the other cup removal tool over the
other bearing cup
• Thread the M8 screw all the way in until
it starts pushing on the other side. It is
contacting the inside of the top hat piece.
• Keep threading until one of the cups is full
pushed out.
• Next insert the drift tool through the shock
eyelet and rest it rmly against the bearing
cup that is still pressed in the shock eyelet.
• Gently, but rmly, hammer the drift tool
until the bearing cup is fully removed from
the shock eyelet.
If you do not have the Rocky Mountain
Bearing Eyelet Tool Kit, use a blind bearing
puller:
• Use a blind bearing puller (8 mm
extension) to remove both bearings.
• Remove the centre sleeve.
• Use the blind bearing puller (10 mm
extension) to remove the empty cups.
NOTE: the inner diameter of the cups is 11
mm, which means the 12 mm extension
won’t t (So don't force it); Use the 10 mm
extension.
To install new cups, use a bearing press or
vice with soft jaws installed, making sure
to press on the outer edge of the cups,
and don’t forget the centre spacer sleeve
between the cups.
Service
Your frame is equipped with cartridge bearings in the rear eyelet, allowing for better
small-bump compliance. These bearings are carried by cups that have a very rm press
t into the shock shaft.

Powerplay Owner’s Manual
12
ENGLISH
RIDE-4
Position
SLACK
The lower bottom bracket
and progressive suspension
increase stability at higher
speeds. Recommended for
more aggressive trail riding
Position 3
NEUTRAL

blend of geometry and
suspension performance to
cater to a wide variety of trails
Position 4
STEEP
The higher bottom bracket
and linear suspension allow for
better pedal clearance, a more
supportive initial suspension
rate, and a position on the bike
better suited for climbing.
READY FOR ANY TRAIL
The RIDE-4™ adjustment system allows

suspension with a single 5-mm Allen key
STEEPER

SLACKER

LE S S
PROGRESSIV E
SUSPENSION
MORE PROGRESSIVE
SUSPENSION
The RIDE-4™ adjustment system allows riders to quickly ne-tune their geometry with
a single 5-mm Allen key. Four congurations are possible thanks to a pair of rotating
chips. Geometry setup is a complex art form with huge variables in rider style, preference,
terrain and ability. We do recommend the use of professional services, but we also believe
that learning to dial in your own bike is the best way to fully understand its performance.
When adjusting your RIDE-4 position, make gradual, incremental changes, take notes
and be methodical. Don’t adjust in a hurry before a big ride. Take your time and enjoy the
process.
1
95
1
9
5
1
95
1
9
5

Powerplay Owner’s Manual
13
ENGLISH
Shock tment
We check clearances for many shocks but cannot guarantee compatibility with all makes


Critical Dimensions
One chainring size only:
34t
Bottom bracket standard:
Press Fit BB92
Ream depth (CARBON/ALLOY):
SM: 190mm | 150mm
MD: 235mm | 195mm
LG: 240mm | 200mm
XL: 290mm | 250mm
Seatpost outer diameter: 30.9 mm
Seat QR inner diameter: 34.9 mm
Headset standard:
ZS44 top
ZS56 bottom
Fork:
Altitude PP /
Instinct PP
Max Travel =170mm
Max Axle to Crown
Length = 586
Hardware:
20 mm x M8
Shock dimensions:
Altitude PP: 230 x 62.5mm
Instinct PP: 210 x 55mm
Hardware:
Rocky Mountain
Bearing Eyelets
Rear hub spacing:
Boost 148 mm
Brake standard:
200 mm post mount
Max rotor:
223 mm
Max tire size:
29 x 2.6
Minimum insertion:
100 mm
Approved shocks for Altitude Powerplay and Instinct Powerplay
Fox
• FLOAT DPS
• FLOAT X
• FLOAT X2
• DHX
• DHX2
Can Creek
• DB Coil
• DBiL Coil
• DB Air
• DBiL Air
RockShox
• Deluxe
• Super Deluxe
• Super Deluxe Coil
*SIDLuxe not approved
UDH Compatibile
Marzocchi
• Bomber RC

Powerplay Owner’s Manual
14
ENGLISH
Images
Integrated
Jumbotron display
Speed sensor
on rotor
Dual position rear
axle

Powerplay Owner’s Manual
15
ENGLISH
Battery
access hatch
Torque
sensor
Lower idler
Spider w. clutch
bearing
Drive pinion
Charging port
Cable collector
xing screw

Powerplay Owner’s Manual
16
ENGLISH
CLICK
Rider screen scroll
Menu Navigation
Ok / Enter / Select
HOLD
Access main menu
Escape to rider screen
CLICK
Assist UP
HOLD
Reset trip
(Odo view only)
CLICK
Assist DOWN
HOLD
Walk mode
Back 1 level menu
HOLD
Up button and mode
button for diagnostic
menu
Rider Controls
TMI (Thumb – Machine Interface, aka the remote)

Powerplay Owner’s Manual
17
ENGLISH
Rubber seal
To remote
To drive
Jumbotron
The Jumbotron display is the communication centre of your Powerplay™ bike. It serves
to operate the system, display information and diagnose and repair issues. Firmware
updates will be carried out through the USB module and computer as required.
Display
Fixing screw
HOLD
Power On
CLICK
cycle through
assist
HOLD
Power OFF
