Roger Access Control System
RWL-2-SL Standalone Door Lock
Operating Manual
Firmware version: 1.1
Document version: Rev. A

RWL-2-SL Operating Manual.doc 2021-12-20
2/12
DESIGN AND APPLICATION
RWL-2-SL lock enables read-in access control based on MIFARE proximity cards - based on the card
numbers stored in its memory, the lock decides autonomously if the access can be granted.
The RWL-2-SL lock consists of two escutcheons with handles. Card reader is installed in the external
escutcheon while the battery pack is installed in the internal one. The internal handle is permanently
coupled with latch and door can be always open without use of electronics. The external handle is
separated from the latch and moves freely. When the access is granted the electronic module couples
the external handle with latch to enable door opening. The RWL-2-SL lock can be optionally equipped
with door cylinder and then be opened from the outside with traditional metal key. The lock is
supplied by 4 AAA batteries. Low battery level can be signalled locally. The batteries enable one year
operation for average 10 opening cycles per day.
Depending on door opening direction and handle location on the door leaf the adequate type of RWL-
2-SL lock must be applied.
Version Description
RWL-2-SL-L Left hand door, left hand reverse door
RWL-2-SL-R Right hand door, right hand reverse door
Fig 1. RWL-2-SL-L installation scenarios (view from the outside)
Fig. 2. RWL-2-SL-R installation scenarios (view from the outside)

RWL-2-SL Operating Manual.doc 2021-12-20
3/12
Mechanical construction
External part of RWL-2-SL
The external part of RWL-2-SL consists of escutcheon with handle and it is dedicated to installation at
the entry to controlled room. The escutcheon includes card reader (A) and hole for door cylinder
which can be used for emergency door opening with mechanical key. The electronic module which is
located inside the escutcheon includes service contact (B) and programming contacts (C). Wires with
plug (E) are used to connect the module with battery pack. Three isolated wires (F) are not used in
RWL-2-SL.
Fig. 3. RWL-2-SL entry escutcheon
Fig. 4. Electronic module inside entry escutcheon

RWL-2-SL Operating Manual.doc 2021-12-20
4/12
Internal part of RWL-2-SL
The internal part of RWL-2-SL consists of escutcheon with handle and it is dedicated to installation at
the exit from controlled room. The internal escutcheon includes battery pack. In order to replace
batteries remove hex screw and battery cover. Wires with plug (G) are connected to socket (E) at
external escutcheon in order to supply it.
Fig. 5. RWL-2-SL exit escutcheon
Door cylinder
RWL-2-SL lock enables installation of a lock cylinder. Such cylinder enables emergency door opening
from the outside using metal key. The size of cylinder depends on door thickness and it must be
selected in such way that it would not protrude by more than 16mm over door surface of inside and in
range 21-24 from outside.
FUNCTIONAL DESCRIPTION
The RWL-2-SL can be used as autonomous access control point, where the access is granted based on
the data stored in the lock’s memory. The lock requires configuration which can be done from the
programming computer with the RogerVDM application and connected to the lock through RUD-1
communication interface. If the lock is designated to operate with list of 50 users, each equipped with
Main card and Backup card , it can be programmed manually without computer. In this scenario, two
programming cards, called ADD card and DEL card, are used to program the unit.
Note: Due to the small size of the proximity keyfobs, they may be incorrectly detected by the built-in
proximity sensor. In the RWL series locks, it is recommended to use full-size ISO proximity cards.
Proximity cards
The lock is equipped with a card reader which supports MIFARE® cards. Factory configured device
reads card serial number (CSN - Chip Serial Number ), but using RogerVDM software it can be

RWL-2-SL Operating Manual.doc 2021-12-20
5/12
configured to use programmable card number (PCN – Programmable Card Number ) stored in the
encrypted memory of the MIFARE card.
Card number
The card number which RWL-2-SL lock reads from the card and returns to the access controller is
called RCN ( Returned Card Number ). In general, the RCN can be composed of two sections:
·CSN section
·PCN section
The CSN section is a part of the RCN card number taken from the card serial number (CSN). The
serial number is programmed by card manufacturer.
The PCN section is a part of the RCN card number taken from the card’s programmable memory. The
programmable number can be encrypted with own key in order to enable protection against card
copying.
Due to relatively easy copying of the card serial numbers (CSN), it is recommended to configure the
lock for operation with programmable card numbers (PCN).
Standalone Access Control
The lock grants access for cards stored in its memory. Up to 100 cards can be defined and stored in
lock’s memory. Each card can be authorised for momentary door opening (option: Normal access )
and/or to open the door for unlimited time (option: Office access ). If the card is authorized for Normal
access then it opens the lock for the time specified by the parameter Lock pulse . If the card is
authorized for Office mode then it can open the lock for unlimited time. When lock is switched to
Office mode door can be open without use of a card. If the card is authorised for Normal access and
Office mode then in order to get normal access it must be used once while in order to activate Office
mode it must be used twice.
Backup cards
Up to 100 cards can be defined and stored in lock’s memory. Each card can belong to individual user.
Optionally the lock can operate with 50 users only. In such a case each user can have two cards: Main
card and Backup card . Both cards have the same authorizations and the enrolment of Backup card is
optional. Factory new lock is configured to operate with 50 users. This mode is also used when lock’s
default settings are restored. Switching to 100 users mode can be done only by means of RogerVDM
software. The main benefit of Backup cards is to enable selective removing of Main cards from the
lock’s memory even if such Main cards are not physically available (e.g. lost or damaged). Therefore
it is recommended to mark and store Backup cards in designated place for future use.
Note: Backup card is assigned with same authorizations as accompanying Main card and can be used
in the same way as the Main card .
LED indicators
RWL-2-SL lock is equipped with 3 LED indicators which functions are described in the table below.
LED indicators
Name Colour Description
LED RED Red Indicator is blinking when lock waits for the optional second
card reading. If it occurs, lock switches to Office mode .
LED BLUE Blue Indicator:
·2 sec pulse when access is granted and external
handle is coupled
·two 2 sec pulses when access is denied

RWL-2-SL Operating Manual.doc 2021-12-20
6/12
·lights steadily when operates in Office mode
LED
SYSTEM Orange ·lights steadily in case of lock’s configuration error
·pulses slowly in case of low battery level (batteries
must be replaced)
Power supply
RWL-2-SL lock is supplied from 4 pcs of AAA batteries. In case of average 10 operations daily the
alkaline batteries enable 1 year functioning. Low battery level is reported to VISO management
software and additionally it is signalled locally by orange LED SYSTEM pulsing and acoustic signal
generated prior to entering standby mode.
CONFIGURATION
RWL-2-SL lock can be programmed manually or from PC computer. All configuration settings can be
setup and edited using RogerVDM program. Connection to PC requires RUD-1 interface.
Factory new lock is configured with 2 programming cards (ADD card and DEL card). Lock pulse by
default is set to 2 sec while built-in RFID reader is configured to read card serial numbers (CSN).
Factory cards
Label Name Authorization
ADD ADD programming card New card adding to the lock
DEL DEL programming card Card deleting from the lock
Configuration recovery from the lock
In some circumstances it might be required to recover the configuration settings from the lock. Such
operation can be done by means of RogerVDM software. Regardless of the operating mode it is not
possible to recover communication password and card encryption keys. Recovery of the user cards
programmed in the lock’s memory, can be disabled by means of Card codes protection option, which
by default is set off so the card codes can be read from the lock’s memory.
Note: Once the Card code protection option is set, the only way to clear it is to execute memory reset
which erases entire lock’s memory.
Manual programming of the users
The lock can be configured manually without computer. Using manual programming it is possible to
add and delete user cards. Factory new lock is configured with Backup cards and delivered with 2
programming cards (ADD card and DEL card). The manual programming of the users can be used
either when lock operates with Backup cards (50 users limit) or without Backup cards (100 users
limit). When lock operates with 100 user limit, programming steps related to the Backup cards shall be
skipped.
Note: It is possible to program new ADD and DEL programming cards during memory reset
procedure.
User adding
A. Read ADD programming card.
B. Read first card to program user’s Main card .
C. Read second card to program user’s Backup card .
Notes:

RWL-2-SL Operating Manual.doc 2021-12-20
7/12
·New user shall be granted Office access if step A is repeated twice.
·New user shall be granted Normal access and Office access if step A is repeated thrice.
·If Backup card is not needed then read ADD programming card again in step C.
·If already programmed card is used in step B or C then the lock shall generate 2 sec
acoustic warning and shall finish programming procedure.
Example: Programming of user with Normal access
·Read ADD programming card once.
·Read first card to program user’s Main card .
·Read second card to program user’s Backup card .
·Wait till 3 acoustic beeps ar e generated by lock and then you can continue with more cards
programming.
Example: Programming of user with Office access
·Read ADD programming card twice.
·Read first card to program user’s Main card .
·Read second card to program user’s Backup card .
·Wait till 3 acoustic beeps ar e generated by lock and then you can continue with more cards
programming.
Example: Programming of user with Normal access and Office access
·Read ADD programming card thrice.
·Read first card to program user’s Main card .
·Read second card to program user’s Backup card .
·Wait till 3 acoustic beeps ar e generated by lock and then you can continue with more cards
programming.
User deleting
A. Read DEL programming card.
B. Read Main card or Backup card to remove both cards from the lock’s memory.
Note: All cards can be removed from memory using memory reset procedure.
Example: User deleting
·Read DEL programming card.
·Read Main card or Backup card to remove both cards from the lock’s memory.
·Wait till 3 acoustic beeps are generated by lock and then you can continue with more cards
programming.
Programming with RogerVDM software
RogerVDM software enables full configuration of the lock, it is also possible to configure list of 100
users with Main cards instead of default list of 50 users with Main cards and Backup cards . The
selection of user limit is done with the parameter Backup cards . When the option is set to [1]: Yes
then lock operates with 50 users limit.
Note: It is recommended to backup RWL-2-SL settings, save them to file and protect against loss and
access of unauthorized persons.
The procedure below includes steps required to configure the lock using computer and RogerVDM
software.

RWL-2-SL Operating Manual.doc 2021-12-20
8/12
1. Place jumper on MEM pins.
2. Connect the lock to RUD-1 interface using dedicated cable (fig. 6).
3. Short RST pins for a moment preferably by placing and removing jumper – Orange LED
SYSTEM shall pulsate.
4. In RogerVDM select Device/New and then select type of device (RWL-2-SL) and serial
COM port with RUD-1 interface.
5. Select required settings.
6. Make backup by saving settings to file (button: Send to File… ).
7. Upload settings to the lock (button: Send to device ).
8. In RogerVDM select Device/Disconnect .
9. Remove jumper from MEM pins.
10. Short RST pins for a moment preferably by placing and removing jumper.
11. The lock is ready for operation.
Fig. 6. Connection of lock to the RUD-1 interface
RogerVDM commands
The table below includes commands which are available in RogerVDM software for RWL-2-SL lock.
Command/button Description
Tab: Configuration
Load defaults Restore default settings
Read from File… Load backup configuration
Send to File... Save backup configuration
Read from Device Reads configuration from device
Send to Device Upload configuration to device
Tab: Credentials
Add Adds new user
Edit Edit existing user
Delete Delete existing user
Delete all Delete all users

RWL-2-SL Operating Manual.doc 2021-12-20
9/12
Read from file Read users list from file
Write to file Save users list to file
Read from device Read users list from device
Send to device Save users list to device
RWL-2-SL configuration parameters in RogerVDM
The table below includes RWL-2-SL configuration parameters which can be modified using RogerVDM
software within low level configuration of device (tab: Configuration ).
Parameter Function
General settings
LED SYSTEM flash after card
read When option is set then card reading is confirmed with flash on LED SYSTEM. Default value: Yes.
Short sound after card read When option is set then card reading is confirmed with short
acoustic beep. Default value: Yes.
LED SYSTEM pulsing when
card close to the reader When option is set then orange LED SYSTEM pulses whenever card is detected near the reader. Default value: No.
Battery low level signalisation When option is set then lock signals low battery level by orange
LED SYSTEM indicator pulsing and series of 5 acoustic beeps after
card reading. Default value: Yes.
Buzzer loudness level The parameter defines loudness level of the built-in buzzer. When
set to zero then buzzer is disabled. Default value: 100%
Standalone mode
Lock pulse [s] The parameter defines lock opening time when access is granted.
Default value: 2s.
ADD programming card The card code of the ADD programming card.
DEL programming card The card code of the DEL programming card.
Backup cards When option is on, then each user programmed in the lock can
have both Main card and Backup card . When the option is off then
each user can have the Main card only. Default value: Yes.
Card codes protection When option is set then it is not possible to read user card codes
from the lock’s memory. Once option is set it can be cleared by
memory reset procedure only. The purpose of the option is to
prevent unauthorized person to read card numbers from the lock’s
memory. Default value: No.
Advanced card read settings
CSN length The parameter defines number of bytes taken from the card serial
number (CSN) and applied in the returned card number (RCN).
Default value: 8.
Mifare Classic settings
Sector type When the parameter is enabled then returned card number (RCN)
is composed of two parts: the programmable card number (PCN)
and the card serial number (CSN).
When the option is disabled then the returned card number (RCN)
is composed of the card serial number (CSN) only.
Default value: None.

RWL-2-SL Operating Manual.doc 2021-12-20
10/12
Format The format of the programmable card number (PCN) stored in the
card’s memory. Default value: BIN.
First byte position (FBP) The parameter specifies the position of the most significant byte
(MSB) of programmable card number (PCN). Default value: 0.
Last byte position (LBP) The parameter specifies the position of the least significant byte
(LSB) of programmable card number (PCN). Default value: 7.
Sector ID The parameter specifies sector number in card’s memory where
programmable card number (PCN) is stored. Default value: 0.
Application ID The parameter Application ID (AID) is located in card’s MAD sector
and it specifies the sector where programmable card number
(PCN) is stored if the Sector type (see above) is configured as
MAD. Default value: 5156 (Roger AID).
Block ID The parameter specifies the block number where programmable
card number (PCN) is stored in a particular sector of card’s
memory. For sectors 0-31, blocks 0-2 are available while for
sectors 32-39, blocks 0-14 are available. Default value: 0.
Key type The parameter specifies key type used for encryption of data in
card’s memory. Default value: A.
Key The parameter specifies 6-byte key used to encrypt data in card’s
memory. Default value: FF...FF.
Users
Credentials tab in RogerVDM top menu enables management of the cards programmed in the lock’s
memory. As explained earlier, lock can operate with 50 users with Main card and Backup card or 100
users with Main card only. Each user can be granted with Normal access and/or Office mode
authorisation. If programmed, the Backup card have the same authorisations as a Main card it
accompanies. When user is granted with the Normal access authorisation it can open a door for the
time defined by Lock pulse parameter. When user is granted with Office mode it can open the door for
unlimited time and then, when required using the same card it can terminate Office mode . Both
options can be granted to the same user.
When card has both authorisations, with the first card usage lock opens for Lock pulse time and waits
for optional second card usage what is signalled by LED SYSTEM blinking. If the card is used second
time lock switches into Office mode . If the lock is in the Office mode then with the single use of a card
with Office mode authorisation lock terminates Office mode .
Memory reset
Memory reset erases all programmed card and restores factory configuration settings. After reset the
locks operates with 50 users list and reads card serial number (CSN). In order to perform memory
reset procedure proceed with following steps:
·Remove jumper from the MEM pins (if applicable).
·Short RST pins for a moment preferably by placing and removing jumper.
·When acoustic signalization is started place jumper on MEM pins and the devices shall
confirm memory reset with 3 acoustics beeps.
·Read any proximity card and it shall be new ADD programming card.
·Read any proximity card and it shall be new DEL programming card.
·Wait for 3 acoustic beeps. The lock shall restore default factory settings and shall switch to
normal operation.

RWL-2-SL Operating Manual.doc 2021-12-20
11/12
INSTALLATION
The lock is designed for installation in door with 38 to 75mm thickness and with 72mm handle
spacing. Prior to installation make sure that door cylinder is long enough.
Lock installation
·Make holes in door using drilling template. In case of non-rebated door it might be
necessary to use metal plate. Both, drilling template and metal plate are included in the
factory new set.
·Optionally install external door contact (e.g. reed relay) and deadbolt contact - connect
them to brown and yellow wires.
·Lead battery wires through hole and then connect them to the external escutcheon.
·Check position of spindle support (fig. 7) and mount door handle spindle.
·Install batteries (4xAAA) in the pack and then insert into internal escutcheon.
·Mount escutcheons and verify if the internal handle controls the cylinder and metal key can
open the door.
Note: Ensure access to metal key to enable emergency opening of the door.
Fig. 7 Proper position of spindle support
Specification
Parameter Value
Power supply 4 x AAA (LR03) alkaline batteries
Battery life Approx. 1 years with 10 entries per day
Door thickness 38 – 75 mm
Handle spacing 72 mm
Built-in card reader ISO/IEC 14443A MIFARE®
Environmental class
(acc. to EN 50131-1) Class I, indoor general conditions, temperature: +5°C to +40°C, relative humidity: 10 to 95% (no condensation)
IP code IP40
Dimensions 47 x 280mm
Weight Approx. 1100g
Certificates CE (see: INSTALLATION section)

RWL-2-SL Operating Manual.doc 2021-12-20
12/12
Ordering information
Product Description
RWL-2-SL-L Standalone door lock with escutcheons; left hand, left hand reverse
RWL-2-SL-R Standalone door lock with escutcheons; right hand, right hand
reverse
Product history
Product version Released Description
1.1 XII 2021 The first commercial version of the product
This symbol placed on a product or packaging indicates that the product
should not be disposed of with other wastes as this may have a negative
impact on the environment and health. The user is obliged to deliver
equipment to the designated collection points of electric and electronic
waste. For detailed information on recycling, contact your local authorities,
waste disposal company or point of purchase. Separate collection and
recycling of this type of waste contributes to the protection of the natural
resources and is safe to health and the environment. Weight of the
equipment is specified in the document.
Contact:
Roger sp. z o.o. sp.k.
82-400 Sztum
Gościszewo 59
Tel.: [phone]
Fax: [phone]
Tech. support: [phone]
E-mail: [e-mail]
Web: www.roger.pl
