Rohde & Schwarz FSWP User manual

R&S®FSWP
Phase Noise Analyzer
Getting Started
1177575602
Version 13
(;ÛÇÆ2)

This manual describes the following R&S®FSWP models with firmware version
2.00 or higher:
●R&S®FSWP8 (1322.8003K08)
●R&S®FSWP26 (1322.8003K26)
●R&S®FSWP50 (1322.8003K50)
© 2021 Rohde & Schwarz GmbH & Co. KG
Mühldorfstr. 15, 81671 München, Germany
Phone: [phone] - 0
Email: [email protected]
Internet: www.rohde-schwarz.com
Subject to change – data without tolerance limits is not binding.
R&S® is a registered trademark of Rohde & Schwarz GmbH & Co. KG.
Trade names are trademarks of the owners.
1177.5756.02 | Version 13 | R&S®FSWP
Throughout this manual, products from Rohde & Schwarz are indicated without the ® symbol , e.g.
R&S®FSWP is indicated as R&S FSWP.

Contents
R&S®FSWP
3Getting Started 1177.5756.02 ─ 13
Contents
1 Safety and Regulatory Information...................................... 9
1.1 Safety Instructions................................................................................9
1.2 Warning Messages in the Documentation........................................12
1.3 Korea Certification Class A................................................................13
2 Documentation Overview....................................................14
2.1 Getting Started Manual.......................................................................14
2.2 User Manuals and Help...................................................................... 14
2.3 Service Manual....................................................................................14
2.4 Instrument Security Procedures....................................................... 15
2.5 Printed Safety Instructions................................................................ 15
2.6 Data Sheets and Brochures............................................................... 15
2.7 Release Notes and Open Source Acknowledgment (OSA).............15
2.8 Application Notes, Application Cards, White Papers, etc...............16
3 Preparing for Use.................................................................17
3.1 Lifting and Carrying............................................................................17
3.2 Unpacking and Checking................................................................... 17
3.3 Choosing the Operating Site............................................................. 17
3.4 Setting Up the R&S FSWP..................................................................18
3.4.1 Placing the Product on a Bench Top.....................................................18
3.4.2 Mounting the R&S FSWP in a Rack..................................................... 19
3.5 Connecting the AC Power..................................................................20
3.6 Switching the Instrument On and Off............................................... 21
3.7 Connecting to LAN............................................................................. 22
3.8 Connecting a Keyboard......................................................................23
3.9 Connecting an External Monitor........................................................24

Contents
R&S®FSWP
4Getting Started 1177.5756.02 ─ 13
3.10 Windows Operating System...............................................................25
3.11 Logging On..........................................................................................27
3.12 Checking the Supplied Options.........................................................29
3.13 Performing a Self-Alignment............................................................. 30
3.14 Considerations for Test Setup...........................................................30
4 Instrument Tour................................................................... 32
4.1 The Front Panel...................................................................................32
4.1.1 Display (Touchscreen).......................................................................... 33
4.1.2 Power Key.............................................................................................35
4.1.3 System Control Keys............................................................................ 35
4.1.4 The Function Keys................................................................................ 36
4.1.5 The Keypad...........................................................................................37
4.1.6 Navigation Control................................................................................ 38
4.1.7 RF Input (50 Ω)..................................................................................... 40
4.1.8 Signal Source Output............................................................................40
4.1.9 USB Ports............................................................................................. 41
4.1.10 Power Sensors......................................................................................41
4.1.11 Probe Power Connector (3 Pins).......................................................... 41
4.1.12 Noise Source Control............................................................................42
4.1.13 Trigger Input and Output.......................................................................42
4.1.14 Baseband Input.....................................................................................42
4.1.15 External Mixer (Optional)...................................................................... 43
4.1.16 DC Power Supply..................................................................................43
4.1.17 LO AUX Input (Optional)....................................................................... 44
4.2 The Rear Panel.................................................................................... 44
4.2.1 Removable Hard Disk........................................................................... 46
4.2.2 AC Power Supply Connection and Main Power Switch........................ 46

Contents
R&S®FSWP
5Getting Started 1177.5756.02 ─ 13
4.2.3 Display Port and DVI.............................................................................46
4.2.4 LAN....................................................................................................... 47
4.2.5 USB Ports............................................................................................. 47
4.2.6 IF / Video / Demod Output.................................................................... 47
4.2.7 IF Wide Out...........................................................................................47
4.2.8 Sync Trigger Input and Output..............................................................48
4.2.9 AUX Port............................................................................................... 48
4.2.10 GPIB Interface...................................................................................... 49
4.2.11 External Generator Control (Optional).................................................. 49
4.2.12 OCXO (Optional)...................................................................................49
4.2.13 REF INPUT / REF OUTPUT................................................................. 50
4.2.14 Labels on R&S FSWP...........................................................................51
4.2.15 Device ID.............................................................................................. 51
5 Trying Out the Instrument...................................................52
5.1 Initial Setup..........................................................................................54
5.2 Measurements.....................................................................................55
5.2.1 Measurement Selection........................................................................ 55
5.2.2 The Phase Noise Measurement........................................................... 56
5.2.3 The Additive Noise Measurement.........................................................58
5.2.4 The Baseband Noise Measurement..................................................... 59
5.2.5 The Pulsed Phase Noise Measurement............................................... 60
5.2.6 The Pulsed Additive Noise Measurement.............................................61
5.2.7 Adding Another Measurement Channel................................................62
5.3 Result Evaluation................................................................................62
5.3.1 Trace Smoothing...................................................................................63
5.3.2 Integration Ranges................................................................................65
5.3.3 The Cross-Correlation Gain Indicator................................................... 66

Contents
R&S®FSWP
6Getting Started 1177.5756.02 ─ 13
5.3.4 Miscellaneous Evaluation Tools............................................................67
5.4 Measurement Configuration.............................................................. 68
5.4.1 Frequency Configuration.......................................................................68
5.4.2 The Half Decade Configuration Table...................................................69
5.4.3 Pulsed Measurement Configuration......................................................70
5.4.4 Signal Generation................................................................................. 71
5.4.5 DUT Power Supply............................................................................... 72
6 Operating the Instrument....................................................74
6.1 Understanding the Display Information............................................74
6.1.1 Channel Bar.......................................................................................... 75
6.1.2 Window Title Bar...................................................................................78
6.1.3 Marker Information................................................................................79
6.1.4 Spot Noise Information......................................................................... 80
6.1.5 Measurement Progress Information......................................................80
6.1.6 Frequency Information in Diagram Footer............................................ 81
6.1.7 Instrument and Status Information........................................................81
6.1.8 Error Information................................................................................... 83
6.2 Accessing Functions..........................................................................84
6.2.1 Toolbar.................................................................................................. 85
6.2.2 Softkeys................................................................................................ 86
6.2.3 Context Menus......................................................................................87
6.2.4 On-screen Keyboard.............................................................................87
6.3 Changing the Focus........................................................................... 88
6.4 Entering Data.......................................................................................89
6.4.1 Entering Numeric Parameters...............................................................89
6.4.2 Entering Alphanumeric Parameters...................................................... 90
6.5 Displaying Results..............................................................................92

Contents
R&S®FSWP
7Getting Started 1177.5756.02 ─ 13
6.5.1 Activating and Deactivating Channels.................................................. 92
6.5.2 Laying out the Result Display with the SmartGrid.................................94
6.5.3 Changing the Size of Windows............................................................. 98
6.5.4 Switching Between a Split and Maximized Window Display.................99
6.5.5 Changing the Display..........................................................................100
6.6 Remote Control................................................................................. 100
6.6.1 Remote Desktop Connection.............................................................. 101
6.6.2 Connecting a PC via the GPIB Interface.............................................101
7 Contacting Customer Support......................................... 102
Index................................................................................... 103

Contents
R&S®FSWP
8Getting Started 1177.5756.02 ─ 13

Safety and Regulatory Information
R&S®FSWP
9Getting Started 1177.5756.02 ─ 13
1 Safety and Regulatory Information
The product documentation helps you use the product safely and efficiently. Fol-
low the instructions provided here and in the Chapter 1.1, "Safety Instructions",
on page 9.
Intended use
The product is intended for the development, production and verification of elec-
tronic components and devices in industrial, administrative, and laboratory envi-
ronments. Use the product only for its designated purpose. Observe the operating
conditions and performance limits stated in the data sheet.
Target audience
Where do I find safety information?
Safety information is part of the product documentation. It warns you of potential
dangers and gives instructions on how to prevent personal injury or damage
caused by dangerous situations. Safety information is provided as follows:
●In Chapter 1.1, "Safety Instructions", on page 9. The same information is
provided in many languages as printed "Safety Instructions". The printed
"Safety Instructions" are delivered with the product.
●Throughout the documentation, safety instructions are provided when you
need to take care during setup or operation.
1.1 Safety Instructions
Products from the Rohde & Schwarz group of companies are manufactured
according to the highest technical standards. To use the products safely, follow
the instructions provided here and in the product documentation. Keep the prod-
uct documentation nearby and offer it to other users.
Use the product only for its intended use and within its performance limits. Inten-
ded use and limits are described in the product documentation such as the data
sheet, manuals and the printed "Safety Instructions". If you are unsure about the
appropriate use, contact Rohde & Schwarz customer service.
Safety Instructions

Safety and Regulatory Information
R&S®FSWP
10Getting Started 1177.5756.02 ─ 13
Using the product requires specialists or specially trained personnel. These users
also need sound knowledge of at least one of the languages in which the user
interfaces and the product documentation are available.
Never open the casing of the product. Only service personnel authorized by
Rohde & Schwarz are allowed to repair the product. If any part of the product is
damaged or broken, stop using the product. Contact Rohde & Schwarz customer
service at http://www.customersupport.rohde-schwarz.com.
Lifting and carrying the product
The product is heavy. Do not move or carry the product by yourself. A single per-
son can only carry a maximum of 18 kg safely depending on age, gender and
physical condition. Look up the maximum weight in the data sheet. Use the prod-
uct handles to move or carry the product. Do not lift by the accessories mounted
on the product. Accessories are not designed to carry the weight of the product.
To move the product safely, you can use lifting or transporting equipment such as
lift trucks and forklifts. Follow the instructions provided by the equipment manu-
facturer.
Choosing the operating site
Only use the product indoors. The product casing is not waterproof. Water that
enters can electrically connect the casing with live parts, which can lead to elec-
tric shock, serious personal injury or death if you touch the casing. If
Rohde & Schwarz provides accessories designed for your product, e.g. a carrying
bag, you can use the product outdoors.
Unless otherwise specified, you can operate the product up to an altitude of
2000 m above sea level. The product is suitable for pollution degree 2 environ-
ments where nonconductive contamination can occur. For more information on
environmental conditions such as ambient temperature and humidity, see the
data sheet.
Setting up the product
Always place the product on a stable, flat and level surface with the bottom of the
product facing down. If the product is designed for different positions, secure the
product so that it cannot fall over.
If the product has foldable feet, always fold the feet completely in or out to ensure
stability. The feet can collapse if they are not folded out completely or if the prod-
Safety Instructions

Safety and Regulatory Information
R&S®FSWP
11Getting Started 1177.5756.02 ─ 13
uct is moved without lifting it. The foldable feet are designed to carry the weight of
the product, but not an extra load.
If stacking is possible, keep in mind that a stack of products can fall over and
cause injury.
If you mount products in a rack, ensure that the rack has sufficient load capacity
and stability. Observe the specifications of the rack manufacturer. Always install
the products from the bottom shelf to the top shelf so that the rack stands
securely. Secure the product so that it cannot fall off the rack.
Connecting to power
The product is an overvoltage category II product. Connect the product to a fixed
installation used to supply energy-consuming equipment such as household
appliances and similar loads. Keep in mind that electrically powered products
have risks, such as electric shock, fire, personal injury or even death.
Take the following measures for your safety:
●Before switching on the product, ensure that the voltage and frequency indica-
ted on the product match the available power source. If the power adapter
does not adjust automatically, set the correct value and check the rating of the
fuse.
●Only use the power cable delivered with the product. It complies with country-
specific safety requirements. Only insert the plug into an outlet with protective
conductor terminal.
●Only use intact cables and route them carefully so that they cannot be dam-
aged. Check the power cables regularly to ensure that they are undamaged.
Also ensure that nobody can trip over loose cables.
●If the product needs an external power supply, use the power supply that is
delivered with the product or that is recommended in the product documenta-
tion or a power supply that conforms to the country-specific regulations.
●Only connect the product to a power source with a fuse protection of maxi-
mum 20 A.
●Ensure that you can disconnect the product from the power source at any
time. Pull the power plug to disconnect the product. The power plug must be
easily accessible. If the product is integrated into a system that does not meet
these requirements, provide an easily accessible circuit breaker at the system
level.
Safety Instructions

Safety and Regulatory Information
R&S®FSWP
12Getting Started 1177.5756.02 ─ 13
Cleaning the product
Use a dry, lint-free cloth to clean the product. When cleaning, keep in mind that
the casing is not waterproof. Do not use liquid cleaning agents.
Meaning of safety labels
Safety labels on the product warn against potential hazards.
Potential hazard
Read the product documentation to avoid personal injury or product damage.
Heavy product
Be careful when lifting, moving or carrying the product. Carrying the product requires
a sufficient number of persons or transport equipment.
Electrical hazard
Indicates live parts. Risk of electric shock, fire, personal injury or even death.
Hot surface
Do not touch. Risk of skin burns. Risk of fire.
Protective conductor terminal
Connect this terminal to a grounded external conductor or to protective ground. This
connection protects you against electric shock if an electric problem occurs.
1.2 Warning Messages in the Documentation
A warning message points out a risk or danger that you need to be aware of. The
signal word indicates the severity of the safety hazard and how likely it will occur
if you do not follow the safety precautions.
WARNING
Potentially hazardous situation. Could result in death or serious injury if not avoi-
ded.
CAUTION
Potentially hazardous situation. Could result in minor or moderate injury if not
avoided.
Warning Messages in the Documentation

Safety and Regulatory Information
R&S®FSWP
13Getting Started 1177.5756.02 ─ 13
NOTICE
Potential risks of damage. Could result in damage to the supported product or to
other property.
1.3 Korea Certification Class A
이 기기는 업무용(A급) 전자파 적합기기로서 판매자 또는 사용자는 이 점을 주의하
시기 바라며, 가정외의 지역에서 사용하는 것을 목적으로 합니다.
Korea Certification Class A

Documentation Overview
R&S®FSWP
14Getting Started 1177.5756.02 ─ 13
2 Documentation Overview
This section provides an overview of the R&S FSWP user documentation. Unless
specified otherwise, you find the documents on the R&S FSWP product page at:
www.rohde-schwarz.com/manual/FSWP
2.1 Getting Started Manual
Introduces the R&S FSWP and describes how to set up and start working with the
product. Includes basic operations, typical measurement examples, and general
information, e.g. safety instructions, etc.
A printed version is delivered with the instrument. A PDF version is available for
download on the Internet.
2.2 User Manuals and Help
The user manual contains the description of all instrument modes and functions.
It also provides an introduction to remote control, a complete description of the
remote control commands with programming examples, and information on main-
tenance, instrument interfaces and error messages. Includes the contents of the
getting started manual.
The contents of the user manual are available as help in the R&S FSWP. The
help offers quick, context-sensitive access to the complete information for the
instrument and its firmware.
The user manual is also available for download or for immediate display on the
Internet.
2.3 Service Manual
Describes the performance test for checking the rated specifications, module
replacement and repair, firmware update, troubleshooting and fault elimination,
and contains mechanical drawings and spare part lists.
Service Manual

Documentation Overview
R&S®FSWP
15Getting Started 1177.5756.02 ─ 13
The service manual is available for registered users on the global
Rohde & Schwarz information system (GLORIS):
https://gloris.rohde-schwarz.com
2.4 Instrument Security Procedures
Deals with security issues when working with the R&S FSWP in secure areas. It
is available for download on the Internet.
2.5 Printed Safety Instructions
Provides safety information in many languages. The printed document is deliv-
ered with the product.
2.6 Data Sheets and Brochures
The data sheet contains the technical specifications of the R&S FSWP. It also
lists the firmware applications and their order numbers, and optional accessories.
The brochure provides an overview of the instrument and deals with the specific
characteristics.
See www.rohde-schwarz.com/brochure-datasheet/FSWP
2.7 Release Notes and Open Source Acknowledg-
ment (OSA)
The release notes list new features, improvements and known issues of the cur-
rent firmware version, and describe the firmware installation.
The open-source acknowledgment document provides verbatim license texts of
the used open source software.
Release Notes and Open Source Acknowledgment (OSA)

Documentation Overview
R&S®FSWP
16Getting Started 1177.5756.02 ─ 13
See www.rohde-schwarz.com/firmware/FSWP
2.8 Application Notes, Application Cards, White
Papers, etc.
These documents deal with special applications or background information on
particular topics.
See www.rohde-schwarz.com/application/FSWP
Application Notes, Application Cards, White Papers, etc.

Preparing for Use
R&S®FSWP
17Getting Started 1177.5756.02 ─ 13
3 Preparing for Use
Here, you can find basic information about setting up the instrument for the first
time.
3.1 Lifting and Carrying
The carrying handles are designed to lift or carry the instrument. Do not apply
excessive external force to the handles.
See "Lifting and carrying the product" on page 10.
3.2 Unpacking and Checking
1. Unpack the R&S FSWP carefully.
2. Retain the original packing material. Use it when transporting or shipping the
R&S FSWP later.
3. Using the delivery notes, check the equipment for completeness.
4. Check the equipment for damage.
If the delivery is incomplete or equipment is damaged, contact
Rohde & Schwarz.
3.3 Choosing the Operating Site
Specific operating conditions ensure proper operation and avoid damage to the
product and connected devices. For information on environmental conditions
such as ambient temperature and humidity, see the data sheet.
See also "Choosing the operating site" on page 10.
Choosing the Operating Site

Preparing for Use
R&S®FSWP
18Getting Started 1177.5756.02 ─ 13
Electromagnetic compatibility classes
The electromagnetic compatibility (EMC) class indicates where you can operate
the product. The EMC class of the product is given in the data sheet under "Gen-
eral data".
●Class B equipment is suitable for use in:
– Residential environments
– Environments that are directly connected to a low-voltage supply network
that supplies residential buildings
●Class A equipment is intended for use in industrial environments. It can cause
radio disturbances in residential environments due to possible conducted and
radiated disturbances. It is therefore not suitable for class B environments.
If class A equipment causes radio disturbances, take appropriate measures to
eliminate them.
3.4 Setting Up the R&S FSWP
The R&S FSWP is designed for use on a bench top or in a rack.
See also:
●"Setting up the product" on page 10
●"Intended use" on page 9
3.4.1 Placing the Product on a Bench Top
To place the product on a bench top
1. Place the product on a stable, flat and level surface. Ensure that the surface
can support the weight of the product. For information on the weight, see the
data sheet.
2. WARNING! A stack of products can fall over and cause injury. Never stack
more than two products. Otherwise, mount them in a rack.
Stack as follows:
● All products must have the same dimensions (width and length).
● Do not exceed a total load of 50 kg placed on the product at the bottom of
the stack.
Setting Up the R&S FSWP

Preparing for Use
R&S®FSWP
19Getting Started 1177.5756.02 ─ 13
Left = Stacked correctly
Right = Stacked incorrectly, too many products
3. NOTICE! Overheating can damage the product.
Prevent overheating as follows:
● Keep a minimum distance of 10 cm between the fan openings of the prod-
uct and any object in the vicinity.
● Do not place the product next to heat-generating equipment such as radia-
tors or other products.
3.4.2 Mounting the R&S FSWP in a Rack
To prepare the rack
1. Observe the requirements and instructions in "Setting up the product"
on page 10.
2. NOTICE! Insufficient airflow can cause overheating and damage the product.
Design and implement an efficient ventilation concept for the rack.
To mount the R&S FSWP in a rack
1. Use an adapter kit to prepare the R&S FSWP for rack mounting.
a) Order the rack adapter kit designed for the R&S FSWP. For the order num-
ber, see the data sheet.
b) Mount the adapter kit. Follow the assembly instructions provided with the
adapter kit.
2. Lift the R&S FSWP to shelf height.
Setting Up the R&S FSWP

Preparing for Use
R&S®FSWP
20Getting Started 1177.5756.02 ─ 13
3. Grab the handles and push the R&S FSWP onto the shelf until the rack brack-
ets fit closely to the rack.
4. Tighten all screws in the rack brackets with a tightening torque of 1.2 Nm to
secure the R&S FSWP in the rack.
To unmount the R&S FSWP from a rack
1. Loosen the screws at the rack brackets.
2. Remove the R&S FSWP from the rack.
3. If placing the R&S FSWP on a bench top again, unmount the adapter kit from
the R&S FSWP. Follow the instructions provided with the adapter kit.
3.5 Connecting the AC Power
In the standard version, the R&S FSWP is equipped with an AC power supply
connector.
The R&S FSWP can be used with different AC power voltages and adapts itself
automatically to it. Refer to the datasheet for the requirements of voltage and fre-
quency.
For safety information, see "Connecting to power" on page 11.
To connect the AC power
1. Plug the AC power cable into the AC power connector on the rear panel of the
instrument. Only use the AC power cable delivered with the R&S FSWP.
2. Plug the AC power cable into a power outlet with ground contact.
The required ratings are listed next to the AC power connector and in the data
sheet.
For details on the connector, refer to Chapter 4.2.2, "AC Power Supply Connec-
tion and Main Power Switch", on page 46.
Connecting the AC Power
