Rohl MB2009 User manual

Installation guide / Guide d'installation / Guía de instalación
USA / QC : 1.866.473.8442 - ONT :1.888.287.5354
Before beginning the installation:
Read all instructions.
Purge the water supply system before connecting it to the faucet.
Avant de commencer l'installation:
Lire toutes les instructions.
Purger votre système d’alimentation d'eau avant d’effectuer le branchement
au robinet.
Antes de iniciar la instalación:
Lea todas las instrucciones.
Es necesario purgar previamente su sistema de alimentación de agua para
efectuar la conexión del grifo.
Tools and equipment required / Outils et matériel requis / Herramientas
y material requerido para instalación:
ALIGN
ALIGNER
ALINEAR
GUI-08 Rev15 2018-09
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
PETIT
SMALL
PEQUEÑO
TIGHTEN
SERRER
APRETAR
BOTTOM VIEW
VUE DE DESSOUS
VISTA INFERIOR
  
  
x2 x2
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
Installation guide / Guide d'installation / Guía de instalación
USA / QC : 1.866.473.8442 - ONT :1.888.287.5354
Before beginning the installation:
Read all instructions.
Purge the water supply system before connecting it to the faucet.
Avant de commencer l'installation:
Lire toutes les instructions.
Purger votre système d’alimentation d'eau avant d’effectuer le branchement
au robinet.
Antes de iniciar la instalación:
Lea todas las instrucciones.
Es necesario purgar previamente su sistema de alimentación de agua para
efectuar la conexión del grifo.
Tools and equipment required / Outils et matériel requis / Herramientas
y material requerido para instalación:
ALIGN
ALIGNER
ALINEAR
GUI-08 Rev15 2018-09
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
PETIT
SMALL
PEQUEÑO
TIGHTEN
SERRER
APRETAR
BOTTOM VIEW
VUE DE DESSOUS
VISTA INFERIOR
  
  
x2 x2
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
Installation guide / Guide d'installation / Guía de instalación
USA / QC : 1.866.473.8442 - ONT :1.888.287.5354
Before beginning the installation:
Read all instructions.
Purge the water supply system before connecting it to the faucet.
Avant de commencer l'installation:
Lire toutes les instructions.
Purger votre système d’alimentation d'eau avant d’effectuer le branchement
au robinet.
Antes de iniciar la instalación:
Lea todas las instrucciones.
Es necesario purgar previamente su sistema de alimentación de agua para
efectuar la conexión del grifo.
Tools and equipment required / Outils et matériel requis / Herramientas
y material requerido para instalación:
ALIGN
ALIGNER
ALINEAR
GUI-08 Rev15 2018-09
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
PETIT
SMALL
PEQUEÑO
TIGHTEN
SERRER
APRETAR
BOTTOM VIEW
VUE DE DESSOUS
VISTA INFERIOR
  
  
x2 x2
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
Installation guide / Guide d'installation / Guía de instalación
USA / QC : 1.866.473.8442 - ONT :1.888.287.5354
Before beginning the installation:
Read all instructions.
Purge the water supply system before connecting it to the faucet.
Avant de commencer l'installation:
Lire toutes les instructions.
Purger votre système d’alimentation d'eau avant d’effectuer le branchement
au robinet.
Antes de iniciar la instalación:
Lea todas las instrucciones.
Es necesario purgar previamente su sistema de alimentación de agua para
efectuar la conexión del grifo.
Tools and equipment required / Outils et matériel requis / Herramientas
y material requerido para instalación:
ALIGN
ALIGNER
ALINEAR
GUI-08 Rev15 2018-09
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
PETIT
SMALL
PEQUEÑO
TIGHTEN
SERRER
APRETAR
BOTTOM VIEW
VUE DE DESSOUS
VISTA INFERIOR
  
  
x2 x2
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
IF NEEDED
SI NÉCESSAIRE
SI NECESARIO
WARNING:
Do not use pliers or channel locks
Note hook
orientation
IMPORTANT: WE RECOMMEND THE USE OF A LICENSED PLUMBER TO INSTALL
THIS PRODUCT. PLEASE READ AND UNDERSTAND THE PROVIDED
INSTALLATION INFORMATION BEFORE PROCEEDING.
FITTING INSTRUCTIONS:
Recommended deck through holes 1-3/8”.
1. Flush out all pipework to remove any foreign material. The hot supply line should be
fitted on the left when viewed from the front of the fitting.
To fit spout:
2.
SPOUT (1) and secure into place with mounting BRACKET (4) and NUT (5) from
underneath the sink. After SPOUT (1) is securely fastened, install TEE ASSEMBLY
(6) on threaded nipple. See Figure 1.
To fit handle assembly and valve body:
3. Fit mounting NUT(10) on valve BODY(11) approximately halfway down shaft. Install
second mounting NUT (10) on valve BODY from top side of sink; adjustment is
needed for proper height (may need assistance for installation of the valve BODY
into its location). Place handle 'O'RING (9) and ESCUTCHEON (8) onto top
NUT (10). Place HANDLE (7) on top of ESCUTCHEON (8) and screw handle hub,
knurled area, until fastened. Ensure HANDLE (7) is parallel to front of sink on the
off position. See Figure 2.
4. Connect hot/cold water supply to appropriate ½” NPSM valve BODY(14); bottom
connection. Connect the spout HOSES to the appropriate side of valve
BODY(14). See Figure 2.
To assemble the drain and pop-up to sink:
5. Remove drain PLUG(12) from FLANGE(13). Place FLANGE(13) and white
WASHER(14) through sink drain opening. SEALANT is recommended to maintain a
seal between FLANGE(13) and white WASHER(14). From bottom side of sink,
place cone shaped rubber WASHER(15) onto FLANGE(13) and slide up against
sink bottom. Note: Cone portion of WASHER(15) to face upward. Next slide on clear
flat WASHER(16) and secure with flange NUT(17). Place clear WASHER(18) into
drain BODY(19) and thread onto FLANGE(13).
** Adjust drain BODY(19) alignment, as required, by loosening flange NUT (17), rotate
assembly for alignment of ball ROD(24) to pop-up ROD(21) and re-tighten flange
NUT(17).
6. Apply thread sealant to TAILPIECE(20) and attach to drain BODY(19). Attach
TAILPIECE(20) to p-trap drain (not included). See Figure 3.
7. Place drain PLUG(12), oriented as shown, with hook away from faucet, into
FLANGE(13). Insert ball ROD(24) into the drain's rod opening, secure with ball rod
NUT(25). Do not over-tighten ball rod NUT(25). Insert pop-up ROD(21) through
spout and secure to STRAP(22), approximately 1" from end of ROD(21), with
SCREW(23).Adjust the rise of the PLUG(12) through elevation holes in STRAP(22).
Use CLIP(26) to secure ball ROD(24) to STRAP(22). Adjust ball ROD(24) and pop-
up ROD(21) so drain will open and close properly. See Figure 4.
8. After all items are installed and system is pressurized, check all connections for leaks.
CARE AND MAINTENANCE:
WE RECOMMEND OCCASIONAL CLEANING WITH WARM SOAPY WATER
FOLLOWED BY POLISHING WITH A SOFT CLOTH TO KEEP THE PLATED FINISH IN
GOOD CONDITION. DO NOT USE ABRASIVE LIQUIDS, POWDERS, OR PADS TO
CLEAN THE PRODUCT. YOU WILL DAMAGE THE FINISH AND VOID THE
WARRANTY.
Place spout ‘O’RING (3) and ESCUTCHEON (2) over the 1-3/8” center hole. Align
See Figure 3.
8" lavatory faucet
FI08L
*
Specifications
Descriptions
Ceramic cartridge
Pop-up drain
3/8" speedway compression
Available colors
C : Chrome
BN : Brushed Nickel (PVD)
Available flows
•5.7 L/min, 1.5 gpm (US) 60psi *
•1.9 L/min, 0.5 gpm (US) 60psi ( FI08L-05 )
•3.7 L/min, 1 gpm (US) 60psi ( FI08L-10 )
*EPA certification applicable to the indicated model only*
Certifications
CSA B125.1
NSF/ANSI standard 61 and 372
ASME A112.18.1
CMR248 Approval
ADA
Sizes, models and finishes may differ from thoses presented.
Warranty
This Riobel Inc. product you have purchased carries a Limited Lifetime Warranty on the chrome, PVD finish, blacks and all working parts and is guaranteed from the
initial purchase date against all manufacturing defects. All other finishes, including plastic components, are guaranteed for one year. All electric and/or electronic parts
are covered by a 5-year limited warranty.
Customer Service
Ontario, West Canada : 888-287-5354 Quebec, Maritimes, United States : 866-473-8442
2020.07.25
8" lavatory faucet
FI08L
*
Specifications
Descriptions
Ceramic cartridge
Pop-up drain
3/8" speedway compression
Available colors
C : Chrome
BN : Brushed Nickel (PVD)
Available flows
•5.7 L/min, 1.5 gpm (US) 60psi *
•1.9 L/min, 0.5 gpm (US) 60psi ( FI08L-05 )
•3.7 L/min, 1 gpm (US) 60psi ( FI08L-10 )
*EPA certification applicable to the indicated model only*
Certifications
CSA B125.1
NSF/ANSI standard 61 and 372
ASME A112.18.1
CMR248 Approval
ADA
Sizes, models and finishes may differ from thoses presented.
Warranty
This Riobel Inc. product you have purchased carries a Limited Lifetime Warranty on the chrome, PVD finish, blacks and all working parts and is guaranteed from the
initial purchase date against all manufacturing defects. All other finishes, including plastic components, are guaranteed for one year. All electric and/or electronic parts
are covered by a 5-year limited warranty.
Customer Service
Ontario, West Canada : 888-287-5354 Quebec, Maritimes, United States : 866-473-8442
2020.07.25
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
Note hook
orientation
IMPORTANT: WE RECOMMEND THE USE OFA LICENSED PLUMBER TO INSTALL
THIS PRODUCT. PLEASE READ AND UNDERSTAND THE PROVIDED
INSTALLATION INFORMATION BEFORE PROCEEDING.
FITTING INSTRUCTIONS:
Recommended deck through holes 1-3/8”.
1. Flush out all pipework to remove any foreign material. The hot supply line should be
fitted on the left when viewed from the front of the fitting.
To fit spout:
2.
SPOUT (1) and secure into place with mounting BRACKET (4) and NUT (5) from
underneath the sink. After SPOUT (1) is securely fastened, install TEE ASSEMBLY
(6) on threaded nipple. See Figure 1.
To fit handle assembly and valve body:
3. Fit mounting NUT(10) on valve BODY(11) approximately halfway down shaft. Install
second mounting NUT (10) on valve BODY from top side of sink; adjustment is
needed for proper height (may need assistance for installation of the valve BODY
into its location). Place handle 'O'RING (9) and ESCUTCHEON (8) onto top
NUT (10). Place HANDLE (7) on top of ESCUTCHEON (8) and screw handle hub,
knurled area, until fastened. Ensure HANDLE (7) is parallel to front of sink on the
off position. See Figure 2.
4. Connect hot/cold water supply to appropriate ½” NPSM valve BODY(14); bottom
connection. Connect the spout HOSES to the appropriate side of valve
BODY(14). See Figure 2.
To assemble the drain and pop-up to sink:
5. Remove drain PLUG(12) from FLANGE(13). Place FLANGE(13) and white
WASHER(14) through sink drain opening. SEALANT is recommended to maintain a
seal between FLANGE(13) and white WASHER(14). From bottom side of sink,
place cone shaped rubber WASHER(15) onto FLANGE(13) and slide up against
sink bottom. Note: Cone portion of WASHER(15) to face upward. Next slide on clear
flat WASHER(16) and secure with flange NUT(17). Place clear WASHER(18) into
drain BODY(19) and thread onto FLANGE(13).
** Adjust drain BODY(19) alignment, as required, by loosening flange NUT (17), rotate
assembly for alignment of ball ROD(24) to pop-up ROD(21) and re-tighten flange
NUT(17).
6. Apply thread sealant to TAILPIECE(20) and attach to drain BODY(19). Attach
TAILPIECE(20) to p-trap drain (not included). See Figure 3.
7. Place drain PLUG(12), oriented as shown, with hook away from faucet, into
FLANGE(13). Insert ball ROD(24) into the drain's rod opening, secure with ball rod
NUT(25). Do not over-tighten ball rod NUT(25). Insert pop-up ROD(21) through
spout and secure to STRAP(22), approximately 1" from end of ROD(21), with
SCREW(23).Adjust the rise of the PLUG(12) through elevation holes in STRAP(22).
Use CLIP(26) to secure ball ROD(24) to STRAP(22). Adjust ball ROD(24) and pop-
up ROD(21) so drain will open and close properly. See Figure 4.
8. After all items are installed and system is pressurized, check all connections for leaks.
CARE AND MAINTENANCE:
WE RECOMMEND OCCASIONAL CLEANING WITH WARM SOAPY WATER
FOLLOWED BY POLISHING WITH A SOFT CLOTH TO KEEP THE PLATED FINISH IN
GOOD CONDITION. DO NOT USE ABRASIVE LIQUIDS, POWDERS, OR PADS TO
CLEAN THE PRODUCT. YOU WILL DAMAGE THE FINISH AND VOID THE
WARRANTY.
Place spout ‘O’RING (3) and ESCUTCHEON (2) over the 1-3/8” center hole. Align
See Figure 3.
8" lavatory faucet
FI08L
*
Specifications
Descriptions
Ceramic cartridge
Pop-up drain
3/8" speedway compression
Available colors
C : Chrome
BN : Brushed Nickel (PVD)
Available flows
•5.7 L/min, 1.5 gpm (US) 60psi *
•1.9 L/min, 0.5 gpm (US) 60psi ( FI08L-05 )
•3.7 L/min, 1 gpm (US) 60psi ( FI08L-10 )
*EPA certification applicable to the indicated model only*
Certifications
CSA B125.1
NSF/ANSI standard 61 and 372
ASME A112.18.1
CMR248 Approval
ADA
Sizes, models and finishes may differ from thoses presented.
Warranty
This Riobel Inc. product you have purchased carries a Limited Lifetime Warranty on the chrome, PVD finish, blacks and all working parts and is guaranteed from the
initial purchase date against all manufacturing defects. All other finishes, including plastic components, are guaranteed for one year. All electric and/or electronic parts
are covered by a 5-year limited warranty.
Customer Service
Ontario, West Canada : 888-287-5354 Quebec, Maritimes, United States : 866-473-8442
2020.07.25
8" lavatory faucet
FI08L
*
Specifications
Descriptions
Ceramic cartridge
Pop-up drain
3/8" speedway compression
Available colors
C : Chrome
BN : Brushed Nickel (PVD)
Available flows
•5.7 L/min, 1.5 gpm (US) 60psi *
•1.9 L/min, 0.5 gpm (US) 60psi ( FI08L-05 )
•3.7 L/min, 1 gpm (US) 60psi ( FI08L-10 )
*EPA certification applicable to the indicated model only*
Certifications
CSA B125.1
NSF/ANSI standard 61 and 372
ASME A112.18.1
CMR248 Approval
ADA
Sizes, models and finishes may differ from thoses presented.
Warranty
This Riobel Inc. product you have purchased carries a Limited Lifetime Warranty on the chrome, PVD finish, blacks and all working parts and is guaranteed from the
initial purchase date against all manufacturing defects. All other finishes, including plastic components, are guaranteed for one year. All electric and/or electronic parts
are covered by a 5-year limited warranty.
Customer Service
Ontario, West Canada : 888-287-5354 Quebec, Maritimes, United States : 866-473-8442
2020.07.25
INSTALLATION INSTRUCTIONS FOR
MB2009, MB2019
DECK MOUNTED WIDESPREAD LAVATORY FAUCET
Ø2 5/8”
4”
8”
Ø2 5/8”
2 1/8”
5 29/32”
3 1/32”
2 5/8”
3”
5 11/16”
Ø2 5/8”
4”
8”
Ø2 5/8”
2 1/8”
5 29/32”
3 1/32”
2 5/8”
3”
5 11/16”
6 1/2" CTRS
3 PARKER, IRVINE, CA 92618 HOUSEOFROHL.COM

TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2

10
9


x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08


 
TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2 
10

9

x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08


 
TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2 
10
9

x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08


 
TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2 
10
9

x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08


 
TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2 
10
9

x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08




TEMPLATE
GABARIT
PLANTILLA
TOP VIEW
VUE DE DESSUS
VISTA SUPERIOR
CLOSED POSITION COLD WATER
POSITION FERMÉE EAU FROIDE
POSICIÓN CERRADA AGUA FRÍA
CLOSED POSITION HOT WATER
POSITION FERMÉE EAU CHAUDE
POSICIÓN CERRADA AGUA CALIENTE
ALIGN
ALIGNER
ALINEAR
2
3
TIGHTEN IN THE ORDER SHOWN
SERRER DANS L'ORDRE INDIQUÉ
APRETAR EN EL ORDEN INDICADO
1
HAND TIGHTEN
SERRER À LA MAIN
APRETAR A MANO
1.
HOT WATER : 5 SECONDS
EAU CHAUDE : 5 SECONDES
AGUA CALIENTE : 5 SEGUNDOS
2.
COLD WATER : 5 SECONDS
EAU FROIDE : 5 SECONDES
AGUA FRÍA : 5 SEGUNDOS
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
CHECK
VÉRIFIER
VERIFICAR
TIGHTEN SCREWS
SERRER LES VIS
APRETAR LOS TORNILLOS
+/- 1mm [1/32 in]
x2 
10
9

x2
x2
x2
ADJUST
AJUSTER
AJUSTE
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
HOT
CHAUD
CALIENTE
COLD
FROID
FRÍO
MA08


 
16
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
INSTALLATION INSTRUCTIONS
Deck Mounted Widespread Lavatory
Faucet with Pop-up Waste
MB2019DM MB2019LM
MB2029DM MB2029LM
3 Parker, Irvine, CA 92618
Phone: [phone]
Fax: [phone]
Website: www.rohlhome.com
2
5
8
"
MB2019 - 6
MB2029 - 8"
1
2
"
3
4
"
10
"
2
5
8
"
MAX
2
1
2
"
"
2
1
2
"
3
4
2
5
8
"
1
"
(REC. HOLE
SIZE 1 )
6 1/2" SPOUT
8" SPOUT
POP-UP WASTE
ASSEMBLY
3
8
"
WARRANTY
ROHL LLC warrants this product to be free from defects in materials or workmanship
for as long as the original consumer purchaser owns their home.
ROHL LLC will provide free of charge, at its option, replacement part(s) or product (or
a comparable alternative product) to replace those which have proven defective in
materials or workmanship. We will not assume liability for labor expended or damages
accruing from the use of material purchased from us. If material is defective, the limit
of damage is the price of the defective material.
The finishes French Brass and Satin Gold are living finishes and have no warranty.
Proof of purchase (original sales receipt) from the original consumer purchaser must
be made available to Rohl LLC for all warranty claims. The warranty is not
transferable and is extended solely to the original purchaser of the product.
WARRANTY EXCLUSION
This warranty is for normal domestic use only and excludes defect or injury caused by
or resulting from misuse, abuse or neglect, accidental damage or improper
installation. The lifetime limited warranty does not apply to replacement of
components where damage is caused by normal wear and tear.
WARRANTY WILL BE INVALID IF:
A. The product has not been correctly installed (whether by a plumber, contractor,
service provider or member of the purchaser's household) in accordance with the
manufacturer's instructions.
B. The surface finish of the product has been damaged by use of unsuitable
cleaning agents or improper materials, i.e. damage by agents containing acidic,
corrosive, abrasive or alcohol-based substances or through scouring the surface
by abrasive cloths.
C. Damage has occurred to component parts due to foreign materials in the water
supply (e.g. stones, metal shavings). All water lines must be flushed clear of all
debris prior to installing the product. It is strongly recommended that in areas
where foreign materials may be present in the water supply, an inline filter be
fitted on both the Hot and Cold inlets. This will ensure your warranty remains
valid.
D. The product has been exposed to excessive high water temperature (above 80°
Celsius or 175° Fahrenheit).
PARTS ONLY WARRANTY
This warranty does not cover labor charges incurred and / or damage sustained in
installation, repair or replacement, nor incidental or consequential damages.
GUARANTEE TO THE CONSUMER
Ø2 5/8”
4”
8”
Ø2 5/8”
2 1/8”
5 29/32”
3 1/32”
2 5/8”
3”
5 11/16”
Note hook
orientation
IMPORTANT: WE RECOMMEND THE USE OF A LICENSED PLUMBER TO INSTALL
THIS PRODUCT. PLEASE READ AND UNDERSTAND THE PROVIDED
INSTALLATION INFORMATION BEFORE PROCEEDING.
FITTING INSTRUCTIONS:
Recommended deck through holes 1-3/8”.
1. Flush out all pipework to remove any foreign material. The hot supply line should be
fitted on the left when viewed from the front of the fitting.
To fit spout:
2.
SPOUT (1) and secure into place with mounting BRACKET (4) and NUT (5) from
underneath the sink. After SPOUT (1) is securely fastened, install TEE ASSEMBLY
(6) on threaded nipple. See Figure 1.
To fit handle assembly and valve body:
3. Fit mounting NUT(10) on valve BODY(11) approximately halfway down shaft. Install
second mounting NUT (10) on valve BODY from top side of sink; adjustment is
needed for proper height (may need assistance for installation of the valve BODY
into its location). Place handle 'O'RING (9) and ESCUTCHEON (8) onto top
NUT (10). Place HANDLE (7) on top of ESCUTCHEON (8) and screw handle hub,
knurled area, until fastened. Ensure HANDLE (7) is parallel to front of sink on the
off position. See Figure 2.
4. Connect hot/cold water supply to appropriate ½” NPSM valve BODY(14); bottom
connection. Connect the spout HOSES to the appropriate side of valve
BODY(14). See Figure 2.
To assemble the drain and pop-up to sink:
5. Remove drain PLUG(12) from FLANGE(13). Place FLANGE(13) and white
WASHER(14) through sink drain opening. SEALANT is recommended to maintain a
seal between FLANGE(13) and white WASHER(14). From bottom side of sink,
place cone shaped rubber WASHER(15) onto FLANGE(13) and slide up against
sink bottom. Note: Cone portion of WASHER(15) to face upward. Next slide on clear
flat WASHER(16) and secure with flange NUT(17). Place clear WASHER(18) into
drain BODY(19) and thread onto FLANGE(13).
** Adjust drain BODY(19) alignment, as required, by loosening flange NUT (17), rotate
assembly for alignment of ball ROD(24) to pop-up ROD(21) and re-tighten flange
NUT(17).
6. Apply thread sealant to TAILPIECE(20) and attach to drain BODY(19). Attach
TAILPIECE(20) to p-trap drain (not included). See Figure 3.
7. Place drain PLUG(12), oriented as shown, with hook away from faucet, into
FLANGE(13). Insert ball ROD(24) into the drain's rod opening, secure with ball rod
NUT(25). Do not over-tighten ball rod NUT(25). Insert pop-up ROD(21) through
spout and secure to STRAP(22), approximately 1" from end of ROD(21), with
SCREW(23).Adjust the rise of the PLUG(12) through elevation holes in STRAP(22).
Use CLIP(26) to secure ball ROD(24) to STRAP(22). Adjust ball ROD(24) and pop-
up ROD(21) so drain will open and close properly. See Figure 4.
8. After all items are installed and system is pressurized, check all connections for leaks.
CARE AND MAINTENANCE:
WE RECOMMEND OCCASIONAL CLEANING WITH WARM SOAPY WATER
FOLLOWED BY POLISHING WITH A SOFT CLOTH TO KEEP THE PLATED FINISH IN
GOOD CONDITION. DO NOT USE ABRASIVE LIQUIDS, POWDERS, OR PADS TO
CLEAN THE PRODUCT. YOU WILL DAMAGE THE FINISH AND VOID THE
WARRANTY.
Place spout ‘O’RING (3) and ESCUTCHEON (2) over the 1-3/8” center hole. Align
See Figure 3.
11 12
Most products or parts carry “Limited Warranties”
against manufacturing defects.
Please visit houseofrohl.com/support/ for complete
product and nish warranty.
The nishing touch on every product is its exquisite
surface. Great care has been taken to ensure that
the nal step in the manufacturing - whether it is
a sink, faucet, tting or an accessory - delivers
perfection. Like any quality item, no matter how
durable, care should be taken when cleaning and
maintaining these nishes. Please visit houseofrohl.
com/support/ for complete nish care and cleaning
instructions for your particular nish.
LIMITED WARRANTY
FINISH CARE & MAINTENANCE
Phone: (800) 777 - 9762
Email: [email protected]
Website: houseofrohl.com
3 PARKER, IRVINE, CA 92618
