Roland V-drums User manual

V-Tour®S e r i e s
M i d-L i n e V-Drums G e t a F i rs t -C l a ss Upgr a d e
V-Drums®
NPC_US_071211-_Ver.3_INTAGLIO.qxp 12/28/07 2:26 PM Page 8

N e w Sound Eng i n e , Un li m i t e d Expr e ss i on
TD- 9 SX
TD-9 Percussion Sound Modulex1
PD-105BKV-Pad(forSnare) x1
PD-85BKV-Pad(forTom)x3
CY-5Dual-Trigger CymbalPadx1
CY-8 Dual-Trigger CymbalPadx1
CY-12R/C V-CymbalRide/Crashx1
KD-8Kick Trigger Padx1
FD-8Hi-HatControlPedalx1
MDS-9DrumStand x1
*TD-9 supports therim-triggering on theV-Pads (Mesh) forToms and the3 way-triggering forRide.
9
V-Drums V-Tour S e r i e s
TD- 9 SX
●AdvancedTD-9 modulewithexpressivenew
sounds,real-audiosongs and patterns
●Comfortablemesh-headtomand snare pads
withrimtriggering
●Three-waytriggering forridecymbal
●Scopefunction withgraphicalLCDdisplay
●USBhostforaudio-file(.WAV) playback
●Specialcableforeasypadconnections
●Sturdy drumrack (MDS-9) withnewlydesigned
ball-clamps forthesnare and cymbalarms and anew
hi-hatmountformaximumflexibility
Withanewadvancedsound engineatits core,themid-rangeV-Drums familyhas newbragging rights.The
newTD-9 sound moduleis loadedwithfreshsounds,and offers adeeper levelofexpression.Together with
Roland’s mostadvancedtriggering technology,this kitis destinedtobecomeabighitwithdrummers worldwide.
*Kick pedalnotincludedand shownonlyforphotography purposes.
Connection cables are partiallyhiddenforphotography purposes.
NPC_US_071211-_Ver.3_INTAGLIO.qxp 12/28/07 2:26 PM Page 9

TD- 9 S
TD-9 Percussion Sound Modulex1
PDX-8V-Pad(forSnare) x1
PD-8Dual-Trigger Padx3
CY-5Dual-Trigger CymbalPadx1
CY-8 Dual-Trigger CymbalPadx2
KD-8Kick Trigger Padx1
FD-8Hi-HatControlPedalx1
MDS-9DrumStand x1
10
V-Drums®V-Tour®S e r i e s
TD- 9 S
●AdvancedTD-9 sound enginewithnewsounds
and audiobacking patterns
●Mesh-headsnare pad
●Scopefunction withgraphicalLCDdisplay
●USBhostforaudio-file(.WAV) playback
●Specialcableforeasypadconnections
●Sturdy drumrack (MDS-9) withnewlydesigned
ball-clamps forthesnare and cymbalarms and a
newhihatmountformaximumflexibility
Th e A ff ord a b l e A l t e rn a t i v e w i t h
Adv a n ce d F ea t ur e s
Fordrummers who wantastate-of-the-artV-Drums kitbutanevenmore cost-effectiveoption,theTD-9Soffers
all ofthefeatures and advantages oftheTD-9SXbutwithrubber tompads insteadofmeshand adual-trigger
ridecymbal.
*Kick pedalnotincludedand shownonlyforphotography purposes.
Connection cables are partiallyhiddenforphotography purposes.
NPC_US_071211-_Ver.3_INTAGLIO.qxp 12/28/07 2:26 PM Page 10

11
Cymb a l P a r t s S e t
R e p a i r-P a r t s P a c ka g e
This packageincludes three essentialcomponents;Stopper,FeltWasher,and Wing Nut. Compatible
products includeall Roland CY series cymbals.
CYM- 10
Th e N e x t -G e n e r a t i on V-Drums Modu l e
TheTD-9 is theanchorofRoland's newmid-lineV-Drums kits.Withhundreds
ofnewsounds,real-audiosongs and patterns onboard,plus newScopeand
Quick Rec/Quick Playpracticefunctions,full V-Hi-Hat(VH-11) compatibility,
and three-wayridetriggering available,theTD-9 raises thebar significantly
inits pricerange.
Note:Playableaudiofiles by USBHostviawav-fileformat.
Fast,Friendly,Fun
Nomore squinting atasmall screen—theTD-9 is outfittedwithaluxurious,largebacklitdis-
playwithaccompanying oversizedbuttons and controls.Its friendly,icon-baseduser interface
makes editing sounds and customizing kits fastand fun.
Interactive Innovation
Playalong withreal-audiobacking songs tobuildyourmusicalexperiencebase.UsetheUSB
porttoimportaudiofiles ofyourchoice(.WAV),back up yourdata,orsavea“quick record”
performance.The"Quick Record"and "Quick Play"features allowyou to
immediatelyrecordand playback solodrumparts,ordrumparts performed
withthebacking songs.Specialconnecting cableallows forfast, cleanand
easyconnection tothepads.
P e r c uss i on Sound Modu l e
TD- 9
ThenewMDS-9 drumrack offers a
sturdy four-legdesign withnew,
improvedball-jointsnare and cymbal
mounts,and anewhi-hatmountfor
fast, flexiblecomponentplacement.
Convenience &Stability
Whether you’re insearchofaclean,
streamlinedsetup foryourhomeora
strong rack forgigs thatsets up and tears
downfast, thenewMDS-9 delivers.
Notes:TheMDS-9 is speciallydesignedinconjunction
withthenewestV-Drums kit(TD-9SX/TD-9S).Itdoes not
includeamounting plateforsound-moduleattachment.
Drum S t a nd
MDS- 9
