Roland IU-1000F User manual

Special Color Ink Guide
(Basic Edition)
Thank you very much for purchasing this product.
• To ensure correct and safe usage with a full understanding of this product's performance, please be sure to read
through this manual completely and store it in a safe location.
• Unauthorized copying or transferal, in whole or in part, of this manual is prohibited.
• The specications of this product and the contents of this operation manual are subject to change without notice.
• The operation manual and the product have been prepared and tested as much as possible. If you nd any
misprints or errors, please inform us.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur through
use of this product, regardless of any failure to perform on the part of this product.
• Roland DG Corporation assumes no responsibility for any direct or indirect loss or damage that may occur with
respect to any article made using this product.
This manual describes how to print using spot color ink.
Spot color inks such as gloss and white can be used as a base for
printing color images or as a surface layer for adding gloss to color
prints.

Company names and product names are trademarks or registered trademarks of their respective holders.
Copyright © 2020 Roland DG Corporation
http://www.rolanddg.com/

Contents
Contents..............................................................................................................................................................................................3
Overview .............................................................................................................................................................................................4
Spot Color Printing.........................................................................................................................................................4
Workow and Software Used.....................................................................................................................................4
Available Print Types......................................................................................................................................................5
Print Data Types...............................................................................................................................................................6
Printing ................................................................................................................................................................................................8
Creating Print Data for Spot Colors ..........................................................................................................................8
Creating a RIP File (Without Gloss Finish)............................................................................................................ 10
Creating a RIP File (With Gloss Finish) .................................................................................................................. 13
Outputting Data to the Printer with Print Control........................................................................................... 18
1

2
Overview
Spot Color Printing
Spot color printing uses non-CMYK spot color inks. This enables printing of a color image on top of a white ink to
make the colors more vivid, or printing gloss ink on top of a color image to provide a gloss nish. Primer ink can
also be printed underneath a color image to improve adhesion to the media.
[1]: Base (White or primer ink)
[2]: Image or illustration (CMYK, etc.)
[3]: Finish (Gloss nish with a gloss ink)
Workow and Software Used
Workow
*1: The o󰀩cial name of the software is Roland DG IU-1000F UV Print Control Center. The term "Print Control"
is used in this manual.
Software
Type of software Name of software Function
Design software Adobe Illustrator Can be used to specify where to print white,
gloss, and primer inks within the print data.
RIP software SAi FlexiPRINT Production
Manager 19
Can be used to create a RIP le with registered
printing conditions, layout settings, and spot
color information.
Printing software Print Control
Can be used to load RIP les, to congure
spot color settings, and to perform printing
operations.
Create print data Create RIP le Send completed RIP data
Design tool such as
Adobe Illustrator or
SAi Flexi
RIP software such
as SAi FlexiPRINT
Production
Manager 19
Print Control*1

Overview
3
Available Print Types
This section describes the types of printing that use white ink (W), gloss ink (Gl), and primer ink (Pr).
Print types
Print Control can be used to specify the combination of color ink, white ink, gloss ink, and primer ink. Cyan,
magenta, yellow, and black are referred to as 4C.
IMPORTANT
Printing with gloss ink (Gl) must be done through a separate print job than that of the other inks,
and the image must be rasterized using the Standard output prole (resolution: 635 × 600 dpi).
Outputting in the same job as 4C is only possible when the print mode is "4C-Gl_Standard." In such cases, the
gloss ink is printed with a matte nish.
[1]: Gloss ink
[2]: Color ink
[3]: White ink
[4]: Primer ink
Color set Application example Overview
W - 4C
White ink is used as the base for color data.
4C - Gl*1
Gloss ink is applied on top of color data.
Pr - 4C
Primer ink is used as the base of the color data.
W - 4C
+ Gl (separate job)*2
White ink is used as the base for color data. Coating with
gloss ink is performed in a separate job.
Pr - W - 4C
White ink and primer ink are used as the base of the color
data.
Pr - 4C
+ Gl (separate job)*2
Primer ink is used as the base of the color data. Coating
with gloss ink is performed in a separate job.

Overview
4
Color set Application example Overview
Pr - W - 4C
+ Gl (separate job)*2
White ink and primer ink are used as the base of the color
data. Coating with gloss ink is performed in a separate job.
4C - W
White ink is used on top of the color data. This is mainly
used for reverse printing on transparent media.
Pr - 4C - W
Primer ink is used as the base of the color data, and white
ink is used on top of the color data. This is mainly used for
reverse printing on transparent media.
*1: This set can be used when the print mode is set to "4C - Gl _ Standard." In this case, the gloss ink has a matte nish.
*2: This set can be used when RIP is performed at Standard (635×600dpi). Adjusting the UV lamp position enables
printing with a gloss nish using gloss ink. (If the UV lamp position is not adjusted, a matte nish will be produced.)
Print Data Types
Spot color print data comes in one of the following patterns.
Spot color only printing
Print data for spot colors must be created.
"P. 6 "Creating Print Data for Spot Colors"
Print data for spot colors Spot color printing

Overview
5
Spot color printing in layers with patterns
Printing spot color with di󰀨erent shapes and sizes on a non-square pattern
Print data for spot colors must be created.
"P. 6 "Creating Print Data for Spot Colors"
A
A
A
A
Printing spot color with the same shapes and sizes throughout a square pattern (such as a photo)
Congure the spot color using RIP software.
"P. 8 "Creating a RIP File (Without Gloss Finish)"
MEMO
To print spot color in the same shape and size throughout a square pattern (such as a photo), the spot color
can be set using the RIP software without creating spot color print data.
Spot color lamination (Overprint)
Pattern
Spot color printing
Pattern printing
Spot color printing
Pattern printing
Spot color placed on base
Pattern
Pattern with a white spot
color base
Spot color printing
Pattern printing

6
Creating Print Data for Spot Colors
This section describes how to create the following print data using Adobe Illustrator.
Laminate the pattern using gloss spot color, and print white spot color on the base.
A
A
A
A
[1]: Finish (Gloss nish with a gloss ink)
[2]: Image or illustration (CMYK)
[3]: Base (White or primer ink)
Procedure
A Congure the layer settings.
Make three layers, and stack them as shown in the gure.
Congure the settings for each layer ([1] to [3]) as follows.
A
A
Layer name Swatch (*1) Overprint Fill (*2)
Layer [1] Gloss Spot2 On
Layer [2] CMYK No On
Layer [3] White Spot1 O󰀨
*1: Specify a swatch for each object within a layer.
*2: "Overprint Fill" in the "Attributes" window
IMPORTANT
If the overprint settings are not congured, areas that overlap the object below will not be printed.
Pattern with a white spot color base
(Overprinted pattern on top of spot color)
Gloss spot color laminated on pattern (Overprint)
Printing

Printing
7
B Specify a spot color.
Create two new swatches, and congure the settings as follows.
A
A
Swatch Name Color Type
Swatch [1] Spot1 Spot color
Swatch [2] Spot2 Spot color
IMPORTANT
A spot color must be specied for every object printed with white, gloss, or primer ink. This ensures the RIP
software and the printer can recognize the print area for the spot color correctly. Congure the settings as
indicated below.
Spot color ink Swatch Name Color Type
White Spot 1
Spot colorGloss Spot 2
Primer Spot 3
C Save the print data.
Save the print data in EPS or PDF format.

Printing
8
Creating a RIP File (Without Gloss Finish)
This section describes how to create a RIP le using SAi FlexiPRINT Production Manager 19. For information on
how to create les using other RIP software, contact the applicable software distributor.
MEMO
• Selecting an output prole that is suitable for the color set used for spot color printing from the general-
purpose proles available ensures output with optimal color management.
• For basic information on using the RIP software, such as how to set the media size and layout for print data,
refer to the Help manual included with the software.
Procedure
A Read the spot color print data or pattern print data using the RIP software.
Add the print data as a RIP software job.
B Double-click the added job.
Double-click to open the [Job Properties] window.

Printing
9
C Click the [Color Management] tab.
Select the best prole for [Output prole].
MEMO
Output prole names are structured according to the following rules. Refer to these rules to select the
best prole.
US_Clear-media_2-3_W-4C_Quality_635x900.icc
[1]: Name of ink being used (US: US ink, UE: UE ink)
[2]: Media type (White-media: White background, Clear-media: Transparent)
[3]: Color set (W - 4C, Pr - 4C, etc.)
[4]: Print quality and resolution (High Quality: 635 × 1800 dpi, Quality: 635 × 900 dpi, Standard:
635 × 600 dpi, Production: 635 × 300 dpi, Draft: 635 × 300 dpi)
D Congure the overprint settings.
If [Overprint Fill] is set for print data objects, do not check [Ignore overprint] on the [ Color Management ]
tab.

Printing
10
E Congure the spot color settings.
Set each spot channel to [Spot color] on the [Printer Options] tab.
Printing spot color with di󰀨erent shapes and sizes on a non-square pattern
Printing spot color with the same shapes and sizes throughout a square pattern (such as a photo)
* Selecting [Substrate] makes it possible to print bases with the same sizes and shapes on square
photos and other patterns without creating print data for spot colors.
F Perform RIP processing using the print data.
After conguring the job property settings, click the [Send] button to save the le to a folder.
Primer
White
Gloss
Spot color printing
Pattern printing

Printing
11
Creating a RIP File (With Gloss Finish)
This section describes how to create a RIP le using SAi FlexiPRINT Production Manager 19. For information on
how to create les using other RIP software, contact the applicable software distributor.
IMPORTANT
When applying a gloss nish with gloss ink, the job using gloss ink must be di󰀨erent than jobs
using other inks. For gloss ink, select the "Standard 635 × 600" prole.
MEMO
• Selecting an output prole that is suitable for the color set used for spot color printing from the
general-purpose proles available ensures output with optimal color management.
• For basic information on using the RIP software, such as how to set the media size and layout for print
data, refer to the Help manual included with the software.
A
A
Procedure
A Read the print data to be set as the rst job using the RIP software.
Add the print data as a RIP software job.
B Double-click the added job.
Double-click to open the [Job Properties] window.
W - 4C: Set as the rst job, and then execute RIP.
Gl (Gloss nish): Set as the second job, and then execute RIP.

Printing
12
C Click the [Color Management] tab.
Select the [US_Clear-media_2 - 4_W - 4C_High Quality_635 × 1800.icc] prole for printing color and
white data.
MEMO
Output prole names are structured according to the following rules.
US_Clear-media_2-4_W-4C_High Quality_635x1800.icc
[1]: Name of ink being used (US: US ink, UE: UE ink)
[2]: Media type (White-media: White background, Clear-media: Transparent)
[3]: Color set (W - 4C, Pr - 4C, etc.)
[4]: Print quality and resolution (High Quality: 635 × 1800 dpi, Quality: 635 × 900 dpi, Standard:
635 × 600 dpi, Production: 635 × 300 dpi, Draft: 635 × 300 dpi)
D Congure the overprint settings.
If [Overprint Fill] is set for print data objects, do not check [Ignore overprint] on the [Color Management ]
tab.

Printing
13
E Congure the spot color print settings.
Set each spot channel to [Spot color] on the [Printer Options] tab.
F Perform RIP processing using the print data.
After conguring the job property settings, click the [Send] button to save the le to a folder.
G Save the le in any folder.
H Read the print data to be set as the second job using the RIP software.
Add the print data as a RIP software job.
I Double-click the added job.
Double-click to open the [Job Properties] window.
IMPORTANT
Congure the layout settings such as media size and data size the same as for the rst job.
White

Printing
14
J Click the [Color Management] tab.
Select the [US_White-media_1 - 2_4C_Standard_635 × 600.icc] prole for printing gloss (gloss nish).
MEMO
Output prole names are structured according to the following rules.
US_White-media_1-2_4C_Standard_635x600.icc
[1]: Name of ink being used (US: US ink, UE: UE ink)
[2]: Media type (White-media: White background, Clear-media: Transparent)
[3]: Color set (W - 4C, Pr - 4C, etc.)
[4]: Print quality and resolution (High Quality: 635 × 1800 dpi, Quality: 635 × 900 dpi, Standard:
635 × 600 dpi, Production: 635 × 300 dpi, Draft: 635 × 300 dpi)
K Congure the overprint settings.
If [Overprint Fill] is set for print data objects, do not check [Ignore overprint] on the [Color Management ]
tab.

Printing
15
L Congure the spot color print settings.
Set each spot channel to [Spot color] on the [Printer Options] tab.
M Perform RIP processing using the print data.
After conguring the job property settings, click the [Send] button to save the le to a folder.
Gloss

Printing
16
Outputting Data to the Printer with Print Control
This section describes how to read a le saved through RIP processing using Print Control, and how to output the
data to the printer. The following spot color printing example is used here.
A
A
IMPORTANT
When applying a gloss nish with gloss ink, adjust the position of the UV lamp.
""Adjusting the UV Lamp Position" in the Operating Instructions
Procedure
A Start Print Control.
B Under [Task Select], select the directory where the RIP-processed le is saved.
Double-click the le to open the [Properties] window.
C Select [2 - 3 W - 4C] for the color set.
W - 4C: Printed as rst job
Gl (Gloss nish): Printed as second job

Printing
17
D Click [OK].
The [Medium Thickness] window appears. Click [Print].
Printing starts.
E Adjust the UV lamp position.
Adjust the position of the UV lamp so that it is in the position for gloss nish with gloss ink.
""Adjusting the UV Lamp Position" in the Operating Instructions
F Select the second job for gloss ink nishing.
Double-click the le to open the [Properties] window.
G Select [8_Gl].
MEMO
The [8_Gl] color set can only be selected if RIP was performed in Standard 635 × 600 dpi mode.
H Click [OK].
The [Medium Thickness] window appears. Click [Print].
Printing starts, and the gloss ink is printed on the W-4C.

R1-200331FA02149
