Rollei Actioncam 9s Plus User manual

Actioncam
9s Plus
Touch
Display
ANLEITUNG AUF DEUTSCH
USER MANUAL IN ENGLISH
www.rollei.de

24
ENGLISH
Before the First Use
Read the operating instructions and the safety instructions carefully before using
the device for the first time.
Keep the operating instructions together with the device for future use. If other people use this device, make
this manual available to them. If you pass on the device to a third party, this manual belongs to the device
and must be supplied with it.
Explanation of symbols
The following symbols are used in this manual, on the camera or on the packaging.
Products marked with this symbol comply with all relevant community regulations of the
European Economic Area.
Products marked with this symbol are operated with direct current.

25
What‘s in the Box
1x Rollei Actioncam 9s Plus
1x Remote control 2.4 GHz
1x Underwater protective housing
1x Exchangeable lithium-ion battery
1x Bike mount
7x Brackets
1x Helmet holder
4x Velcro straps
2x Adhesive stickers
4x Cable ties
1x Metal cable
1x Micro-USB cable
1x Lens cleaning cloth
1x User manual

26
ENGLISH
Attention
1. This product is a delicate product, do not drop or hit it anywhere.
2. Do not place the camera near to streng magnetism, such as magnets and motors.Avoid to place the
product near anything emitting strong radio waves, a strong magnetic field may cause the product to
malfunction or damage the image and sound.
3. Do not place the camera at high temperatures or direct sunlight.
4. Use brand microSD memory cards as ordinary cards do not guarantee the proper use.
5. Da not use microSD memory cards in or near magnetic places to avoid lass of data.
6. During the charging process, if there is overheating, smoke or odor, unplug the power immediately and
stop charging to avoid fire.
7. Keep away the camera and its accessories from children to avoid choking or electric shocks.
8. Store the product in a cool and dry place.
9. Da not use the camera when it is low power or in charging.
10. Do not attempt to open or modify the camera housing in any way as this will invalidate the warranty.

27
Technical Data
Model Rollei Actioncam 9s Plus
Chip Icatch V39
Sensor resolution 12 M resolution
Lens Wide angle lens | aperture F = 2.8 | focal length f: 2.7 mm
Video resolution 4K 3840 x 2160 at 60/30 fps
2.7K 2704 x 1520 at 30 fps
1080p 1920 x 1080 at 120/60/30 fps
720p 1280 x 720 at 240/120/60 fps
Still image resolution 20 M*: 5120 x 3840 4:3
16 M*: 4640 x 3480 4:3
14 M*: 4320 x 3240 4:3
10 M: 3648 x 2736 4:3
8 M: 3264 x 2448 4:3
5 M: 2592 x 1944 4:3
2 M: 1600 x 1200 4:3
Display 2“ touchscreen display and 1.4“ selfie display
Data format Video: MOV (H.264) I Photo: JPG
Memory microSD memory card up to 64 GB
Connectors Micro-USB, Micro HDMI, 1/4“ thread
Waterproofing Camera body waterproof up to 7 meters, in underwater housing
waterproof up to 30 meters
Microphone Built-in microphone
Additonal Features White balance, webcam function, electronic image stabilization

28
ENGLISH
Technical Data
Modes Video: Normal, Slow Motion, Loop Recording, Time Lapse, Fast Motion
Photo: Single shots, Continuous shots, Self-timer, Time-lapse, Long time
exposure
WiFi iEEE 802.11 / b / g / n 2.4 GHz
Max. transmission power 10 dBm
Battery life Up to 85 min. at 4K resolution
Power Li-Ion battery 3.7 V / 1,000 mAh / 3.7 Wh
Input DC 5 V 2 A
Operating temperature -10° – 60° C
Size | Weight 6.55 x 4.38 x 2.65 cm | 129 g / 109 g (incl. / excl. battery)
Box content 1x Rollei Actioncam 9s Plus, 1x remote control 2.4 GHz, 1x underwater
protective housing for depths of up to 30 m, 1x exchangeable lithium-
ion battery, 1x bike mount, 7x brackets, 1x helmet holder, 4x velcro
straps, 2x adhesive stickers, 4x cable ties, 1x metal cable, 1x micro-USB
cable, 1x lens cleaning cloth, 1x user manual
Technical details are subject to change without notice. Misprints and errors excepted. Reproduction of these operating
instructions – even in part – is not permitted. *interpolated

29
Components
Selfie / front display
Lens
Built-in speaker
Micro-HDMI slot
Micro-USB slot
1/4“ tripod connection
Battery compartment and microSD slot
Mode button
Built-in microphone
Shutter / select button
Power / WiFi button
Operation indicator
Charging indicator
Touch display screen
11
98
12
10
14
13
1
4
3
5
67
2
1
2
3
4
5
6
7
8
9
10
11
12
13
14

30
ENGLISH
Waterproof Case
– Insert Camera into Waterproof Case
1. Ensure the case is clean.
2. Insert the camera and make sure the lens fits neatly in the lens cavity.
3. Close the locking clamps.
4. The camera can be mounted using the accessories provided.
Battery
Before using the device for the first time, you must fully charge the battery.
– Charging the Battery
1. Connect the camera to a computer or USB power supply (DC 5V 2A).
2. The charging status light turns on while the battery is charging.
3. The charging status light turns off when the battery is fully charged.
– Changing the Battery
1. Hold the camera so that you can see the camera display and slide the battery cover to the right to
open the battery compartment.
2. Remove the battery.
3. lnsert the new battery so the contacts line up with those of the camera.
Note: Operation is also possible while charging (e.g. via a power bank).
Getting Started
– Turn On: Press and hold the power / WiFi button for 3 seconds.When the camera is turned on, the
Operation Indicator turns on.
– Turn Off: Press and hold the power / WiFi button for 3 seconds.

31
Modes of the Camera
The Rollei 9s Plus offers various photo and video modes. In the following we give you a short explanation of
how they work. On the following pages you can find detailed descriptions how to change the settings for each
mode.
– “Normal” video mode: You can record a single video with normal speed.
– “Seamless” video mode: Here you can record in a loop.The loop recording can be set in an interval of 1 or 5
minutes. After this interval, a new recording is made and saved in each case. If the memory card is full, the
recordings made so far will be overwritten.
– “V-Timelapse” video mode: In timelapse video mode the camera takes pictures every 0.5 seconds up
to every minute and creates a video out of that. You can choose the video length from 5 minutes up to 30
minutes or endless.
– “SlowMotion” video mode: The camera records a sequence and replays it in slowmotion.
– “FastMotion” video mode: Here the camera replays the video faster than recorded, from double time
up to 15 times faster. Compared to time-lapse video mode, these recordings are a little slower.
– “Single” photo mode: You can take a single shot.
– “Burst” photo mode: This allows you to take 3 shots/1s, 7 shots/2s, 15 shots/4s, 30 shots/8s.
– “P-Timelapse” photo mode: In timelapse photo mode the camera takes pictures every 0.5 seconds up to
every minute for 5 to 30 minutes or unlimited.
– “CountDown” photo mode: You can set a timer on 2 or 10 seconds delay.
– “LongExp” long exposure photo mode: It uses a long-duration shutter speed to sharply capture the
stationary elements of images.
– Date Stamp: You can add a watermark to your pictures or videos, either with just the date or with date and
time.

32
ENGLISH
Touch Function
You can use the rear touch screen to access the functions of the camera.
– Swipe to the left or right to change between the video mode and
the photo mode.
In the video or photo mode you can access the playback mode via the
symbol in the left lower corner (1) and the settings with the symbol in
the right lower corner (3). To access the mode menu, touch the lower
middle part (2).
– Swipe up to access the mode menu of video and photo.
– Swipe down to open shortcuts to lock and power off for quick
operations.
– To unlock touch the display and swipe from left to right, following
the arrows, or press the shutter / select button.
1 2 31 2 3

33
Button Function
Overview Menu
To get access to the mode menu,
press the shutter / select button
for 3 seconds. Cycle through the
menu (see above) with the mode
button, confirm with the shutter /
select button.
Video Mode
Press the shutter / select button when power on to start recording.
A red light on the screen will flash as well as the operation indicator
while recording. Press shutter / select button again to stop recording.
Photo Mode
Press the shutter / select button to take a single picture.
You can choose between video mode, photo mode, playback mode and
settings by pressing the mode button shortly. Access the playback mode
or the camera settings by confirming with the shutter / select button.
Cycle through the settings with the power / WiFi button and confirm with
the shutter / select button the requested options. Exit the menu with the
mode button or by confirming the arrow back.

34
ENGLISH
Settings
In the System Setting mode you can
enter the settings for the system
and choose different parameters
for the camera. Please observe that
the parameters will be activated
depending on the chosen video/
photo mode.
Parameters for the camera in video mode:
– Video resolution: Here you can set the resolution of your recordings.
– Video Quality: You can set the video quality between low, medium and high.
– Voice Record: When it is on, sound is recorded, when it is off, recordings are without sound.
– EV: You can set the exposure compensation between -2.0 (image becomes darker) and +2.0 (image becomes
brighter) by tapping on the display.
– Image Stabilization: With Image stabilization turned on, the video will be smoother.
– Loop Record: Here you can take shots of the duration of the interval again and again and save them indivi-
dually.
– Timelapse Interval: You can set different intervals to determine the speed of the time lapse video.
– Timelapse Duration: You can determine the duration of your time-lapse recording here.
– Slow Motion Movie: You can turn this on or off. If this function is switched on, the playback of your recor-
ding depends on the resolution frame rate.The higher this is (up to max. 120), the slower you can play back
the video.
– Fast Motion Movie: This function describes the fast motion function, which gives you a 2 to 15 times played
back recording.
– Wind Noise Reduction: This function improves your sound recording in the video and suppresses ambient
noise.

35
Settings
Parameters for the camera in video mode:
– Auto Low Light: In low light conditions, this function is useful for brightening your image.
– Metering: Here you can set the image area on which the camera focuses, e.g. in the center (Center), at
different points (Multi) or at one point (Spot).
– Date Stamp: Here you can give your images a date stamp or a date and time stamp.
Parameters for the camera in photo mode:
– Photo Resolution: Here you can set the resolution of your pictures.
– ISO: The ISO value can be adjusted automatically or set manually between 100 and 3,200.
– EV: You can set the exposure compensation between -2.0 (image becomes darker) and +2.0 (image beco-
mes brighter).
– Timelapse Interval: You can set different intervals to determine the speed of time lapse shooting.
– Timelapse duration: You can determine the duration of your time-lapse recording here.
– Photo Burst: Here you can set how many series pictures you want to take in one time sequence.
– Delay Timer: This function describes the self-timer that you can set here.
– Long Exposure: Here you can set the extended exposure time of the photo.
– Metering: Here you can set the image area on which the camera focuses, e.g. in the center (Center), at
different locations (Multi) or at one point (Spot).
– Date Stamp: Here you can give your photos a date stamp or a date and time stamp.

36
ENGLISH
Settings
System settings:
– Power Frequency: Set the frequency of your ambient light to get the best results.
– Sounds: Here you can turn on and off the shutter sound, boot up sound, and key beep sound, and vary their
volume.
– White Balance: Set different white balance settings for optimal recordings.There is also a white balance for
underwater shots.
– Effects: Here you can apply various filters to your images.
– Distortion Calibration: Use this function to straighten out the distortion at the edge of the image caused
by the wide-angle lens.
– Date & Time: Set the date and time here.
– Display Flip: This function rotates the display 180° to allow the camera to be operated upside down.
– Screen Saver: Set to turn off the display automatically after a certain time.
– Auto Power Off: Sets the camera to turn off automatically after a certain time.
– Power On Auto Record: This function automatically starts recording a video directly when the camera is
turned on with the previously set settings.
– USB: Set whether the camera is recognized as a removable disk (MSDC – mass storage device class) or
webcam (PCCAM) when connected to a PC via USB.
– Language: Change the language of the camera menu here.
– Format Card: Format your memory card here, e.g. after a firmware update.
– System: Here you will find the function to reset the camera to factory settings, as well as information on the
firmware (system info) and your memory card (card info).

37
Playback Video and Photo
In the playback mode you can preview the videos and photos taken.
– Playback Files on Camera: Make sure you selected the Video
or Photo Playback menu on the camera. Press the corresponding
symbol on the touchscreen or press the power / WiFi button to
cycle the videos or photos, then press the shutter / select button
to playback the videos.
– Delete Files on Camera: On the symbol for deleting files mark
the requested file first by touch or by pressing the shutter / select
button for a couple of seconds, then again shortly and again for a
couple of seconds, then choose the deleting options with the mode
button. Confirm by pressing the shutter / select button, choose yes
or no option with the mode button and confirm again with the
shutter / select button.
Selfie Mode / Switch to the Front Display
To switch displays, press the
mode button for 3 seconds.
1 2 31 2 3

38
ENGLISH
Webcam Function
The Actioncam 9s Plus can also be used as a webcam. To do this, set the “USB” item in the settings menu to
“PCCAM”, make sure you insert a microSD memory card and then connect the camera to your PC via USB.
As a webcam, the camera has a full HD resolution of 1920 x 1080 p and a frame rate of 30 fps.
Note: Please note that you need a separate microphone for audio transmissions, as the internal microphone
is not used for this function.
The compatibility of the camera as a webcam also depends on the program used.
Connection of an external Monitor
You can connect an external monitor via the micro HDMI port. You can use all resolutions of the camera as
resolution, as long as the monitor supports them.
Note: The camera does not support live online streaming.
Remote Control
You can operate the Actioncam remotely using the remote control supplied.
There are two triggers, one for photo mode (1) and one for video mode (2),
which take a photo or start and stop recording a video.
Radio frequency of the remote control: 2.412 – 2.472 GHz;
transmitting power: 10 dBm
Note: The remote control is not waterproof.

39
Storage / Micro Cards
This camera is compatible with up to 64 GB capacity microSD and microSDXC memory card.You must use
a microSD memory card with a U3 or V30 speed rating at least. We recommend using brand-name memory
cards for maximum reliability in high vibration activities.
Please note:
– The memory card is not included in the standard package, you will need to buy an extra memory card.
– Please format the microSD and microSDXC memory card on the camera before using.
– Please restart the camera after formating.
– Please insert the memory card in the correct way, otherwise the card slot might get damaged.
WiFi Setting / Operation via App
You can connect the camera to your smartphone via the integrated WiFi function.Turn the camera on and
swipe up on the touchscreen to turn on WiFi using the mode menu, or briefly press the power / WiFi button
to activate WiFi. The camera‘s WiFi is activated, the power indicator blinks, and the WiFi information (network
name and network password „1234567890“) appears on the camera‘s monitor. Then connect the camera
to the smartphone by going to the WiFi settings of your smartphone, selecting the camera‘s network and
connecting it. Download the free app „8s/9s/11s Plus Actioncam“ (Android version) from the Google Play
Store or the iOS version „Rollei 8s/9s/11s Plus Actioncam“ from the App Store and install it on your smart-
phone.After installing it, open the app and select the camera network from the list. You will see the camera
on the screen of your phone.To exit WiFi mode press the power / WiFi button shortly.

40
ENGLISH
WiFi Setting / Operation via App
Here you can download the app:
Firmware Updates
Our cameras are delivered with the latest firmware by default. If a firmware update is required for your
device, you will find it in the download centre at downloads.rollei.com.
Download on the

41
Disposal
Dispose of the packaging according to its type. Use the local possibilities for collecting paper,
cardboard and other materials (applicable in the European Union and other European countries
with systems for the separate collection of recyclable materials).
Devices that are marked with this symbol must not be disposed of with household waste!
You are legally obliged to dispose of old devices separately from to dispose of household waste.
Information on collection points that accept old appliances free of charge can be obtained from
your local authority or town council.
Batteries and rechargeable accumulators must not be disposed of in household waste!
As a consumer you are legally obliged to dispose of all batteries and accumulators, whether
they contain harmful substances* or not, to be disposed of in an environmentally sound manner.
Accumulators and batteries are therefore marked with the symbol shown opposite. For more infor-
mation, contact your dealer or contact return and collection points in your community.
*marked with: Cd = Cadmium, Hg = Mercury, Pb = Lead
Battery Warning
– Never dismantle, crush, or pierce the battery, or allow the battery to short-circuit. Da not expose the
battery in high temperature environment, if battery leaks or bulges, stop continue to use.
– Always charge using the designated charger. Risk of explosion if battery is replaced by an incorrect type.
– Keep the battery out of reach of children.
– Batteries may explode if exposed to naked fire. Never dispose batteries in a fire.
– Follow your local regulations for disposing used batteries.
– Before disposing the device, remove the battery.
