Rollei PDF-S 240 SE User manual

1
Main features
• Multiscannerwith5.1megapixelsimagesize
• Highscanningqualityof1800dpiand2400dpi(interpolated)
• Digitizeslides,negativesandphotosinamatterofseconds
• Automaticandmanualexposure
• Automaticcolourbalance
• PowersupplyviaUSBcable
Contents of box
Theboxcontainsthefollowingcomponents:
 1. RolleiMultiScannerPDF-S240SE
 2. 1xslideholder
 3. 1xnegativeholder
 4. 3photoholders(9x13cm,10x15cmand13x18cm)
 5. USBcable
 6. USBmainsadapter
 7. SoftwareCD
 8. Instructionmanual
 9. Warrantycard
Dearcustomer,
Congratulationsonpurchasingahigh-qualityRolleiproduct.Youhaveacquiredamodern
MultiScannerwithexcellenttechnicalfeaturesandrespectiveaccessories,whichisparticularly
easytooperate.Pleasestudythisinformationindetail,observingsafetyinstructions,inparticular.
Thescannercomeswitha2-yearwarranty.Youwillneedtheenclosedwarrantycardandyour
salesreceiptintheeventoftheMultiScannerdevelopingafault.Keeptheseinasafeplace
togetherwiththeinstructionmanual.
Pleaseincludetheinstructionmanualwhenpassingonthescannertoathirdparty.
Note:
• Onlyusethescannerfortheintendedpurposes.Wherethescannerhasbeenusedfor
 otherpurposes,resultingindamage,thewarrantyshallbeinvalidated.Injuriesand
 damagetotheenvironmentcanalsoonlybeavoidedifusedcorrectly.

2
Contents
01 Introduction
01 Main features
01 Contents of box
02 Contents
04 1. Safety Instructions
06 2. Overview of device
07 3. Inserting slides
08 4. Inserting negatives
09 5. Inserting photos
10 6. General operation
10 6.1. Quick start
11 6.2. Main menu
12 6.3. Capture
13 6.3.1. Flipping an image
14 6.3.2. Adjusting image brightness and colors
14 6.3.3. Scanning and editing
15 6.3.4. Scanning more images
16 6.3.5. Memory full
16 6.4. Playback
17 6.4.1. Automatic slideshow
17 6.4.2. Individual playback
17 6.4.3. Editing menu
20 6.5. Film type (only in lm scanner mode)
21 6.6. Eects (only in photo scanner mode)
21 6.7. Select photo format (only in photo scanner mode)
22 6.8. Set resolution

3
23 6.9. Language setting
23 6.10.USB mode
24 7. BlazePhoto (image processing software)
24 7.1. Installation
24 7.2. Editing functions
24 7.2.1. Import photos (Get Photo)
25 7.2.2. Preview
26 7.2.3. Edit
28 7.2.4. Create
28 7.2.5. Share
29 8. Disposal
29 9. Warranty and Service
30 10. Conformity
31 11. Technical Specication
32 12. Index

4
1. Safety Instructions
HAZARD for children
• Childrendonotrecognizethehazardsthatcanresultfromtheincorrectuseofelectrical
 equipment.Thescannershouldconsequentlybekeptawayfromchildren.
• Keepchildrenawayfrompackagingmaterial.Dangerofsuocation!
ELECTRICAL hazard
• NeverimmersetheMultiScanner,theUSBconnectioncableandtheUSBmainsadapterinwater,
 asthismaycauseanelectricalshock.
• Donottouchthescannerwithwethandsanddonotoperateintheopenorinroomswithahigh
 humidity.
• Donotplaceanycontainerslledwithwater,suchasvasesnearthescanner.Thecontainermay
 tipoverandliquidmayimpairelectricalsafety.
• TheMultiScannermayonlybeconnectedtoaPCwithaUSBinterfacefromversion1.1onwards.
 Intheeventofafault,theoperationwithanUSB1.0interfacemaycauseashortcircuitandre
 hazard.
• AlwaysdisconnecttheMultiScannerfromthemains...
 ...ifyouarenotusingthedeviceforsometime,
 ...duringthunderandlightning,
 ...priortocleaningthedeviceand
 ...incaseofmalfunctioningduringtheoperation.
 WhentheMultiScannerispluggedintothesocketalwayspullontheUSBmainsadapterandnot
 ontheUSBconnectioncable.
• PullUSBcableoutoftheUSBsocketofthecomputertodisconnectthedevicefromthePC.
• Theconnectioncablemaynotbekinkedorsquashed.Keepconnectioncableawayfromhot 
 surfacesandsharpedges.
• DonotoperatethescannerifthereisanyvisibledamagetotheUSBconnectioncableortheUSB
 mainsadapter
• Donotmakeanychangestothescanner.DonotreplacetheUSBconnectioncableorUSBmains
 adaptoryourself.Repairsonthedeviceshouldonlybecarriedoutbyaspecialistworkshoporby
 theServiceCentre.Incorrectrepairscancauseconsiderablehazardsfortheuser.
• DonotoverloadtheUSBconnectionsofyourcomputer.Iftoomanydevicesareconnectedto
 thecomputer,suchascordlessmouse,mediaplayer,mobilephonesorotherUSB-operated 
 devices,theremaynotbesucientpoweravailabletooperatetheMultiScanner.

5
WARNING against injuries
• InstallUSBconnectioncablesothatitdoesnotbecomeatriphazard.
CAUTION – material damage
• PlaceMultiScanneronasturdy,levelsurface.
• Protectthedeviceagainstmoisture,dust,hightemperaturesanddirectsunlightasthesemay
 causemalfunctioningandcandamagetheelectronicsorhousing.
• Ensurethatthereisenoughspaceforventilationaroundthedevice.
• Keepasafedistancetoheatsources,suchashobsorovens.
• DonotdroptheMultiScanneranddonotsubjectittostrongimpacts.
• Donotplaceanycandlesorothernakedamesclosetothedevice.
• Donotplacedeviceclosetostrongmagneticelds,e.g.loudspeakers,asthismayinterferewith
 itsfunctioning.
• Donotuseharshchemicalsoraggressiveorabrasivecleaningagents.
Purpose of use
TheMultiScannerisintendedforprivateuseandnotforcommercialpurposes.

6
14
1
4
6
7
5
8
9
15
10
11
12
13
16
18 19
17
20
2
3
 1. ON/OFFswitch
 2. ControlLEDphotoscanmode
 3. ControlLEDlmscanmode
 4. SCANbutton
 5. Switchforscanmode
 6. MiniUSB2.0connection
 7. SD/SDHCandMMCmemorycardslot
 8. Leftbutton
 9. ENTERbutton
10. Rightbutton
11. MODEbutton
12. Insertionslotforphotoholder
13. Sliderforselectingscantemplate
14. 6.1cmTFT-LCDcolourmonitor
15. Slideholderininsertionslotforslidesand 
 negatives
16. Slideholder
17. Negativeholder
18. Holderfor9x13cmphotos
19. Holderfor10x15cmphotos
20. Holderfor13x18cmphotos
2. Overview of device

7
3. Inserting slides
Opentheslideholderatthepointmarked“Open“andplacetheopenholderinfrontofyouas
shownbelow.Theslidescannowbeplacedtherightwayup(notturnedandnotreversed)inthe
recessesprovidedintheholder.
Closetheslideholderandpressdowntheedgesuntiltheyengage.
NowinserttheslideholderfromtherightintotheMultiScanner’sinsertionslotforslideand
negativeholderssothatthewhitetrianglemarkingisfacingthefrontandisvisible.
SlidetheslideholderintotheMultiScanneruntilitengagesnoticeablyintherstslideposition.
Note:
• Caution:Donotinsertslideholderfromtheleftsideintotheinsertionslotofthescanner
 anddonotpulltheholderoutoftherightsideofthescanner!Anydamageresultingfrom
 suchincorrecthandling,isnotcoveredbythewarranty!
• Handleslideswithduecare.Dust,scratchesorngerprintswillbevisibleonthesaved
 image.Whenworkingwithslides,wearcottongloves,wherepossible.Usecompressedair
 forremovingdustfromslides.SuchadeviceisnotincludedwiththeMultiScannerbutcan
 bepurchasedfromspecialistretailersforocematerialsorelectronicproducts.

8
4. Inserting negatives
Openthenegativeholderatthepointmarked“Open“andplacetheopenholderinfrontofyouas
shownbelow.Thenegativescannowbeplacedtherightwayup(notturnedandnotreversed)in
therecessprovidedintheholder.Youcanusethenumbersonthenegativestripasaguide.
Closethenegativeholderandpressdowntheedgesuntiltheyengage.
NowinsertthenegativeholderfromtherightintotheMultiScanner’sinsertionslotforslideand
negativeholderssothatthewhitetrianglemarkingisfacingthefrontandisvisible.
SlidethenegativeholderintotheMultiScanneruntilitengagesnoticeablyintherstnegative
position.
Note:
• Caution:Donotinsertnegativeholderfromtheleftsideintotheinsertionslotofthe
 scanneranddonotpulltheholderoutoftherightsideofthescanner!Anydamage
 resultingfromsuchincorrecthandling,isnotcoveredbythewarranty!
• Handlenegativeswithduecare.Dust,scratchesorngerprintswillbevisibleonthesaved
 image.Whenworkingwithslides,wearcottongloves,wherepossible.Usecompressedair
 forremovingdustfromthenegatives.SuchadeviceisnotincludedwiththeMultiScanner
 butcanbepurchasedfromspecialistretailersforocematerialsorelectronicsproducts.
• ThedesignofthenegativeholdercomplieswiththeISOstandard.Insomecasestheholes
 ofthenegativesdonotttheholderaccurately.Thisiscausedbynon-standardcameras.
 Insuchcasesasmallblacklineappearsontheedgeofthepicture,whichcanbeeasily
 removedwithanimageeditingprogram.

9
5. Inserting photos
Insertaphotointothephotoholderfortherespectivepicturesize.Theholders
areavailableinsizes9x13cm(3½“x5“),10x15cm(4“x6“)and13x18cm(5“x7“).
Insertpictureframeintoslotinthetopofthescanner(seeillustration).Priortoscanningphotos,
ensurethatnoslideornegativeholderhasbeenleftinthescanner.
Note:
• Handlephotoswithduecare.Dust,scratchesorngerprintswillbevisibleonthesaved
 image.
Note:
• Observethatpriortocommencingthescanningoperationtherightimagesizeforthe
 pictureholdermustbesetinthemenu.

10
6. General operation
6.1. Quick start
• Toscanslidesornegatives,slidetheswitchatthetopforthescanmodeandforselectingthe
 insertionslottotheleft“Filmscanner”position.
 Toscanphotos,slidebothswitchestotheright,totheposition“Photoscanner”.
• Placeslide,negativeorphototobescannedintherespectiveholder.
• Inserttheslideornegativeholderintotheinsertionslotontherightofthedeviceorplacethe
 photoholderintheslotonthetopofthedevice.
• Placethememorycardinthememorycardslot.
• Usingoneofthefollowingtwooptionsconnectthescannertopower:
 1.ConnecttheMultiScannertoacomputerusingtheUSBcable
 2.ConnectthedevicetothemainsusingtheUSBcableandtheUSBmainsadaptor.
• PushtheOn/O switchtoswitchontheMultiScanner.
• Forscanning,followtheinstructionsonscreen.Alwaysconrmselectionofthefunctionby
 pressingthe ENTERkey.
• YoucantransferthedatafromthememorycardtothecomputerviatheUSBconnection.For
 thispurpose,connecttheMultiScannertothecomputerusingtheenclosedUSBcable. 
 AfterselectingtheUSBmode,thescannerappearsasaremovablestoragedeviceunder 
 MyComputer.
Note:
• Iftheswitchforthescanmodeandtheswitchforselectingtheinsertionslotareinthe
 sameposition“Filmscanner”or“Photoscanner”,therespectiveLEDwilllightupnexttothe
 switch-onbutton.

11
Ifnomemorycardisinsertedinthedevice,thefollowingwarningappearswhentheMultiScanner
isswitchedon.Thewarningdisappearsafterseveralseconds.
6.2. Main menu
Afterswitchingonthescanner,themainmenuofthescanmodeappearsonthedisplay.
Wheninsubmenus,youcanreturntothisMainmenuatanytimebypressingtheMODEkey.
ThetwoillustrationsbelowshowtheMainmenuforthelm scanner modeintwodierent
selectionconditionswithinformationabouttheavailableoptions.
Languagesetting
 USBmode
 Recordingmode
 Playback
 Filmtype
 Resolution
Main Menu - Film scanner mode

12
ThenexttwoillustrationsshowtheMainmenuofthephoto scanner modewithinformationabout
theavailableoptions.
Therespectiveoptioncanbeselectedusingthe/buttonintheMainmenu;conrmyour
selectionbypressingtheENTERkey.
6.3. Capture
Selecttheoption“Capturemode“intheMainmenuandstartthemodebypressingtheENTERkey.
Inthenextstepthescanpreviewoftheselectedoriginalisshownonthedisplay(Livedisplay).
Duringthescanpreview,thelivedisplaysymbolisshowninthetopleftcornerofthescreen.Ifa
memorycardhasbeeninserted,thememorycardsymbolappearsinthebottomrightcornerofthe
screen.
Languagesetting
 USBmode
 Recordingmode
 Playback
 Eect(multi-coloured/black&white)
 Imagesize(9x13,10x15,13x18cm)
 Resolution
or Enter
Main Menu - Photo scanner mode

13
6.3.1. Flipping an image
Duringthescanpreview(livedisplay)youhavetheoptionofippingtheimageverticallyor
horizontallypriortoscanning.Thisfunctioncanbeusedtocorrecttheorientationofincorrectly
insertedpictures.
Pressthekeytoiptheimagehorizontallyfromlefttoright.
Pressthekeytoiptheimageverticallyfromtoptobottom.
Note:
• Thesetippedalignmentshallalsoremainiftheimageischangedoranothermenuis
 selectedafterwhichscanningiscontinued.Theippedalignmentshall,however,not
 remainiftheMultiScannerisswitchedo.
horizontal
ipping
vertical
ipping

14
6.3.2. Adjusting image brightness and colors
Duringthescanpreviewyouhavetheoptionofchangingthebrightnessvalue(EV)andalsothe
colorvalue.
FirstpresstheENTERbutton.Nowthemonitorwilldisplaythesettingsforthebrightnessandalso
forthecolorsred(R),green(G)andblue(B).ChoosethedesiredvaluebypressingENTERandMODE
andchangethesettingsbypressingandwithintherangeof-2to+2.Toapplythechanges
youhavemade,presstheSCANbutton.
Thesettingswillapplyseparatelytoslides,negativesandphotoprintsandwillbekeptevenifthe
devicehasbeenswitchedo.
6.3.3. Scanning and editing
PresstheSCANkeyduringthescanpreviewtoscantheimage.Theimagethenappearsintheedit
menu.
ThesymbolsintheEditmenuhavethefollowingmeaning:
Save:Savetherecordedimage.
 Cancel:Canceleditingoftheimage.
 Home:BacktotheMainmenu.
Scanned image
SCAN

15
Save
Usethe/keysintheEditmenutoselecttheoption
“Save“andclickontheENTERkey.Therecordedimageis
thensavedonthememorycard.
Thescannerthenreturnstothescanpreview.
Cancel
Usingthe/buttonsselectthe“Cancel”optionand
conrmtheselectionbypressingENTER.Thisinterrupts
theeditingofthecurrentlyscannedimageandreturnsto
thelivedisplayfunction.
Caution:Thescannedimagewillnotbesaved!
Home
Usingthe/buttonsselectthe“Home”optiontoreturn
fromtheeditmenutotheMainmenuandpressENTER.
AlternativelyyoucanpresstheMODEkey.
Caution:Thescannedimagewillnotbesaved!
6.3.4. Scanning more images
Afterselectingoneoftheoptions“Save”or“Cancel”,thescannerreturnstothescanpreview(live
display).Pushtheslideornegativeholdertothenextimageorinsertthenextphototocontinuethe
scanningprocess.
Save

16
6.3.5. Memory full
IftheSCAN keyispressedintheRecordingmodeandthe
followingwarningappearsontheMultiScannerdisplay,the
usedmemoryisfull.Inthiscaseyouwillhavetorsttransfer
theimagestothecomputerorinsertanewmemorycard
beforescanningfurtherimages.
6.4. Playback
SelectPlaybackintheMainmenutoviewimagesalreadyscanned.Whilstthescannerisswitched
on,youcanreturntotheMainmenubypressingtheMODE buttonortheMenusymbol.Usingthe
/buttonsintheMainmenu,selectthe“Playback”modeandpresstheENTERkey.
or
Note:
• IfthememorycardisremovedorinsertedwhilsttheMultiScannerisswitchedon,a
 warningmessagethatthedevicehastoberestarted,appearsonscreen.Thescannerthen
 switchesoautomatically.Thescannerhastobeswitchedonagaintocontinuescanning.
Film scanner mode Photo scanner mode

17
6.4.1. Automatic slideshow
AssoonasyouhaveswitchedonthePlaybackmode,all
imagesofofthememorycardareautomaticallydisplayed
at2-secondintervals.
OnlyimagesscannedbytheMultiScannerwillbe
displayed;imagesfromothersourcescannotbeplayed
back.
IfPlaybackhasbeenselectedbutthememorycontainsno
scannedimagethedisplaybrieyshowsthemessage“No
le“.ThedevicethenreturnstotheMainmenu.
6.4.2. Individual playback
Ifthe ENTERkeyispressedduringtheslideshow,the
slideshowstopsandthelastimageispermanently
displayed.Younowhavetheoptiontoselecteachlastor
nextimagewiththeandkeys.
Insteadofthesymbolforindividualpicturedisplaythetop
partofthedisplaynowshowsthelenameofthecurrent
image.
6.4.3. Editing menu
ToeditanalreadyscannedimageselectENTER
onceduringtheautomaticslideshowtoenter
individualplaybackmode.Usingtheor
keytoselecttheimageyouwishtoedit.Select
ENTERagaintoreturntotheEditmenu.
ThesymbolsintheEditmenuhavethefollowing
meaning:
Rotateby+90degrees:rotaterecordedimageby+90degrees(totheright).
 Rotateby-90degrees:rotaterecordedimageby-90degrees(totheleft).
 Delete:deletethisimageonthememorycard.
 Exit:returntoslideshow.
 Save:saveeditedimagetothememorycard.
 Home:returntoMainmenu.
Symbol for
slideshow mode
Symbol for
single image display
Last image Next image

18
Belowisanotherillustrationofthedescribedmenusequences.
Rotate images
Scannedimagescansubsequentlyberotated.Torotatetheselectedimageby90degreesclockwise,
selecttheoption“Rotate+90°”usingthe/keysintheEditmenuandclickontheENTER key.
Youcanthencontinueturningtheimageorsaveit.Inthesamemanneryoucanturnanimage
counter-clockwiseby90degreesbyselectingtheoption“Rotate-90°”.
ENTER ENTER
Slideshow mode Individual image mode
Use/keystopage
throughimages
Editing mode
Note:
• Therotatedimageisnotautomaticallysaved.Thisonlyoccursaftertheoption”Save”has
 beenselected.
ENTER

19
Save
Topermanentlysaveanimage,rstusethe/keystoselecttheoption“Save”.Afterpressingthe
ENTERkeytheimageissavedandthenextimageisshownonthescreen.
Delete
Tocompletelydeletetheshownimage,rstselecttheoption“Delete”with/keysintheEdit
menu.AfterpressingtheENTERkeytheimageisdeletedandthenextimageisshownonthe
screen.Atthesametimetheselectionchangesautomaticallyto“Exit”.Select“Delete”againtodelete
moreimages.
Exit
Assoonasthe“Exit”functionisselectedintheEditmenu,thedisplayreturnstotheslideshow,
startingwiththerstimage.
Note:
• Caution:Deletedimagescannotbereinstated!
ENTER
ENTER
ENTER
