Rollplay W501-R Assembly instructions

Owner’s Manual and Assembly
Instructions
Model #: W501-R, W501-W
Read and understand the entire manual before assembly and
operation. The vehicle must be assembled by an adult who has
read and understands the instructions.
Made in China.
Styles and colors may vary.
Call 1-888-982-9309 for assistance and replacement parts.
Before returning to the store, contact Rollplay with questions.
IMPORTANT:
Save this manual with your sales receipt.
®
12V Nighthawk

Introduction
Thank you for purchasing th We hope the rider
enjoys it for miles to come. Please read this instruction guide carefully
before assembling and operating the vehicle. Please have your model
number and serial number ready before calling.
Please contact Rollplay Customer Service with any questions.
Hours: 9 AM - 5 PM (CST), Monday - Friday
Phone: [phone]
Email: [email protected]
Web: www.rollplay.com
12V 7AH
12V 100W
6 Years and Up
50 kg (110 lbs)
79.5 x 65.5 x 21.5 cm
8-12 Hours
snim09-07
Specifications:
BATTERY
MOTOR
AGE
MAX WEIGHT
PRODUCT SIZE
SPEED
CHARGE TIME
RUN TIME
CHARGER OUTPUT DC 12V
(31.3 x 25.8 x 8.5 in)
Up to 10.5 km/h (6.5 mph)

IMPORTANT!
YOU MUST CHARGE THE BATTERY
FOR 24 HOURS BEFORE FIRST USE!
Charge the battery after each use.
Charge the battery at least once a month, even if the vehicle is not in use.
Do not charge for more than 30 hours.
BEFORE RETURNING YOUR PRODUCT TO THE
STORE, CONTACT ROLLPLAY WITH QUESTIONS.
1-888-982-9309
Read this entire manual to ensure
proper assembly and safe operation
of the vehicle.
Call or email Customer Service if you need assistance or replacement
parts. Please have your model number and serial number ready before
calling. Please have proof of purchase. Keep your sales receipt or register
your product at www.rollplay.com as we require proof of purchase.
[email protected]

This page is intentionally left blank.

5
Table of Contents
Safety..........................................................6
Parts............................................................8
Flagpole Assembly.................................... 9
Remove the Seat ......................................10
Charge the Battery ..................................11
Operating Instructions ............................12
Maintenance.............................................13
General Care............................................
.......................................
14
Troubleshooting Guide............................15
Service and Repairs ................................
16
Warranty ...................................................
17
Product Registration ...............................
18
19
FCC Information

6Safety
WARNING: SAFETY RIDING RULES
,
•The user must follow all safety rules and guidelines, or serious injury or death may occur to the user.
•Always use common sense and safe practices when using the vehicle. The user must be at least 6 years old and
weigh no more than 50 kg (110 lbs). The recommended rider age is only an estimate and can be affected by the
rider's size, weight or skills. Any rider unable to t comfortably on the Nighthawk should not attempt to ride it. A
parent's decision to allow his or her child to ride this product should be based on child's maturity, skill and ability to
follow rules.
• This product contains small parts that are for adult assembly only. Keep small children away when assembling.
Remove and dispose of all protective material and plastic bags before assembly.
• Riders must always wear a tted helmet that complies with U.S. Consumer Product Safety Commission (CPSC)
Standard 16 CFR 1203. Elbow pads and knee pads, a long-sleeved shirt, long pants, and gloves are recommended.
Always wear athletic shoes (lace-up shoes with rubber soles), never ride barefoot or in sandals, and keep shoelaces
tied and out of the way of the wheels, motor, and drive system.
• Come to a stop when approaching an obstruction, turn away, and use the vehicle elsewhere.
• Only sit on the seat on the vehicle.
• Do not allow more than one rider.
• Do not overload the vehicle. Do not remove the weight restriction decals.
• Do not pull the vehicle with another vehicle or similar device.
• Keep body parts such as hands, legs, hair and clothing away from moving parts. Moving parts can cause serious
injury.
• Always wear shoes on the vehicle.
• Do not operate near streets or motor vehicles.
• Do not operate near drop-offs such as steps, steep inclines, or hills. Operate on relatively level ground.
• Do not operate near water, swimming pools, or other uids.
• Do not operate in dangerous weather conditions such as rain or snow.
• Do not operate near loose dirt, mud, sand, or ne gravel.
• Do not operate near ammable vapors (gasoline, paint thinner, acetone, etc).
• Always use the vehicle in a safe, secure environment with adult supervision.
• The vehicle should be used with caution as skill is required to avoid falls or collisions causing injury to the user and
third parties.
• Do not touch the electric motor on your product when in use as it can become very hot.
• Do not activate the foot pedal throttle unless you are seated and in a safe, outdoor environment suitable for riding.
• This product was manufactured for performance and durability, but it is not impervious to damage. Bumping into
obstacles, jumping or other aggressive riding can overstress and damage any product, including the Nighthawk, and
the rider assumes all risk associated with high-stress activity.
• Secure hold on handle at all times.
PREVENT INJURIES AND DEATHS:
NEVER LEAVE CHILD UNATTENDED. ALWAYS keep child in view when child is in vehicle. Direct adult
supervision is REQUIRED.
NEVER use in roadways, near motor vehicles, on or near steep inclines or steps, swimming pools, or other bodies
of water.
ALWAYS wear shoes, a helmet and shoes.
ALWAYS sit on the seat. Do NOT lean backwards.
RISK OF FIRE. Do not bypass.

7
Safety
(Continued)
WARNING: BATTERY SAFETY
• Battery posts, terminals and related accessories contain lead and lead compound
components. DO NOT open the battery.
• Contact exposure to battery leakage (lead acid) may cause serious injury.
Immediately contact your doctor if exposure occurs. If the chemical is on the skin,
immediately give the person water or milk. Do not give water or milk if the person
is vomiting or has decreased alertness. Do not induce vomiting.
•
explosion. It could permanently damage the system. Keep the charger housing
closed to prevent exposed wiring, which may cause electric shock.
IMPORTANT:
charged for a full 24 hours (no more than 30 hours).
WARNING: ADULT SUPERVISION
REQUIRED
• Before using the vehicle, the rider must understand the vehicle controls and safety
issues.
• It is the responsibility of the adult to educate the child and to determine if the child
is capable of understanding the vehicle controls.
• An adult must ALWAYS directly supervise the use of this vehicle.
• NEVER leave a child unsupervised in the vehicle.

8Parts
7. Vehicle Body
8. Support Wheels (x2)
9. Front Wheels
10. Washers (x4)
11. Wheel Nuts (x4)
12. Rear Wheel Assembly
13. Motor Cover
14. Chain
15.
Gas Pedal16.
17. Brake Pedal
1. Manual
Battery
3. Charger
4. Flagpole
5. Seat
6. Handle Bars (x2)
12
10
10
13
13
11
11
7
10
11
9
10
11
9
1
5
6
15
14
16
17
2
3
4
8
8
Motor

9
Flagpole Assembly
Insert the agpole into the agpole hole at the back of the vehicle.

10 Remove the Seat
The battery is located underneath the seat. Please remove the seat to charge the battery.
Remove the Seat:
Rotate the seat lock (Fig.1) to the unlock position and lift up the seat
using the indentation at the front of the seat.
Install the Seat:
After charging the battery (see page 11 for charging instructions),
rotate the seat lock to the unlock position. Slide the seat into place on
the vehicle body. Use a coin or at head screwdriver to turn the lock
to the locked position.
Fig.1

11
Charge the Battery
1. Ensure the vehicle is stopped and the power switch is turned off.
2. Unlock and remove the seat (see page 10 for seat removal instructions).
3. Unplug the red battery connector (A) from the red engine connector.
4. Connect the red battery connector (A) to the battery charger connector
(B) and plug the battery charger into 120V outlet (C).
Note: Do not use the vehicle while it is plugged in.
C

12 Operating Instructions
Note: Wear protective equipment including a helmet and
padding to avoid possible injury.
Power Button
Brake Pedal
Accelerator
Foot Pedal
Driving Instructions:
Before riding the vehicle, ensure the battery is connected and seat is secure,
and locked into place. Make sure the rider is seated and leaning forward. Press
the power button to turn on the vehicle. The light will turn on if the vehicle is
charged.
To Begin: Grip the handlebars tightly and lean forward while riding. Press the
Accelerator Foot Pedal down slowly at rst to go forward. The vehicle will stop
if the foot pedal is released.
To Brake: Press down on the Brake Pedal to come to a stop.
To Turn or Spin: While moving, lean to the desired direction until the support
wheel touches the ground. Note: Do not lean back while riding.
To Drift: Increase your speed, then take your foot off the gas pedal and lean
into the side of the desired direction.

13
Maintenance
Important Battery and Charger Information
• Only an adult who has read and understands the safety warnings may
handle and operate the battery and battery charger. Keep away from
children.
•
time.
• Recharge the battery immediately after each use. Charge for at least
8-12 hours, but no more than 20 hours.
• Charge the battery at least once a month, even if the vehicle is not used
or stored.
• Never leave the battery in a discharged condition.
• Connect the terminal of the battery and charger, then plug the charger
into a 120V AC outlet.
• It is normal for the charger to heat slightly. If the charger rises above
71°C / 160°F, disconnect the charger and call Customer Service for
assistance.
• Keep the charger away from water or excessive moisture to prevent
short-circuiting.
• Do not charge the
battery with any other charger.
• Do not attempt to recharge non-rechargeable batteries with the original
charger.
• Do not replace the battery with any other battery, or the warranty
will be voided.
• Remove damaged batteries from the vehicle immediately. Recycle or
dispose of the used batteries responsibly.
• Do not short circuit the supply terminals.
• Do not leave the battery connected in the vehicle for extended periods
of time when the vehicle is not being used. Disconnect the battery
connector from the engine connector before storing.
• The vehicle is equipped with a thermal fuse to protect the electric
circuit. If the vehicle cuts out, turn the vehicle off and on to reset.

14 General Care
• Regularly inspect all vehicle parts to ensure they are in good working
condition.
• Regularly inspect the charger, cord, plug, and other related parts for
damage.
• Remove any damaged parts and immediately contact Customer Service
for replacement parts. See Service information on Page 16.
• DO NOT operate the vehicle if there are any damaged parts.
• Carefully clean the vehicle with a damp cloth and mild soap. Do not
get water in or near any electrical parts. Do not wash the vehicle with a
hose.
• Store the vehicle indoors or use a tarp to cover it. Keep away from
stoves, heaters, or other sources of heat.

15
Troubleshooting Guide
Problem Potential Cause Solution
Vehicle does not run Battery is low Recharge the battery
Battery terminal
connector loose or
detached
Reconnect battery connector
Battery not charged Recharge Battery
Electrical Components
Broken
Call Customer Service for
troubleshooting
Battery is dead Call Customer Service for
replacement battery
Drive chain fell off Reinstall the chain
Motor is damaged Call Customer Service
Vehicle only runs for a
short time
Undercharged battery Ensure a secure connection
when the battery is
recharging. Recharge for at
least 8-12 hours
Overcharged battery Never charge the battery for
more than 30 hours
Battery is old Replace battery
Vehicle runs slowly Battery is not fully
charged
Ensure a secure connection
when the battery is recharging
Battery is old Call Customer Service to
order replacement battery
Too much weight on
vehicle
Reduce weight on vehicle
(Max. Weight: 50 kg / 110 lb)
Harsh conditions Operate the vehicle on level
ground and safe surfaces
Caster Wheel is Worn Call Customer Service
Motor or gearbox making
grinding noise
Motor or gear damage Call Customer Service
Vehicle unable to drift Support wheel screw is
loose
Tighten the screw
Support wheel is wor Replace caster wheel
Completely read through the manual and troubleshooting guide before
contacting Customer Service.

16 FCC Information
This device complies with part 15 of the FCC Rules. Operation is subject
to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits
are designed to provide reasonable protection against harmful interference
in a residential installation.
This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user
is encouraged to try to correct the interference by one or more of the
following measures:
• Reorient or relocate the receiving antenna.
• Increase the distance between the equipment and the receiver.
• Consult dealer or an experienced radio/TV technician for help.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Check the state or local requirements for the product before using the
product.
responsible for compliance could void the user’s authority to operate the
equipment.

17
If your product requires service, repairs or replacement parts, please
contact Rollplay Customer Service.
Hours: 9 AM - 5 PM (CST), Monday - Friday
Phone: [phone]
Email: [email protected]
Web: www.rollplay.com
For a list of available replacement parts, please visit www.rollplay.com
WE WILL REQUIRE PROOF OF PURCHASE. Please save your sales
receipt or register your product at www.rollplay.com.
Service and Repairs
Before returning your vehicle to the store, contact
Rollplay with questions

18 Warranty
Rollplay 12-Volt Limited Warranty
• One-year limited warranty from the date of purchase with proof of purchase from
a Rollplay certied retailer.
• Six month limited warranty on the 12-Volt battery with proof of purchase from a
Rollplay certied retailer.
•
•
This one-year limited warranty covers the ride-on vehicle against defects in
materials and workmanship to the original purchaser. Proof of purchase receipt
from a Rollplay certified reseller is required.
Rollplay ensures the original 12-Volt battery is warranted for 6 months from initial
• This warranty covers normal use and does not cover the Rollplay vehicle or
abuse, misuse, improper service or other causes not arising out of defects in
materials or workmanship. Evidence of any attempt at consumer repair will void
this warranty.
• This warranty does not cover, and is not intended to exclude any liability on the
part of Rollplay, whether under this warranty or implied by law for any indirect or
consequential damages for breach of warranty. Some states may not allow the
exclusion or limitation so this limitation may not apply to you.
Should you need service or assistance with your vehicle during the warranty period:
• Please do not return vehicle to the store.
• Consult the troubleshooting guide in this manual and online at www.rollplay.com
or
• Call Rollplay Customer Service at 1-888-982-9309
may vary from state to state.
Please save your original sales receipt.

19
Product Registration
Fill out the form below and mail it to:
Rollplay Products
1131 W Blackhawk St.
Second Floor
Chicago, IL 60642
www.rollplay.com
We will use the information provided only for your warranty. We will not sell,
rent or share your personal information.
First Name: Last Name: Title:
Address:
City: State: Zip Code:
Email: Phone:
Date of Purchase:
The following product information is on the cover of the owner’s manual.
Product Name: Model Number:
Serial Number: Retailer Place of Purchase:
Product Registration
Questions or comments? Contact us at www.rollplay.com or call 1-888-982-9309.
