RooDog Rogue User manual

RooDog Electric Bicycle
USER
MANUAL
Black
Pantone Red 032C
Pantone Blue 072C
En 15194 official standard
Rogue

www.roodog.co.uk |32 |www.roodog.co.uk

www.roodog.co.uk |54 |www.roodog.co.uk
Thank you for buying a RooDog electric bike. This is one of the best purchases
you will ever make providing it is cared for properly.
Important: Please read this manual carefully before use and follow
instructions provided at all times
For your own safety check brakes, gears, lights and tyre pressures are fully
operational and correct before any bike ride. Also check all fasteners, quick
release bolts and anything else that may be of hazard prior to setting off.
Important:
Please read & follow battery care guidelines in this booklet before first use.
Identity:
Serial number:
Dealer stamp: Date purchased: / /

www.roodog.co.uk |76 |www.roodog.co.uk
Parts I.D
We continually strive to give the best products
possible to our customers and therefore parts
are subject to change without notice.
Contents
1 x Electric bike, 1 x Battery, 1 x Charger, 1 x User Manual and 1x Battery Care Manual
Index
Parts I.D ......................................................................................................................................................7
Bike assembly......................................................................................................................................... 8
Getting started & how to use power assistance..............................................................9
LCD Display - Display Interface................................................................................................ 10
Battery Charging & Removal ..................................................................................................... 11
Maintenance ................................................................................................................................12-13
General Specifications............................................................................................................14-15
Warranty................................................................................................................................................. 16
Troubleshooting.........................................................................................................................17-18
1. Saddle
2. Lights
8. Gear selector
9. LCD display
16. Battery
Charge Point
11. Battery
10. Battery Key Lock
4. Front disc brake
3. Front suspension
12. Bike frame
13. Pedal6. Front chain ring
14. Side stand
7. Rear 7 speed gars
15. Rear wheel
hub motor
5. Rear disc brake

www.roodog.co.uk |98 |www.roodog.co.uk
Bike Assembly:
Tools Required: 4, 5 and 6mm Allen keys, 10 and 15mm spanners
›Remove all packaging carefully: Select a good area to
assemble the bike. Preferably on a non abrasive surface so
you don’t damage the bike.
›Easier with two people: Have someone hold the bike upright
for you.
›Handle bars: Remove all the 4/5mm handle bar bolts and
bracket at the end of the stem, place handle bars in position
and replace the bracket and bolts, tightening with fingers
first. Once all 4 bolts are situated correctly you can tighten
with the 4/5mm Allen key but do this from corner to corner
and only a little bit at a time on each to keep the bracket
even. For example: tighten top right corner bolt first, then
bottomleft corner bolt second and so on.
›Front wheel: Place bike in a bike maintenance stand or turn
up side down so the bike is standing on the handlebars and
saddle but again try to do this on a non abrasive surface
to avoid damage. (remove battery first in order to lighten
and make it easier to manoeuvre the bike). Once in position
take the front wheel and the quick release skewer/axle bolt.
Undo the plastic end cap and take off one spring (leaving
one spring on). Slide the bolt through the Centre of the front
wheel until it comes out the other side, then place the spring
back on first (small end first) followed by the plastic end cap
and loosely tighten. Pick the wheel up and slide into the
slots provided on the front fork and push downwards until
it stops. Once aligned you can tighten up the skewer bolt.
(lever should point upward when fitted correctly)
›Disc brake: If not already correct adjust brake by releasing
brake cable with 5mm Allen key then adjust accordingly and
re-tighten. Spin thewheel to make sure it spins freely. You
can make minor adjustments by turning the plastic screw
located on the brake cable near the brakecalliper.
›Pedals: Locate pedals, separate left and right pedals
indicated by L / R print on threaded end of the pedal. Screw
in each pedal in to the crank arms with your fingers ensuring
not to cross thread them. Once located correctly, tighten
with 15mm spanner.
Note: Your wheel should fully stop once the brake lever
is depressed halfway. If it does not stop, re-adjust them
accordingly.
Getting Started and how to use your power assistance:
Once your bike has been safety checked and is ready to ride
the next step is to turn on the electric. To do this, ensure your
battery is locked on to the bike and switch the battery switch to
the on position.
Press the power button on the LED display on the handlebars.
In doing this the display should light up with red LED lights.
Once turned on the display will indicate battery life and it will
automatically select the lowest level of pedal assist. This will be
indicated by one red LED light nearest the minus sign of the
assist part of the display.
At this point if you start to ride the bike the PAS assistance will
automatically kick in and assist you whilst pedalling. (Tip: stay on
the lowest level until you become confident enough to increase
the power) You can increase the level of assistance simply by
pressing the + button, this will be indicated by the LED light
moving closer to the + sign. You can repeat this until you reach
maximum assistance. (15.5 M.P.H) To come back down the
assistance levels simply press the -button. IMPORTANT: Please be
aware that the assistance is also sensitive to how fast you pedal
and will only give you maximum assist when you are pedalling
relatively fast. (this applies in most levels selected)
To turn off the assistance so you are only using manual pedalling
either press the power button or move down through the assist
modes with the -button until the LED no longer is lit up.
On the right-hand side of the handlebars, you will find (if fitted)
a half twist grip throttle. When the bike is turned on, the throttle
is active and operates independently of pedalling, a bit like a
moped (no requirement to pedal). Please note the red isolation
button also needs to be in the depressed position for the
throttle to be on.
Simply twist the half grip throttle and it will propel the bike. It is
limited though to what level of assistance you have selected on
the PAS. (remember using the throttle will use more battery life
up quicker).
Turning the lights On/Off
To turn the lights on/off, have the power turned on for the LCD
display and simply hold down the + button for a few seconds.
Repeat in order to turn off.
IMPORTANT: When using the throttle try to avoid hill starts
and only use pedalling when the bike seems under strain to
avoid motor burnout. In not doing this it can also void your
warranty.
*See the next page if your bike is tted with LCD display

www.roodog.co.uk |1110 |www.roodog.co.uk
LCD Display - Display Interface Battery Charging & Removal:
Step 2
Place your hand at the bottom of the battery. Push the bottom of the battery up until it releases.
Step 1
Put the key in and turn 180 degrees anticlockwise to unlock the battery.
Step 3
Take hold of the battery and slide up out of the housing bracket.
To replace the battery simply do everything in reverse but make sure you align the connection
points correctly.
DO NOT FORCE ON AS YOU MAY DAMAGE THE TERMINALS.

www.roodog.co.uk |1312 |www.roodog.co.uk
Maintenance Continued:
Tyre pressures:
›Tyres should be routinely checked for correct pressure (this is
stated on the tyre side wall). Failure to do this will result in tyre
or rim damage, more energy will be required to propel the
bike (meaning less miles per charge) and possibly may even
result in a puncture.
Repairing a puncture:
›If you have a puncture, we recommend you have it repaired
by a specialist.
›To remove the rear wheel, you must first separate the electric
hub motor from the bike. In order to do this, locate the cable
coming out of the hub motor and follow it along to the quick
release (QR) plug. Disconnect the plug and all clips and ties
before attempting to remove the rear wheel.
›Prior to removing the wheel from the frame take note how
all the washers are situated so you can replace them in the
correct order in which they came off.
›When replacing the wheel back in the frame, ensure the bolts
are aligned correctly (you may need a 10mm spanner to
help) and seated right and all washers are in correctly before
tightening up the nuts to hold it in position.
›Finally reconnect the motor plug fully so the clip clicks in.
(incorrectly replaced in may result in a sudden lose of power
or may even damage the contacts connecting the motor).
Motor QR plug:
Press here to release
then pull apart.
Maintenance:
Maintaining your bike ensures you will get the most out of every
ride and increases the longevity of your RooDog electric bike.
How much you can do yourself really depends on your skill,
knowledge, experience level and if you have the necessary tools
for the job.
If there is anything you do not understand or are unsure of how
certain things work, it is always best to contact your RooDog
dealer for advice.
Disclaimer: Please be aware general maintenance is not
covered by the warranty and is therefore a service that will be
chargeable.
Before every ride:
›Check brakes, lights, gears and tyre pressures are correct.
›Check fasteners, bolts and anything else that may come loose
over time. Check battery is fully charged, or at least has enough
charge to complete your planned journey.
Weekly:
›Clean the bike, including chainring and gears – (do not use
excessive water around electrical parts)
›Oil the chain and keep all moving parts well lubricated and free
from damp.
Every month:
›Check for worn brake pads and replace if necessary.
›Check headset for looseness by rocking the bike back and
forth whilst having the brakes applied. If loose have your
dealer check it.
›Check free movement of handlebar. If tight have dealer
check it.
›Check cables for free movement, rust, kinks and fraying.
Replace if necessary
›Check wheel spokes are all tight and wheel spins true. Have
your dealer fix it if they are not. (spokes can break and wheel
rims can be bent if this is not regularly checked)
›Check tyre for tread and check sidewalls are in good condition.
Replace if necessary.
Every 3000 miles or annually:
›Have the bike inspected and serviced at your local dealer
including general inspection of the hub motor and all
electrical parts.

www.roodog.co.uk |1514 |www.roodog.co.uk
General Specifications
Motor: 250w 36v rear wheel hub brushless motor with
max speed of 15.5 mph which is allowed by UK/EU
regulation
Gears: Shimano 7 speed megarange
Battery: 36v 11Ah lithium-ion Tyres: Kenda 20-inch x 4.0
Charge time: 4 - 6 hours from flat Frame: 6061 aluminum alloy
Range: Up to 30 miles per full charge, dependent on
weight of cyclist, frequent use of pedal assist,
pressure in tyres & terrain etc. (please note frequent
use of throttle if fitted and hill climbing will
significantly reduce the range of the battery)
Lights: LED lights front and rear (both operate from the
battery and are intergrated in to the LCD display
on the handlebars)
LED Display: Battery indicator, management of the 5 speed PAS,
LED lights and PAS system
Front
fork:
Black aluminium alloy suspension
Power mode: Pedal only, pedal assist PAS (a combination of
pedaling and motor). All bikes are also throttle
fitted (which means no pedaling is required).
Please note throttle speed is capped at 4mph by
UK regulation
Brake: Tektro front & rear disc brake
Contoller: 5 speed Weight: 31.0KG including battery, 28KG without
Rims: Aluminium alloy, 75mm wide, double wall (BLACK) Max
load:
120KG (18.9 stone). Including rider and all
luggage.
180mm
1130mm
1700mm
550mm
740mm
520mm
520mm

www.roodog.co.uk |1716 |www.roodog.co.uk
Troubleshooting
Problem Possible Causes Solution
Power on but motor not
working:
›Motor not connected correctly.
›Rotation disc damaged or not close enough to
sensor.
›Brake lever is pulled in triggering the cut off sensor.
›Loose connection or controller fault.
›Check connection plug is pushed
together fully.
›Clean and push closer if needed.
Contact dealer if damaged.
›Make sure both brake levers are fully out
not triggering the sensor.
›Contact your dealer.
No Power at all: ›Uncharged or dead battery.
›Key not turned on.
›Faulty switch or loose connection somewhere. i.e
the LCD display.
›Faulty controller.
›Recharge the battery and try again. If
problem remains then contact your
dealer.
›Check the key is on position
›Check the connections of the LCD
display, the motor and the battery.
›Contact your dealer.
Traveling shorter distances per
charge than rated:
›Hill climbing, frequent stop/starting, head wind or
heavy load, excessive use of throttle.
›Tyre pressures too low.
›Battery under charged or faulty charger.
›Battery capacity loss or damage.
›Use 1.1 pedal assist and pedal harder.
Reduce the use of throttle and lighten
the load when ever possible.
›Inflate tyre to correct amount indicated
on tyre sidewall.
›Charge the battery or contact dealer.
›Contact dealer to inspect.
Warranty:
Requirements for warranty:
›Bike warranty must be registered to benefit from extended
2-year warranty
›Please retain your receipt as proof of purchase as this is your
1-year warranty and warranty will start from the date of
purchase.
›Warranty is nontransferable and only applies to original
owner.
›Warranty covers – main bike frame, front forks, mud guards,
wheel rims, gears, bearings, motor casing and hub motor, LCD
controller display, brakes (excluding brake pads), battery and
charger
Items covered by 2 year warranty:
›Battery (provided cared for in conjunction with battery care
instructions)
›Motor casing & hub motor
›Bike frame
All other parts covered by the warranty are guaranteed
for a period of 12 months.
Exclusions from warranty:
›When subject to neglect or misuse or resulting in damage due
to an accident.
›Poor maintenance or modifications that no longer complies
with regulations or original technical specifications.
›Damage due to external causes such as left out in heavy rain, or
long-term weathering causing rust and decay etc.
›The bike is put up for hire.
›The Battery is used incorrectly or tampered with (warranty seal
is broken). This also applies to charging. (always use the charger
provided by the manufacturer)
›Battery is not cared for in conjunction with the battery care
instructions provided
Items not covered:
Brake pads, tyres, lights and cables or anything else that can be seen as consumables. These parts can however be purchased
from RooDog Ltd or from your local retailer/bike shop.
To register your warranty please go to:
https://www.roodog.co.uk/warranty-registration-form/

18 |www.roodog.co.uk
Troubleshooting Continued:
Problem Possible Causes Solution
Charging:
Charger light stays green
when I plug in to the battery.
Why? (the light should turn
red to indicate the battery is
charging and green when it
is full)
›Battery is already full.
›Charger lead not connected to the battery properly.
›Fault with the charger.
›The battery has gone in to sleep mode due to not
been charged to protect the cells.
›Drain some power by riding the bike
and then retry charging.
›Check the connection.
›Contact Dealer.
›Contact Dealer.
Charger doesn’t work: ›Fuse has blown.
›Has been damaged through misuse.
›Change fuse and retry.
›Contact dealer.
Important:
Always use the charger supplied by the manufacturer to avoid damaging your battery

www.RooDog.co.uk
Black
Pantone Red 032C
Pantone Blue 072C
0005.07 | 2022
