ROOMS TO GO HD1622-392C User manual

DVDR HD1622-392C CHEST
SKU# 32616231
Thank you for purchasing this quality product. Be sure to check all packing material carefully for small
parts. which may have come loose inside the carton during shipment. Identify and count all parts and
compare with the parts list below:
No. Picture Description Dimension Qty
Hardware List
No. Description Qty
1
2
Part List
A
B
C
D
Chest
Front Left Leg (Packed Inside Drawer)
JCBC (M6) with Spring Washer and Washer
Allen Key (M4)
M6 x P1.0 x 40mm 8 Pcs
4 x 65mm 1 Pc
Front Right Leg (Packed Inside Drawer)
Back Left Leg (Packed Inside Drawer)
EBack Right Leg (Packed Inside Drawer)
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
FTipping Restraint (Packed Inside Drawer) 1 Pc
3Phillips Screwdriver -Not Provided
ASSEMBLY INSTRUCTION
Hardware Pack Location (s) : Bolts pack inside bottom drawer ( Leg inner carton)
PAGE 1 OF 2
Chest SKU # 32616231
PART INSIDE
Hardware
& Legs
PART INSIDE
A
DB
C
Manufactured by (DVDR) for
HARDWARE
Version #1-2023/10/02

ASSEMBLY INSTRUCTION
PAGE 2 OF 2
ASSEMBLY TIPS:
1. Remove hardware from box and sort by size.
2. Please check to see that all hardware and parts are present prior start of assembly.
3. Please follow attached instructions in the same sequence as numbered to assure fast and easy assembly.
WARNING!
1. Don't attempt to repair or modify parts that are broken or defective.Please contact the store immediately.
2. This product is for home use only and not intended for commercial establishments.
Assembly Step
Front Left Front Right
Back Left Back Right
C
E
B
D
STEP 1
Fasten the leg as shown.
Wall
Affix Tipping Restraint
to wall behind Chest
STEP 2
F
C
C
1
1
1
2
Manufactured by (DVDR) for
DVDR HD1622-392C CHEST
SKU# 32616231
