ASSEMBLY INSTRUCTIONS
ITCO 4265-CH SIDE CHAIR
SKU# 42442652
Manufactured for Rooms To Go.
Thank you for purchasing this quality product. Be sure to check all packing material for small parts which may have
come loose inside carton during shipment. Identify and count all parts and compare with the hardware list as below:
Hardware List
Parts List
No. PictureDescription Dimension Qty
Long Bolt M6 x 80mm 6 x P1.0 x 80mm 8 Pcs
A
B
No. Description
Chair Back
Seat With Frame
PARTS DETAIL
Qty
8 Pcs
Spring Washer Ø 1/4" x 12
6 x P1.0 x 35mm
CFront Leg- Left
Wood Screw
Allen Key
M4 x 38mm
8 Pcs
DFront Leg- Right
ESide Stretcher- Left
FSide Stretcher- Right
M4
Flat Washer Ø 1/4" x 19
Short Bolt M6 x 35mm
Spring Washer Ø 1/4" x 12
Flat Washer Ø 1/4" x 19
3 Pcs
3 Pcs
3 Pcs
4 Pcs
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
1 Pc
Hardware Pack Location (s) :
4265-CH SIDE CHAIR SKU# 42442652
1
2
3
4
A
Hardware Pack Location

Assembly steps
Page 2 of 3
NOTE :
Make sure this product assemble on the flat and soft surface. Follow the instructions. Tighten all the nuts, bolts or screws
firmly and make sure this product does not wobble before use.
STEP 1
STEP 2
B
D
C
1
4
Attach front leg- left (C) and front leg- right (D ) to the seat with frame (B)
Tighten with Allen Bolt, Lock Washer and Flat Washer (1) using Allen Key (4).
Attach seat with frame (B) side stretcher- left (E) side stretcher- right (F) to the chair back (A)
and tighten with Long Bolt, Lock Washer and Flat Washer (1) and Short Bolt, Lock Washer and
Flat Washer (2) using Allen Key (4).
4
1
4
2
F
E
A

Assembly steps
Page 3 of 3
NOTE :
Make sure this product assemble on the flat and soft surface. Follow the instructions. Tighten all the nuts, bolts or screws
firmly and make sure this product does not wobble before use.
STEP 3
STEP 4
Complete Assemble
3
F
E
Screwdriver - Not provided
Tighten side stretcher to front leg and chair back with wood screw (3) using screwdriver (Not provided).
