Rotaid TOTEM User manual

INSTALLATION MANUAL
INDOOR
TOTEM
Rotaid AED Cabinets

Parts-list
Footplate Totem
Backboard (optional)
Set for footplate Set for Rotaid Wall
Cabinet
2x Allen key
(4 en 5 mm)
Screw Set:

Rotaid AED Cabinets - Totem
EN instructions
4. After mounting the cabinet,
you can xate the cap of the spacer
again by using the 4mm Allen-Key.
Mounting the totem (requires 2 persons)
1. Before starting assembly of the totem,
please make sure to do this on
a protected oor so the totem will
not be damaged.
Fixate the foot plate to the totem frame,
by using the bolts, washers and rings
and an Allen-Key (5mm).
2. Before mounting the cabinet to
the totem, please remove the 4 bolts
of the cap on the rear of the rectangular
spacer by using the 4mm Allen-Key.
3. Now xate the backplate of the
Rotaid cabinet via the 4 bolts, washers
and nuts with the 4mm Allen-Key.
Use a 10 mm spanner for a secure
attachment.
(Optional: when you have opted for
the signage board (Rotaid part number
302), please mount this together with
the backplate of the cabinet. The board
should be positioned between the
backplate of the cabinet and the spacer.)

Keizersveld 52D 5803 AN, Venray The Netherlands
rotaid.com [email protected] [phone]
