OWNER’S MANUAL
IMPORTANT
Read and understand all safety guidelines and
instructions carefully before operating.
Quality Power Tool Accessories
Stationary Router Table
Models 3551 & 3511

GENERAL INFORMATION
You have purchased a ROUSSEAU CO. STATIONARY ROUTER TABLE
MODELS 3551 or 3511. Both models are excellent for building a router table,
work bench, or a similar use where a solid base is necessary.
WARRANTY
This product has a lifetime warranty to the original purchaser that applies to
defects in materials and workmanship only. We will repair or replace the product
or part(s) at our discretion. This warranty does not apply to product failure
or defects due to normal wear, direct or indirect misuse, abuse, negligence,
accidents, alterations, unauthorized repairs or lack of maintenance. The item
must be shipped prepaid to our Clarkston, WA location. If items must be
returned for warranty service, call to receive a Return Goods Authorization
(RGA) number and further instructions.
SAFETY GUIDELINES
THIS SECTION CONTAINS IMPORTANT SAFETY INFORMATION
CONCERNING HAZARDS THAT MAY CAUSE SERIOUS INJURY OR DEATH,
and/or damage to product or tools if used improperly. Please read the following
instructions very carefully.
Always follow the safety recommendations and guidelines
provided by the manufacturer of your tools and supplies.
When in doubt, refer to your owner’s manual.
Always wear ear and eye protection. Failure to do so may
cause severe injury to hearing or sight.
Always wear substantial footwear. Failure to do so may cause
severe injury to feet.
Always know where you are driving stakes. Before using,
locate all buried lines and cables. Call your utility or cable
company if you are unsure.

RECOMMENDED TOOLS FOR ASSEMBLY
•Tape Measure
• (2)-1/2”Endwrenches
• (1)-9/16”Endwrench
• Drilland3/16”bit
• 3/8”Socketwithratchet
• Safetygoggles
PARTS INCLUDED
HARDWARE INCLUDED
(4) Long Cross Chan-
(4) 2” Square Legs
(2) Short Cross Chan-
(2) Short Cross Chan-
• (2) Nylon Spacers
• (32) 5/16” Hex Kep Nuts
• (32) 5/16” X 3/4” Hex Head Bolts
• (4) 3/8” X 1-1/2” Levelers
• (4) 1/4” X 1” Self Tapping Screws
• (4) 3/8” Hex Nuts

1392 Port Drive, Clarkston, WA 99403
800-635-3416 • 509-758-3954 • Fax [phone]
email:[email protected] • www.rousseauco.com
STEP 1) Bolt long
sections together (n-
ger tight) with nuts on
inside. Make sure all
holes on cross chan-
nels are to the top.
STEP 2) With long
sections bolted to-
gether...
STEP 3)...Measure
from bottom left to top
right and from bottom
right to top left on each
side. Adjust until mea-
surements are equal.
STEP4) Tie long sec-
tions together with short
cross channels and
repeat step 3 to square
short sides.
STEP5) Once stand is
square turn frame up-side-
down and align on under-
side of table top. Mark
holes on short channels
for drilling.
STEP 6) Remove
frame and drill holes
3/4” deep using 3/16”
bit and nylon spacers
provided.
STEP 7) Replace
frame and fasten into
position using 1/4” X
1” self tapping screws
and 3/8” socket.
STEP8) Thread nuts
down to the bottom of
leveler shaft.
STEP 9) ...Screw in
levelers and adjust as
necessary. Use nut to
lock in place.
NYLON
SPAC-
3310 & 3312 REV. 01-05
