Rowlinson SS158D User manual

Before assembly
•We recommend that time is taken to read the
instructions before starting assembly, then
follow the easy step by step guide.The
instruction sheet is only a guide to the
assembly. Certain items may not be shown
to scale.
•Check all components prior to assembly
•This product should be assembled by no
less than two people.
•Never attempt to erect the assembly in high
winds.
Recommended tools for assembly
•Step Ladder
x 2
No. Components Qty.
1Door Panel 1
2Window Panel 4
3Back Panel 1
4Roof Panel 6
5Finial 1
6Pegs 6
No. Fixing kit Qty.
7Webbing straps 30 1
23
4
5
6
5. Securing to the ground
Locate gazebo is in the desired position. For each corner of the wall panels Loop a webbing strap through the bottom
most webbing strap and through the eye of a peg. Push the peg into the ground and tighten the webbing strap.
Webbing strap at the bottom of each
corner of the wall panels
Loop the webbing strap through the
wall panel corner bottom webbing strap
the eye of the peg.
Push the peg firmly into the ground
before tightening the webbing straps
6. Tighten all webbing straps
Finish by fully tightening all the webbing straps.
7
Caution
The willow Gazebo is best positioned in
a sheltered area of the garden, it is
recommended that this gazebo be
taken down if high winds are forecast.
A large build up of snow on the roof
may cause collapse. During snowy
weather regularly brush the snow of
the roof. It is recomended to take the
gazebo down if snow is forecast.
Willow Gazebo
Assembly Instructions
English SS158D
2015 © Rowlinson Garden Products Ltd
If in doubt of any aspect regarding the assembly, use or safety of your gazebo please contact us:
Help Line: (Normal Office Hours) 01829 261 121
Email: [e-mail]
ROWLINSON GARDEN PRODUCTS LIMITED
Green Lane
Wardle Nr. Nantwich
Cheshire
CW5 6BN
www.rowgar.co.uk
We constantly improve the quality of our products, occasionally
the components may differ from the components shown and
are only correct at time of printing. We reserve the right to
change the specification of our products without prior notice.
Top Tip: To help preserve and prolong
the life of the Willow Gazebo brush on
a light coating of linseed oil.

3. Finial
Position the finial centrally onto the point of the roof panels and secure using two webbing straps.
1. Wall panels assembly
Open out the six wall panels and arrange into a hexagon shape. Secure the two open ends together using three
webbing straps, do not fully tighten the webbing straps at this stage.
Join the two open ends together
webbing straps
Ensure the bottom webbing is positioned about
150mm from the bottom of the two panels
Loop the webbing straps through the
roof panels and around the top frame
of the wall panels.
Webbing straps
Ensure the roof is positioned
centrally with equal overhang
all round.
Webbing straps
Webbing straps
2. Roof panels assembly
Open out the roof panels and arrange into a six sided cone shape. Secure the two open ends using three webbing
straps, Do not fully tighten the webbing straps at this Stage.
4. Roof to Wall panels
Lift the roof onto the wall panels, ensure that the corners of the roof line up with the corners of the walls. Adjust the
wall panels making sure they are standing straight with the roof sitting centrally with an equal overhang all round. Once
in position secure each roof panels to the wall it’s sitting on using two webbing straps.
Webbing straps
Webbing straps
Webbing straps
Webbing straps
Pull the strap behind the centre bar
on the buckle
Then loop over the top of the centre
bar and pull the strap through the
otherside of the buckle
Webbing straps
