Royal Prestige Xtractor HU-200 User manual

Instruction Manual
• Pleasereadtheinstructionscarefullybeforeusing.
• Pleasekeeptheuser’sguidewhereitiseasily
accessible.
• Designandproductdevelopmentmaybe
upgradedwithoutapublicnotice.

2 | Xtractor
NOTE TO NEW USERS
TheXtractorbyRoyalPrestige®isacompletelydifferentmechanism
where fresh juice comes from squeezing rather than grinding. The
Xtractorisanewlydevelopedpatentedproductwhichiscapableof
making soy milk, vegetable extracting, fresh squeezed fruit juice,
soupsandmuchmore.
LSTS(LowSpeedTechnologySystem)squeezesinsteadofgrinding
which allows the juice to maintain it’s pure color, natural taste,
nutrientsandvitamins.
For better use and maintenance of the product please follow the
instructionscarefully.
Pleaserefertothisinstructionmanualwhenyouarehavingtechnical
difcultiesorwhenyouareunsureoftheusageofthisproduct.
TABLE OF CONTENTS
Introduction.................................................................................... 2
AttachmentListing......................................................................... 3
SafetyPrecautions.......................................................................... 4
AssemblyInstructions..................................................................... 7
HowtousetheRoyalPrestige®Xtractor..................................... 10
Warningswhileoperating............................................................ 11
Howtodisassembleandclean..................................................... 12
Beforerequestingforrepairservice............................................. 13
ProductSpecication................................................................... 14

Xtractor | 3
ATTACHMENT LISTING
Hopper
TopSet
Base
Pusher Containers(2)
Bowl
Pulpejection Juiceejection
Strainer
Squeezing
Screw
Cleaning
Brush
Spinning
Brush

Donotturnonuntilyouare
readytouse.
Donotoperatewithan
emptybowl.

Asshownbelow,thehopper
edgemustpointtothe“close”
symbolonthebaseinorder
forthemachinetooperate
properly.
Notice
Important

4 | Xtractor
SAFETY PRECAUTIONS
WARNING
• Pleasereadcarefullybeforeusing.
• Pleasefollowinstructionstoavoidinjuries.
Warning Signs
Warning :Violatingthissignmayleadtoseriousinjuryorevendeath.
Caution : Violatingthissignmayleadtoseriousdamagetotheproduct.
Donotuseotherthan120
voltpower.
•Cancauseelectrocution,re,or
productdamage.
Donotforceplugintooutlet;
ensureplugisawayfromany
heatsourceandisnotbentor
twistedinanyway.
•Maycauseelectrocutionorre.
Donotdisassemblethebase.
PleasecontactyourRoyal
Prestige®Distributoror
CustomerServicefortrouble
shooting.
• Violatingtheseinstructionsmaycause
electrocutionorre.
Stopusewhentheelectrical
cordisdamagedorloose.
•\Violatingtheseinstructions
maycauseelectrocution
orre.
Donotplugorunplugthe
electricalplugwithwethands.
•Cancause
electrocution.
Pleasepluginyouroutlet
properly.
•Notdoingsocan
causeelectrocution,
re,orproduct
damage.

Xtractor | 5
WARNING
Donotputanyunknown
substanceintothemachine.
• Violatingtheseinstructionsmaycause
electrocutionorre.
Keepthebasedriedatall
times.
•Violatingtheseinstructionsmaycause
electrocutionorre.
CAUTION
Donotoperatewhenthe
hopperisloose.
• Violatingtheseinstructionsmaycause
electrocutionorre.
Donotunplugtheoutletwhen
thereisgasexposure,rather
openallwindowsforair
ventilation.
•Violatingtheseinstructionsmaycause
electrocutionorre.
Operateonaatandsteady
surface.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Donotputanyobjectsthat
arenotinstructedinsidethe
machine.
Keepawayfromchildrenor
anyonenotfamiliarwiththe
usageofthisproduct.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Donotdisassembleanyparts
whileoperatingthemachine.
Donotputanyunknownobjects
inwhileoperatingthemachine.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.

6 | Xtractor
CAUTION
Donotmoveunitwhile
operating.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Shouldthesqueezingscrew
jam,putinreversefor2-3
secondsthentryoperating
again.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Donotdisassemblewhile
operating.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
• Disassembleafterthepowerisoff.
Donotuseanythingotherthan
thepusher.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Donotusemorethan30
minutescontinuously.
• Itwilloverheatthemotor.
Donotsubmergethemotorin
water.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Afteruse,removetheplug
fromtheoutlet.Donotuse
cordtoremoveplug.
Whileusing,ifthereisany
unusualodor(heat,smoke)
stopuseimmediatelyand
contactyourRoyalPrestige®
Distributor.
Thebaseweighs12.125lbs.
Pleaselifttheunitwithtwo
hands.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.
Donotrinsewithwaterthatis
warmerthan175degreesF.
• Violatingtheseinstructionsmaycause
injuriesordamagetotheproduct.

Xtractor | 7

ASSEMBLY INSTRUCTIONS
Placethestrainerintothe
spinningbrush
Placethestrainerandspinning
brushintothebowl.
• Makesurethereddotonthestrainer
andthereddotonthebowlare
aligned.
Pushthesqueezingscrewinto
thestrainer.
1
2
3
Strainer
Red dot on the
spinning brush
Red dot on
the bowl
Squeezing
screw
Spinning
brush
Bowl
Bowl
Strainer

8 | Xtractor
Assemblethehopperonto
thebowl.
• Makesurethearrowonthe
hopperandthereddotonthe
bowlarealigned.
Assembletheentiretopset
ontothebase.
• Asshownbelow,assemblethe
bowlontothebaseandtwist
thebowlsothatthehopper
edgeispointingto“close”sign.
4
5
Hopper
Bowl
Base
ASSEMBLY INSTRUCTIONS
The arrow
on the hopper
Red dot
on the bowl
Juice
ejection
OPEN
CLOSE

Xtractor | 9
Connectthepowercord.
Placecontainersunderboth
ejections.(Juiceandpulp
ejection)
Underneaththebowl,thereisayellowrubberplugwhichallowsallthejuicetoonly
dischargefromthefreshjuiceejection.
Therubberplugcanberemovedforcleaning.Simplygrabontoonesideoftherubber
plugandpullout.
6
Rubber plug
ASSEMBLY INSTRUCTIONS

10 | Xtractor
HOW TO USE THE XTRACTOR
Themachinehasthreesettings.
• “On”startsmotortostartmaking
juice.
• “Rev”isreverse.Onlyusewhen
ingredientsarestuckandyouneed
tounclog.
• “Off”isatcenterposition.This
allowsthemachinetoturnoff.
Rinseingredientsthoroughly
beforeputtingintothe
machine.
• Afterrinsing,putingredientsinto
themachineusingthepusher.
• Removeanyhardseedsbefore
using.
Turnoffthemachineafterusing.
Dryyourhandsbeforetouchingthepowerswitch.
1
2
3
Warning
Anyunusedjuiceshouldbe
refrigerated.
Donotoperatewithwethands.
Donotturnonuntilyouare
readytouse.
Donotoperatewithanempty
bowl.

Xtractor | 11
WARNINGS WHILE OPERATING
Donotuselongerthan
30minutesatatime.
Violatingthewarningmay
causeseriousdamagetothe
product.
Donotoperatewithwet
hands.
Violatingthewarningmay
causeseriousdamagetothe
productorelectrocution.
Donotuseanythingasa
pusher(fork,chopsticks,
spoons,etc.)otherthan
thepusheritself.
Violatingthewarningmay
causeseriousdamagetothe
product.
When machine is stuck and not operable, please...
Violatingthewarningmay
causeseriousdamagetothe
product,especiallythescrew.
Removeanyhardseeds.
Turnoffthemachineandputitinreverse
forfewsecondsthentryoperatingagain.
Whenreverseswitchdoesnotwork,turn
offthemachineandreassemblefollowing
theinstructionsgiven.Afterreassembly,
pleasetryturningonthemachine.
OFF
REV
ON

12 | Xtractor
HOW TO DISASSEMBLE AND CLEAN
Turnmachine“Off”
andunplugit.
1
Pleasedrytheattachments
aftercleaning.
6
Ordertodisassemble.
1.Hopper
2.Squeezing
screw
3.Strainer
4.Spinning
brush
5.Bowl
3
Usethebrushtoclean
thoroughlyafteroperating.
Donotusemetalspongestoclean,
itwilldamagethemachine.
Donotusedishwashertoclean.
4
Donotrinsethebasewith
directwater,usedrytowel
ordamptoweltoclean.
5
Twistthehoppertounlock
bygrabbingthetwo
ejections.Makesurethe
arrowisalignedwiththe
opensignbeforepullingoff
thebowl.
2

Xtractor | 13
BEFORE REQUESTING REPAIR SERVICE
Machinedoesnot
operate.
a.Checkifthepowercordhasbeenpluggedincorrectly.
b.Checkiftheassemblyhasbeendonecorrectly.
c.CallCustomerService.
Thejuicedoesnot
dischargesufciently
orthereisjuice
dischargingfromthe
pulpejector.
a.Checkiftherubberplughasbeeninstalledcorrectly.
b.Checkiftheingredientsarefresh.
Machineis
stopped.
a.Checkiftherearetoomanyingredientsinsertedatone
time.
b.Checkifthehardseedsareremoved.
 -Turnoffthemachineandtrythereversebuttonfor2-3
secondsthentryoperatingagain.
Machineis
“squeaking”when
makingjuice.
Thissoundisperfectlynormal.Itisthesoundofthejuice
beingextractedbythesqueezingscrew.
Themachineshakes. Thisshakingisperfectlynormal.Itisasignthatthemotor
isworkingproperly.

14 | Xtractor
PRODUCT SPECIFICATION
ProductName RoyalPrestige®Xtractor
ModelName HU-200
Voltage 120V
Frequency 60Hz
PowerConsumption 150w
RevolutionsPerMinute 80rpm
ElectricalCordLength 4.5ft
Motor Single-PhaseInduction
Weight 11.5lbs
Dimensions
Width 6.81in
Length 9.84in
Height 15.83in
StandardUsageTime Lessthan30minutescontinuously
FOR DETAILED WARRANTY INFORMATION,
PLEASE VISIT ROYAL PRESTIGE®ON THE WEB AT
www.royalprestige.com
Forwarrantyservice,returntheproducttoourServiceCenter:
HyCiteCorporation
RoyalPrestige®ServiceCenter
2115PinehurstDrive
Middleton,WI53562
1-800-279-3373
