RSA Lighting QCT-1675BK User manual

Type: Project:
RSA LIGHTING 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2004 RSA Lighting All Rights Reserved • Specifications subject to change without notice. QC1
HOT AIMING lamp
adjustment with a regular
phillips screwdriver
4” Adjustable Slot Aperture Trimless Fixture
w/ Hot Aiming Adjustability
New Construction Housing - 4.75” Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
13.25"
8.22"
4.63"
7.25"
MDL
For 277 volt transformer add “277” to end of item #.
Item # Description Finish Voltage / Wattage
QCT-1675WH / QCT-900
QCT-1675BK / QCT-900
QCT-1675S / QCT-900
QCT-1675SS / QCT-900
QCT-1675PM / QCT-900
Quiet Ceiling Series Adjustable Slot Aperture Trimless
Fixture with New Construction Housing w/ Magnetic
Transformer
White
Black
Silver
Stainless Steel
Primer
12V / 75W Max.
Hanger Bars extend from
14.00” to 25.25” max.
Mudding Ring adjusts in
plaster frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
Butterfly Brackets
for commercial
installations
4.00" Dia.
1.34"
1.75"
DESCRIPTION:
Recessed slot aperture trimless fixture.
360orotational adjustability and 45o(0o
vertical to 45otilt) angle adjust with angle
locking mechanism in trim. Exclusive
adjustable mud ring accommodates 1/2”,
5/8”, 3/4” & 1” ceilings.
ELECTRICAL:
120V input, 12V output. Junction box is
U.L. listed for through branch wiring.
Ball
Detent
Retainers
45º locking rack & pinion angle
adjustment mechanism
w/ Hot Aiming feature
Internal rotation
ring with locking
adjustment.
Provides 360º
rotation and
secures original
trim position after
relamping or
maintenance.
Angle Indicators
Lamp holder can accept
up to three (3) optical
accessories
Steel Safety
Cable
CONSTRUCTION:
Housing and plaster frame: 18 gauge CRS
Trim ring, j-box and hanger assemblies:
16 gauge CRS.
SYSTEM PROTECTION:
Thermal protection provided to guard
against overheating and misuse of insu-
lation over and around fixture. Vent holes
in housing provide cooler operation.
Magnetic
Transformer
Perforated flap for secure
drywall installation
Mud Ring adjusts in plaster
frame to accommodate
1/2”, 5/8”, 3/4” & 1” ceilings.
c QCT-1675WH c QCT-1675BK
c QCT-1675S c QCT-1675SS
c QCT-1675PM
w/ QCT-900 Housing
Ceiling mudding compound
is applied right to the edge
of the fixture.
Mudding Compound
REV 062904
