DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
Perforated
Meshplate
Thermal
Protector
7.45”
4.65”
12.01”
4.65”
16.14”
15.01”
10.96”
Integral Electronic
Metal Halide Ballast
45º x 45º
Adjust
Double
Gimbal
A ... Housing
Housing, junction box & trimless
meshplate assembly are all steel
construction. Perforated meshplate allows
for trimless installation in drywall/plaster
ceilings by allowing the ceiling’s mudding
compound to be applied right up to the
edge of the fixture opening. Includes
a beveled “knife-edge” lips to ensure a
clean edge. Can accommodate 0.50” to
1.25” ceiling thickness. Optional Chicago
Plenum configuration available.
B ... System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture. Vent
holes in housing provide cooler operation.
C... Junction Box
Junction Box is UL listed for through
branch wiring, 6 #12 90º C supply
conductors or 60º C for end of run. The
fixture is also UL listed as ‘access above
ceiling not required’.
D... Electrical
Electrical accessible through ceiling
opening. J-Box located on the side wall
of the housing behind removable access
doors. Integral electronic metal halide
ballasts on individually removable “trays”
for easy maintenance. May also be con-
figured for remote power.
E ... Lamps
One (1) CDM-TM Metal Halide lamp with
reflector mounted in adjustable double
gimbal. Lamp holder is individually remov-
able and may be regressed 1” for additional
cut-off. Lamp can accept up to three opti-
cal accessories (i.e. lens + hex louver +
snoot). 45º x 45º locking lamp adjustment.
Beveled-edge lamp ring is secured with
threadless, bayonet action. Optional
retractable arm is available for lamp pull-
down and extreme aiming. Includes GU6.5
TAL socket.
F ... Mounting
Butterfly Brackets accept 1/2” EMT,
C Channel, Tbar fasteners, and bar
hangers. Four tabs on housing for
securing to structure. Perforated flaps
along housing sides for securing trimless
insert to fixture and drywall.
G... Labels
cULus listed for non-type IC
applications, suitable for use in damp
locations.
Ceiling Cut-Out: 5.44” x 5.44”
COMBOLIGHT®
Next Generation
Recessed
Single-Lamp Fixture
One (1) Light
CDM-TM Metal Halide
New Construction
Housing
Trimless
ORDERING INFORMATION
An adjustable Single-lamp Recessed fixture for trimless installation suitable for
downlighting and accent applications. Utilizes ONE (1) CDM-TM Metal Halide
(Philips® Mini Master Color) lamp.
For new construction applications. Insulation must be kept 3” from all sides
and at least 1” above the housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
rev 022408
Configuration
C1 =COMBOLIGHT Recessed
One (1) Light
Housing
N =New Construction
C =Chicago Plenum
C1 E N
Lamp Type / Wattage Label / Reflector Type
020MMN =20 Watt CDM-TM Mini Master Color Narrow
020MMM =20 Watt CDM-TM Mini Master Color Medium
020MMW =20 Watt CDM-TM Mini Master Color Wide
039MMN =39 Watt CDM-TM Mini Master Color Narrow
039MMM =39 Watt CDM-TM Mini Master Color Medium
039MMW =39 Watt CDM-TM Mini Master Color Wide
Power Supply
E =Electronic Metal Halide
Ballast
Power Supply
Voltage
1 =120V
2 =277V
Lamp Mechanism
G =Double Gimbal
R =Retractable Double Gimbal
Trim Finish
W =White
B =Black
S =Industrial Silver
Trim Insert
N =Trimless
Housing Interior/Electrical Door
/Sleeve Finish
W =White
B =Black
S =Industrial Silver
CDM-TM Lamp with Reflectors
This fixture utilizes the Philips® Mini Master Color Lamp
and includes high-performance clear aluminum reflectors in
narrow, medium, or wide distributions. Non-standard color
reflectors are available upon request.
