RSA Lighting CMOB User manual

Type: Project:
RSA LIGHTING LLC 9660 - 9700 TOPANGA CANYON BLVD. CHATSWORTH CA. 91311
TOLL FREE: 800-356-3030 • 818-349-3030 • FAX: [phone] • www.rsalighting.com
©2002 RSA Lighting LLC All Rights Reserved • Specifications subject to change without notice. CM1
Recessed fixed trim suitable for
downlighting applications.
Ultra low profile trim flange for
minimum ceiling architecture
interference. Provides a sleek,
architectural look.
Trim has a durable powder coat
finish.
Inside of trim and lamp holder
finished with flat black powder
coat for reduced lamp glare.
Trim is retained in housing with
heavy duty torsion spring clip.
All ComboMini™ fixtures can
accept up to two (2) optical
accessories per lamp.
Housing Construction:
Plaster frame and housing are
18 gauge CRS with durable pow-
der coat finish.
Integral electronic transformer
with 14 gauge CRS galvanized J-
Box assembly. External thermal
protection. UL listed for through
branch wiring for 8 #12, 90ºC
supply conductors or 60ºC sup-
ply conductors for end of run.
7.125"
7.125"
4.75"
5.5"
1.625"
3.625"
15"
4.25"
4.5"
4.5"
2.5"
Aperture
2.5"
Aperture
Provided with two (2) 14 gauge steel
butterfly type brackets for black iron
installations.
Vent holes in housing (1/2” diameter)
provide cooler operation.
Housing adjusts in plaster frame to accom-
modate various ceiling thicknesses.
Item # Description Finish Voltage / Wattage
CM0W
CM0B
CM0S
Combo Mini Recessed Downlight
One Light Square
White
Black
Silver
12V / 75W Max.
Combo Mini Recessed Downlight
One (1) Light Square
New Construction Housing - 7.13” Height
12V Bi-Pin Base MR16 Lamp 75 Watts Max.
 CM0W  CM0B
 CM0S
