DESCRIPTION Catalog # Type
Project
Comments Date
Prepared by
SPECIFICATION FEATURES
www.cooperlighting.com
10.75” elc. 14.06” mag.
5.00”
J-box with integral
electronic
transformer
Magnetic transformer
configuration shown
below
Xfmr. J-box
3.81” sq.
4.30”
width elc.
only
Mag.
width
same as
housing
A...Housing
Constructed of 18 gauge CRS with white
powder coated finish.
B ...System Protection:
Thermal protection provided to guard
against overheating and misuse of
insulation over and around fixture.
Vent holes in housing provide cooler
operation.
C ...Electrical
Integral j-box and low voltage (12V)
transformer . 120V input, 12V output.
Junction box is U.L. listed for through
branch wiring. Includes four 1/2 trade
size knockouts.
D...Lamp
12V MR16 50 watts max. (not included)
“POSI-GRIP” bi-pin lamp socket for firm,
mechanical lamp connection.
E ...Mounting
Housing is secured with four snap-in
retaining brackets. Clip mounting slots in
the housing accommodate 1/2”, 1”, and
1-1/2” ceiling thickness.
Ceiling Cut-Out: 3.68” sq..
MINI
ACCURUS
ACM514RM
Remodel Housing
for Square Trim
FOR 12V MR16 50 watts max.
ORDERING INFORMATION
Housing
ACM514RM =
Mini Accurus
Remodel Housing
for Square Trim
w/Integral Transformer
Voltage
120 =120 volts primary (standard)
277 =277 volts primary (available)
Remodel housing for Mini Accurus small aperture square trimless fixtures.
(ACM5101, ACM5102, ACM5103, ACM5104).
For non-I.C. remodel applications. Fixture is installed after the ceiling.
Insulation must be kept 3” from all sides and at least 1” above the
housing.
Specifications and Dimensions subject to change without notice.
RSA Lighting • 7945 Orion Ave. • Van Nuys, CA 91406 • 818-349-3030 • FAX [phone]
Transformer
ELC =Electronic
MAG =Magnetic
ACM514RM
rev. 031407
