RTI RKM-1+ User manual

70-210122-15 V1.1
Reference Guide
It’s Under Control®
Copyright © 2018 • Remote Technologies Incorporated • All rights reserved.
For news about the latest updates, new product information, and new accessories, please visit our web site at:
www.rticorp.com
For general information, you can contact RTI at:
Remote Technologies Incorporated
5775 12th Ave. E Suite 180
Shakopee, MN 55379
Tel. [phone]
Fax [phone]
[email protected]
Contacting RTI
Safety Suggestions
Federal Communications Commission Notice
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. Any changes or modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may cause undesired operation.
Read and Follow Instructions. Read all safety and
operating instructions before operating the unit.
Retain Instructions. Keep the safety and operating
instructions for future reference.
Heed Warnings. Adhere to all warnings on the unit and in
the operating instructions.
Heat. Keep the unit away from heat sources such as
radiators, heat registers, stoves, etc., including ampliers
that produce heat.
Power Sources. Connect the unit only to a power supply
of the type described in the operating instructions, or as
marked on the unit.
Water and Moisture. Do not use the unit near water—for
example, near a sink, in a wet basement, near a swimming
pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or
liquids to be spilled into the enclosure through openings.
Servicing. Do not attempt any service beyond that
described in the operating instructions. Refer all other
service needs to qualied service personnel.
Damage Requiring Service. The unit should be serviced
by qualied service personnel when:
Objects have fallen or liquid has been spilled into the
unit.
The unit has been exposed to rain.
The unit does not appear to operate normally or
exhibits a marked change in performance.
The unit has been dropped or the enclosure has been
damaged.
N27917
Limited Warranty
RTI warrants its products for a period of three (3)
years (one year for included battery packs); or for a
period of time compliant with local laws when applicable
from the date of purchase from RTI or an authorized
RTI distributor.
This warranty may be enforced by the original
purchaser and subsequent owners during the warranty
period, so long as the original dated sales receipt or
other proof of warranty coverage is presented when
warranty service is required.
Except as specied below, this warranty covers all
defects in material and workmanship in this product.
The following are not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this
Guide.
3. Repair or attempted repair by anyone other than
Remote Technologies Incorporated.
4. Failure to perform recommended periodic
maintenance.
5. Causes other than product defects, including lack
of skill, competence or experience of user.
6. Shipment of this product (claims must be made to
the carrier).
7. Being altered or which the serial number has been
defaced, modied or removed.
DECLARATION OF CONFORMITY (DOC)
The Declaration of Conformity for this product can be found on the RTI website at: www.rticorp.com/declaration
RKM-1+
Multi-Room Audio Keypad
Programmable Function
Buttons
USB Port
Display Lens with
Backlit Selected
Source Film
Source Select Button
Wallplate
Threaded
Holes
Electrical Box
Mounting Holes
Control Port
RKM-1+ Front RKM-1+ Rear
Faceplate - Interchangeable
colors included: White, Light
Almond and Black

It’s Under Control®
The RKM-1+ audio keypad is designed for multi-room audio control, and provides the exibility
to control almost any multi-zone receiver or distributed audio system.
The RKM-1+ provides superior quality and these specic features:
• Provides feedback from multi-zone receivers via any RTI XP series control processor.
• Includes interchangeable white, black, and light almond wallplates and function buttons.
• Non-volatile Flash memory stores system conguration even when power is lost.
• IR output port drives up to 1000 feet of wire for standalone control.
• Field upgradable rmware.
• USB programming.
• Eight (8) fully programmable hard buttons.
• Interchangeable LED backlit lms.
• LED backlit lms provide feedback of power status, selected source, and volume level.
• Use any standard Decora®type wallplate.
Key Features
Installation & Operation
Mounting
The RKM-1+ is designed for ush-mount installations in walls or cabinets. It requires an available
mounting depth of 1.5 inches (38mm) including cables, from the front surface of the wall. RTI
recommends that the RKM-1+ be mounted in a single-gang electrical box or mud ring.
Power
The RKM-1+ is turned on simply by applying power to it either via a connecting block (e.g. the
RTI CB-8) or other power supply (9VDC - 16VDC, 350 mA), such as an RTI PS16-1.
Selected Source Film, Faceplate and Button Installation
The selected source lm is LED backlit and may be changed to more closely match the audio
sources that will be controlled. A sheet with ten lens lms is included with the RKM-1+, each
with different source congurations. Additionally, different colored wallplates and buttons ship
with your RKM-1+, allowing you to further tailor your RKM-1+.
To install the selected source display lm and/or change the faceplate and button color:
1) Remove the faceplate by pressing a small at-
head screwdriver into the release tab slots and
use your ngers to pry-up and carefully remove
the faceplate.
2) Place screwdriver in groove on backside of face-
plate and press down to pry display lens off
3) Choose appropriate selected source lm and
faceplate/button color.
4) Align lm inside the raised edge on the back-
side of the display lens (the letters will appear
reversed from backside so that they appear cor-
rectly when viewed from frontside).
5) Once aligned, press lm rmly in place.
6) Snap display lens back onto faceplate color of
your choice, paying attention to correct orienta-
tion.
7) If changing keypad buttons, gently slide each
button off rubber mold one at a time. Carefully
align new buttons and press down until rmly
seated.
8) Snap faceplate back onto RKM-1+ enclosure.
RKM-1+
Faceplate (backside)
Display Lens (backside)
LED Backlit Film
Groove
Release Tab Slots
(Decora®is a registered trademark of Leviton Manufacturing Co. Inc.)
If you are encountering any problems or have a question about your RTI product, please contact RTI Technical Support for
assistance (see the Contacting RTI section of this guide for contact details).
RTI provides technical support by telephone or e-mail. For the highest quality service, please have the following
information ready, or provide it in your e-mail.
• Your Name
• Company Name
• Telephone Number
• E-mail Address
• Product model and serial number (if applicable)
If you are having a problem with hardware, please note the equipment in your system, a description of the problem, and
any troubleshooting you have already tried.
If you are having a problem with software, please note what version you have installed, the operating system on your
PC, a description of the problem, and any troubleshooting you have already tried. If you are calling about a software or
programming question or problem, please be at you computer when you place your call. This will considerably speed up
the troubleshooting process.
Please do not return products to RTI without return authorization.
Connection Options
Service & Support
CONTROL PORT
RS-232 (1)
POWER / IR
SENSE
IR / SERIAL / SENSE
EXPANSION +12VDC, 1A
MULTI-PURPOSE I/O PORTS RS-232 (2)
ETHERNET
RS-232 (3)
TRIGGERS RELAYS
RTI COM
POWER
123123 1 2 3
GND INPUT
HIGH OUT
ABABAB
4
1 2 3 56
+12VDC
3-24VDC 12V,100mA MAX 3A@30VDC MAX
GND
GND
Pin 5 +16VDC
Pin 6 Infrared
Pin 4 +16VDC
Pin 3 Infrared
Pin 2 RS-485+
Pin 7 Ground
Pin 1 RS-485-
Pin 8 Ground
XP-6s Control Processor
CB-8
Connecting
Block
Power
Supply
Power
Supply
Tuner
Cleaning
Occasional cleaning may be required, depending on use. To clean your RKM-1+, lightly dampen a lint-free cloth with a
glass cleaner or mild detergent, and wipe the buttons, surrounding bezel, and wallplate.
RKM-1+
(rear)
Television
Shades
