RTS WKP-1 User manual

WKP-1
RTS innovating the future of communications
™
• Microphone - The WKP-1 keypanel has a built-in waterproof
Electret microphone. The microphone can be “hot mic” enabled or
disabled through the use of a dip switch setting.
• Key Panel Assignment - Key assignments, GPIO operation, and
panel listen/muting functions are set via AZ-Edit™Software for the
intercom matrix.
• Audio Control - Vandal and weather resistant front panel volume
controls adjusts listen level to the internal speaker. An internal limit
adjustment sets the lower level of minimum volume achievable.
• Audio Processing - An integral limiter/compressor insures
maximum intelligibility of the spoken word. The compressor uses
the RTS Standard compression design.
• Dual Power - The keypanel can be powered locally or remotely via
a CAT 5 connection from the matrix.
The WKP-1 keypanel is the industrial keypanel from
Telex. Telex has refined the look of multi-location security
with this keypanel. It offers simplified operation and
integrates seamlessly with RTS™digital intercom systems
(RTS™ADAM™/Zeus™intercom systems). The physical
size and weather-resistant design provides a flexible and
robust intercom system. The GPI relay switch lets the user
set up door latching, unlatching and other related actions
by pressing a single button from any panel in the system.
Features:
• Environmental - The unit sustains exposure to rain, snow, and
direct sun, allowing it to work in all environments. It operates in
temperatures ranging from -30° F to 120° F. The mechanical
design of the anodized, aluminum front panel and non-removable
volume control knob provide a vandal resistant panel.
• GPI Relay - The WKP-1 has a local GPI relay four-pin terminal
contact closure to give the user the functionality of latching,
unlatching doors or other related functions, with the press of
a button.
• Front Panel - Single button interface for push to talk operation.
There is a built-in waterproof speaker for listening capabilities. The
panel has three LEDs used to indicate power ON, microphone ON,
and Incoming Call Signaling.
INDUSTRIAL KEYPANEL
TM
Industrial Matrix
Intercom Keypanel
IM106071

WKP-1
INDUSTRIAL MATRIX INTERCOM KEYPANEL
©2003 Telex Communications, Inc.
RTS 38110-231 Litho 3/03 ZM
innovating the future of communications
™
All specifications are subject to change without notice.
Telex Communications, Inc.
12000 Portland Avenue South
Minneapolis, MN 55337
1-800-392-3497
fax: [phone]
www.rtssystems.com
TM
WARRANTY INFORMATION
Products are warranted by Telex Communications, Inc. to be free from defects in materials and
workmanship for a period of three years from the date of sale.
The sole obligation of Telex during the warranty period is to provide, without charge, parts and labor
necessary to remedy covered defects appearing in products returned prepaid to Telex. This warranty
does not cover any defect, malfunction or failure caused beyond the control of Telex, including
unreasonable or negligent operation, abuse, accident, failure to follow instructions in the manual,
defective or improper associated equipment, attempts at modification and repair not authorized by
Telex, and shipping damage.
To obtain warranty service, follow the procedures entitled “Procedure for Returns” and “Shipping to
Manufacturer for Repair or Adjustment.”
This warranty is the sole and exclusive express warranty given with respect to RTS products. It is
the responsibility of the user to determine before purchase that this product is suitable for the user’s
intended purpose.
ANY AND ALL IMPLIED WARRANTIES, INCLUDING THE IMPLIED WARRANTY OF
MERCHANTABILITY ARE LIMITED TO THE DURATION OF THIS EXPRESS LIMITED WARRANTY.
NEITHER TELEX NOR THE DEALER WHO SELLS TELEX PRODUCTS IS LIABLE FOR INCIDENTAL
OR CONSEQUENTIAL DAMAGES OF ANY KIND.
Distributed by:
Ordering Information
Model No. Description Order by Cat.
WKP-1 Industrial Keypanel 9000-7746-000
2
1
3
4
5
1GPI Relay Contact 4-pin Terminal
Local or Remote Power Switch
Local Power 3-Pin Terminal
RJ45/CAT-5 Connection
8-pin Terminal
RJ12 Connection
1
2
3
4
5
WKP-1 Industrial Matrix Intercom Keypanel Specifications
Matrix
Input/Output: 8 dBu nominal,16 dBu maximum
Panel Mic Input
Mic Type: Electret Condenser
Nominal Level: -44 dB ±3 dBu
Directivity: Omni Directional
Speaker
Output: 3 watts
Power Requirements
Power Requirements: 15 VDC 250 mA for local power
24 VDC up to 500 mA for remote power
“300 or more”
Connections
• RJ45 for use with Standard CAT-5 cabling
• RJ12 for use with RTS Matrix Standard 3-pair cabling
• Terminal Strip for use with unterminated cabling
6
6
4.562''
4.5''
minimum 3''
The keypanel fits a standard 2-gang,
minimum 3” deep electrical box*.
*Electrical box not included with keypanel
Terminal Strip RJ45 RJ12
RS485+ Audio_IN+ Data-
RS485- Audio_IN- Audio from Matrix+
NC GND Audio to Matrix+
Audio_OUT+ RS485+ Audio to Matrix-
Audio_OUT- RS485- Audio from Matrix-
NC Power Data+
Audio_IN+ Audio_OUT+ N/A
Audio_IN- Audio_OUT- N/A

Innovating the Future of Global Communications
Technical Data Sheet
The WKP-1 keypanel is the industrial keypanel
from RTS. RTS has rened the look of
multi-location security with this keypanel. It offers
simplied operation and integrates seamlessly with
RTS digital intercom systems. The physical size
and weather-resistant design provides a exible
and robust intercom system. The GPI relay switch
lets the user set up door latching, unlatching and
other related actions by pressing a single button
from any panel in the system. The WKP-1 ts a
standard US dual gang electrical box.
• Environmental, the unit sustains exposure to rain,
snow, and direct sun, allowing it to work in all
environments. It operates in temperatures ranging
from -30°F (-34°C) to 120°F (49°C). The mechanical
design of the anodized, aluminum front panel and
non-removable volume control knob provide a vandal
resistant panel.
• The WKP-1 has a local GPI relay 4-pin terminal
contact closure to give the user the functionality of
latching, unlatching doors or other related functions,
with the press of a button.
• Front Panel single button interface for push to talk
operation. There is a built-in waterproof speaker for
listening capabilities. The panel has three (3) LEDs
used to indicate power on, microphone on, and
incoming call signaling.
• The WKP-1 keypanel has a built-in waterproof Electret
microphone. The microphone can be hot mic enabled
or disabled through the use of a dip switch setting.
• Key assignments, GPIO operation, and panel
listen/muting functions are set via AZedit software for
the intercom matrix.
• Vandal and weather-resistant front panel volume
controls adjusts listen level to the internal speaker.
An internal limit adjustment sets the lower level of
minimum volume achievable.
• Audio processing, an integral limiter/compressor
insures maximum intelligibility of the spoken word.
The compressor uses the RTS standard compression
design.
• Dual power, the keypanel can be powered locally or
remotely via a CAT-5 connection from the matrix.
Features
WKP-1
Value Series Wall Keypanel
Line Drawing
MINMAX
VOLUME
MIC
PUSH
TO
TALK
POWER
MIC ON
CALL
WKP-1

Innovating the Future of Global Communications
www.rtsintercoms.com
Specications
Order Information
Matrix
Input/Output: 8dBu nominal, 16dBu (max.)
Panel Mic Input
Mic Type: Electret Condenser
Nominal Level: -44dB ±3dBu
Directivity: Omni Directional
Speaker
Output: 3 Watts
Power Requirements
15VDC 250mA for local power
24VDC up to 500mA for remote power at distances of 300ft–1000ft
Connections
RJ-45 for use with standard CAT-5 cabling
RJ-12 for use with RTS Matrix standard 3-pair cabling
Terminal strip for use with unterminated cabling
Weight
0.76lbs (0.35kg)
WKP-1 • WKP-1 • Single-channel industrial keypanel
WKP-1 BOP • WKP-1 BOP • 8-port Breakout and power distribution panel
The specication information is preliminary and is subject to change without notication.
Brand names mentioned are the property of their respective companies.
Bosch Security Systems, Inc. | 12000 Portland Avenue South | Burnsville, Minnesota 55337
Telephone: 877·863·4169 | Fax: [phone]
Form Number: F.01U.247.126 Rev 06
Date: August 2011
