RTW TMR7-Radio User manual

TMR7-Radio | TMR7-Mount
Software Version 8-03 and higher | 01.2020
Quick Start Guide
EN

EN-2 Manual | TouchMonitor TMR7-Radio | TMR7-Mount
Please note:
The external power supply is UL Listed for CAN/US, model
ATS 065T-P/A240, manufactured by Adapter Technology Co Ltd.
(RTW 1178-R), Class II double insulated, rated:
Input: 100 - 240 V, 47 - 63 Hz, 1 A max.
Output: 24 Vd.c., 2.71 A, 65 W
The figures in this operating manual are carefully created and are
used to illustrate the descriptions. However, they may differ a little bit
from the displays of your unit.
The current version of this manual and the available firmware/firmware
updates can be found under Audio Monitors/TouchMonitor TMR7 in
the download area of our web site:
https://www.rtw.com/en/support/manuals-software.html.
The package contains a USB flash device source by a third party com-
pany. The device is certified to be CE conform and RoHS compliant.
A detailed RoHS declaration of conformity about TouchMonitor
TMR7-Radio and TMR7-Mount can be found in the appendix.
Quick Start Guide
for
RTW TouchMonitor TMR7-Radio | TMR7-Mount
Manual Version: 1.0
Issued: 18.03.2020
Software Version: 8-03 and higher (01.2020)
© 03/2020 | Technical changes without prior notice!
RTW GmbH & Co. KG
Am Wassermann 25 | 50829 Köln | Germany
Fon +49 221. 70 913-0 | Fax +49 221. 70 913-32
rtw@rtw.com | www.rtw.com
WEEE Reg.-no.: DE 90666819
RoHS Conformity: These instruments comply with and fall under cate-
gory 9 Monitoring and control equipment of the regu-
lations of the Directive 2011/65/EU on the restric-
tion of the use of certain hazardous substances in
electrical and electronic equipment of the European
Parliament and Council from June 8th, 2011.
Please carefully read the safety instructions, understand
them and act as requested to prevent any hazards or not
to violate any laws.

EN-3Manual | TouchMonitor 7“/9“ Series common Safety Instructions
EN
Safety Instructions
The following symbols may be marked on the panels or covers of
equipment or module and are used in this manuals with these terms:
WARNING!
This symbol alerts you to a potentially hazardous condition, such as
the presence of dangerous voltage that could pose a risk of electrical
shock. Refer to the accompanying Warning Label or Tag, and exercise
extreme caution.
ATTENTION!
This symbol alerts you to important operating considerations or a po-
tential operating condition that could damage equipment. If you see
this marked on equipment, consult the operating manual for precauti-
onary instructions.
NOTE
This symbol points your attention to specific characteristics that are
no malfunctions.
Important Safety Instructions
• Read these instructions. Study carefully and understand all safety
and operating instructions before you install and operate the unit!
• Keep these instructions. Keep all safety and operating instructions
for future reference!
• Heed all warnings on the unit and in the safety and operating inst-
ructions before you install and operate the unit!
• Follow all instructions to ensure against injury to yourself and da-
mage to the unit or other objects connected to the unit.
To prevent possible electrical shock, death, fire, injuries and malfunc-
tions, use this product only as specified.
Only use attachments and accessories specified by the manufacturer.
The units of the TouchMonitor series are designed for indoor use only
and may only be operated with a power supply unit provided for it.

Safety InstructionsEN-4 Manual | TouchMonitor 7“/9“ Series common
WARNING!
Always follow the safety precautions below to avoid the possibility of serious injury or even death from electrical shock, short-circuiting, dama-
ges, fire, or other hazards. These precautions include, but are not limited to, the following:
• Do not apply a potential to any terminal that exceeds the maxi-
mum rating of that terminal.
• Avoid exposed circuitry. Do not touch exposed connections and
components when power is present.
• Turn off and disconnect the power supply immediately it the unit
produces unusual smells, noises or smoke, or if foreign substan-
ces (e. g. liquids) or foreign objects enter the unit.
• Because of the installed battery the unit shall not be exposed to
excessive heat such as sunshine, fire, or similar.
• Caution: Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type.
• Do not cover the unit and do not place any objects or anything
containing liquids on it.
• Do not insert your fingers or any other objects into the housing.
• Do not operate without cover plates or panels.
• Do not operate with suspected failures. If you suspect there is da-
mage to the unit, have it inspected by qualified service personnel.
• Do not use this apparatus near water.
• Do not operate in wet/damp conditions.
• Do not operate in explosive atmosphere.
• Do not operate in dusty environments.
• Do not open the housing. Inside, there are no user-serviceable
parts. Any necessary servicing shall be performed by a properly
qualified technician.
• Do not attempt to repair any part of the unit. Repairs shall only be
carried out by qualified personnel.
• Never remove any parts from the unit and do not make any modi-
fications to the unit without the express written consent of RTW.
Modifications can cause both safety hazards and affect the unit’s
conformity and certifications.
• Only use the power cord and power supply specified for this pro-
duct and certified for the country of use.
• Use with power supply model ATS 065T-P/A240, manufactured
by Adapter Technology Co Ltd. (RTW 1178-R).
• The power cord of the external power supply disconnects the pro-
duct from the power source. Do not block the power cord or power
supply; it must remain accessible to the user at any time.
• Connect and disconnect properly. Use only connectors specified
for this product and fix them tight before use.
• Observe all terminal ratings and markings on the product. Consult
the operating manual for further ratings information before making
connections to this product.

EN-5Manual | TouchMonitor 7“/9“ Series common Safety Instructions
EN
ATTENTION!
Always follow the safety precautions below to avoid the possibility of physical injury to you or others, or damage to the unit or other property.
These precautions include, but are not limited to, the following:
• Do not block any ventilation openings. Install in accordance with
the manufacturer‘s instructions to prevent the internal temperature
from becoming too high.
• Do not install near any heat sources such as radiators, heat registers,
stoves, or other apparatus (including amplifiers) that produce heat.
• Also keep away the unit from direct incident solar radiation.
• Keep product surfaces clean and dry. Clean only with dry cloth.
• Never use any solvent based liquids for cleaning the housing
surfaces and the display.
• Do not place the unit in an unstable position where it might
accidently fall over.
• Before connecting any devices to the unit make sure that the
power supply is disconnected.
• Protect the power cord from being walked on or pinched particu-
larly at plugs, convenience receptacles, and the point where they
exit from the apparatus.
• Unplug this apparatus during lightning storms or when unused for
long periods of time.
• Before moving the unit, remove all connected cables.
• When transporting or moving the unit, always take care not to
scratch or damage the housing surfaces and the display.
• Refer all servicing to qualified service personnel. Servicing is re-
quired when the apparatus has been damaged in any way, such as
power-supply cord or plug is damaged, liquid has been spilled or
objects have fallen into the apparatus, the apparatus has been ex-
posed to rain or moisture, does not operate normally, or has been
dropped.
Information on installed battery
The pcb features a battery socket with a 3 V Li/Mn coin cell battery, type CR 1225. It must be inserted from the side with its positive pole on
top and its negative pole towards the pcb surface.

Environmental ConsiderationsEN-6 Manual | TouchMonitor 7“/9“ Series common
Environmental Considerations
Observe the following information about the environmental impact
of the product and the following guidelines when recycling an instru-
ment or component (product end-of-life handling):
• Equipment Recycling
Production of this equipment required the extraction and use of
natural resources. The equipment may contain substances that
could be harmful to the environment or human health if improperly
handled at the product’s end of life. In order to avoid release of
such substances into the environment and to reduce the use of
natural resources, we encourage you to recycle this product in an
appropriate system that will ensure that most of the materials are
reused or recycled appropriately.
• Battery Recycling
This product contains a lithium manganese dioxide (Li/Mn) bat-
tery, which must be recycled or disposed of properly according to
your local government regulations.
• Restriction of Hazardous Substances
These instruments comply with and fall under category 9 Moni-
toring and control equipment of the regulations of the Directive
2011/65/EU on the restriction of the use of certain hazardous
substances in electrical and electronic equipment of the European
Parliament and Council from June 8th, 2011. This product may
contain lead, cadmium and/or mercury in slight quantities. Please
dispose of or recycle the electronic parts or devices according to
your local government regulations.

EN-7Manual | TouchMonitor TMR7-Radio | TMR7-Mount Index of Content
EN
Index of Content
Safety Instructions 3
Important Safety Instructions 3
Warning! 4
Attention! 5
Environmental Considerations 6
Index of Content 7
Before You Begin 8
Introduction 8
Scope of Delivery 10
Installation 11
Connection 12
Pin Assignment 13
Getting Started 15
System Start-up 15
Adapt the TouchMonitor to your Audio System 16
Create Your Own Preset 18
Working with Instruments and Presets 23
Delivered Presets 25
Software Update 32
Specifications (Extract) 34
EC Declaration of Conformity 39
RoHS Declaration of Conformity 40
Licenses of the Implemented Software 41

Before You Begin | IntroductionEN-8 Manual | TouchMonitor TMR7 Smart
Before You Begin
Introduction
Thank you for purchasing a TouchMonitor TMR7-Radio resp. TMR7-
Mount. Loudness, true peak, PPM, audio vectorscope, moving-coil
instruments, RTA, chart, and correlation: The TMR7-Radio and TMR7-
Mount 4-channel solution featuring 7“ touchscreen and the unique
TouchMonitor operating concept integrate all metering options requi-
red in radio broadcasting to a solution made to measure.

EN-9Manual | TouchMonitor TMR7 Smart Before You Begin | Introduction
EN
Simple and flexible
The graphical user interface used in the TouchMonitor range is con-
trolled simply by using your finger or a mouse. Instruments can be
scaled, randomly positioned and combined in almost every way for
optimized use of available screen space. Even multiple instruments of
the same type, assigned to different input channels and configurations,
can be displayed simultaneously. A context-sensitive, on-screen help
feature and the intuitive operatable menu system supports the user,
allowing him to make setup changes with ease.
Audio I/O interface
TMR7-Radio‘s resp. TMR7-Mount‘s hardware and software are per-
fectly adjusted to radio-broadcast requirements and easily integrates
into any studio environments. The four audio inputs provided by the two
AES3 XLR ports are flexibly configurable for mono, stereo, or multi-
channel sources, providing separate instruments for each source. So
TMR7 allows parallel monitoring of the on-air signal and a PFL source.
Integrated Software
With the integrated software package, TMR7-Radio and TMR7-
Mount are fully equipped and ready for use. The comprehensive set
of frequently used instruments provides all relevant loudness and
audio metering tools to meet the demands.
Many display functions are available to choose from: loudness meters
compliant to all relevant loudness standards including Loudness Sum,
numerical displays, Loudness Range, and Loudness Chart, Audio
Vectorscope, Real-Time Analyzer (RTA), Stereo Correlator, and Moving
Coil instruments.

Before You Begin | Scope of DeliveryEN-10 Manual | TouchMonitor TMR7-Radio | TMR7-Mount
Scope of Delivery
Unpack the instrument and check, if you received all items listed. If components are missing, please contact your dealer. The instruments in-
cluded in the software package are also listed.
TouchMonitor TMR7-Radio | TMR7-Mount
Table-top unit TMR7S
PPM/TP
2 x AES3 In
2 x AES3 Out
>
with Audio Interface: with Software:
> >
Moving Coil
Vectorscope
Chart
AES Status
Global Keyboard
Correlator
LRA
Clock
RTA
Loudness Sum
Loudness Num
Hardware Status
Panel-mount TMR7-Mount > >
Quick start guide
Quick start guide
Mains adapter
USB flash drive (Presets, Man.)
USB flash drive (Presets, Man.)

EN-11Manual | TouchMonitor TMR7-Radio | TMR7-Mount Installation
EN
Installation
The TouchMonitor TMR7-Radio table-top unit is designed for free
positioning on tables, desks, et. al. The panel-mount version TMR7-
Mount is designed for panel-mounting e. g. into mixing consoles. All
necessary power supply voltages are supplied through the +24 V DC
- 1 A connector. Use with power supply model ATS 065T-P/A240,
manufactured by Adapter Technology Co Ltd. (which is the external
power supply unit RTW 1178-R wide voltage power supply, included
in TMR7-Radio package, optional for TMR7-Mount). The units fea-
ture a 7“ VGA 16 : 9 touch screen.
Optional an external computer mouse or a Wacom® graphics tablet
can be connected to one of the USB interfaces.
The other ports and interfaces are connected with the appropriate
standard connection cables.
ATTENTION – Please read before installing:
• Before installing the unit please study the safety instructions and
the information on connection and pin assignment.
• An external overcurrent protective device (2 A max.) shall be
installed when using an external 24 V DC power supply!
• Make sure that the delivered power supply unit is not connected.
• Place or mount the unit at a suited place.
• Connect your signal sources and all your other components to the
appropriate connectors, using the correct standard connection
cables for the components. Take care about the pin assignment!
• Finally, connect the locking 4-pin low voltage connector of the ex-
ternal power supply to the +24 V DC - 1 A connector on the rear.
Connect the external power supply to mains.
• The TouchMonitor will initiate its system startup sequence. After
the boot-up the unit is ready for use.

Installation | ConnectionEN-12 Manual | TouchMonitor TMR7-Radio | TMR7-Mount
Connection
TouchMonitor TMR7-Radio | TMR7-Mount
GP IO
(RJ-12)
AES3 In 1
(XLR-F)
LAN
(RJ-45)
USB A 2.0
(Full Speed)
4-pin locking low voltage connector
External:
USB mouse
Wacom® graphics tablet
24 V DC - 1 A
1
AES3 Out 1
(XLR-M)
1
AES3 In 2
(XLR-F)
2
AES3 Out 2
(XLR-M)
2
VGA is
not used

EN-13Manual | TouchMonitor TMR7-Radio | TMR7-Mount Installation | Pin Assignment
EN
24 V - 1 A (4-pin locking low voltage connector, Typ Binder 710)
Pin: Function:
1 - 2 +24 V DC
3 - 4 0 V
NOTE - An external overcurrent protective device (2 A max.)
shall be installed when using an external 24 V DC power supply!
AES3 Out 1, AES3 Out 2 (transformer-bal., 3-pin XLR-M)
Pin: Function:
1 Shield/chassis
2 +, hot
3 –, cold
AES3 In 1, AES3 In 2 (transformer-bal., 3-pin XLR-F)
Pin: Function:
1 Shield/chassis
2 +, hot
3 –, cold
NOTE - The AES3 inputs are permanently terminated with 110 .
Pin Assignment
Pin 1 Pin 2
Pin 3
(External view of the connector)
Pin 2 Pin 1
Pin 3
(External view of the connector)
Pin 2
Pin 1
Pin 3
Pin 4
(External view of the mounted connector)

Installation | Pin AssignmentEN-14 Manual | TouchMonitor TMR7-Radio | TMR7-Mount
Pin Assignment (continued)
(External view of
the connector)
LAN
RJ-45 standard network connector (10/100 MBit)
GP IO (RJ-12 6P6C socket)
External control of functions defined in the Global Keyboard menu.
The inputs defined as „active low“ have to be switched against 0 V
(Pin 1).
Pin: Function:
1 GND (0 V)
2 - 6 Function acc. to definition in the menu
Block diagram of the GPIO interface
USB-A
2 Full Speed USB 2.0 interfaces for the connection of USB flash dri-
ves (presets, updates) and an external mouse or Wacom® tablet.

DE-15Manual | TouchMonitor 7“/9“ Serien allgemein Schnellstart | Inbetriebnahme
DE
Schnellstart
Inbetriebnahme
Bitte vergewissern Sie sich vor dem Anschließen der Stromversor-
gung, dass die folgenden Anschlüsse passend zu Ihrem Gerät (TM7,
TMR7, TM9 oder entsprechende Modelle) und zu Ihrer individuellen
Installation vorgenommen wurden:
• Analoge und/oder digitale Audio-Eingangssignale (je nach Typ
und Ausstattung Ihres Gerätes)
• Digitale Ausgänge (falls vorhanden)
• Optionaler externer VGA-Bildschirm (16 : 9) (nicht TMR7 Smart)
• Optionale USB-Maus
• LAN/Ethernet-Netzwerkanschluss (falls benötigt)
• Netzspannung
Nach dem Anlegen der Stromversorgung startet der TouchMonitor
direkt sein Betriebssystem. Nach kurzer Zeit erscheint die Haupt-
Bildschirmseite, das Gerät ist betriebsbereit.
Wir nehmen an, dass Sie Ihren TouchMonitor zum ersten Mal starten.
An dieser Stelle sollten Sie einige globale Einstellungen zur Anpas-
sung Ihres Gerätes an Ihr Audio-System vornehmen. Nach dieser
kurzen Prozedur können Sie Ihr erstes Preset für Ihre Arbeit erstellen.
HINWEIS - Die Abbildungen in den folgenden Abschnitten
können Optionen zeigen, die auf Ihrem Gerät nicht verfügbar sind.
Der Options-Umfang ist abhängig vom Typ Ihres Gerätes (TM7,
TMR7, TM9 oder entsprechende Modelle), von dessen Hardware-
Konfiguration und von den auf dem Gerät freigeschalteten Lizenzen
bzw. der auf dem Gerät installierten Software.

Schnellstart | Anpassung des TouchMonitors an Ihr Audio-SystemDE-16 Manual | TouchMonitor 7“/9“ Serien allgemein
4.
5.
Anpassung des TouchMonitors an Ihr Audio-System
Die folgende Beschreibung führt Sie durch die wichtigsten Schritte der globalen Einstellungen, um einmalig den TouchMonitor für Ihr Audio-
System zu konfigurieren. Diese Einstellungen bleiben beim Laden neuer Presets unverändert.
1. Falls nicht sichtbar, berühren Sie eine freie Stelle des Bildschirms
zur Anzeige der Steuerleiste.
1.
2.
3.
2. Berühren Sie die Taste Menü im rechten Bereich der Steuerleiste.
Sie gelangen ins Menü-System, das Hauptmenü wird angezeigt.
4. Berühren Sie, falls erforderlich, die Taste Menüsprache. Wählen
Sie in der rechten Hälfte des Menüs Ihre Sprache, die Auswahl
wird auf der Taste Menüsprache angezeigt.
Die Umstellung auf die neue Sprache erfolgt nach Neustart.
4.
3. Berühren Sie die Taste System. Sie gelangen ins System-Menü,
von dem das Untermenü General aktiviert ist (Taste ist in der
Steuerleiste markiert).
5. Berühren Sie die Taste Audio im linken Bereich der Steuerleiste,
um ins Untermenü Audio zu gelangen.

DE-17Manual | TouchMonitor 7“/9“ Serien allgemein Schnellstart | Anpassung des TouchMonitors an Ihr Audio-System
DE
6. Falls Ihr TouchMonitor eine definierte Referenzquelle benötigt,
berühren Sie die Taste Sync-Referenz und wählen Sie die ge-
wünschte Option in der rechten Hälfte des Menüs.
Die Anzahl der verfügbaren Sync-Referenz-Quellen ist abhän-
gig vom Geräte-Typ und von Umfang und Art der installierten
Audio-Schnittstellen.
7. Berühren Sie die Taste Uhr, falls Sie das aktuelle Datum und die
aktuelle Uhrzeit einstellen möchten. Berühren Sie die Taste Zeit
übernehmen zum Starten der internen Uhr.
6.
8. Berühren Sie dieTaste Speichern, um Ihre globalen Einstellung
zu sichern. Das Gerät kehrt zurück in den normalen Anzeige-
Modus.
7.
8.

Schnellstart | Erstellen eigener PresetsDE-18 Manual | TouchMonitor 7“/9“ Serien allgemein
Erstellen eigener Presets
Presets enthalten die Einstellungen für Ihren Work-Flow. Sie können Audio-Gruppen erstellen, die auf bestimmte Eingänge zugreifen und ei-
nes oder mehrere Instrumente mit dieser Zuordnung enthalten. Ebenso können Sie Non-Audio-Gruppen erzeugen, die von Audio-Eingangssi-
gnalen unabhängige Instrumente enthalten, z. B. Uhren, Hardware-Statusinformationen oder ein Globales Tastenfeld.
Gehen Sie wie folgt vor, wenn Sie ein neues Preset erstellen möchten:
4. Berühren Sie die Taste Neu. Ein Preset mit einem editierbaren
vorgegebenen Namen wird erstellt (siehe Abbildung unter 5., be-
rühren Sie die Taste Preset-Name zur Änderung).
3.
4.
1. Falls nicht sichtbar, berühren Sie eine freie Stelle des Bildschirms
zur Anzeige der Steuerleiste.
2. Berühren Sie die Taste Menü im rechten Bereich der Steuerleiste.
Sie gelangen ins Menü-System, das Hauptmenü wird angezeigt.
3. Berühren Sie die Taste Presets verwalten. Sie gelangen ins
Menü Interne Presets.

DE-19Manual | TouchMonitor 7“/9“ Serien allgemein Schnellstart | Erstellen eigener Presets
DE
7. Die Taste Modus erscheint und ist markiert. Wählen Sie Ihren
Kanalmodus in der rechten Hälfte des Menüs.
Die Anzahl der Modi ist abhängig vom Geräte-Typ und von
den aktivierten Software-Lizenzen.
5. Berühren Sie die Taste Audio neu zur Erstellung der ersten
Audio-Gruppe.
5.
6. Die Taste Domäne ist markiert. Wählen Sie die Domäne der ein-
gesetzten Signalquelle in der rechten Hälfte des Menüs.
6.
8. Falls die Lizenz Loudness and SPL display (SW20002) akti-
viert oder das Gerät ein TMR7 Smart ist, erscheint das Unterme-
nü Loudness-Typ. Wählen Sie Ihren bevorzugten Loudness-Typ.
7.
8.

Schnellstart | Erstellen eigener PresetsDE-20 Manual | TouchMonitor 7“/9“ Serien allgemein
9. Links erscheint das Feld Instrumente und rechts eine Liste der
verfügbaren Instrumente.
Die Anzahl der Instrumente ist abhängig von den aktivierten
Software-Lizenzen.
11. Wenn Sie mit der Auswahl fertig sind, berühren Sie die Taste
fertig. Sie kehren ins Menü Preset zurück.
9.
10. Berühren Sie jeweils die Tasten der gewünschten Instrumente.
Die Auswahl erscheint als Piktogramm im Feld Instrumente.
10.
11.
Das Menü Preset zeigt nun die gerade erstellte Audio-Grup-
pe mit einem kleinen farbigen Dreieck in der linken oberen
Ecke. Im Normalbetrieb sind alle Instrumente dieser Gruppe
mit diesem Dreieck markiert. Bei mehreren Gruppen erleich-
tert die Farbmarkierung die Identifizierung, zu welcher Gruppe
ein Instrument gehört.
12. Berühren Sie die Taste View. Das angezeigte Untermenü dient
der Anordnung der Instrumente auf dem Bildschirm. Die definier-
ten Gruppen mit ihren Instrumenten erscheinen in der linken
Hälfte des Menüs (nächstes Bild).
12.
This manual suits for next models
1
Table of contents
Other RTW Recording Equipment manuals
