RTX RTX8930 User manual

Version 0.1 Page | 1
Headset Operations Manual
RTX8930

Version 0.1 Page | 2
Contents
Headset Operations Manual.......................................................................................................................1
Contents......................................................................................................................................................2
1 About This Document .........................................................................................................................3
1.1 Audience .......................................................................................................................................... 3
1.2 Abbreviations................................................................................................................................... 3
1.3 References/Related Documentations.............................................................................................. 3
1.4 Document History............................................................................................................................ 3
2 Basic Operation...................................................................................................................................4
2.1 How to Switch the Headset On/Off ................................................................................................. 4
2.1.1 Switching on the headset ......................................................................................................... 4
2.1.2 Switching off the headset ......................................................................................................... 4
2.2 Registration...................................................................................................................................... 4
2.2.1 Initial Registration..................................................................................................................... 4
2.2.2 Subsequent Registrations ......................................................................................................... 4
3 Calls Operations..................................................................................................................................5
3.1 Incoming Call.................................................................................................................................... 5
3.1.1 Answering an Incoming Call...................................................................................................... 5
3.1.2 Reject an Incoming Call............................................................................................................. 5
3.1.3 Ending a Call.............................................................................................................................. 5
3.2 Volume and Muting ......................................................................................................................... 5
3.2.1 Adjusting Call Volume............................................................................................................... 5
3.2.2 Muting the Microphone ........................................................................................................... 5

Version 0.1 Page | 3
1 About This Document
This document describes the features and functionalities available in the RTX SME VoIP DECT 8930
Headset. We describe how to operate the headset without going into details about its mechanical
features. The reference for features and operation in this manual is RTX generic mode.
1.1 Audience
This guide is intended for everyday users as well as system administrators.
1.2 Abbreviations
For the purpose of this document, the following abbreviations hold:
DECT: Digital Enhanced Cordless Telecommunications
IPEI: International Portable Equipment Identity
MAC: Media Access Control
PBX: Private Branch Exchange
1.3 References/Related Documentations
[1]: How_To_Deploy_SME_Network_V1.3
[2]: SME VoIP System Guide, Version 2.5
1.4 Document History
Revision
Author
Issue Date
Comments
0.1
TMS
26-Jul-2016
Initial version.

Version 0.1 Page | 4
2 Basic Operation
This section describes how to switch on and off the RTX 8930 headset and how to register the unit on
an RTX 8660 SME VoIP system.
2.1 How to Switch the Headset On/Off
2.1.1 Switching on the headset
To switch the headset on, press the AUX key. When the headset is on, the blue LED will blink fast for a
short while until a signal is detected. When the headset locks onto a base, a voice prompt will
announce Headset subscribedand the blue LED pattern will change to a blink with a 2 second
interval.
2.1.2 Switching off the headset
To switch the headset off, long-press the AUX key together with the VOL+ and VOL- keys (press and
hold the three keys for five seconds). The blue LED will give a short blink before switching off.
2.2 Registration
2.2.1 Initial Registration
The first time the RTX 8930 headset is to be registered on a base system, the unit should simply be
switched on and it will enter registration mode automatically. Registration mode can be identified by
observing that the blue LED is blinking fast.
2.2.2 Subsequent Registrations
If the RTX 8930 headset has already been registered on the same or another base system and needs to
be re-registered, the required action is to press and hold the HOOK OFF key together with the VOL+
and VOL- keys until the blue LED starts blinking fast.
NOTE: The blue LED will not start blinking in registration mode if the unit is cradled and charging.
Please check the additional document via [2] for more information about terminal registration on a
base system.

Version 0.1 Page | 5
3 Calls Operations
3.1 Incoming Call
As the headset receives an incoming call, a ringtone will be played back.
3.1.1 Answering an Incoming Call
To answer an incoming call, press the HOOK OFF key.
3.1.2 Reject an Incoming Call
It is not currently possible to reject an incoming call.
3.1.3 Ending a Call
To end an ongoing call, press the HOOK OFF key.
3.2 Volume and Muting
3.2.1 Adjusting Call Volume
It is possible to adjust the earpiece volume up or down during calls by pressing the VOL+ and VOL-
keys, respectively.
There are six volume steps. A beep is played back to indicate that the volume is adjusted. A higher
frequency beep is played back when the volume cannot be adjusted further up or down.
3.2.2 Muting the Microphone
It is possible to mute the microphone during calls be pressing the MUTE key. The microphone is
unmuted by pressing the MUTE key again.
A voice prompt announcing Mute onis played back when mute is activated. A voice prompt
announcing Mute offis played back when mute is deactivated.


InterferenceInformation
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevice
mustacceptanyinterferencereceived,includinginterferencethatmaycauseundesired
operation.
ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigital
device,pursuanttoPart15oftheFCCRules.Theselimitsaredesignedtoprovide
reasonableprotectionagainstharmfulinterferenceinaresidentialinstallation.This
equipmentgenerates,usesandcanradiateradiofrequencyenergyand,ifnotinstalled
andusedinaccordancewiththeinstructions,maycauseharmfulinterferencetoradio
communications.However,thereisnoguaranteethatinterferencewillnotoccurina
particularinstallation.Ifthisequipmentdoescauseharmfulinterferencetoradioor
televisionreception,whichcanbedeterminedbyturningtheequipmentoffandon,the
userisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowing
measures:
 Reorientorrelocatethereceivingantenna.

Increasetheseparationbetweentheequipmentandreceiver.
 Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthe
receiverisconnected.
 Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
ModificationsnotexpresslyapprovedbyRTX couldvoidthe user'sauthorityto operate
theequipment.
Privacyofcommunicationsmaynotbeensuredwhenusingthisequipment.
ExposuretoRadioFrequency(RF)Signals
RegulatoryInformationUnitedStates
This wireless headset is a radio transmitter and receiver. It
is designed and manufactured not to exceed the emission limits
for exposure to radio frequency (RF) energy set by the FCC of the U.S.
Government. These limits are part of comprehensive guidelines
general population. The guidelines are based on the safety standards
previously set by both U.S. and international standards bodies.
These standards include a substantial safety margin designed to assure the safety of all persons,
regardless of age and health. This device and its antenna must not be co-located
other antenna or transmitter.
and establish permitted levels of RF energy for the
or operating in conjunction with any


InterferenceInformation
ThisproductmeetstheapplicableIndustryCanadatechnicalspecifications.
Leprésentmatérielestconformeauxspecificationstechniquesapplicablesd’Industrie
Canada.

ThisdevicecomplieswithIndustryCanadalicence‐exemptRSSstandard(s).Operationis
subjecttothefollowingtwoconditions:
(1)thisdevicemaynotcauseinterference,and
(2)thisdevicemustacceptanyinterference,includinginterferencethatmaycause
undesiredoperationofthedevice.LeprésentappareilestconformeauxCNRd’Industrie
Canadaapplicablesauxappareilsradioexemptsdelicence.L’exploitationestautorisée
auxdeuxconditionssuivantes:
(1)l’appareilnedoitpasproduiredebrouillage,et
(2)l’utilisateurdel’appareildoitacceptertoutbrouillageradioélectriquesubi,mêmesile
brouillageestsusceptibled’en
compromettrelefonctionnement.

ThisClassBdigitalapparatuscomplieswithCanadianICES‐003.
CetappareilnumériquedelaclasseBestconformeàlanormeNMB‐003duCanada.

UnderIndustryCanadaregulations,thisradiotransmittermayonlyoperateusingan
antennaofatypeandmaximum(orlesser)gainapprovedforthetransmitterbyIndustry
Canada.Toreducepotentialradiointerferencetootherusers,theantennatypeandits
gainshouldbesochosenthattheequivalentisotropicallyradiatedpower(e.i.r.p.)isnot
morethanthatnecessaryforsuccessfulcommunication.
RegulatoryInformationCanada
Conformémentàlaréglementationd’IndustrieCanada,leprésentémetteurradiopeut
fonctionneravecuneantenned’untypeetd’ungainmaximal(ouinférieur)approuvé
pourl’émetteurparIndustrieCanada.Danslebutderéduirelesrisquesdebrouillage
radioélectriqueàl’intentiondesautresutilisateurs,ilfautchoisirletyped’antenneet
songaindesortequelapuissanceisotroperayonnéeéquivalente(p.i.r.e.)nedépasse
pasl’intensiténécessaireàl’établissementd’unecommunicationsatisfaisante.

ThedeviceiscompliancewithRFfieldstrengthlimits,userscanobtainCanadian
informationonRFexposureandcompliance.
Leprésentappareilestconformeauxlimitesd’intensitédechampRF,lesutilisateurs
peuventsurl’expositionauxradiofréquencesetlaconformitéandcomplianced’acquérir
lesinformationscorrespondantes.
ExposuretoRadioFrequency(RF)Signals
The device is compliance with RF exposure guidelines, users can obtain Canadian
compliance. Le présent appareil est conforme .Après examen de
champ RF,les utilisateurs peuvent sur l’exposition aux radio
informations correspondantes.
fréquences et la conformité and compliance d’acquérir.les
ce matériel aux conformité ou aux limites d’intensité de
information on RF exposure and
