Rubinet 4UHO2 User manual

4UHO2
FEATURES:
- Brass construction with choice of 21 nishes
- Requires tempered water supply
- Fixed Shower Head & Adjustable Hand Held Shower
- Quarter turn diverter mechanism
- 2.5 gpm @ 60 psi
CONTACT US:
If you need assistance with installation, replacement parts or have any questions regarding your Rubinet product,
please call a Customer Service representative at: 905-851-6781 toll free 1-800-461-5901 or visit www.rubinet.com
30” Slide Bar with Fixed Shower Head,
Adjustable Hand Held Shower & Diverter
1
ASSEMBLY INSTRUCTION 4UHO2
REMOVAL OF FAUCET:
Always turn the water supply off before removing the existing faucet or disassembling a valve. Open both faucet handles to relieve water pressure
and to ensure that the water has been successfully turned off.
CARE OF FAUCET:
The use of warm water and a soft cloth is all that is required to clean Rubinet products. The patina of our living nishes (Oil Rubbed Bronze &
Tuscan Brass) will change as a result of normal use. Applying Mineral Oil on occasion will create a softer look, subtle color changes and character.
120200
799
31 1/2"
74
2 15/16"
98
3 7/8"
60" Double Spriral
Flex Hose
397
15 5/8"
200
7 7/8"
170
6 11/16"
Cut Slide Bar
this end to suit
height requirements
1 11/16"
2 5/16"
1/2"NPT

6
2 7
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
9XSCRAC03
Screw
9Y0HOAB3C
Slide Bar Tube
9YSHWRN5A
Shower Head
9YHHSAB4A
Slide Bracket
9XSHWSA1C
1/2˝ Nipple
9Y000AB1B
Slip Fit Adapter
9Y000AB1E
Escutcheon
9YHHSSF9A
Hand Shower
9YFLH001A
Flex Hose
Lower Housing
Assembly
9Y000AB2C
Upper Housing
9YSHWSA3B
Shower Arm
9Y000AB1E
Escutcheon
9XSCRPG01
Plastic Insert
9XACCWM02
Mounting Plate

1
1
2
2
5 1
2
6 3
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
* Tighten all set screws before installing Shower Head
*MUST CUT FLUSH
TO THE SLIP FIT ADAPTER

3 4
4 5
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
* Do not tighten set screws for Slide Bar adjustment later.

3 4
4 5
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
* Do not tighten set screws for Slide Bar adjustment later.

1
1
2
2
5 1
2
6 3
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
* Tighten all set screws before installing Shower Head
*MUST CUT FLUSH
TO THE SLIP FIT ADAPTER

6
2 7
30” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO230” Slide Bar with Fixed Shower Head, Adjustable Hand Held Shower & Diverter 4UHO2
9XSCRAC03
Screw
9Y0HOAB3C
Slide Bar Tube
9YSHWRN5A
Shower Head
9YHHSAB4A
Slide Bracket
9XSHWSA1C
1/2˝ Nipple
9Y000AB1B
Slip Fit Adapter
9Y000AB1E
Escutcheon
9YHHSSF9A
Hand Shower
9YFLH001A
Flex Hose
Lower Housing
Assembly
9Y000AB2C
Upper Housing
9YSHWSA3B
Shower Arm
9Y000AB1E
Escutcheon
9XSCRPG01
Plastic Insert
9XACCWM02
Mounting Plate

4UHO2
FEATURES:
- Brass construction with choice of 21 nishes
- Requires tempered water supply
- Fixed Shower Head & Adjustable Hand Held Shower
- Quarter turn diverter mechanism
- 2.5 gpm @ 60 psi
CONTACT US:
If you need assistance with installation, replacement parts or have any questions regarding your Rubinet product,
please call a Customer Service representative at: 905-851-6781 toll free 1-800-461-5901 or visit www.rubinet.com
30” Slide Bar with Fixed Shower Head,
Adjustable Hand Held Shower & Diverter
1
ASSEMBLY INSTRUCTION 4UHO2
REMOVAL OF FAUCET:
Always turn the water supply off before removing the existing faucet or disassembling a valve. Open both faucet handles to relieve water pressure
and to ensure that the water has been successfully turned off.
CARE OF FAUCET:
The use of warm water and a soft cloth is all that is required to clean Rubinet products. The patina of our living nishes (Oil Rubbed Bronze &
Tuscan Brass) will change as a result of normal use. Applying Mineral Oil on occasion will create a softer look, subtle color changes and character.
120200
799
31 1/2"
74
2 15/16"
98
3 7/8"
60" Double Spriral
Flex Hose
397
15 5/8"
200
7 7/8"
170
6 11/16"
Cut Slide Bar
this end to suit
height requirements
1 11/16"
2 5/16"
1/2"NPT
