Rugged CCTV PLATINUM 622 User manual

Contents
1Notes .........................................................- 1 -
2Product Introduction .................................- 2 -
2.1 Production Instruction................................... - 2 -
2.2 Product Feature................................................ - 2 -
3Product Structure ......................................- 3 -
4Technical Parameters ................................- 9 -
5OSD Menu tree .......................................... - 10 -
6Product Installation ...................................- 12 -
6.1 Note ...................................................................... - 12 -
6.2 Installation Tools and Information ........... - 12 -
6.3 Installation Method......................................... - 12 -
6.4 Connection ......................................................... - 14 -
Appendix: FAQ .................................................- 15 -

1080P XVI Camera Series XV2100(V0.02)

1Notes
Read this manual carefully before use.
1)To reduce the risk of electric shock, do not open the machine and
maintain by yourself, please consult a professional service person.
2)To prevent fire or shock hazard, use the power after safety
certification, the input voltage, current, voltage polarity and
operating temperature must meet the requirements of this camera.
3)Please note the operating temperature and environmental
requirements of the camera, avoid too low or too high temperature.
General operating temperature range of -10ć+50ć(Fahrenheit
temperature is 14122). Avoid flooding and rain, minimize dust
and moisture erosion, otherwise camera would be damaged.
4)Cameras in use should avoid direct sunlight, glare, otherwise the
sensor will be damaged.
5)Do not touch the sensor surface, if any foreign objects exits, a
cotton swab or lens paper can be used to wipe, if it is difficult to
remove, a neutral detergent diluted with water would be useful. Do
not use corrosive solution.
7)In order to make the camera work smoothly and obtain a
satisfactory image, the power cord and video connection can not be
too long, otherwise the increase of line loss will lead to the
inadequate magnitude of the operating voltage of the camera or
video signal Inadequate.
8)In order to prevent the camera from falling, please do not place
the camera on an unstable bracket, base or other unstable objects.
Otherwise it will lead to injury, at the same time, the camera will be
damaged.
9)The camera cannot be placed near the radiator or heating resistor.

1080P XVI Camera Series XV2100(V0.02)

2Product Introduction
2.1 Production Instruction
This series of cameras are adopted CMOS image sensor with
high performance, which provides mega pixel resolution and
supports HD video. Moreover, it supports monitoring signals coaxial
transmission. Transmission distance can reach more than 300M
based on 75-3 coaxial cable. The series can support both TVI/CVBS
960H output as well as realize high speed, long distance and real
time video transmission.
2.2 Product Feature
1.1/2.9“ 2.0M SONY Exmor CMOS
2. Full HD Resolution:
1080p 30f ps / 720p 60f ps
3. WDR(Wide Dynamic Range)
4. ACE(Advanced Contrast Enhancement)
5. DNR(Digital Noise Reduction. 2D+3D)
6. Def og Function
7.Day&Night
8. Privacy Mask Function
9. Motion Detection
10. Auto White Balance
11.Smart IR Function
12. Low Power Consumption:80mA
13. Support Coaxial Control Signal
14.Microphone Embeded(Optional)


1080P XVI Camera Series XV2100(V0.02)

3Product Structure
The followings are the dimensions of some products. No further
notice for the upgraded version.
Photo 3-3 Indoor Mini Camera
Photo 3-2 Indoor IR Dome Camera
43mm
48.7mm
43mm 20mm

1080P XVI Camera Series XV2100(V0.02)


Photo 3-4 Indoor BOX Camera
Photo 3-5 Outdoor IR Dome Camera
93.2 mm
81.7 mm
105.9 mm
Photo 3-6 Outdoor IR Dome Camera
205mm
83.8mm
65.6mm

1080P XVI Camera Series XV2100(V0.02)

Photo 3-7 Outdoor Vari-focal Dome Camera
119mm
129.5 mm
104mm

Photo 3-8 Outdoor Vari-focal Dome Camera
Photo 3-9 Outdoor Vari-focal Dome Camera

Photo 3-12 Outdoor IR Bullet Camera
1080P XVI Camera Series XV2100(V0.02)


Photo 3-10 Outdoor IR Bullet Camera
Photo 3-11 Outdoor IR Bullet Camera
173.6 mm
69.9 mm
68.2 mm
154mm
68.5mm
68.7mm

1080P XVI Camera Series XV2100(V0.02)

Photo 3-14 Outdoor IR Bullet Camera
283.7 mm(Adjustable)
75.5 mm
76.8 mm
Ø85.6 mm
Photo 3-13 Outdoor IR Bullet Camera
Photo 3-15 Outdoor IR Bullet Camera
217mm
72mm
66.7mm

1080P XVI Camera Series XV2100(V0.02)

Photo 3-16 Outdoor Vari-focal Bullet Camera

Photo 3-17 Outdoor Vari-focal Bullet Camera
Photo 3-18 Outdoor Vari-focal Bullet Camera
327mm
111.8mm
95.3mm

1080P XVI Camera Series XV2100(V0.02)

4Technical Parameters

I
M
A
G
E
Resolution HD-Analog: 1920h1080p(1080p/30fps)
1280h720p(720p/60fps)
Analog:960H
Image Sensor 1/2.9” 2.0M SONY IMX323LQJ-C Exmor
CMOS
Total Pixels 1945(H)h1109(V)
Effective Pixels 1945(H) h1097 (V)
Scanning System Progressive
Video Output
S/N Ratio 50dB(AGC OFF)
Min.Illumination COLOR˖0. 1Lux@(F2.0ˈAGC ON)
B&W˖0.001Lux@(F2.0ˈAGC ON)
F
U
N
C
T
I
O
N
Day & Night EXTERN,COLOR, B&W,AUTO
White Balance AUTO
DNR 2D+3D NR
ACE OFF/LOW/MIDDLE/HIGH
Defog OFF/ON
IRIS AUTO,MANUAL
PRIVACY MASK ONǃOFF(16Zones)
MOTION DET ONǃOFF(4Zones)
S
P
E
C
Working
Temperature
Humidity
-10ć~60ćూHumidity 90% or less
(non-condensing)
Storage Temperature -20ć~+60ć
Power Supply DC12Vf10%(AC 24V Optional)
Power
Consumption
1.20W MAX
Press and hold for 5 seconds the "menu" button to switch
output format among AHD CVI and TVI
Press the button once to activate the OSD, which can also
be done by the DVR, if the DVR supports such function

1080P XVI Camera Series XV2100(V0.02)

5OSD Menu tree

Ͷͽʹ
Ͳͽʹ
ͳ΃ͺ͸͹΅ͿͶ΄΄
΄͹Ά΅΅Ͷ΃
΄ͶͿ΄Ά΁
Ͳ͸ʹ
KELVIN
R-GAIN
B-GAIN
;΀͵Ͷ
ͽͶ·Ͷͽ
͹΁΀΄
·΁΀΄
͹΄ͺ΋ Ͷ
·΄ͺ΋Ͷ
Έ͵΃ ΈͶͺ͸͹΅
͵Ϳ΃
;΀͵Ͷ
͵Ͷͽ ͲΊ
͵ͿͽͶ·Ͷͽ
Ϳ͵ͽͶ·Ͷͽ
ͺ΃ͽͶ͵
SMART-IR LVL
΁΀ͽͲ΃ͺ΅Ί
΄͹Ͳ΃΁ͿͶ΄΄
ʹ΀ͽ΀΃͸ͲͺͿ
ͷ΃ͶͶ΋Ͷ
ͷͽͺ΁
ACE
GAMMA
ί
ί
ί
ί
΀ͷͷ
ί
΀ͷͷ௚͹ͺͿ·௚·ͺͿ·௚͹·ͺͿ·
΀ͷͷ௚΀Ϳ
0~20
0~20
͹ͺ͸͹௚ͽ ΀Έ
0~20
ͲΆ΅΀௚; ͲͿΆͲͽ௚ͷͽͺʹͼͶ΃
΀ͷͷ௚Ή ௚Ή ௚Ή ௚Ή ௚Ή 
0~20
ͲΆ΅΀
ͲΆ΅΀ΖΩΥ
ͺ;Ͳ͸Ͷ
0~20
0~20
0~20
ͲΆ΅΀௚ʹ΀ͽ΀΃௚ͳΈ௚ͶΉ΅Ͷ΃Ϳ
ί
Ͳͽͽ͵ͲΊ௚NIGHT ONLY
;ΒΚΟ; ΖΟΦ
΄ΖΔΠΟΕΒΣΪΞΖΟΦ
NORMAL௚DEBLUR
ͺͿ͵΀΀΃௚΀Ά΅͵΀΀΃௚͵Ͷ ͳͽ Ά΃
0~20
΀ͷͷ௚ͽ΀Έ௚; ͺ͵͵ͽͶ௚͹ͺ͸͹
0.45௚0.5௚0.55௚0.6௚0.65
΀ͷͷ௚΀Ϳ
ͽͶͿ΄
ͶΉ΁΀΄Ά΃Ͷ
Έ͹ͺ΅ͶͳͲͽ ;ͲͿΆͲͽ
PRESET
ͽ΀Έ௚;ͺ͵͵ͽͶ௚͹ͺ͸͹
ͳͲʹͼͽͺ͸͹΅
͹ͽʹ
ͳͽʹ
΀ͷͷ௚ͽ ΀Έ௚; ͺ͵͵ͽ Ͷ௚͹ͺ͸͹
ͽ΀Έ௚;ͺ͵͵ͽͶ௚͹ͺ͸͹
ί
͵ͲΊͿͺ͸͹΅

1080P XVI Camera Series XV2100(V0.02)


;΀͵Ͷ
LEVEL
΀Ά΅΁Ά΅; ΀͵Ͷ
ʹ΀ͽ΀΃΄΁ͲʹͶ
ͷ΃Ͳ; Ͷ΃Ͳ΅Ͷ
ʹ·ͳ΄
USER OFFSET 0~20
·Ͷ΃΄ͺ΀Ϳ
COMM ADJ ʹͲ;ͺ͵
LANGUAGE
ZOOM DIS
΋΀ͿͶͿΆ;
΋΀ͿͶ͵ͺ΄΁
͹΁΀΄
·΁΀΄
͹΄ͺ΋ Ͷ
·΄ͺ΋Ͷ
ΊͽͶ·Ͷͽ
ʹ΃ͽͶ·Ͷͽ
ʹͳͽͶ·Ͷͽ
΄ͶͿ΄ͺ΅ͺ·ͺ΅Ί
ΈͺͿ͵΀Έ΅΀ͿͶ
ΈͺͿ͵΀ΈΆ΄Ͷ
ΈͺͿ͵΀Έ΋΀ͿͶ
͵Ͷ΅͹΁΀΄
͵Ͷ ΅ · ΁ ΀΄
͵Ͷ ΅ ͹΄ ͺ΋ Ͷ
͵Ͷ ΅ · ΄ ͺ΋ Ͷ
ͲͽͲ΃;
΀Ϳ ΈͶͺ͸͹΅ 0%~100%
ADJUST COLORBAR
LENS ADJ LENS ADJ
΃Ͷ΄Ͷ΅΀Ϳ
ͶΉͺ΅
΀Ϳ
;΀΅ͺ΀Ϳ
΀ͷͷ௚΀Ϳ
0~40
0~60
0~40
OFFǃON
ͺ;Ͳ͸Ͷ
΀ͷͷ௚΀Ϳ
΄͹Ͳ͵ͺͿ͸
SPECIAL
΀ͷͷ௚΀Ϳ
0~3
΀ͷͷ
0~40
0~20
0~20
0~20
΀ͷͷ
0~20
0~6
0~255
ENG௚CHN
΁΃ͺ·ͲʹΊ
΀ͷͷ
΀Ϳ
0~15
΀ͷͷ௚΀Ϳ
0~60
0~40
0~40
΄Ί΄΅Ͷ;
1080P௚720P
HD-CbCr௚YU V௚SD-CbCr
25/30௚50/60
PAL௚NTSC
ͳͽͲʹͼͽͶ·Ͷͽ
FULL
COMP
V0.0.2
͵Ͷͷ΀͸
΀ͷͷ
΀Ϳ ͲΆ΅΀௚; ͲͿΆͲͽ
ͽ΀Έ௚;ͺ͵͵ͽͶ௚͹ͺ͸͹
0~60

1080P XVI Camera Series XV2100(V0.02)

6Product Installation
6.1 Note
1) Make sure the unit is powered off before installation.
2) Check power supply voltage consistent with the electric
voltage to prevent voltage unworthy, resulting in damage to
the device.
3) Do not use in the environment beyond the boundaries of the
temperature, and maintain good ventilation to prevent the rain
in order to reduce the risk of fire or electric shock.
4) The installation and maintenance of this product should be
professional, please do not in any way to remove or modify the
equipment; can only use the required accessories of
manufacturers. Problems caused by unauthorized repair are at
your own risk.
6.2 Installation Tools and Information
Prepare the required engineering data and instructions. Before
installation please prepare the following tools and
instrumentation: A straight or a Phillips-head screwdriver,
multi-meter, scissors, needle nose pliers, tape measure, pencil
and so on.
6.3 Installation Method
1. Check the equipment whether it is damaged.
2. Mounting bracket or base.
ķIf the cement wall, install the expansion screws (expansion
screw holes need stand or base hole), and then mount

1080P XVI Camera Series XV2100(V0.02)

bracket or base.
ĸIf the wooden wall, use self-tapping screws to mount.
3. Mounting the camera
a. Dome Camera
Adjust the lens position and make it aim at the monitoring
points and present a clear picture, manually fix lens location
and adjust the hemisphere cover. Re-examine the screen
whether the character meets the requirement. Tighten the
hemisphere cover.
b. Box Camera
Adjust the body so that the lens aims at the monitoring points
and presents a clear picture. Tighten the screws, to ensure that
it does not move.
Installation method above is for reference only, the specific
installation, please be kind.
Note:
The wall needs to bear at least 3X weight of bracket (base)
and camera.

1080P XVI Camera Series XV2100(V0.02)

6.4 Connection
Connection as show in the figure below








1080P XVI Camera Series XV2100(V0.02)

Appendix: FAQ
Q: No picture with power on
A: It may result from abnormal power supply. Please check if the
power supply voltage and its polarity are correct. Besides, please
confirm if wires connection and monitors are normal.
Q: Unclear image output
A: It is caused by incomplete adjustment of the lens back focus.
Loose the fixed screw of the lens until it turns clear. If not, please
check if the lens is in good condition, or the lens surface and
sensor surface exits foreign objects. If exits, it can be wiped by
degreasing cotton swab or lens paper.
Q: Horizontal interference fringes on image
A: This phenomenon is generally caused by too strong hum bar of
power supply, which needs to be filtered out. It may also be
related to the used monitor or peripheral devices.
Q: Constantly change of the ground color of image
A: This phenomenon is caused by color scrolling, which is mainly
due to alternating electromagnetic field of fluorescent lamp, and
the inherent phenomenon of camera. It can be weakened with
two methods: one is to reduce the usage of fluorescent lamp. The
other is to enlarge the distance with the camera. To overcome it
thoroughly, please select LL synchronization camera.
