Rugged CCTV stainless steel dome camera User manual

Features
䯲1/3" 520K/610K Sony Exview HAD CCD II
Minimum Resolution 0.1 Lux (F1.2, 50 IRE).
S/N Ratio 52dB.
䯲High Resolution 680 TV Lines
This camera has realized high resolution of 680 TV lines using the top-notch full digital image
processing, 12 Bit A/D serial signal processing and special algorithm technologies.
䯲DNR (Digital Noise Reduction)
The DNR technology eliminates noise thus generating a distinct and clear image.
䯲DAY&NIGHT (Output the Filter changing signal)
This camera has the DayNight function which outputs the filter changing signal with detecting the
illumination condition.
Day&Night operation feature an ‘auto’ mode which switches between day and night mode
automatically based upon the level of illumination on the scene.
点EXT mode changes between day and night operation upon triggering from an external source.
And also, the COLOR mode operates in daytime conditions to provide optimum colors, and B/W mode
operates in night-time conditions to enhance the definition of the image.
点marks represent the factory default function. (EXT2)
䯲OSD (On Screen Display)
This camera supports the OSD function which is used with multi language. And so, the camera
can be controlled bye selecting text displayed on the monitor screen.
䯲SMART IR
This camera function is to recognize things under low illumination by controlling IR intensity of
radiation and AE in accordance with changes of camera surrounding.
1

General Specifications & Functions
Specifications
Items Sub-items NTSC PAL
CCD
Device SONY 1/3" CCD SONY 1/3" CCD
Total 1020(H) X 596(V) 1020(H) X 596(V)
Effective 976(H) X 494(V) 976(H) X 582(V)
Sync
Inter. H/V 15,734/59.94Hz 15,625/50Hz
LL H/V 15,750/60Hz 15,625/50Hz
Performance
Horizontal / Verical Resolution 680 TV Lines
Minimum illumination (F1.2) Color : 0.1 Lux(50IRE) / 0.02 Lux(15IRE)
B/W : 0.08Lux(50IRE) / 0.002 Lux(15IRE)
S/N Ratio 52dB
Functions
OSD English/ Japaness / German / French / Russian
Portuguess / Spanish / Chinese
Day & Night Sofware
ATW 1800~10500K
High Speed Shutter 1/60(1/50) ~ 1/10Ksec
ATR(adaptive tone reproduction) Off/ON(Luminance(L,M,H),Contrast(L,ML,M,MH,H))
AGC Level Setting
AUTO iris DC Auto Iris
MANUAL iris Off/On (Level Setting)
Camera ID Off/On (Letters A to Z, Numerals 0 to 9, Symbols)
White Balance ATW/PUSH/USER1/USER2/ANTI CR/MANUAL/PUSH LOCK
DNR Off/2D(Y 0-15)
Gamma(r) 0.45
Color Gain Control Level Setting
Motion Detection 4 Area (On/Off, Position, Sensitivity)
Privacy Mask 8 Area (On/Off, Color, Position)
Etc. Function Sharpness, Reverse (H)
In/Output
Power Input DC+12V±10%
Video Output VBS 1.0V p-p (75ohm Terminated)
Alarm Output Open Collector / Normal: Open Active:0V (Ground)
Power Consumption 400mA
Operating Temperature Absolute : -10ȋC ~ +50ȋC
Operating Humidity Less than 90%
Dimension 126(L)X116(H)X126(W)mm
3

OSD Menu tree
Main Menu Sub
-
Menu Descriptions
LENS
AUTO DC Auto Iris, speed level
MANUAL Manual Iris
SHUTTER/AGC
AUTO Auto Iris, Shut + Auto iris, Brightness, AGC on/off, AGC brightness
MANUAL Shut + AGC , shutter(1/50,1/60 ~1/10k), AGC
WHITE BAL
ATW Speed, Delay time, Frame size, Environment (in/outdoor)
PUSH All pull-in
USER1 Outdoor fixed gain
USER2 Fluorescent light fixed gain
ANTI CR Color rolling suppressing
MANUAL R gain, B gain setting
PUSH LOCK Hold
BACK LIGHT
OFF Off
BLC Back light compensation
HLC High light compensation
PICT ADJUST Image mirror, Adjust brightness, Adjust contrast, Adjust sharpness,
Adjust HUE, Adjust GAIN
ATR ON Luminance (L,M,H), Contrast (L,ML,M,MH,H)
OFF OFF
MOTION DET
OFF OFF
ON Detect sense, block display, monitor area, area sel.
PRIVACY
ON Area sel(1-8), color(1-8), transparency(0-1),Mosaic on/off
OFF OFF
DAY/NIGHT
AUTO Burst off/on, delay time, day to night, night to day
COLOR Color Mode
B/W Black & White Mode , Burst off/on, IR Optimizer on/off
EXT1 External Input 1
EXT2 External Input 1
DNR DNR Mode(Y), Level(0 - 15)
CAMERA ID
OFF Camera ID OFF
ON Camera ID ON
SYNC
INT Line Lock OFF
LL Line Lock ON (phase 0 - 524(624)
LANGUAGE Select Language
CAMERA RESET Set Camera Default
SAVE ALL All the settings of the internal OSD MENU are saved
4

OSD Menu Functions
䯲Main Menu
●LENS
The function is used to set the mechanical iris of the lens.
●SHUTTER/AGC
This function is used to set AE or ME.
●WHITE BAL
This function is used to set the white balance operation made.
●BACKLIGHT
This function is used to set the back-light compensation operation.
●PICT ADJUST
The function is used to set the image adjustment items (mirror, brightness, contrast, sharpness, hue, gain)
●AT R
The function is used to set the ATR (adaptive tone reproduction) operation.
Unlike the wide dynamic range (WD) function for two exposed images-one with a long-time exposure
and one with a short-time exposure-the ATR function provides gradation compensation for one image
shot over one exposure time.
The WD function makes it possible to obtain the optimum image by setting and controlling the AE reference
level independently for two images, one with a long-time exposure and one with a short-time exposure.
No effect in improving the visibility of the images using the ATR function will be achieved in cases where,
as a result of overexposure or other forms of saturation, the contrast information of the images has been
lost at the point when the signals are input to the ATR processing block.
For this reason, the AE reference level must be set depending on whether importance is to be placed on
visibility in the low-luminance areas or in the high-luminance areas.
5
SETUP MENU
LENS AUTO↵
SHUTTER/AGC AUTO↵
WHITE BAL ATW↵
BACKLIGHT OFF
PICT ADJUST ↵
ATR OFF
MOTION DET OFF
NEXT↵
EXIT↵SAVE ALL

NEXT Page
●MOTINON DET
The function is used to set the motion detection operation.
●PRIVACY
The function is used to set up to eight privacy masks.
●DAY/NIGHT
The function is used to set the Day/Night function.
●NR
The function is used to set the noise reduction.
●CAMERA ID
The function is used to set the camera ID.
●SYNC
The function is used to display the current synchronization mode.
●LANGUAGE
The function is used to select the language in which to display the internal OSD men.
●CAMERA RESET
The function initializes all the internal OSD menu settings together.
●SAVE ALL
The function is used to save the various settings of the internal OSD menu in the EEPROM together.
KEY FUNCTIONS:
6
SETUP MENU
PRIVACY OFF
DAY/NIGHT AUTO↵
NR ATW↵
CAMERA ID OFF
SYNC INT
LANGUAGE ENGLISH
CAMERA RESET
BACK↵
EXIT↵SAVE ALL
▲: Up
▼: Down
 : Left
 : Right
○:Enter(Setup)

●LENS “" "ඖ” This function can adjust the intensity of radiation incoming to the camera.
Use the IIGIඔIGIඖIGI○IGswitch to select a menu item.
FUNCTION OPTION DESCRIPTION
LENS
AUTO
MANUAL
SHUTFIX + M IRIS , SHUT + M IRIS
SHUT
■AUTO IRIS (AE) ↵
FUNCTION OPTION DESCRIPTION
TYPE DC "" ""
VIDEO ""
DC servo
VIDEO servo (Not Used)
MODE AUTO "" ""
CLOSE ""
OPEN ""
The mechanical iris is controller automatically
The mechanical iris is fixed to close
The mechanical iris is fixed to open
SPEED 0~255 "" "" Sets the convergence speed of the mechanical iris.
■MANUAL(ME)
7
AUTO IRIS
TYPE DC
MODE AUTO
SPEED IIIIIȗIIIIII 080
RETURN↵
SETUP MENU
LENS MANUAL↵
SHUTTER/AGC AUTO↵
WHITE BAL ATW↵
BACKLIGHT OFF
PICT ADJUST ↵
ATR OFF
MOTION DET OFF
NEXT↵
EXIT↵SAVE ALL

●SHUTTER/AGC “" "ඖ”
FUNCTION OPTION DESCRIPTION
SHUTTER/AGC AUTO
MANUAL
Sets AE
Sets ME
■AUTO SETUP ↵
FUNCTION OPTION DESCRIPTION
HIGH
LUMINANCE
MODE
AUTO IRIS "" ""
SHUT+ AUTO IRIS ""
SHUTFIX + MIRIS
SHUT + MIRIS
Specifies AE control on the medium and high
brightness side
BRIGHTNESS 0~255 "" "" Specifies the high and medium brightness side
reference
LOW
LUMINANC
MODE OFF "" "”
AGC ""
Specifies AE control on the low-brightness
side
BRIGHTNESS
X0.25 "" "”
X0.50 "”
X0.75 "”
X1.00 "”
Specifies the low brightness side reference
■MANUAL SETUP The ME settings are selected on this screen.
FUNCTION OPTION DESCRIPTION
MODE SHUT + AGC "SHUT + AGC" is the only option available for
the ME operation mode.
There are no other options
SHUTTER 1/60(1/50),1/100(1/120),1/2
50,1/500,1/1K,1/2K,1/4K,1/10K
Sets the ME shutter speed
AGC 6.00,12.00,18.00,24.00,30.
00,36.00,42.00,44.80
Sets the AGC value [dB] for ME
8
MANUAL SETUP
MODE SHUT+AGC
SHUTTER 1/60
AGC 6.00
RETURN↵
AUTO SETUP
HIGH LUMINANCE
MODE AUTO IRIS
BRIGHTNESS IIIIIȗIIIIII 024
LOW LUMINANCE
MODE AGC
BRIGHTNESS X0.50
RETURN↵

●WHITE BAL “" "ඖ”
White balance can be set to ATW, PUSH, USER1, USER2, ANTI CR, MANUAL or PUSH LOCK.
ATW (Auto Tracking White balance) and PUSH (Full pull-in) are continuously monitoring/analyzing the color temperature of the
incoming light and correcting the white balance.
ATW limits the color temperature range at about 2,500˚K~8,500˚K to reduce the excessive compensation for the big object which
has a single color. PUSH has no limits between about 1,800˚K~10,500˚K but it may over-compensate the white balance for
the big object which has a single color. In cases where it goes under 2,500˚K such as halogen light, ATW may stop. If so,
PUSH mode is recommended. USER1 and USER2 are a fixed white balance which is user-programmable by R-GAIN and B-
GAIN and useful only for the steady light. ANTI CR (Anti Color Rolling) can reduce color rolling under the fluorescent light
when the camera operates in shutter control without an auto iris lens. (NTSC version only)
FUNCTION OPTION DESCRIPTION
WHITE BAL
ATW Auto trace white balance
PUSH All pull-in
USER1 Outdoor fixed gain
USER2 Fluorescent light fixed gain
ANTI CR Color rolling suppression. (NTSC version only)
MANUAL Manual white balance
PUSH LOCK Hold
■AT W
FUNCTION OPTION DESCRIPTION
SPEED 0~ 255 "" "" Adjusts the pull-in speed ATW
DELAY CNT 0~ 255 "" "" Sets the time-based hysteresis of ATW
ATW FRAME
X0.50
X1.00
X1.50
X2.00
"" "”
""
""
""
Sets the pull-in frame magnification
ENVIRONMENT Indoor
Outdoor
"" "”
"”
Sets the pull-in frame(indoor/outdoor)of ATW
ATW
SPEED IIIIIIIIIIȗŊŊI 245
DELAY CNT IȗIIIIIIIIIIII 003
ATW FRAME X2.00
ENVIRONMENT INDOOR
RETURN↵

■USER1 WB
FUNCTION OPTION DESCRIPTION
B-GAIN 000 - 255 Used for operating the B gain in the WB fixed gain mode
R-GAIN 000 - 255 Used for operating the R gain in the WB fixed gain mode
■USER2 WB
FUNCTION OPTION DESCRIPTION
B-GAIN 000 - 255 Used for operating the B gain in the WB fixed gain mode
R-GAIN 000 - 255 Used for operating the R gain in the WB fixed gain mode
●MANUAL
FUNCTION OPTION DESCRIPTION
LEVEL 000 - 255 Sets the B and R gain values for manual WB
910
USER1
B-GAIN IIIIIIIIIIȗIII 045
R-GAIN IȗIIIIIIIIIIII 026
RETURN↵
USER2
B-GAIN IIIIIIIIIIȗIll 045
R-GAIN IȗIIIIIIIIIIII 026
RETURN↵
MANUAL WB
LEVEL IIIIIIIIIIȗIll 045
RETURN↵

●BACKLIGHT
FUNCTION OPTION DESCRIPTION
BACKLIGHT OFF IඔIGIඖIG
BLC IඖIG
HLC IඖIG
Backlight compensation OFF
Backlight compensation ON
High light compensation ON
●PICT ADJUST “○”
FUNCTION OPTION DESCRIPTION
MIRROR OFF "" ""
ON ""
Sets the horizontal flip for display output
BRIGHTNESS 0~255 "" "" Sets the screen brightness
CONTRAST 0~255 "" "" Sets the screen contrast
SHARPNESS 0~255 "" "" Sets the screen sharpness
HUE 0~255 "" "" Adjusts the hue
GAIN 0~255 "" "" Adjusts the gain
●ATR(Adaptive tone reproduction)
OFF/ ON “" "ඖ” “○”
FUNCTION OPTION DESCRIPTION
LUMINANCE
LOW
MID
HIGH
""
"" ""
""
Sets the extent of the luminance compression
CONTRAST
LOW
MIDLOW
MID"
MIDHIGH"
HIGH
""
""
“" ""
“"
""
Sets the extent of the contrast enhancement
11
PICT ADJUST
MIRROR OFF
BRIGHTNESS ġȗIIIIIIIIIIIII ıııġ
CONTRAST IIIIIIIIȗIIIII 128
SHARPNESS IIIIIIIIȗIIIII 128
HUE IIIIIIIIȗIIIII 128
GAIN IIIIIIIIȗIIIII 128
RETURN↵
ATR
LUMINANCE MID
CONTRAST MID
RETURN↵

●MOTION DET
FUNCTION OPTION DESCRIPTION
DETECT SENSE 000-127 Sets the motion detection sensitivity.
BLOCK DISP
OFF
ON
ENABLE
"" ""
""
""“○”
Controls the ON/OFF status of the motion
detection block display.
MONITOR AREA OFF"
ON
“" ""
""
Sets whether to use the monitoring frames.
OFF: The monitoring frames are not used.
ON: The monitoring frames are used.
AREA SEL 1/4
2/4
3/4
4/4
"" ""
""
""
""
Monitoring frame 0.
Monitoring frame 1.
Monitoring frame 2.
Monitoring frame 3.
TOP 000-244
"" "" Sets the top side of the monitoring frame
selected by the AREA SEL parameter.
BOTTOM 000-244
"" "" Sets the bottom side of the monitoring frame
selected by the AREA SEL parameter.
LEFT 000-474
"" "" Sets the left side of the monitoring frame
selected by the AREA SEL parameter.
RIGHT 000-474
"" "" Sets the right side of the monitoring frame
selected by the AREA SEL parameter.
■BLOCK DISP
FUNCTION OPTION DESCRIPTION
BLOCK DISP ENABLE “○” The display switches to the "dead band setting" screen,
when the Enter operation input is performed from the
ENABLE selected status.
●PRIVACY “○”
12
MOTION DET
DETECT SENSE IIIIIIIIIIIȗII IJIJIJ
BLOCK DISP OFF
MONITOR AREA OFF
AREA SEL 1/4
TOP IIȗIIIIIIIIIII 022
BOTTOM IIIIIIIIIIȗIII 108
LEFT IIȗIIIIIIIIIII 042
RIGHT IIIIIIIIIIȗIII 211
RETURN↵
PRIVACY
AREA SEL 1/8
TOP IΠIIIIIIIIIII 022
BOTTOM IIIIIIIIIIΠII 108
LEFT IIȗIIIIIIIIII 042
RIGHT IIIIIIIIIIȗII 211
COLOR 1
TRANSP 1.00
MOSAIC OFF
RETURN↵

FUNCTION OPTION DESCRIPTION
AREA SEL 1/8,2/8,3/8,4/8,5/8,6/8,7/8,8/8 Selects the mask frame to be adjusted.
TOP 000-244(NTSC)
000-288(PAL)
Sets the top side of the mask frame selected by the AREA SEL
parameter.
BOTTOM 000-244(NTSC)
000-288(PAL)
Sets the bottom side of the mask frame selected by the AREA
SEL parameter.
LEFT 000-474(NTSC)
000-468(PAL)
Sets the left side of the mask frame selected by the AREA SEL
parameter.
RIGHT 000-474(NTSC)
000-468(PAL)
Sets the right side of the mask frame selected by the AREA SEL
parameter.
COLOR 1-8 Sets the colors of the mask frames.
TRANSP 0.00,0.50,0.75,1.00 Sets the transparency ratio of the mask frames.
MOSAIC OFF ON Sets the mask frame mosaic to ON or OFF.
●DAY/NIGHT “" "ඖ”
FUNCTION OPTION DESCRIPTION
DAY/NIGHT
AUTO
COLOR
B/W
EXT1
点EXT2
Day or Night is automatic. (NOT USED)
Only color.
Only b/w.
External Input 1. (NOT USED)
External Input 2.
点marks represent the factory default function. (EXT2)
EXT2 : DAY :COLOR→ IR LED OFF.
NIGHT: B/W → IR LED ON.
侀When the CAMERA RESET function execute, need to re-enter DAY/NIGHT function selects EXT2 item.
■B/W
FUNCTION OPTION DESCRIPTION
BURST OFF
ON
Burst signal OFF.
Burst signal ON.
IR OPTIMIZER OFF
ON
IR OPTIMIZER OFF.
IR OPTIMIZER ON.
MODE AUTO
CENTER Can be selected AUTO or CENTER.
LEVEL 0-31 Sets the IR OPTIMIZER LEVEL
侀Setting value also applies to EXT1ˣEXT2 item.

●NR “○”
This item is used to set the noise reduction
FUNCTION OPTION DESCRIPTION
Y LEVEL 000-015 Sets the Y filter strength.
●CAMERA ID “" "ඖ”
FUNCTION OPTION DESCRIPTION
CAMERA ID OFF
ON
Camera ID display OFF.
Camera ID display ON.
■CAMERA ID
FUNCTION OPTION DESCRIPTION
CAMERA ID
↑↓→ ← The camera ID cursor moves.
CLR The character selected by the camera ID cursor is cleared.
POS The display switches to the camera ID display position setting
screen.
13
NR
Y LEVEL IIȗIIIIIIIIIII 004
RETURN↵
CAMERA ID
CAMERA
ABCDEFGHIJKLMNOPQRSTUV
WXYZ0123456789-I”#$%&’
()_ ’, ; : < = > ? @ \ * X + /
↔↑↓CLR POS
RETURN↵

●SYNC “" "ඖ”
This option is not adjustable – it’s always on.
The Line-Lock (L/L) feature allows the camera to synchronize its frame rate to the power line phase. The function is only
available when the camera is operated by AC power. It allows the reduction of the fluorescent lights color rolling effect. When
using 12v DC power, the camera is automatically set to internal (INT) synchronization mode.
FUNCTION OPTION DESCRIPTION
SYNC INT
LL
Internal mode.
Line lock mode.
■LL
FUNCTION OPTION DESCRIPTION
PHASE 0 - 524(NTSC)
0 – 624(PAL)
Adjusts the phase in the vertical direction when the line lock
mode is established.
●LANGUAGE “" "ඖ”
FUNCTION OPTION DESCRIPTION
LANGUAGE
ENGLISH, JAPANESE,
GERMAN, FRENCH,
RUSSIAN, PORTUGUESE,
SPAINS, CHINESE
Selects the language in which to display the
internal OSD menu.
●CAMERA RESET “○”
FUNCTION OPTION DESCRIPTION
CAMERA RESET None All the internal OSD menu settings are initialized
●SAVE ALL
FUNCTION OPTION DESCRIPTION
SAVE ALL None All the settings of the internal OSD menu are saved
14
