RusAutomation QWCD35 User manual

QWCD35/QWCD35SD
Model
Name Voltage
Current
Built-in Sound
And Volume
Weight
(Kg)
Color
QWCD35
DC12V
~24V
Max.
1.3A
▪
Bit Input : 5Ch
(SD card only)
▪
Binary Input : 31Ch
▪
Warning sound :
Max. 115dB
▪
MP3 : Max. 113dB
1.10 R
A
G
B
QWCD35
SD
DC12V
~24V
Max.
1.2A
1.15
AC110V~
220V
Max.
0.31A
1
QWCD35/QWCD35SD
▪QWCD35/QWCD35SD Specification
▪QWCD35/QWCD35SD Dimensional drawing
No. 1 2 3 4 5 Sound tone
0 0 0 0 0 0 No sound
1 0 0 0 0 1 Rel rel rel
2 0 0 0 1 0 Slow Ambulance PI-PO
3 0 0 0 1 1 Oit Oit warning sound
4 0 0 1 0 0 Emergency WA-U(Yelp)
5 0 0 1 0 1 Pi- buzzer
6 0 0 1 1 0 7 Short PI / 1 Long
7 0 0 1 1 1 Pi o Pi o
8 0 1 0 0 0 Phone Ring
9 0 1 0 0 1 Pi- buzzer
10 0 1 0 1 0 Pi pi pi short
11 0 1 0 1 1 Di o Di o 2 tones buzzer
12 0 1 1 0 0 Oit Oit warning sound
13 0 1 1 0 1 Slow Ambulance PI-PO
14 0 1 1 1 0 Slow Di o Di o
15 0 1 1 1 1 Fast Li o li o
16 1 0 0 0 0 Fire.A-ANG
17 1 0 0 0 1 Fast Ambulance PI-PO
18 1 0 0 1 0 Slow Ambulance PI-PO
19 1 0 0 1 1 Ri ro ri ro warning sound
20 1 0 1 0 0 Repeat Di-o 3 times
21 1 0 1 0 1 Fire.A-ANG
22 1 0 1 1 0 Ambulance PI-PO
23 1 0 1 1 1 Slow Fire.A-ANG
24 1 1 0 0 0 Pi-pi- buzzer low frequency
25 1 1 0 0 1 Pi-pi- buzzer high frequency
26 1 1 0 1 0 Di-di- buzzer high frequency
27 1 1 0 1 1 Di-di- buzzer low frequency
28 1 1 1 0 0 Rising Po-ong
29 1 1 1 0 1 Fast Ambulance PI-PO
30 1 1 1 1 0 Rising frequency
31 1 1 1 1 1 Repeat A-ANG
OPERATING MANUAL
LED Strobe Light with Siren
Thank you for purchasing Qlight product. Please read this
manual carefully before installing this product for safe and
long use.
1 Feature
▪A new concept of using the horn cover as a light globe.
▪Sound pattern selection switch, volume controller and built-in
SD card reader realize convenient control.
▪There are 31 built-in sounds that can be played in various
environments,
▪User can select MP3 file by themselves in case of SD card
type model
▪Protection rating IP66 allows excellent air tightness where is
dusty and outdoor place
▪Ambient temperature : -30°C to +50°C.
▪Materials : Horn-PC, Housing-PC+ABS BLEND
▪Volume : QWCD35 - Max. 115dB
QWCD35SD- Max. 123dB
2 Specification and Dimension
3 Sound patterns and selection
▪This product supports Bit input(SD Card) and Binary input mode.
▪Bit input mode is specialized option for SD card. 5 sound tones can
be played as pre-defined rule.
▪Following is how to save MP3 files into SD card.
.mp3
File name 20 Koreans, 40 Alphabets
Separator between file number and title
No. of message 01 to 31
▪Binary input mode can played 31 sound tones by using combination
of 5ch switch.
23
_
For Elise
ООО “РусАвтоматизация” 454010 Челябинск, Гагарина 5,
русавтоматизация.рф
Россия, тел. [phone],
тел./факс [phone]
(звонок бесплатный)
,[email protected], www.rusautomation.ru,

2
1
2
1
2 3
4
5
②SDcards
- The SDcard is a compact flash memory card for storing MP3
files.
- After saving the MP3 files in the SDcard with the specified
format, insert the card into the SDcard slot and switch the
sound
setting switch to ON so the sounds can be played from the
SDcard.③PLAY MODE setting switch
- PLAY MODE setting switch is used to choose the channel
input method or select various playing modes. Refer to the
table below for switch features.
1
Bit Input Mode 5 sounds can be played from the selected
group
2
Binary Input Mode Up to 31 sounds available for each model
3
Bit Input Hold
Playback Mode
5 sounds can be played from the selected
group
The sound is repeated if the input signal is
maintained. .(STOP signal makes hold)
4
Binary Input Hold
Playback Mode
Up to 31 sounds available for each model
The sound is repeated if the input signal is
maintained.(STOP signal makes hold)
5
Bit Input Sound
Reduction Mode
5 sounds can be played from the selected
group. You can reduce the volume(15dB) by
using a separate volume reduction signal line
6
Binary Input Sound
Reduction Mode
Up to 31 sounds available for each model
You can reduce the volume(15dB) by using a
separate volume reduction signal line
7
Bit Input Sequence
Memory
5 sounds can be played from the selected
group
If the sound is inputted in a order, it will
remember the order and play each sound about
3 seconds.
The last input channel is fully played
8
Test Mode
In test mode, Ch1 of group is automatically
played back repeatedly.
To end the test mode, switch back to the other
modes.
▪This product has volume controller and channel selection switch.
Please read this manual and refer to figures carefully before use.
1) Globe removal
▪Remove four bolts in front of the globe by using tools.
▪You can see Control PCB on the product body after dismantling
the globe. (There are two types of products. One is pre-recorded
sound type, the other one is SD card type. Please refer
appropriate part from below 2)
2) How to control volume & and channel selection switch for pre-
recorded sound type
▪In case of pre-recorded sound type, there are channel selection
switch and volume controller(Please refer to figure)
4 Volume control &how to use Ch.Selection switch
①Channel selection switch
- According to binary input, user can choose the sound tone
what user want by using channel switch.
②Volume controller
- Volume controller can adjust the volume into the speaker.
3) How to control volume & and channel selection switch for
SD card type(MP3)
▪In case of SD card type, there are SD card slot, play mode
setup switch, channel selection switch and volume controller on
the CONTROL PCB. (Please refer to figure)
①SOUND setting switch
- - I f the switch is ON the SDcard (MP3) will be played, and if the
switch is OFF the built-in sounds will be played..
④Channel selection switch
- By using 5 channel selection switches, one can choose the
appropriate sound source depending on the Binary input and Bit
input.
⑤VOLUME
- You can adjust the speakers sound output by using the
volume dial.
4) Reassembling
▪Reassemble the product as reverse order of dismantling the product.
5 Wiring instruction
▪Standard specification: Use internal connector
(External connector type is optionally provided)
ООО “РусАвтоматизация” 454010 Челябинск, Гагарина 5,
русавтоматизация.рф
Россия, тел. [phone],
тел./факс [phone]
(звонок бесплатный)
,[email protected], www.rusautomation.ru,

3
6
QWCD35/QWCD35SD
QWCD35/QWCD35SD-DC/AC
▪Power line and signal line are exposed to outside in case of LC
type which is using external contact for sound tone selection.
Please refer to below wiring diagram.
▪Power line standard : UL1015-NO.18(0.75sq)Ⅹ2C 400mm
▪Signal line standard : UL1007-NO.22(0.3sq) 400mm
* Warning!
In case of add power into the common line and each signal line,
there will be sound output error.
6 How to mount
▪This product is designed for out door use. However we
recommend you to use this where is less dust and water.
▪Put appropriate holes where the product is installed. (Please
refer to dimensions for mounting holes)
▪Fix the product by using M8-2EA.
7 Caution
▪If using voltage is seriously higher or lower than rated voltage, it
can reduce the self-life of the product or can cause a problem on
product operating. Make sure the using voltage does not exceed
+/-5% of the rated voltage.
▪If lens or body of the product is contaminated by chemicals such
as thinner, benzene, the product can be damaged, discolored or
deformed. Please be careful.
▪Significant impact may cause of damage or short circuit.
▪Do not pull out external lines too much. It may cause of damage
Issue Cause Solution
Non-
Lighting Partly
LED is partly damaged,
supplying higher
voltage then rated
voltage.
Check voltage
Feeble Lighting
Supplying Voltage
Lower Than Rated
Voltage
Check voltage
No light
Wrong wire Check wiring
No power Check power
Sound Tone
Deterioration
or Volume
Decreasing
Supplying Voltage Lower
Than Rated Voltage Make sure voltage
Higher
Volume(dB)
than Standard
Supplying Voltage Higher
than Rated Voltage Make sure voltage
No Sound
Wrong Wiring Make sure wiring
No Power Supply Make sure power
supply
8 Trouble shoot
QLIGHT CO., LTD.
http://www.qlight.com
E-mail: [email protected]
Overseas Marketing Team /Plant
Tel) 055-328-4082 Fax)055-328-3883
185-25 Mukbang-ro, Sangdong-Myeon, Kimhae-Si,
GyeongNam, Korea
9 Customer Service Information
