Ryobi CBL1802 User manual

CORDLESS BLOWER
OPERATOR’S MANUAL (Original Instructions)
Important! It is essential that you read the instructions in this manual before operating
this machine.
Subject to technical modifications.
CBL1802LBC

2

Keep the handles dry and clean.
Consider work area environment. Do not expose
power tools to rain. Do not use power tools in damp
or wet locations. Keep work area lit. Do not use power
tools where there is risk to cause fire or explosion.
Store battery or idle tools. When not in use, tools and
batteries should be stored separately in dry, high or
locked up areas out of reach of children. Ensure that
battery terminals cannot be shorted by other metal
parts such as screws, nails, etc.
Disconnect the tool from its battery pack when not in
use, disconnecting the blower tube before service.
Avoid unintentional starting. Do not carry the tool with
a finger on the switch.
Stay alert. Watch what you are doing. Use common
sense. Do not operate tool when you are tired.
Have your tool repaired by a qualified person. This tool
is in accordance with the relevant safety requirements.
Repairs should only be carried out by qualified persons
using original spare parts, otherwise this may result in
considerable danger to the user.

Use only the manufacturer’s replacement parts. Failure
to do so may cause poor performance, possible injury
and may void your warranty.

Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power
tools that have the switch on invites accidents.
Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, seek
medical help. Liquid ejected from the battery may
cause irritation or burns.
SAVE THESE INSTRUCTIONS. REFER TO THEM
FREQUENTLY AND USE THEM TO INSTRUCT OTHERS
WHO MAY USE THIS UNIT. IF YOU LOAN SOMEONE
THIS UNIT, LOAN THEM THESE INSTRUCTIONS ALSO.

Your blower has been engineered and manufactured to
Ryobi’s high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give
you years of trouble-free performance.
Thank you for buying a Ryobi product.

When using battery operated tools basic safety
precautions should always be followed to reduce
the risk of re, leaking batteries and personal injury,
including the following.
Read all these instructions before operating this product
and keep for future reference.
Do not allow children or untrained individuals to use
this unit.
Wear heavy long trousers, non-slip safety footwear
and gloves.
Never operate unit while bare foot or wearing open
shoes.
Do not wear loose clothing, or jewelry that might get
entangled in this unit.
Do not touch the fan when operating this unit.
Keep all bystanders, children, and pets at least 15m
(50 feet) away. Remember that the operator or user
is responsible for accidents occurring to bystanders,
their property, as well as themselves.
Check for damaged parts. Before further use of the
appliance, any part that is damaged should be carefully
checked to determine that it will operate properly and
perform its intended function.
Check for breakage of parts and any other conditions
that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced
by an authorized service center. Following this rule will
reduce the risk of shock, fire,or serious injury.
Do not force the product. Use the correct tool for your
application. The correct tool will do the job better and
safer at the rate for which it is designed.
Do not over-reach. Keep proper footing and balance
at all times. Proper footing and balance enables better
control of the product in unexpected situations.
Secure long hair so it can not become entangled in
moving parts or air intake.
Do not operate this unit when you are tired, ill, or under
the influence of alcohol, drugs, or medication.
Do not operate in poor lighting.
Never let anyone use your unit who has not received
adequate instructions in the unit’s proper use.

3

Some of the following symbols may be used on this tool. Please study them and understand their meaning. Proper
interpretation of these symbols will allow you to operate the tool better and safer.
  
Safety Alert Precautions that involve your safety.
Read The Operator’s
Manual
Read the operation manual and follow all warnings and safety
instructions.
Eyes and Ears Protection Wear eye protection and ear protection.
Ricochet alert Thrown objects can ricochet and result in personal injury or
property damage. Wear protective clothing land boots.
Keep bystanders away Keep all bystanders, especially children and pets, at least 15m
from the operating area.
Do not touch the fan. Do not touch the fan when operating this unit.
Wet conditions alert Do not expose to rain or damp conditions.
The following signal words and meanings are intended to explain the levels of risk associated with this product.
  
 Indicates an imminently hazardous situation, which, if not
avoided, will result in death or serious injury.
 Indicates a potentially hazardous situation, which, if not avoided,
could result in death or serious injury.
 Indicates a potentially hazardous situation, which, if not avoided,
may result in minor or moderate injury.
 (Without Safety Alert Symbol) Indicates a situation that may
result in property damage.


4



 CBL1802LBC
Motor 18 V DC
Air Velocity 190 km/h
Measured sound
pressure level LPA:83 dB(A), KPA:2 dB(A)
Measured sound
power level LWA:93.7 dB(A), KWA:2 dB(A)
Vibration ah:1.57 m/s2 , K:1.5 m/s2
Weight with
Battery Pack 1.9 kg
Battery Pack 1 x BPL-1815
Compatible
Battery Packs
ABP1801 / ABP1802 /
BPL-1815 / BPL-1820 /
BPL-1820G
Charger 1 x BCL1418
Compatible
Chargers
ACR-1800
(only for ABP1801 / ABP1802)
BCL-1800 / BCL-1800G /
BCL1418
(for all Compatible Battery Packs)


1. Blower housing outlet
2. Power switch
3. Blower tube
4. Latches.
5. Battery pack

See Figure 1.
The safe use of this product requires an understanding
of the information on the blower and in this operator’s
manual as well as a knowledge of the project you are
attempting. Before use of this product, familiarize yourself
with all operating features and safety rules.

The blower tube can be installed on the blower without
using any tools.


To prevent accidental starting that could cause serious
personal injury, always remove the battery pack from
the blower when assembling parts.

See Figure 2.
With the logo area facing up, slide the blower tube
over the outlet on the blower housing.
Press down on the tab on the blower housing outlet.
Push tab on outlet on the blower housing down until
it locks into place through the opening in the blower
tube.


Do not allow familiarity with tools to make you careless.
Remember that a careless fraction of a second is
sufcient to inict serious injury.

You may use this tool for the purposes listed below:
Clearing hard surfaces such as driveways and
walkways.
Keeping decks and driveways free from leaves and
pine needles.

Not intended for use other than what's listed above.

See Figure 3.
Place the power switch in the OFF ( O ) position.
Place the battery pack in the blower. Align raised rib on
battery pack with groove in the blower’s battery port.
Make sure the latches on each side of the battery pack
snap in place and that battery pack is secured in the
blower before beginning operation.

5



When servicing use only identical replacement parts.
Use of any other parts may create a hazard or cause
product damage.
Avoid using solvents when cleaning plastic parts. Most
plastics are susceptible to damage from various types
of commercial solvents and may be damaged by their
use. Use clean cloths to remove dirt, dust, oil, grease,
etc.

Do not at any time let brake uids, gasoline, petroleum
based products, penetrating oils, etc. come in contact
with plastic parts. They contain chemicals that can
damage, weaken or destroy plastic.

Do not attempt to modify this tool or create accessories
not recommended for use with this tool. Any such
alteration or modication is misuse and could result
in a hazardous condition leading to possible serious
personal injury.

To avoid serious personal injury, always remove the
battery pack from the tool when cleaning or performing
any maintenance.

Clean the blower thoroughly before storing. Store the
blower in a dry, well-ventilated place that is inaccessible
to children. Keep away from corrosive agents such as
garden chemicals and de-icing salts.

Waste electrical products should not be
disposed of together with household waste.
Please recycle where facilities exist. Check
with your local authority or retailer for
recycling advice.

When placing battery pack in the blower, be sure raised
rib on battery pack aligns with the back of the blower
and latches into place properly. Improper installation
of the battery pack can cause damage to internal
components.

See Figure 3.
Place the power switch in the OFF ( O ) position.
Locate latches on side of battery pack and depress
both sides to release battery pack.
Remove battery pack from the blower.

See Figures 4.
To start the blower, place the power switch in the ON
( l ) position.
To stop the blower, place the power switch in the OFF
( O ) position.

Battery tools are always in operating condition.
Therefore, switch should always be in the OFF position
when not in use or carrying at your side.

See Figure 5.
To keep from scattering debris, blow around the outer
edges of a debris pile. Never blow directly into the
center of a pile.
To reduce sound levels, limit the number of pieces of
equipment used at any one time.
Use rakes and brooms to loosen debris before
blowing.In dusty conditions, slightly dampen surfaces
when water is available.
Conserve water by using power blowers instead
of hoses for many lawn and garden applications,
including areas such as gutters, screens, patios, grills,
porches, and gardens.
Watch out for children, pets, open windows, or freshly
washed cars, and blow debris safely away.
After using blowers or other equipment, CLEAN UP!
Dispose of debris properly.

TTI warrants this outdoor product to be free of defects in material and workmanship for 24 months from the date of purchase by the original
purchaser, subject to the limitations below. Please keep your invoice as proof of date of purchase.
This warranty is only applicable where the product is used for personal and non-commercial purposes. This warranty does not
cover damage or liability caused by / due to misuse, abuse, accidental or intentional acts by user, improper handling, unreasonable use,
negligence, failure by end user to follow operating procedures outlined in the user’s manual, attempted repair by non-qualied professional,
unauthorised repair, modication, or use of accessories and/or attachments not specically recommended by authorised party. Please see
your local dealer for list of authorised service centres in your area.
This warranty does not cover belts, brushes, bags, bulbs or any part which ordinary wear and tear results in required replacement during
warranty period. This warranty does not cover transportation cost or consumable items such as fuses and batteries.
This limited warranty is void if the product’s original identication (trade mark, serial number, etc.) markings have been defaced, altered or
removed or if product is not purchased from an authorised reseller or if product is sold AS IS and / or WITH ALL FAULTS.
Where permitted, the provisions of this limited warranty are in lieu of any other written warranty, whether express or implied, written or oral,
including any warranty of MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. IN NO EVENT SHALL WE BE LIABLE
FOR SPECIAL, INCIDENTAL, CONSEQUENTIAL OR INCIDENTAL DAMAGES. OUR MAXIMUM LIABILITY SHALL NOT EXCEED THE
ACTUAL PURCHASE PRICE PAID BY YOU FOR THE PRODUCT.
This warranty is applicable only in the European Union, Australia, and New Zealand. Outside these areas, please contact your
authorised Ryobi dealer to determine if another warranty applies.


Machine: CORDLESS BLOWER
Name of company: Homelite Far East Co., Ltd.
Address: 24/F, CDW Building,
388 Castle Peak Road,
Tsuen Wan Hong Kong.
Type: CBL1802LBC
Name / title: Andrew John Eyre (BEng, CEng, MIET)
Vice President of Engineering
Signature:
TECHTRONIC INDUSTRIES EMEA
Medina House, Field House Lane,
Marlow, Bucks
SL7 1TB - United Kingdom
RYOBI TECHNOLOGIES (UK) LIMITED
Medina House, Field House Lane,
Marlow, Bucks
SL7 1TB - United Kingdom
Tel: + 44 (0) 1628 894400
Fax: + 44 (0) 1628 894401
Technical Helpline : + 44 (0) 800 389 0305
TECHTRONIC INDUSTRIES FRANCE SAS
Immeuble Le Grand Roissy
Z.A. du Gué - 35 rue de Guivry
77990 Le Mesnil Amelot France
Phone: + 33(0)1 60 94 69 70
Fax: + 33(0)1 60 94 69 79
RYOBI BELGIUM
Avenue des Pâquerettes, 55
Zoning artisanal - bâtiment 5
B - 1410 Waterloo
Belgique
Tel : + 32(0) 2357 8140
Fax : + 32(0) 2357 8149
TTI ITALIA SRL
Via Fratelli Gracchi, 39
20092 Cinisello Balsamo (MI)
Italia
Tel : + 39 02 37050440
Fax : + 39 02 37050444
TECHTONIC INDUSTRIES IBERIA S.L
Av. De la Industria, 52
Coslada – Madrid – España
Tel: [phone]
TECHTRONIC INDUSTRIES SOUTH AFRICA
CO. (PTY) LTD
P.O Box 83888, South Hills,
Johannesburg, 2136
South Africa
TECHTRONIC INDUSTRIES (ASIA) CO., LTD.
24/F, CDW Building,
388 Castle Peak Road,
Tsuen Wan, Hong Kong
Tel : + 852 2402 6888
TECHTRONIC INDUSTRIES CENTRAL EUROPE GMBH
Itterpark 2
D-40724 Hilden
Deutschland
Tel: + 49 (0)960-0
Fax: + 49 (0) 960-238
TECHTRONIC INDUSTRIES
AUSTRALIA PTY LIMITED
Building B, Rosehill Industrial Estate,
3 Shirley Street,
Rosehill NSW 2142
Australia
Tel: [phone] or 1300 361 505
Fax: [phone]
TECHTRONIC INDUSTRIES (NZ) LIMITED
27 Clemow Drive, Mt Wellington
PO Box 12-806, Penrose, Auckland
New Zealand
Tel: + 64 (0) 9 573 0230
Free Call: [phone]
Fax: + 64 (0) 9 573 0231
A&M MIDDLE EAST FZCO
P.O.Box 61254
Jedel Ali, Dubai
United Arab Emirates
Tel.: + 9714 8861399
Fax: + 9714 8861400
TECHTRONIC INDUSTRIES DENMARK APS
Stamholmen 147, 4
DK-2650 Hvidovre
Denmark
Tlf 43 56 55 55
Fax [phone]
E-mail: [email protected]
TECHTRONIC INDUSTRIES NORWAY AS
Stamholmen 147, 4
DK-2650 Hvidovre
Denmark
Tlf.: ([phone]
Faks: ([phone]
E-mail: [email protected]
TECHTRONIC INDUSTRIES SWEDEN AB
Stamholmen 147, 4
DK-2650 Hvidovre
Denmark
Tel [phone]
Fax [phone]
E-mail: [email protected]
TECHTRONIC INDUSTRIES FINLAND OY
Stamholmen 147, 4
DK-2650 Hvidovre
Denmark
Tel. [phone]
Fax [phone]
E-mail: [email protected]
7 / 2010
