Ryobi OBL1820S User manual

FRONT PAGE
OBL1820S

2
Original Instructions
IMPORTANT!
It is essential that you read the instructions
in this manual before assembling, operating,
and maintaining the product.
Subject to technical modication.
Safety, performance, and dependability have
been given top priority in the design of your
cordless blower.
INTENDED USE
The cordless blower is intended only for
outdoor use, in dry, and well-illuminated
conditions.
The product is not intended to be used by
children or persons with reduced physical,
mental, or sensory capabilities.
The product is designed for blowing light
debris, such as leaves, grass, and other
garden waste.
Do not use the product for any other purpose.
GENERAL SAFETY WARNINGS
WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, re,
and/or serious injury. Save all warnings and
instructions for future reference.
WARNING! Never allow children or people
who are unfamiliar with these instructions to
use the product. Local regulations may restrict
the age of the operator.
TRAINING
■Read the instructions carefully. Be familiar
with the controls and the correct use of the
product.
■Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
■Do not use the product while tired, ill, or
under the influence of drugs, alcohol, or
medication.
PREPARATION
■Some regions have regulations that restrict
the use of the product to some operations.
Check with your local authority for advice.
■Wear hearing protection at all times whilst
operating the product. This will prevent
exposure to noise that could cause a
permanent hearing injury. Protection such
as ear plugs can limit your exposure and
reduce noise.
■Wear full eye protection at all times while
operating the product. Wear a full face
mask or fully enclosed goggles. Normal
spectacles or sunglasses are not adequate
protection. Objects can be thrown at high
speed by the powerful air jet at any time and
may rebound from hard surfaces toward the
operator.
■While operating the product, always wear
substantial footwear and long trousers.
Do not operate the product when barefoot
or wearing open sandals. Avoid wearing
clothing with loose fitting or that has hanging
cords or ties.
■Do not wear loose clothing or jewellery that
can be drawn into the air inlet. Secure long
hair so it is above shoulder level to prevent
entanglement in moving parts.
■Before each use, ensure that all controls
and safety devices function correctly. Do
not use the product if the off switch does not
stop the product.
■Operate the product in the recommended
position and only on a firm and level surface.
■Do not operate the product on a paved or
gravel surface where ejected material could
cause injury.
■Before each use, always inspect the housing
for damage. Ensure that guards and handles
are in place and properly secured. Replace
worn or damaged components in sets to
preserve balance. Replace damaged or
unreadable labels.
■Never operate the product while people,
especially children, or pets are nearby.
■Keep all cooling air inlets clear of debris.
■Use rakes and brooms to loosen debris
before blowing.
■Clear the work area before each use.
Remove all objects such as rocks, broken
glass, nails, wire, or string that can be blown
a considerable distance by high velocity air.
■Injuries may be caused or aggravated by
prolonged use of a tool. When using any
tool for prolonged periods, ensure you take
regular breaks.
BATTERY TOOL USE AND CARE
■Recharge only with the charger specified by
the manufacturer. A charger that is suitable
for one type of battery pack may create a
risk of fire when used with another battery
pack.

3
Original Instructions
■Use power tools only with specifically
designated battery packs. Use of any other
battery packs may create a risk of injury and
fire.
■When battery pack is not in use, keep it away
from other metal objects, like paper clips,
coins, keys, nails, screws or other small
metal objects that can make a connection
from one terminal to another. Shorting the
battery pack terminals together may cause
burns or a fire.
■Under abusive conditions, liquid may be
ejected from the battery pack; avoid contact.
If contact accidentally occurs, flush with
water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the
battery pack may cause irritation or burns.
■Do not use a battery pack or tool that
is damaged or modified. Damaged or
modified batteries may exhibit unpredictable
behaviour resulting in fire, explosion, or risk
of injury.
■Do not expose a battery pack or tool to fire
or excessive temperatures. Exposure to fire
or excessive temperature above 130°C may
cause explosion.
■Follow all charging instructions and do not
charge the battery pack or tool outside
the temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range
may damage the battery and increase the
risk of fire.
OPERATION
■Operate the product only at reasonable
hours—not early in the morning or late at
night when people might be disturbed.
■Never operate the product in an explosive
atmosphere.
■Avoid using the product in bad weather
conditions, especially when there is a risk
of lightning.
■Keep bystanders, children, and pets 15 m
away from the area of operation. Stop the
product if anyone enters the area.
■Do not operate the product in poor lighting.
The operator requires a clear view of the
work area to identify potential hazards.
■Operating similar tools nearby increases
both the risk of hearing injury and the
potential for other persons to enter your
working area.
■Always be sure of your footing on slopes.
Walk, never run.
■Keep proper footing and balance. Do not
overreach. Overreaching can result in loss
of balance.
■Never use the product with defective guards
or shields, or without safety devices in place.
■To reduce the risk of injury associated with
contacting rotating parts, always turn off the
product and remove the battery pack. Make
sure that all moving parts have come to a
complete stop:
●before leaving the product unattended
●before clearing blockages
●before checking, cleaning, or working on
the product
●before inspecting the product after
striking a foreign object
●whenever the product starts to vibrate
abnormally (inspect immediately)
■Immediately turn off the product and remove
the battery pack in the event of accident
or breakdown. Do not operate the product
again until it has been fully checked by an
authorised service centre.
■Do not modify the product in any way or
use parts and accessories that are not
recommended by the manufacturer.
■If the product is dropped, suffers heavy
impact, or begins to vibrate abnormally,
immediately stop the product and inspect
for damage or identify the cause of the
vibration. Any damage should be properly
repaired or replaced by an authorised
centre.
BLOWER SAFETY WARNINGS
■Wear a face filter mask in dusty conditions
to reduce the risk of injury associated with
the inhalation of dust.
■Slightly dampen surfaces in dusty
conditions.
■Do not use the product near open windows.
■Use the full blower nozzle extension so that
the air stream can work close to the ground
and perform effectively.
■Do not point the blower nozzle in the
direction of people or pets.
■Never place objects inside the blower tubes.
■Do not place the product on top of or near
loose debris. Debris can be sucked into the
intake vent, resulting in possible damage to
the product.

4
Original Instructions
ADDITIONAL BATTERY SAFETY
WARNINGS
To reduce the risk of re, personal injury, and
product damage due to a short circuit, never
immerse the tool, battery pack or charger in
uid or allow uid to ow inside them. Corrosive
or conductive uids, such as seawater, certain
industrial chemicals, and bleach or bleach-
containing products, etc., can cause a short
circuit.
TRANSPORTATION AND STORAGE
■Turn off the product, remove the battery
pack, and allow it to cool down before
storing or transporting.
■Remove all foreign materials from the
product. Store the product in a cool, dry, and
well-ventilated place that is inaccessible
to children. Keep the product away from
corrosive agents, such as garden chemicals
and de-icing salts. Do not store the product
outdoors.
■For transportation in a vehicle, secure the
product against movement or falling to
prevent injury to persons or damage to the
product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery pack in accordance with
local and national provisions and regulations.
Follow all special requirements on packaging
and labelling when transporting batteries by a
third party. Ensure that no batteries can come
in contact with other batteries or conductive
materials while in transport by protecting
exposed connectors with insulating, non-
conductive caps or tape. Do not transport
battery packs that are cracked or leaking.
Check with the forwarding company for further
advice.
MAINTENANCE
Use only original manufacturer’s replacement
parts, accessories, and attachments. Failure to
do so can cause possible injury, can contribute
to poor performance, and may void your
warranty.
Servicing requires extreme care and
knowledge and should be performed only by a
qualied service technician. Have the product
serviced by an authorised service centre only.
■Check all nuts, bolts, and screws at frequent
intervals for proper tightness to ensure that
the product is in safe working condition. Any
part that is damaged should be properly
repaired or replaced by an authorised
service centre.
■Bring the product to an authorised service
centre to replace damaged or unreadable
labels.
■You may make adjustments or repairs that
are described in this manual. For other
repairs, contact an authorised service
centre.
■After each use, clean the product with a
soft, dry cloth.
CLEARING A BLOCKAGE
■To reduce the risk of injury associated with
contacting moving parts, always turn off
the product, remove the battery pack, and
make sure that all moving parts have come
to a complete stop.
■Remove the blower tubes to inspect for
blockage. Clear the tubes if required.
■Reinstall the blower tubes before starting
the product.
SYMBOLS ON THE PRODUCT
Safety alert
Read and understand all
instructions before operating
the product. Follow all warnings
and safety instructions.
Beware of thrown or ying
objects. Keep all bystanders,
especially children and pets,
at least 15 m away from the
operating area.
Rotating fans. Keep hands and
feet out of openings while the
product is running.
Remove the battery pack
before starting any work on the
product.
Wear ear protection.
Wear eye protection.

5
Original Instructions
Do not expose the product to
rain or damp condition.
94
Guaranteed sound power level
Regulatory Compliance
Mark (RCM). This product
meets applicable regulatory
requirements.
Waste electrical products
should not be disposed of
with household waste. Please
recycle where facilities exist.
Check with your local authority
or retailer for recycling advice.
SYMBOLS IN THIS MANUAL
Note
Warning
Parts or accessories are sold
separately

6
Know your product
OBL1820S
RBL1850S
RBL1820S
R18BLW24
RBL1851S
On/off switch
Handle
Tube latch
Nozzle tab
Blower tube
High speed nozzle
Operator’s manual
Battery pack
Charger

7
Getting Started
1
2
1
4
2 3
4
Wear full eye and ear protection,
substantial footwear, and long trousers
at all times while operating the product.
Do not operate the product when
barefoot or wearing open sandals.
Insert the high-speed nozzle into the
blower tube until it clicks into place.
Install the battery pack. Make sure that
the latches on the battery pack snap in
place. Slide up the switch to turn on the
product.
Hold the blower with the handle in your
right hand, and let the air stream work
close to the ground.
Insert the blower tube into the product
until it clicks into place.

8
p.10
p.11
p.9
Using the product Cleaning the
product
Storing the product

9
Operation
1
2
USING THE PRODUCT
1. Install the battery pack. Make sure that
the latches on the battery pack snap in
place.
2. Slide up the switch to turn on the product.
Hold the blower with the handle in your
right hand, and let the air stream work
close to the ground.

1
2
1
2
3
CLEANING THE PRODUCT
1. Slide down the switch to turn off the
product.
2. Press the battery latch button, and
remove the battery pack.
3. Clean the blower using a brush.
WARNING! Avoid using solvents when
cleaning plastic parts. Most plastics are
susceptible to damage from various types of
commercial solvents and may be damaged
by their use. Use a clean brush to remove
dirt, dust, lubricant, grease, etc.
10
Maintenance

1
2
2
2
1
3
4
20210721v4
1
STORING THE PRODUCT
1. Slide down the switch to turn off the
product.
2. Press the battery latch button, and
remove the battery pack.
3. Push the blower tube latch, and remove
the blower tube.
4. Store the product in a cool, dry, and well-
ventilated place that is inaccessible to
children.
11
Storage

PRODUCT SPECIFICATIONS
Cordless blower
Model OBL1820S
Rated voltage 18 V
Air velocity 245 km/h
Weight (with battery) 2.33 kg
Weight (without battery) 1.60 kg
Vibration level (in accoordance with Annex BB of EN 50636-2-100)
Total value
ah= 0.88 m/s2
Uncertainty of measurement
K= 1.5 m/s2
Noise emission level (in accordance with Annex CC of
EN 50636-2-100)
A-weighted sound pressure
level at operator’s position
LpA = 79.2 dB(A)
Uncertainty of measurement
K = 3.0 dB
LWA + KWA
94 dB(A)
BATTERY AND CHARGER
Model RBL1851S RBL1850S RBL1820S
Battery pack RB1850C RB18L50 RB18L40
Weight 0.73 kg 0.73 kg 0.73 kg
Charger RC18120 BCL14181H BCL14181H
Weight 0.4 kg 0.4 kg 0.4 kg
Compatible
battery
packs
RB18L13, RB18L13Z, RB18L15, RB18L15A,
RB18L15B, RB1815C, RB18L20, RB18L20A, RB1820C,
RB18L25, RB18L25A, RB18L26, RB18L30, RB18L30A,
RB18L40, RB18L40A, RB1840C, RB1840X, RB18L50,
RB18L50A, RB1850C, RB1850X, RB18L60, RB18L60A,
RB18L90, RB18L90A
Compatible
chargers
RC18115, RC18150U, BCL14181H, BCL14183H,
BCL1418IV, RC18120, RC18627U, BCS618G
Model R18BLW24 OBL1820S
Battery pack RB1840C -
Weight -
Charger RC18120 -
Weight - -
Compatible battery
packs
RB18L13, RB18L13Z, RB18L15, RB18L15A,
RB18L15B, RB1815C, RB18L20, RB18L20A,
RB1820C, RB18L25, RB18L25A, RB18L26,
RB18L30, RB18L30A, RB18L40, RB18L40A,
RB1840C, RB1840X, RB18L50, RB18L50A,
RB1850C, RB1850X, RB18L60, RB18L60A,
RB18L90, RB18L90A
Compatible chargers
RC18115, RC18150U, BCL14181H,
BCL14183H, BCL1418IV, RC18120,
RC18627U, BCS618G
* BCL1418IV is compatible for changing in vehicles with 12 V DC outlets.
SPARE PARTS
High speed nozzle 525803001

WARNING! The declared vibration total
values and the declared noise emission values
given in this instruction manual have been
measured in accordance with a standardised
test and may be used to compare one tool with
another. They may be used for a preliminary
assessment of exposure.
The declared vibration and noise emission
values represent the main applications of the
tool. However, if the tool is used for di󰀨erent
applications, used with di󰀨erent accessories,
or poorly maintained, the vibration and noise
emission may di󰀨er. These conditions may
signicantly increase the exposure levels over
the total working period.
An estimation of the level of exposure to
vibration and noise should take into account
the times when the tool is turned o󰀨 or when
it is running idle. These conditions may
signicantly reduce the exposure level over the
total working period.
Identify additional safety measures to protect
the operator from the e󰀨ects of vibration and
noise, such as maintaining the tool and the
accessories, keeping the hands warm (in case
of vibration), and organising work patterns.

BACK PAGE
961497019-01
Imported by:
Techtronic Industries Australia Pty Ltd
31 Gilby Road, Mount Waverley, VIC 3149
Melbourne, Australia
Techtronic Industries N.Z. Limited
Unit C, 70 Business Parade South,
Highbrook, Auckland 2013, New Zealand
RYOBI is a trade mark of Ryobi Limited, and is used under license.
© 2021 Techtronic Cordless GP.
