Ryobi RBV3650D User manual

RBV3650D
RBV3600
ORIGINAL INSTRUCTIONS
Cordless Blower/
Vacuum

Important!
It is essential that you read the instructions in this manual before assembling,
operating, and maintaining the product.
Subject to technical modification.

1
Safety, performance, and dependability have been given
top priority in the design of your cordless blower/vacuum.
INTENDED USE
The product is intended for use in clearing hard surfaces
such as driveways and walkways. You can also use the
product in keeping decks and driveways free from leaves
and pine needles.
Do not use the product in any way other than those stated.
GENERAL SAFETY WARNINGS
Your blower has been engineered and manufactured to
Ryobi’s high standard for dependability, ease of operation,
and operator safety. When properly cared for, it will give
you years of trouble-free performance.
Thank you for buying a Ryobi product.
WARNING
When using battery operated tools basic safety
precautions should always be followed to reduce the risk
of re, leaking batteries and personal injury, including
the following.
Read all these instructions before operating this product
and keep for future reference.
■Do not allow children or untrained individuals to use this
product.
■Wear heavy long trousers, non-slip safety footwear,
and gloves.
■Never operate product while bare foot or wearing open
shoes.
■Do not wear loose clothing or jewellery that might get
entangled in this product.
■Do not touch the fan when operating this product.
■Keep all bystanders, children, and pets at least 15 m
(50 feet) away. Remember that the operator or user is
responsible for accidents occurring to bystanders, their
property, as well as themselves.
■Check for damaged parts. Before further use of the
product, any part that is damaged should be carefully
checked to determine that it will operate properly and
perform its intended function.
■Check for breakage of parts and any other conditions
that may affect its operation. A guard or other part that
is damaged should be properly repaired or replaced by
an authorised service centre. Following this rule will
reduce the risk of shock, fire,or serious injury.
■Do not force the product. Use the correct tool for your
application. The correct tool will do the job better and
safer at the rate for which it is designed.
■Do not over-reach. Keep proper footing and balance
at all times. Proper footing and balance enables better
control of the product in unexpected situations.
■Secure long hair so it cannot become entangled in
moving parts or air intake.
■Do not operate this product when you are tired, ill, or
under the influence of alcohol, drugs, or medication.
■Do not operate in poor lighting.
■Never let anyone use the product who has not received
adequate instructions in the product’s proper use.
■Keep the handles dry and clean.
■Consider work area environment. Do not expose power
tools to rain. Do not use power tools in damp or wet
locations. Keep work area lit. Do not use power tools
where there is risk to cause fire or explosion.
■Store battery or idle tools. When not in use, tools and
batteries should be stored separately in dry, high or
locked up areas out of reach of children. Ensure that
battery terminals cannot be shorted by other metal
parts such as screws, nails, etc.
■Disconnect the product from its battery pack when not
in use, disconnecting the blower tube before service.
■Avoid unintentional starting. Do not carry the product
with a finger on the switch.
■Stay alert. Watch what you are doing. Use common
sense. Do not operate product when you are tired.
■Have your product repaired by a qualified person.
This product is in accordance with the relevant safety
requirements. Repairs should only be carried out by
qualified persons using original spare parts, otherwise
this may result in considerable danger to the user.
WARNING
Use only the manufacturer’s replacement parts. Failure
to do so may cause poor performance, possible injury
and may void your warranty.
BATTERY TOOL USE AND CARE
■Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
■Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
■Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
■When battery pack is not in use, keep it away from
other metal objects like paper clips, coins, keys, nails,
screws, or other small metal objects that can make a
connection from one terminal to another. Shorting the
battery terminals together may cause burns or a fire.
■Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally
occurs, flush with water. If liquid contacts eyes, seek
medical help. Liquid ejected from the battery may cause
irritation or burns.
Save these instructions. Refer to them frequently and use
them to instruct others who may use this product. If you
loan someone this product, loan them these instructions
also.

2
WARNING
Injuries may be caused, or aggravated, by prolonged
use of a tool. When using any tool for prolonged periods,
ensure you take regular breaks.
ADDITIONAL SAFETY RULES
WARNING
The product is not intended for use by persons (including
children) with reduced physical, sensory, or mental
capabilities, or lack of experience and knowledge.
Children should be supervised to ensure that they do not
play with the product.
WARNING
Your blower/vacuum may be supplied with a harness.
Carefully adjust the harness to comfortably help to
support the weight of the product.
Identify the quick release mechanism and practice using
it before you start using the product. Its correct use may
prevent serious injury in the case of an emergency. Never
wear additional clothing over the harness or otherwise
restrict access to the quick release mechanism.
BLOWER SAFETY WARNINGS
■Wear a face filter mask in dusty conditions to reduce
the risk of injury associated with the inhalation of dust.
■Do not point the blower nozzle in the direction of people
or pets.
■Never place objects inside the blower tubes.
■Do not operate the product near open windows, etc.
■Slightly dampen surfaces in dusty conditions.
■Use the full blower nozzle extension so the air stream
can work close to the ground.
■Do not place blower on top of or near loose debris.
Debris may be sucked into intake vent resulting in
possible damage to the product.
VACUUM SAFETY WARNINGS
WARNING
Never operate the vacuum with only the upper vacuum
tube tted. The risk of personal injury is signicantly
increased if you fail to follow this warning.
■Do not operate vacuum without vacuum bag assembly
installed; flying debris could cause serious injury. Make
sure the vacuum bag is completely zipped closed
before operating.
■Move the vacuum from side to side along outer edge of
debris. To avoid clogging, do not place the vacuum tube
directly into the debris pile.
■Hold the motor higher than the inlet end of the vacuum
tube.
■Always point vacuum tube downhill when working on
a hillside.
■To avoid serious injury to the operator or damage to the
product, do not try to vacuum up rocks, broken glass,
bottles, or other similar objects.
■Avoid situations that could cause fire in the vacuum
bag. Do not operate near an open flame. Do not
vacuum warm ash from fireplaces, barbecue pits, etc.
Do not vacuum discarded cigars or cigarettes unless
the cinders are completely cool.
TRANSPORTATION AND STORAGE
■Stop the product, remove the battery and allow it to cool
before storing or transporting.
■Clean all foreign material from the product. Store it in a
cool dry and well-ventilated place that is inaccessible
to children. Keep away from corrosive agents such
as garden chemicals and de-icing salts. Do not store
outdoors.
■For transportation, secure the product against
movement or falling to prevent injury to persons or
damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories and attachments. Failure to do so can
cause possible injury, poor performance and may void
your warranty.
WARNING
Servicing requires extreme care and knowledge
and should be performed only by a qualied service
technician. For service we suggest you return the
product to your nearest authorised service centre for
repair. When servicing, use only identical replacement
parts.
■You may make adjustments and repairs described
here. For other repairs, contact the authorised service
agent.
■After each use, clean the product with a soft dry cloth.

3
■Check all nuts, bolts and screws at frequent intervals
for proper tightness to ensure the product is in safe
working condition. Any part that is damaged should be
properly repaired or replaced by an authorised service
centre.
KNOW YOUR PRODUCT
See page 6.
1. Fan cover
2. Upper vacuum tube
3. Lower vacuum tube
4. Guide wheels
5. High speed nozzle
6. Lower blow tube
7. Upper blow tube
8. Vacuum bag
9. Bag adaptor
10. Blower/vacuum mode selection lever
11. Front handle
12. Speed selector
13. Rear handle
14. On/Off trigger
15. Locking pin
16. Sliding lock
SYMBOLS ON THE PRODUCT
Safety alert
Read and understand all instructions
before operating the product, follow all
warnings and safety instructions.
Beware of thrown or ying objects.
Keep all bystanders, especially
children and pets, at least 15 m away
from the operating area.
Rotating fans. Keep hands and feet
out of openings while the product is
running.
Wear ear protection.
Wear eye protection.
Do not expose to rain or damp
condition.
Waste electrical products should not
be disposed of with household waste.
Please recycle where facilities exist.
Check with your local authority or
retailer for recycling advice.
Blower mode
Vacuum mode
SYMBOLS IN THIS MANUAL
Note
Warning
The following signal words and meanings are intended to
explain the levels of risk associated with this product.
DANGER
Indicates an imminently hazardous situation, which, if
not avoided, will result in death or serious injury.
WARNING
Indicates a potentially hazardous situation, which, if not
avoided, could result in death or serious injury.
CAUTION
Indicates a potentially hazardous situation, which, if not
avoided, may result in minor or moderate injury.
CAUTION
Without safety alert symbol
Indicates a situation that may result in property damage.

4
x 1
x 1
x 1x 1
x 1x 1
x 1
x 1
x 1
x 1
x 1
x 1
RBV3650D

5
x 1
x 1
x 1x 1
x 1
x 1
x 1
x 1
x 1
x 1
RBV3600

6
11 12
654 7 8 9 10
1
2
3
13
14
15 16

7
1
3
4
5
2
1
2
1
2
1
2
1 3 5
7 8 9
2 4 6

8
